Advantech PCE-5128 User manual

User Manual
PCE-5128/7128
LGA1150
Intel® Core™7/i5/i3/Pentium®/
Xeon®PICMG 1.3 Single Host
Board with VGA/ DVI-D/
(ECC)DDR3 /SATA3.0 / USB3.0 /
Dual GbE

PCE-5128/7128 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2014
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
AMIBIOS is a trademark of American Megatrends Inc.
Intel®, Core™i7/i5/i3, Pentium®and Xeon are trademarks of Intel®Corporation.
Nuvoton is a trademark of Nuvoton Technology Corp.
All other product names or trademarks are the properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2006512811 Edition 2
May 2014

iii PCE-5128/7128 User Manual
Declaration of Conformity
FCC Class A
NOTE: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instruction manual, may cause harmful interference to radio communi-
cations. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for the labo-
ratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name Advantech has come to be
known.
Your satisfaction is our primary concern. Here is a guide to Advantech’s customer
services. To ensure you get the full benefit of our services, please follow the instruc-
tions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are nor-
mally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your Advantech products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every busi-
ness day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.

PCE-5128/7128 User Manual iv
Memory Compatibility
PCE-5128 Compatible Memory
Brand Size Speed Type ECC Vendor PN Memory Advantech PN
Transcend
1GB DDR3 1066 N TS128MLK64V1U SEC K4B1G0846G-BCH9 96D3-1G1066NN-TR
2GB DDR3 1066 N TS256MLK64V1U SEC K4B1G0846G-BCH9 96D3-2G1066NN-TR
1GB DDR3 1333 N TS128MLK64V3U ELPIDA EDJ1108BFBG-
DJ-F 96D3-1G1333NN-TR
2GB DDR3 1333 N TS256MLK64V3U SEC K4B1G0846G-BCH9 96D3-2G1333NN-TR4
4GB DDR3 1333 N TS512MLK64V3N HYNIX H5TQ2G83CFR
H9C 256x8 96D34G1333NN-TR
2GB DDR3 1600 N TS256MLK64V6N MICRON IRM72 D9PFJ NA
4GB DDR3 1600 N TS512MLK64V6N MICRON IUM22 D9PFJ NA
4GB DDR3 1600 N TS512MLK64V6N MICRON 2EM77 D9PFJ
256x8 NA
8GB DDR3 1600 N TS1GLK64V6H micron IZD27 D9PBC
512x8 NA
Apacer
1GB DDR3 1066 N 78.01GC3.420 ELPIDA J1108BDBG-DJ-F
(128x8) 96D3-1G1066NN-AP
2GB DDR3 1066 N 78.A1GC3.421 ELPIDA J1108BDBG-DJ-F
(128x8) 96D3-2G1066NN-AP
4GB DDR3 1066 N 78.B1GDJ.AF1 HYNIX H5TQ2G83BFR-
H9C NA
1GB DDR3 1333 N 78.01GC6.AF0 H5TQ1G83DFR-H9C 96D3-1G1333NN-AP1
DDR3 1333 H5TQ1G83TFR-H9C
2GB DDR3 1333 N 78.A1GDE.4200C ELPIDA J2108BCSE-DJ-F 96D3-2G1333NN-AP2
2GB DDR3 1333 N 78.A1GDE.AF00C Hynix
H5TQ2G838FR(256x8) 96D3-2G1333NN-AP1
4GB DDR3 1333 N 78.B1GDE.AF1 HYNIX H5TQ2G83BFR-
H9C 96D3-4G1333NN-AP
4GB DDR3 1333 N 78.B1GDE.AF1 HYNIX H5TQ2G83BFR
H9C 256x8 96D3-4G1333NN-AP
8GB DDR3 1333 N 78.C1GEP.4210C ELPIDA J4208BASE-DJ-F
512x8 78.C1GEP.4210C
8GB DDR3 1600 N 78.C1GET.ATF0C Micron 2FD27 D9PCP
(512x8) NA
Kingston
2GB DDR3 1333 N KVR1333D3S8N9/
2G
ELPIDA J2108BCSE-DJ-
F(128x8) NA
4GB DDR3 1333 N KVR1333D3N9/4G
KINGSTON
D2568JENCPGD9U(512x
64)
NA
ATP
2GB DDR3 1600 N XQ16A8N2GS-9-AV SEC K4B2G0846D
(256x8) NA
2GB DDR3 1600 N XQ16A8N2GM-9-AV MICRON 2HM77 D9PFJ
(256x8) NA
4GB DDR3 1600 N XQ16B8N4GS-9-AV SEC K4B2G0846D
(256x8) NA
8GB DDR3 1600 N XQ16B8N8GS-9-AV SEC K4B4G0846B
(512x8) NA
DSL
2GB DDR3 1600 N D3US56081XH12AA SEC 113 HCK0
K4B2G0846C 256x8 NA
4GB DDR3 1600 N D3US56082XH12AA SEC 113 HCK0
K4B2G0846C 256x8 NA

