Advantech PCM-5820 Series Installation and operation manual

PCM-5820 Series Startup Manual 1
Packing List
Before you begin installing your board, please make sure
that the following materials have been shipped:
• 1 PCM-5820 Series all-in-one single board computer
• 1 startup manual
• 1 utility disk/CD driver, and manual (in PDF format)
• 1 2.5" IDE flat cable, 44-pin to 44-pin (part no.
1701440351)
• 1 keyboard / PS2 mouse cable (part no.1700060201)
• 1 secondary serial port cable (part no.1701140201)
• 1 parallel cable (part no.1700260250)
• 1 floppy cable, for 3.5" FDD only (part no.1701340602)
• 1 audio cable (part no. 1700160160)
• 1 USB cable (part no.1703100260)
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-5820 Series
please refer to the enclosed CD-ROM or disk
(in PDF format).
Note 2: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/
readstep.html
(Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our support
website at:
http://support.advantech.com
This manual is for the PCM-5820L Rev. A103 or higher, the
PCM-5820E Rev. A101 or higher, or the PCM-5822 Rev.
A101.
Part No.2006582005 3rd Edition
Printed in Taiwan Dec. 1999
PCM-5820 Series Pentium® SBC with CPU,
VGA/LCD, Ethernet & Audio Interface
Startup Manual
Specifications
Standard SBC Functions
•CPU:
Embedded NS GXM-233 processor (PCM-5820/5820L)
Embedded NS GXM-200 processor (PCM-5820E/5822)
•BIOS: AWARD 256 KB Flash memory
•System memory:One 144-pin SODIMM socket
accepts up to 128 MB SDRAM
•Enhanced IDE interface:Supports up to two EIDE
devices.BIOS auto-detect, PIO Mode 3 or Mode 4
transfer, Ultra DMA33 mode (ATA-4) up to 33 MB/sec
•FDD interface: Supports up to two FDDs
•Serial ports: One serial RS-232 port, one serial
RS-232/422/485 port
•Parallel port:One parallel port, supports
SPP/EPP/ECP mode
•Infrared port: Shared with COM2.Transfer rate up to
115 kbps
•Keyboard/mouse connector: Mini-DIN connector
supports standard PC/AT keyboard and PS/2 mouse
•USB interface:Two USB ports, USB 1.0 compliant
•Power management: Supports power saving modes
including Normal/Standby/Suspend. APM 1.1 compliant
•Watchdog timer: 1.6 sec. intervals
Local-bus Flat Panel/VGA Interface
•Chipset: NS CX5530
•Display memory:1 ~ 4 MB share memory, set in BIOS
•Display type: Supports CRT andTFT LCDs.Able to
display both CRT and flat panel simultaneously
•Flat-panel display mode:Panel resolution supports up
to 1024 x 768 @ 16 bpp.Supports 18-bit TFT LCD
panel
•CRT display mode: Non-interlaced CRT monitor
resolutions up to 1280 x 1024 @ 256 colors or 1024 x
768 @ 16 bpp
LVDS (Low Voltage Differential Signal) Interface
(PCM-5820, PCM-5820L, PCM-5820E only)
•Chipset:TI SN75LVDS84 or compatible chipset
•Performance: 18 low-voltageTTL data channels
ANSI/EIA/TIA-644
PCM-5820 Series Pentium®
SBC with CPU, VGA/LCD, Ethernet & Audio

