Advantech PCM-4390 Installation and operation manual

1 PCM-4390 Startup Manual
PCM-4390 Onboard Intel
®
Core Duo 4" EPIC
SBC with LCD/LVDS/GIGA LAN/8 GPIO/ 8 USB2.0
Startup Manual
Before installation, please make sure that you have
received the following:
If anything is missing or damaged, contact your distributor
or sales representative immediately.
Note 1: For detailed contents or the PCM-4390, please
refer to the enclosed CD Disc or disc(in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readerstep2.html(Acrobat is a trademark of
Adobe).
Standard SBC Functions
• CPU: Embedded Intel Core Duo Processor, up to 1.66
GHz
• System Chipset: Intel 945GM GMCH/ICH7M Chipset
• BIOS: AWARD®4 Mbit Flash BIOS
• System memory: 200-pin SODIMM socket Rate II
(DDR2) 128 MB to 1 GB, accept 128/256/512/1 G
(DDR2) 400/533/667 DRAM
• Power Management: APM1.2, ACPI support
• SSD: USB-DOM
• Watchdog: Timer Single chip Watchdog 255-level inter-
val timer, setup by software
• Expansion: Interface PCI-104
• Battery: 2-pin wafer box for external Battery on board I/
O
• I/O Interface: 1 x EIDE (UDMA 33),
1 x K/B (optional), 1 x KB/mouse, 3 x RS232,
1 x RS232/422/485, 1 x LPT
• USB: 8 x USB 2.0 compliant Ports
(2 ports on board connector, 6 ports pinhead)
• Audio: ICH7M AC97 3D surround stereo sound Sup-
ports Line -in, Line-out, Microphone-in (with PCM-410
option)
• IrDA: N/A
• GPIO: 8-bit general purpose input/output
Ethernet
• Chipset: BroadCom BCM5721
• Speed: 10/100/1000 Mbps
• Interface: 2 x RJ45
• Standard: IEEE 802.3u 100Base-T
Display
• Chipset: Intel 945GM chip integrated.
(Extreme Graphics 2)
• Memory Size: Optimized Shared Memory Architecture,
supports up to 64 MB frame buffer using system mem-
ory
• Resolution
CRT Display mode: pixel resolution up to 1600 x 1200 at
85-Hz and 2048 x 1536 at 75-Hz LCD
Display mode: Dual channel LVDS panel supports up to
UXGA panel resolution with frequency range from 25
MHz to 112 MHz
• LCD Interface: 2 Dual Channel (LVDS1 x 36-bit, LVDS2
x 48-bit(Optional) ) LVDS
• LV D S : Hirose connector supports up to 2 channel(2 x
18-bit) LVDS LCD Panel
• Dual Independent: CRT + 36-bit LVDS, LVDS +
LVDS(Dual LVDS optional)
Packing List Specifications
• 1 PCM-4390 SBC
• 1 Startup Manual
• 1 Utility CD
• 1 Cable 20P/10P 10CM EPIC
AT X P o w e r
p/n: 1700002055
• Flat cable 44P IDC 44P/44P/
40P Keyed 50cm
p/n: 1701440504
• Keyboard/Mouse Connector p/n: 1700060202
• FLAT Cable 50P 20CM 3Com
& LPT 1.27mm to D-sub
p/n: 1700002034
• Cable Serial ATA 7P/7P100cm p/n: 1700071000
• Wire RS-422/485 W/D-SUB
COM 4P 15cm
p/n: 1703040157
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCM-4390 Series Rev. A1.
Part No. 2006439000 1st Edition
May 2007.
PCM-4390 Onboard Intel®
Core Duo 4" EPIC SBC with LCD/LVDS/GIGA LAN/8 GPIO/ 8