v PCE-5128/7128 User Manual
PCE-7128 compatible memory
Specification Comparison
Brand Size Speed Type ECC Vendor PN Memory Advantech PN
Apacer
2GB 1066 DDR3 Y 78.A1GC5.423 ELPIDA J1108BDBG-
DJ-F (128x8) NA
4GB 1066 DDR3 Y 78.B1GDK.AF3 Hynix H5TQ2G83AFR
H9C (256x8) NA
1GB 1333 DDR3 Y 78.01GC8.422 ELPIDA J1108BDBG-
DJ-F (128x8) 96D3-1G1333E-AP
2GB 1333 DDR3 Y 78.A1GC8.423 ELPIDA J1108BDBG-
DJ-F (128x8) 96D3-2G1333E-AP
4GB 1333 DDR3 Y 78.B1GDF.AF3 Hynix H5TQ2G83AFR
H9C (256x8) NA
8GB 1600 DDR3 Y 78.C1GER.ATE0C MICRON 2AD27D9PBC NA
ATP
2GB 1333 DDR3 Y AQ56M72E8BJH9S SEC 952 HCH9
K4B1G0846E (128x8) NA
4GB 1333 DDR3 Y AQ12M72E8BKH9S
SAMSUNG 928
K4B2G0846B-HCH9
(256x8)
96D3-4G1333E-AT
8GB 1333 DDR3 Y AQ24M72E8BLH9S SECK4B4G0846B 96D3-8G1333E-AT
Transcend
8GB 1333 DDR3 Y TS1GLK72V3H 96D3-8G1333E-TR NA
8GB 1600 DDR3 Y TS1GLK64V6H micron IZD27 D9PBC
512x8 NA
Part Number PCH Memory VGA DVI-D Backplane LAN SATA3.0 USB3.0 USB2.0
(4 for BP) RAID AMT
PCE-5128G2-
00A1E Q87 Non-ECC Yes Yes*2 PCE-5BXX 2 GbE 6 3 9 Yes Yes
PCE-7128G2-
00A1E C226 ECC Yes Yes*2 PCE-5BXX/ 7BXX 2 GbE 6 3 9 Yes Yes

PCE-5128/7128 User Manual vi
Processor Support
Model
Architecture
Advante
ch P/N
CPU Processor Base
Freq.
(GHz)
L3
cache
Cores/
Treads TDP
DDR3
memory
speed
support
ECC AMT
Processor
Gen Process Socket LGA1150
PCE-7128
Haswell
22nm
TBC E3-1275v3 3.5GHz 8MB 4/8 95W
1600
Yes 9.0
96MPXE-
3.2-
8M10T
E3-1225v3 3.2GHz 8MB 4/4 95W Yes 9.0
TBC E3-1268v3 2.3GHz 8MB 4/8 45W Yes 9.0
PCE-5128/
7128
96MPI7-
3.1-
8M10T
Core I7-4770S 3.1GHz 8MB 4/8 65W No 9.0
96MPI7-
2.3-
8M10T
Core I7-4770TE 2.3GHz 8MB 4/8 45W No 9.0
96MPI5-
2.9-
6M10T
Core i5-4570S 2.9GHz 6MB 4/4 65W No 9.0
96MPI5-
2.7-
4M10T
Core i5-4570TE 2.7GHz 4MB 2/4 35W Yes 9.0
TBC Core i3-4330 3.5GHz 4MB 2/4 54W Yes N/A
96MPI3-
2.4-
4M10T
Core i3-4330TE 2.4GHz 3MB 2/4 35W Yes N/A
TBC Pentium G3420 3.2GHz 3MB 2/2 54W Yes N/A
TBC Pentium
G3320TE 2.3GHz 3MB 2/2 35W Yes N/A
Haswell-R
TBC i7-4790S 3.2GHz 8MB 4/8 65W No 9.0
TBC i7-4790T 2.7GHz 8MB 4/8 45W No 9.0
TBC i5-4590S 3.0GHz 6MB 4/4 65W No 9.0
TBC i5-4590T 2.0GHZ 6MB 4/4 35W No 9.0
TBC i3-4360 3.7GHz 4MB 2/4 54W Yes 9.0
TBC i3-4350T 3.1GHz 4MB 2/4 35W No 9.0