2PCM-5820 Series Startup Manual
TV-out (PCM-5822 only)
•Chipset:CHRONTEL CH7003C
• Supports NTSC, NTSC-EIA (Japan) and PAL TV formats
• Provides Composite, S-video, and SCART (optional)
outputs via RCA (composite) connector and S-video
connector
• Supports 640 x 480 and 800 x 600 input resolutions
• Supports Windows 95/98 andWindows NT driver
• Over-scan, under-scan, and position adjustable
• Auto-detection ofTV presence
Audio Function
•Chipset: NS CX5530
•Audio controller: AC97 version 2.0 compliant interface
•Audio interface:Microphone in, Line in, CD audio in,
Line out, Speaker L, Speaker R
•Power: Accepts +12 V source for improved audio quality
Ethernet Interface (PCM-5820/5820E/5822 only)
•Chipset: RTL 8139
•Ethernet interface:PCI 10/100 Mbps Ethernet. IEEE
802.3 U protocol compatible
•Connection: On-board RJ-45 connector
•I/O address switchless setting
•Built-in boot ROM
Solid State Disk
• Supports one 50-pin socket for CompactFlash™ card
Mechanical and Environmental
•Dimensions (L xW): 145 mm x 102 mm (5.9" x 4.2")
•Power supply voltage: +5 V (4.75V ~ 5.25 V)
•Power requirements:
+5V @ 3 A (typical) (for PCM-5820/5820L)
+5V @ 1.5 A (typical) (for PCM-5820E/5822)
•Operating temperature: 0 ~ 60° C (32 ~ 140° F)
•Weight:0.77 kg (weight of total package)
Jumpers and Connectors
Connectors on the board link it to external devices such as
hard disk drives, a keyboard or expansion bus connectors.
In addition, the board has a number of jumpers that allow
you to configure your system to suit your application.
The tables below lists the function of each of the board's
jumpers and connectors:
Table 2-1: Jumpers
Label Function
J1 Audio power source setting
J2 Clear CMOS PCM-5820 Locating jumpers (component side)
J3 Watchdog timer action
J4 COM2 setting
J5 Buzzer setting
J6 LCD power selector
J7 Ethernet power select (PCM-5822)
Table 2-2: Connectors
Label Function
CN1 CD audio input connector
CN2 Floppy disk connector
CN3 Parallel port connector
CN4 USB connector
CN5 Audio connector
CN6 CPU fan power connector (5820/L/E)
CN7 IR connector (infrared)
CN8 PC/104 connector
CN9 Main power connector (+5 V, +12 V)
CN10 Auxilary power connector (-5 V, -12 V)
CN11 IDE hard disk connector
CN12 LCD connector
CN13 Ethernet connector
CN14 COM2 connector
CN15 LVDS connector (5820/L/E)
CN16 COM1 connector
CN17 PS/2 keyboard + PS/2 mouse
CN18 CRT display connector
CN19 CompactFlash socket
CN20 SODIMM socket
CN21 RCA composite connector (PCM-5822
only)
CN22 S-Video connector (PCM-5822 only)
CN23 ATX feature connector (PCM-5822)
CN24 ATX power button & power LED connector
LED1 Ethernet LED (PCM-5820/E,PCM-5822)
LED2 Power & HDD LED (PCM-5820/L/E
SW1 Reset button (PCM-5820/L/E)
Locating Jumpers

PCM-5820 Series Startup Manual 3
J1: Audio power source
Closed Pins Voltage
*1 - 2 5 V
2 - 3 12 V
J2: Clear CMOS
Closed Pins Result
*1 - 2 3 V battery on
2 - 3 Clear CMOS
J3: Watchdog timer
Closed Pins Result
*1 - 2 Reset
2 - 3 IRQ11
J4: COM2 selector
Closed pins Result
*1 - 2 RS-232
3 - 4 RS-422
5 - 6 RS-485
J5: Buzzer
Pins Result
*closed Enabled
open Disabled
J6: LCD power
Closed pins Voltage
*1 - 2 5 V
2 - 3 3.3 V
J7: Ethernet power select
Closed pins Result
*1 - 2 5 V
2 - 3 Standby 5V
* default setting
Locating Connectors
Warning: Be sure to use the correct component side.
Improper installation can cause serious
Locating connectors component side (PCM-5822 only)
Locating connectors solder side (PCM-5820 Series)
Locating connectors component side (PCM-5820, PCM-5820L,
PCM-5820E only)

4PCM-5820 Series Startup Manual
Board Dimensions component side (PCM-5822 only)
Mechanical Drawings
Board Dimensions component side (PCM-5820, PCM-5820L, PCM-5820E only)
Board Dimensions solder side (PCM-5820 Series)