2 PCM-4390 Startup Manual
Mechanical and Environmental
• Dimensions: 115 x 165mm(4.5" x 6.6")
• Power supply Type: AT X
• Power supply Voltage: ATX, +5 V ± 5%, +3 V ± 5%, 5VSB
± 5%, ±12 V ± 5% (Optional) (12 V optional for PC/104 add
on card and LCD inverter)
• Power Consumption: (Core Duo 1.2 GHz with 512 MB
DDR2 memory) Typical: 3.75 A @ 5 V, 0.49 A @ 3.3 V, 1.08
A @ 5 VSB, 0.48 A @ 12 V
• Operating Humidity: 0%~90% relative humidity, non-con-
densing
• Operating Temperature: 0~60°C(32~140°F)
• Weight: 340g(with Heatsink)
• Storage Temperature:
• Storage Relative Humidity:
The board has a number of jumpers that allow you to configure
your system to suit our application.
The table below lists the function of each of the jumpers and
connectors.
Standard products(0~60°C)
Storage temperature: -20~70°C
Phoenix products(-20~80°C)
Storage temperature: -20~80°C
Platinum Phoenix products(-40~85°C)
Storage temperature:-40~85°C
Standard products(0~60°C)
Relative Humidity:95%@60°C
Phoenix products(-20~80°C)
Relative Humidity:95%@60°C
Jumpers and Connectors
Jumpers
Label Function
J1 Clear CMOS
S2 COM2 Setting
J2/J4 LCD Power
J5 PCI-104 VIO Select
S1 Reset Button
PCM-4390 Connector List
Label Function
CN2
FAN1 CPU fan
CN4 DDRII Connector
CN5 RTC Battery Connector
CN6 GPIO
CN7 ATX Power
CN8 Power Switch
CN9 /CN10 LAN Connector
CN11/CN12 SATA Connector
CN13 Primary IDE
CN14 HD LED & Power LED
CN15/CN17 LVDS Connector
CN16/CN26 Inverter Power
CN18 CRT Connector
CN19 USB MIO Connector
CN20 USB 2Ports Connector
CN21 KB/MS Connector
CN22 ACi97/USB Connector
CN23 COM1
CN24 Print/COM Port
CN25 RS485 TX/RX Pin Header
CN27 PCI-104
CN28 USB Connector
CN29
J1 Clear CMOS
Setting Function
(1-2) Normal
(2-3) Clear CMOS
S2 COM2 Setting
Setting Function
S2(1 ON) RS232
S2(2 ON) RS485
S2(3 ON) RS422
J2/J4 LCD Power
Setting Function
(1-2) +5V
(2-3) +3.3V
J5 PCI-104 VIO Select
Setting Function
(1-2) +5V
(2-3) +3.3V
S1 Reset Button
Setting Function
Push Button to reset system
PCM-4390 Connector List
Label Function

PCM-4390 Startup Manual 3
PCM-4390 Connectors(component side)
PCM-4390 Connectors(solder side)
CN18 CN23 CN12 CN11
CN2
CN10
CN9
CN20 CN21 CN22
CN24
J4
CN17
CN13
CN25
CN6
CN5
CN8
CN14 J1 CN16 CN26 CN3
CN15
J2
CN7
J5 CN27
CN29
S2
CN4
CN19 CN19 CN28
S1

4 PCM-4390 Startup Manual
PCM-4390 Mechanical Drawing(component side)
PCM-4390 Mechanical Drawing(solder side)
0.00
28.82
16.33
55.47 54.53
65.91 92.41
111.13
119.41
136.08
141.57
158.80
147.19
164.00
74.83
156.04
149.71
0.00
5.08
10.16
3.17
5.03
8.92
8.61
39.23
4.01
3.53
81.58
97.18
109.98
115.00
5.08
11.76
66.55
70.99
78.61
104.52
128.65 144.65 158.93
154.81 152.21
150.30
142.29 139.32 146.46 153.54 159.75
5.18
6.82
12.47
15.00
15.85
16.13
9.91
24.16
46.69
56.93
60.38
85.04
81.41
102.98
104.06
106.67
109.98
112.78
108.71
109.88
112.78
25.02
45.59
140.46
110.55
8.82
67.18
16.33
55.47
158.80
147.19
164.00
0.00
5.08
5.03
8.92
97.18
109.98
115.00
5.08
11.76
70.99
5.18
24.16
109.88
67.18
63.57
38.17
90.26
101.97
132.00
143.09
58.72
51.12
56.20
71.45
50.86
122.99
2.87