vii PCE-5128/7128 User Manual
Backplane Support Matrix Table
Initial Inspection
Before you begin installing your motherboard, please make sure that the following
materials have been shipped:
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately. We have carefully inspected the PCE-5128/7128 mechani-
cally and electrically before shipment. It should be free of marks and scratches and in
perfect working order upon receipt. As you unpack the PCE-5128/7128, check it for
signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is
damaged or it fails to meet the specifications, notify our service department or your
local sales representative immediately. Also notify the carrier. Retain the shipping
carton and packing material for inspection by the carrier. After inspection, we will
make arrangements to repair or replace the unit.
Backplane
Model
processor
PCE-5XXX PCE-7XXX
PCE-5128G2-00A1E Yes -
PCE-7128G2-00A1E Yes Yes (Except PCE-7B10-04A1E)
Note! If PCE-5128/7128 is used on different backplanes which has different
PCIe configuration. Below message would be showed on first time
power on, and user has to turn off AC power and then turn on for PCIe
re-configuration.
Caution! PCIe configuration error! Please turn off AC power before re-configura-
tion.
1 PCE-5128 or 7128 PICMG 1.3 Single Host Board
1 PCE-5128/7128 startup manual
1 CD with utility
1 User note for full-sized CPU card P/N: 2002721020
2 Serial ATA HDD data cable P/N: 1700003194
2 Serial ATA HDD power cable P/N: 1703150102
1 COM + printer ports cable kit P/N: 1701260305
1 4-port USB cable kit P/N: 1700008461
Keyboard and mouse Y cable P/N: 1700060202
1 jumper package P/N: 9689000068
1 warranty card

PCE-5128/7128 User Manual viii

ix PCE-5128/7128 User Manual
Contents
Chapter 1 Hardware Configuration......................1
1.1 Introduction ............................................................................................... 2
1.2 Features & Benefits................................................................................... 2
1.3 Specifications ............................................................................................ 3
1.3.1 System .......................................................................................... 3
1.3.2 Memory ......................................................................................... 3
1.3.3 Input/Output .................................................................................. 3
1.3.4 Graphics........................................................................................ 4
1.3.5 Ethernet LAN ................................................................................ 4
1.3.6 Industrial features ......................................................................... 4
1.3.7 Mechanical and environmental specifications............................... 4
1.4 Jumpers and Connectors .......................................................................... 5
Table 1.1: Jumper list .................................................................. 5
Table 1.2: Connectors ................................................................. 5
1.5 Board Layout: Jumper and Connector Locations...................................... 6
Figure 1.1 Jumper and connector locations................................. 6
1.6 Block Diagram........................................................................................... 7
Figure 1.2 PCE-5128 block diagram............................................ 7
Figure 1.3 PCE-7128 block diagram............................................ 7
1.7 Safety Precautions .................................................................................... 8
1.8 Jumper Settings ........................................................................................ 8
1.8.1 How to set jumpers ....................................................................... 8
1.8.2 BIOS CMOS (JCMOS1)................................................................ 9
Table 1.3: JCMOS1/JME1: clear CMOS/ME data....................... 9
1.8.3 Watchdog timer output (JWDT1) .................................................. 9
Table 1.4: Watchdog timer output (JWDT1) ................................ 9
Table 1.5: H/W monitor alarm (JOBS1)...................................... 9
Table 1.6: JERP1: Deep Sleep S5 .............................................. 9
1.9 System Memory ...................................................................................... 10
1.10 Memory Installation Procedures.............................................................. 10
1.11 Cache Memory........................................................................................ 10
1.12 Processor Installation.............................................................................. 10
1.13 Processor Cooler Installation .................................................................. 12
Chapter 2 Connecting Peripherals ....................15
2.1 Introduction ............................................................................................. 16
2.2 Parallel Port (LPT1)................................................................................. 16
2.3 USB Ports (USB12, USB3, USB4, USB56, USB78) ............................... 16
2.4 VGA Connectors (VGA1) ........................................................................ 17
2.5 Serial Ports (COM1 & COM2) ................................................................. 17
2.6 PS/2 Keyboard and Mouse Connector (KBMS1/KBMS2)....................... 18
2.7 CPU Fan Connector (CPUFAN1)............................................................ 18
2.8 Front Panel Connectors (JFP1, JFP2 & JFP3) ....................................... 19
2.8.1 Power LED and keyboard lock (JFP3)........................................ 19
Table 2.1: PS/2 or ATX power supply LED status..................... 19
2.8.2 External speaker (JFP2) ............................................................. 19
2.8.3 Reset connector (JFP1) .............................................................. 20
2.8.4 HDD LED connector (JFP2)........................................................ 20
2.8.5 ATX soft power switch (JFP1)..................................................... 20
2.9 H/W Monitor/Watchdog Timer/Infrared ................................................... 21
2.9.1 H/W monitor alarm (JOBS1) ....................................................... 21
2.9.2 Watchdog timer (JWDT1) ........................................................... 21
2.9.3 Infrared interface (JIR1) .............................................................. 21

