Advantech PCA-6029 User manual

User Manual
PCA-6029
Intel® Core™i7/i5/i3/Pentium®
PICMG 1.0 Single Host Board
with VGA/ DVI-D/ DDR4 /SATA3.0
/ USB3.0 / Dual GbE

PCA-6029 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2021
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. The information provided in this manual is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties that may result from its use.
Acknowledgements
AMIBIOS is a trademark of American Megatrends Inc.
Intel®, Core™i7/i5/i3 and Pentium® are trademarks of Intel® Corporation.
Nuvoton is a trademark of Nuvoton Technology Corp.
All other product names or trademarks are the properties of their respective owners.
Product Warranty (2 years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers will be billed according to the cost of replacement mate-
rials, service time, and freight. Please consult your dealer for more details.
If you believe your product is defective, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages displayed when the prob-
lem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship the pack-
age prepaid to your dealer.
Part No. 2001602900 Edition 1
Printed in China June 2021

iii PCA-6029 User Manual
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference. In
this event, users are required to correct the interference at their own expense.
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for the labo-
ratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name Advantech has come to be
known.
Your satisfaction is our primary concern. Here is a guide to Advantech’s customer
services. To ensure you get the full benefit of our services, please follow the instruc-
tions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are nor-
mally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your Advantech products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every busi-
ness day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.

PCA-6029 User Manual iv
Initial Inspection
Before you begin installing your motherboard, please make sure that the following
materials have been shipped:
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately. We have carefully inspected the PCA-6029 mechanically and
electrically before shipment. It should be free of marks and scratches and in perfect
working order upon receipt. As you unpack the PCA-6029, check it for signs of ship-
ping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or
it fails to meet the specifications, notify our service department or your local sales
representative immediately. Also notify the carrier. Retain the shipping carton and
packing material for inspection by the carrier. After inspection, we will make arrange-
ments to repair or replace the unit.
1 PCA-6029 PICMGG 1.0 Single Host Board
1 PCA-6029 startup manual
2 Serial ATA HDD data cable P/N: 1700003194
1 COM + printer ports cable kit P/N: 1701260305
1 4-port USB cable kit P/N: 1700008461-11
Keyboard and mouse Y cable P/N: 1700060202

v PCA-6029 User Manual

PCA-6029 User Manual vi

vii PCA-6029 User Manual
Contents
Chapter 1 Hardware Configuration......................1
1.1 Introduction ............................................................................................... 2
1.2 Features & Benefits................................................................................... 2
1.3 Specifications............................................................................................ 3
1.3.1 System .......................................................................................... 3
1.3.2 Memory ......................................................................................... 3
1.3.3 Input/Output .................................................................................. 3
1.3.4 Graphics........................................................................................ 3
1.3.5 Ethernet LAN ................................................................................ 3
1.3.6 Industrial features ......................................................................... 4
1.3.7 Mechanical and environmental specifications............................... 4
1.4 Jumpers and Connectors .......................................................................... 5
Table 1.1: Jumper list .................................................................. 5
Table 1.2: Connectors ................................................................. 5
1.5 Board Layout: Jumper and Connector Locations...................................... 6
Figure 1.1 Jumper and connector locations................................. 6
1.6 Block Diagram........................................................................................... 7
Figure 1.2 PCA-6029 Block Diagram........................................... 7
1.7 Safety Precautions.................................................................................... 8
1.8 Jumper Settings ........................................................................................ 8
1.8.1 How to set jumpers ....................................................................... 8
1.8.2 BIOS CMOS (JCMOS1)................................................................ 9
Table 1.3: JCMOS1/JME1: clear CMOS/ME data....................... 9
1.8.3 Watchdog timer output (JWDT1) .................................................. 9
Table 1.4: Watchdog timer output (JWDT1) ................................ 9
Table 1.5: H/W monitor alarm (JOBS1)...................................... 9
Table 1.6: JERP1: Deep Sleep S5 .............................................. 9
1.9 System Memory ...................................................................................... 10
1.10 Memory Installation Procedures.............................................................. 10
1.11 Cache Memory........................................................................................ 10
1.12 Processor Installation.............................................................................. 10
1.13 Processor Cooler Installation .................................................................. 12
Chapter 2 Connecting Peripherals ....................13
2.1 Introduction ............................................................................................. 14
2.2 Parallel Port (LPT1)................................................................................. 14
2.3 USB Ports (USB01USB23,USB45,USB8,USB9,USB1011).................... 15
2.4 VGA Connectors (VGA1) ........................................................................ 15
2.5 Serial Ports (COM1 & COM2) ................................................................. 16
2.6 PS/2 Keyboard and Mouse Connector (KBMS1/KBMS2)....................... 16
2.7 CPU Fan Connector (CPUFAN1)............................................................ 17
2.8 Front Panel Connectors (JFP1, JFP2 & JFP3) ....................................... 17
2.8.1 Power LED and keyboard lock (JFP3)........................................ 18
Table 2.1: PS/2 or ATX power supply LED status..................... 18
2.8.2 External speaker (JFP2) ............................................................. 18
2.8.3 Reset connector (JFP1) .............................................................. 18
2.8.4 HDD LED connector (JFP2)........................................................ 18
2.8.5 ATX soft power switch (JFP1)..................................................... 19
2.9 H/W Monitor/Watchdog Timer/Infrared ................................................... 19
2.9.1 H/W monitor alarm (JOBS1) ....................................................... 19
2.9.2 Watchdog timer (JWDT1) ........................................................... 19
2.9.3 Infrared interface (JIR1) .............................................................. 19
2.10 LAN Ports (LAN1 & LAN2)...................................................................... 20