PCE-5128/7128 User Manual x
2.10 LAN Ports (LAN1 & LAN2)...................................................................... 22
Table 2.2: LAN LED Indicators.................................................. 22
2.11 High Definition Audio Module Interface (HDAUD1) ................................ 23
Figure 2.1 Jumper and connector locations of PCA-AUDIO-
HDA1E ..................................................................... 24
2.12 GPIO Header (GPIO1)............................................................................ 25
2.13 Case Open Connector (JCASE1) ........................................................... 25
Figure 2.2 PCE-5128/7128 Case Open Jumper Locations ....... 25
Table 2.3: Case open mode Jumper ......................................... 26
Figure 2.3 Case Open Warning in BIOS Menu ......................... 26
2.14 Front Panel LAN Indicator Connector (LANLED1).................................. 26
Table 2.4: LAN LED Indicators.................................................. 26
2.15 Serial ATA Interface (SATA1~SATA6).................................................... 27
2.16 LPC Extension Interface (LPC1)............................................................. 28
Chapter 3 AMI BIOS Setup................................. 29
3.1 Introduction ............................................................................................. 30
Figure 3.1 Setup program initial screen..................................... 30
3.2 Entering Setup ........................................................................................ 31
3.2.1 Main Setup.................................................................................. 31
Figure 3.2 Main setup screen .................................................... 31
3.2.2 Advanced BIOS Features Setup................................................. 32
Figure 3.3 Advanced BIOS features setup screen .................... 32
Figure 3.4 PCI Subsystem Settings........................................... 33
Figure 3.5 PCI Express Settings ............................................... 34
Figure 3.6 ACPI Settings ........................................................... 35
Figure 3.7 Trust Computing....................................................... 36
Figure 3.8 S5 RTC configuration ............................................... 37
Figure 3.9 CPU Configuration ................................................... 37
Figure 3.10SATA Configuration.................................................. 39
Figure 3.11Firmware Update Configuration ............................... 41
Figure 3.12AMT Configuration ................................................... 42
Figure 3.13USB Configuration.................................................... 43
Figure 3.14Smart Setting............................................................ 44
Figure 3.15Super IO Configuration............................................. 45
Figure 3.16Serial Port 1 Configuration ....................................... 45
Figure 3.17Serial Port 2 Configuration ....................................... 46
Figure 3.18Parallel Configuration ............................................... 46
Figure 3.19PC Health Status...................................................... 47
3.2.3 Chipset........................................................................................ 48
Figure 3.20Chipset ..................................................................... 48
Figure 3.21PCH IO Configuration............................................... 48
Figure 3.22PCI Express Configuration ....................................... 50
Figure 3.23USB Configuration.................................................... 51
Figure 3.24PCH Azalia Configuration......................................... 52
Figure 3.25System Agent (SA) Configuration ............................ 53
Figure 3.26Graphics Configuration............................................. 54
Figure 3.27NB PCIe Configuration ............................................. 55
Figure 3.28Memory Information ................................................. 56
3.2.4 Boot ............................................................................................ 56
Figure 3.29 Boot ......................................................................... 56
3.2.5 Security....................................................................................... 58
Figure 3.30Security .................................................................... 58
3.2.6 Save & Exit ................................................................................. 59
Figure 3.31Save & Exit............................................................... 59
Chapter 4 Value-Added Software Services ...... 61

xi PCE-5128/7128 User Manual
4.1 Value-Added Software Services ............................................................. 62
4.1.1 Software API ............................................................................... 62
4.1.2 Software Utility ............................................................................ 63
Chapter 5 Chipset Software Installation Utility 65
5.1 Before You Begin .................................................................................... 66
5.2 Introduction ............................................................................................. 66
5.3 Windows® 7 / Windows® 8 Driver Setup................................................ 67
Chapter 6 Integrated Graphic Device Setup .....69
6.1 Introduction ............................................................................................. 70
6.2 Windows 7/ Windows 8 Driver Setup ...................................................... 70
Chapter 7 LAN Configuration.............................71
7.1 Introduction ............................................................................................. 72
7.2 Installation ............................................................................................... 72
7.3 Win XP /Win 7 Driver Setup (LAN).......................................................... 72
Chapter 8 Intel ME...............................................73
8.1 Introduction ............................................................................................. 74
8.2 Installation ............................................................................................... 74
Chapter 9 Intel USB 3.0.......................................75
9.1 Introduction ............................................................................................. 76
9.2 Installation ............................................................................................... 76
Chapter 10 SATA RAID Setup ..............................77
10.1 Introduction ............................................................................................. 78
10.2 SATA RAID Driver and Utility Setup ....................................................... 78
Appendix A Programming the Watchdog Timer..79
A.1 Introduction ............................................................................................. 80
A.1.1 Watchdog timer overview............................................................ 80
A.1.2 Programming the watchdog timer ............................................... 80
Table A.1: Watchdog timer registers.......................................... 81
A.1.3 Example program........................................................................ 82
Appendix B I/O Pin Assignments..........................87
B.1 Parallel Port Connector (LPT1) ............................................................... 88
Table B.1: Parallel port connector (LPT1).................................. 88
B.2 VGA Connector (VGA1) .......................................................................... 88
Table B.2: VGA connector (VGA1) ............................................ 88
B.3 RS 232 Serial Port (COM12)................................................................... 89
Table B.3: RS-232 serial port (COM2)....................................... 89
B.4 USB 2.0 Header (USB56 & 910)............................................................. 89

PCE-5128/7128 User Manual xii
Table B.4: USB Header (USB56 & 910) .................................... 89
B.5 USB3.0 Header (USB12) ........................................................................ 90
Table B.5: USB 3.0 Header (USB12) ........................................ 90
B.6 PS/2 Keyboard/Mouse Connector (KBMS1)........................................... 90
Table B.6: PS/2 keyboard/mouse connector (KBMS1).............. 90
B.7 External Keyboard Connector (KBMS2) ................................................. 91
Table B.7: External keyboard connector (KBMS2) .................... 91
B.8 CPU Fan Power Connector (CPUFAN1) ................................................ 91
Table B.8: CPU fan power connector (CPUFAN1) .................... 91
B.9 Power LED and Keyboard Lock Connector (JFP3 / PWR_LED & KEY
LOCK) ..................................................................................................... 91
Table B.9: Power LED and keyboard lock connector (JFP3 /
PWR_LED & KEY LOCK) ........................................ 91
B.10 External Speaker Connector (JFP2 / SPEAKER) ................................... 92
Table B.10:External speaker connector (JFP2 / SPEAKER)...... 92
B.11 Reset Connector (JFP1 / RESET) .......................................................... 92
Table B.11:Reset connector (JFP1 / RESET) ............................ 92
B.12 HDD LED (JFP2 / HDDLED)................................................................... 92
Table B.12:HDD LED (JFP2 / HDDLED) .................................... 92
B.13 ATX Soft Power Switch (JFP1 / PWR_SW)............................................ 93
Table B.13:ATX soft power switch (JFP1 / PWR_SW)............... 93
B.14 Hi-definition Audio Link Connector (HDAUD1) ....................................... 93
Table B.14:Hi-definition audio link connector (HDAUD1) ........... 93
B.15 SM Bus Connector (JFP2 / SNMP)......................................................... 93
Table B.15:SM bus connector (JFP2 / SNMP) ........................... 93
B.16 LAN1 and LAN2 LED Connector (LANLED1) ......................................... 94
Table B.16:LAN1 and LAN2 LED connector (LANLED1) ........... 94
B.17 GPIO Header (GPIO1)............................................................................ 94
Table B.17:GPIO header (GPIO1).............................................. 94
B.18 Fixed I/O Ranges Decoded by Intel PCH ............................................... 95
Table B.18:Fixed I/O Ranges Decoded by PCH......................... 95
B.19 System I/O Ports..................................................................................... 96
Table B.19:System I/O Ports ...................................................... 96
B.20 Interrupt Assignments ............................................................................. 97
Table B.20:Interrupt Assignments .............................................. 97
B.21 1 MB Memory Map.................................................................................. 97
Table B.21:1 MB memory map ................................................... 97
B.22 PCI Bus Map........................................................................................... 97
Table B.22:PCI Bus Map ............................................................ 97
Appendix C Programming the GPIO .................... 99
C.1 Supported GPIO Register ..................................................................... 100
C.2 GPIO Registers..................................................................................... 100
C.3 GPIO Example Program-1 .................................................................... 100

Chapter 1
1Hardware
Configuration

PCE-5128/7128 User Manual 2
1.1 Introduction
PCE-5128/7128 is a PICMG 1.3 form-factor single host board which is designed with
Intel®Q87 (PCE-5128) and C226 (PCE-7128) PCH for industrial applications that
need high computing power and strong I/O capability. PCE-5128/7128 supports
22nm manufacturing technology, LGA1150 socket Intel® Core™ i7/i5/i3, Pentium®
and Xeon™ processors that integrate memory and graphic controllers, and support
for DDR3 1333/1600 MHz SDRAM up to 16 GB. With advanced computing technol-
ogy, PCE-5128/7128 is suitable for processor hungry industrial applications.
PCE-5128/7128 offers excellent graphics capability with its integrated Intel® HD
graphics core with a minimum 1GB shared memory (requires a minimum 2GB sys-
tem memory). With this, PCE-5128/7128 provides strong 2D/3D graphics processing
power without an additional graphic card to save extra cost, power consumption and
thermal integration effort.
PCE-5128/7128 also has rich I/O interface, which can support Advantech PCE-5BXX
and 7BXX backplanes to offer various expansion slots such as PCI, PCI-X and PCIe
slots with its PCIe lanes that are configured as one x16, or two x8 and four x1.
New SATA Gen3 (600MB/sec) ports satisfy high data applications, like storage and
DVR. Six SATA ports support software RAID 0, 1, 5, 10 for a cost-effective reliable
data solution. Three USB 3.0 ports reach 5Gbps high data rates, and two on-board
RS-232 serial COM ports are for industrial control applications. With flexible I/O and
graphic expansibility, PCE-5128/7128 is an excellent, cost effective graphic or I/O ori-
ented workstation class hardware platform. With outstanding performance and
exceptional features, PCE-5128/7128 is the ideal computing platform for advanced
industrial applications.
1.2 Features & Benefits
Features Benefits
PCE-5128/7128 supports Intel 4th gener-
ation processors
Intel’s 4th generation Core i7/i5/i3/Pentium/Xeon
processor cores with quad/dual-core computing
power brings quantum-leap performance improve-
ment.
PCE-5128/7128 supports DDR3 1333/
1600 SDRAM up to 16 GB
Provides higher memory data transmission and
processing efficiency, bringing higher system per-
formance.
*PCE-7128 supports ECC memory, but PCE-5128
does not.
PCE-5128 supports one x16 lane(s) for
supporting PCE-5BXX series BPs.
PCE-5128 supports one x16 lane(s) for Advantech
backplanes 5BXX series.
PCE-7128 supports dual PCIe x8 or one
x16 lane(s) for supporting both PCE-
7BXX/5BXX series BPs.
PCE-7128 supports dual PCIe x8 or one x16
lane(s) for Advantech backplanes: PCE-7BXX and
5BXX series with single or dual PCIe x8 slot(s).
Fully supports Advantech SUSI APIs and
Utilities.
Reduces customer S/W development effort with
more reliable S/W quality, also provides value-
added utilities such as system monitor and
Embedded Security ID.
SATA Gen3
Provides high performance storage interface.
SATA Gen3 is 6Gb/s which is double bandwidth
with SATA Gen2.
USB 3.0
Provides high transfer data performance interface;
USB 3.0 data transfer rate is 5Gbps which is 10
times faster than USB2.0.

3 PCE-5128/7128 User Manual
Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
CPU: LGA1150-socket Core i7/i5/i3, Pentium and Xeon E3-1200v3 series pro-
cessors
L2 Cache: Please refer to CPU specification for detailed information.
BIOS: AMI SPI BIOS (128 Mb SPI)
System Chipset: Intel Q87(PCE-5128); Intel C226(PCE-7128)
SATA hard disk drive interface: Six SATA3 (600MB/s) are with blue connec-
tors. These interfaces can be enabled/disabled in the BIOS.
1.3.2 Memory
RAM:
–PCE-5128: Up to 16 GB in two 240-pin DIMM sockets. Supports dual-chan-
nel DDR3 1333/1600 MHz SDRAM WITHOUT ECC function.
–PCE-7128: Up to 16 GB in two 240-pin DIMM sockets. Supports dual-chan-
nel DDR3 1333/1600 MHz SDRAM WITH or WITHOUT ECC function.
1.3.3 Input/Output
PCIe bus: One PCIex16 or Two PCIex8 from CPU and One PCIe x4 from PCH
PCI bus: Four PCI masters to the backplane, 32-bit, 33 MHz PCI 2.2 compliant.
Enhanced parallel port: This EPP/SPP/ECP port can be configured to LPT1,
LPT2, LPT3 or disabled. A standard DB-25 female connector provided.
Serial ports: Two RS-232 serial ports
PS/2 keyboard and mouse connector:
One 6-pin mini-DIN connectors is
located on the mounting bracket for easy connection to a PS/2 keyboard and
mouse via the Y-cable included in the package.
USB port: Supports 9 x USB 2.0 ports with transfer rates up to 480 Mbps. (5
ports are on the CPU card and 4 ports are on the backplane), and 3 USB 3.0
ports with transfer rates of up to 5 Gbps.
LPC: One LPC connector to support Advantech TPM LPC modules.
GPIO: Supports 8-bit GPIO from super I/O for general purpose control applica-
tion.
Triple display
PCE-5128/7128 provides three independent dis-
plays, VGA+DVI-D+DVI-D. note: requires 2 x DVI-
D cables for DVI-D output.
Note! PCE-5128/7128 does NOT support PATA(IDE) interface.
Only PCE-7128 supports Intel Xeon processors.
Note! 1. Due to the inherent limitations of the PC architecture, the system
may not fully detect 16 GB RAM when 16 GB of RAM is installed.
2. A 32-bit OS may not fully detect 4 GB of RAM when 4 GB is
installed.

PCE-5128/7128 User Manual 4
1.3.4 Graphics
Controller: Intel® HD Graphics embedded in the processor.
Display memory: Shared memory is subject to OS (install 2 GB or above mem-
ory for basic system configuration).
CRT: Up to 2048 x 1536 resolution, 400 MHz RAMDAC.
DVI-D: Two DVI-D pin header ports support resolution up to 1920 x 1200 @ 60
Hz.
PCI express x16/x8 slot on the backplane: An external graphic card can be
installed in the PCIe x16 / x8 slot for high 2D/3D graphics capability.
1.3.5 Ethernet LAN
Supports single/dual 10/100/1000 Mbps Ethernet port(s) via the dedicated PCI
Express x1 bus which provides 500 MB/s data transmission rate.
Controller:
–LAN 1: Intel® I217LM for both PCE-5128 and PCE-7128.
–LAN 2: Intel® I211(PCE-5128) and I210(PCE-7128).
1.3.6 Industrial features
Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second or one minute (255 levels).
1.3.7 Mechanical and environmental specifications
Operating temperature: 0 ~ 60° C (32 ~ 140° F, Depending on CPU and ther-
mal solution)
Storage temperature: -40 ~ 85° C (-40 ~ 185° F)
Humidity: 20 ~ 95% non-condensing
Power supply voltage: +3.3 V, +5 V, +12 V, +5 VSB
Power consumption: Processor: Intel Core i7-4770S; Memory: DDR3 1600
8GB x 2
Voltage +12 V +5 V +3.3 V +5 VSB
Current 4.02 A 1.36 A 0.81 A 0.09 A
Board size: 338.58 mm (L) x 126.39 mm (W) (13.3" x 4.98")
Board weight: 0.5 kg

5 PCE-5128/7128 User Manual
Chapter 1 Hardware Configuration
1.4 Jumpers and Connectors
Connectors on the PCE-5128/7128 single host board link it to external devices such
as hard disk drives and a keyboard. In addition, the board has a number of jumpers
used to configure your system for your application.
The tables below list the function of each of the board jumpers and connectors. Later
sections in this chapter give instructions on setting jumpers. Chapter 2 gives instruc-
tions for connecting external devices to your motherboard.
Table 1.1: Jumper list
Label Function
JCMOS1 CMOS clear
JME1 Clear ME data
JWDT1 Watchdog timer output selection
JOBS1 HW Monitor Alarm
Table 1.2: Connectors
Label Function
LPT1 Parallel port, Parallel port x 1, supports SPP/EPP/ECP mode
LAN1 Intel I217LM for all SKUs
LAN2 Intel I211(PCE-5128); Intel I210AT(PCE-7128)
VGA1 VGA connector
KBMS1 PS/2 keyboard and mouse connector
KBMS2 External keyboard/mouse connector
COM1 Serial port: COM1; RS-232 (9-pin Box Header)
COM2 Serial port: COM2; RS-232 (9-pin Box Header)
JIR1 Infrared connector
JFP3
(Keyboard Lock and
Power LED)
Power LED
Suspend: Fast flash (ATX/AT)
System On: ON (ATX/AT)
System Off: OFF ((ATX/AT))
JFP2 External speaker / SATA HDD LED connector
JFP1 Power Switch / Reset connector
JCASE1 Case Open
CPUFAN1 CPU FAN connector (4-pin)
LANLED1 LAN1/2 LED extension connector
HDAUD1 HD audio extension module connector
USB12 USB port 1, 2
USB3 USB port 3
USB4 USB port 4
USB56 USB port 5, 6
USB78 USB port 7, 8
SATA1 Serial ATA1
SATA2 Serial ATA2
SATA3 Serial ATA3
SATA4 Serial ATA4
SATA5 Serial ATA5
SATA6 Serial ATA6

PCE-5128/7128 User Manual 6
1.5 Board Layout: Jumper and Connector
Locations
Figure 1.1 Jumper and connector locations
CPU1 CPU Socket
DIMMA1 Memory connector channel A
DIMMB1 Memory connector channel B
GPIO1 GPIO pin header (SMD pitch-2.0 mm)
LPC1 COM port module expansion pin-header
1
COM2
COM1
LAN1
LAN2
VGA1
KBMS1
KBMS2LPC1
JIR1
JOBS1
JWDT1
JCASE1
GPIO1
HD
AUDIO1
JCMOS1
JME1
CPU1
PCH
CPU FAN1 DIMM B1
DIMM A1 SATA3
1,2,4,5
SATA3
3,6 USB78
USB56
USB4USB12
USB3
LPT1
LANLED1
JFP
13¥
DVI1
DVI2
SPI_CN1
JERP1
BMC1
(PCE-7128)

7 PCE-5128/7128 User Manual
Chapter 1 Hardware Configuration
1.6 Block Diagram
Figure 1.2 PCE-5128 block diagram
Figure 1.3 PCE-7128 block diagram

PCE-5128/7128 User Manual 8
1.7 Safety Precautions
1.8 Jumper Settings
This section provides instructions on how to configure your motherboard by setting
the jumpers. It also includes the motherboard’s default settings and your options for
each jumper.
1.8.1 How to set jumpers
You can configure your motherboard to match the needs of your application by set-
ting the jumpers. A jumper is a metal bridge that closes an electrical circuit. It consists
of two metal pins and a small metal clip (often protected by a plastic cover) that slides
over the pins to connect them. To “close” (or turn ON) a jumper, you connect the pins
with the clip. To “open” (or turn OFF) a jumper, you remove the clip. Sometimes a
jumper consists of a set of three pins, labeled 1, 2 and 3. In this case you connect
either pins 1 and 2, or 2 and 3. A pair of needle-nose pliers may be useful when set-
ting jumpers.
Warning! Always completely disconnect the power cord from your chassis when-
ever you work with the hardware. Do not make connections while the
power is on. Sensitive electronic components can be damaged by sud-
den power surges. Only experienced electronics personnel should open
the PC chassis.
Caution! Always ground yourself to remove any static charge before touching the
motherboard. Modern electronic devices are very sensitive to static
electrical discharges. As a safety precaution, use a grounding wrist
strap at all times. Place all electronic components on a static-dissipative
surface or in a static-shielded bag when they are not in the chassis.
Caution! The computer is provided with a battery-powered Real-time Clock.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended by the manufacturer.
Discard used batteries according to manufacturer's instructions.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer’s
instructions.