PCA-6029 User Manual viii
Table 2.2: LAN LED Indicators.................................................. 20
2.11 High Definition Audio Module Interface (HDAUD1) ................................ 21
2.12 GPIO Header (GPIO1)............................................................................ 21
2.13 Case Open Connector (JCASE1) ........................................................... 22
2.14 Front Panel LAN Indicator Connector (LANLED1).................................. 23
Table 2.3: LAN LED Indicators.................................................. 23
2.15 Serial ATA Interface (SATA0~SATA3).................................................... 24
2.16 M.2 Connector ........................................................................................ 24
2.17 LPC Extension Interface (LPC1)............................................................. 25
Chapter 3 AMI BIOS Setup................................. 27
3.1 Introduction ............................................................................................. 28
Figure 3.1 Setup program initial screen..................................... 28
3.2 Entering Setup ........................................................................................ 29
3.2.1 Main Setup.................................................................................. 29
Figure 3.2 Main setup screen .................................................... 29
3.2.2 Advanced BIOS Features Setup................................................. 30
Figure 3.3 Advanced BIOS features setup screen .................... 30
Figure 3.4 Native PCIE Enable setup screen ............................ 31
Figure 3.5 Native ASPM setup screen ...................................... 31
Figure 3.6 Hardware Prefetcher setup screen........................... 32
Figure 3.7 Adjacent Catch Line Prefetch setup screen ............. 33
Figure 3.8 Intel (VMX) Virtualization Technology setup screen. 33
Figure 3.9 Active Processor Cores setup screen ...................... 34
Figure 3.10AES setup screen..................................................... 34
Figure 3.11Intel Trusted Execution Technology setup screen ... 35
Figure 3.12CPU - Power Management Control setup screen .... 36
Figure 3.13Firmware Update Configuration setup screen.......... 36
Figure 3.14Security Device Support setup screen ..................... 37
Figure 3.15Enable ACPI Auto Configuration setup screen ........ 38
Figure 3.16Enable Hibernation setup screen ............................. 38
Figure 3.17Lock Legacy Resources setup screen ..................... 39
Figure 3.18PowerOn by Modem setup screen ........................... 39
Figure 3.19SMART Sekf Test setup screen ............................... 40
Figure 3.20Serial Port 1 Configuration setup screen.................. 41
Figure 3.21Serial Port 2 Configuration setup screen.................. 41
Figure 3.22Parallel Port Configuration setup screen.................. 42
Figure 3.23Case Open Warning setup screen ........................... 43
Figure 3.24CPU Warning Temperature setup screen ................ 43
Figure 3.25ACPI Shutdown Temperature setup screen............. 44
Figure 3.26CPUFAN1 smartfan setting setup screen ................ 44
Figure 3.27SYSFAN1 smartfan setting setup screen................. 45
Figure 3.28SYSFAN2 smartfan setting setup screen................. 45
Figure 3.29Wake system from S5 setup screen......................... 46
Figure 3.30Console Redirection setup screen ........................... 47
Figure 3.31Legacy Console Redirection Settings setup screen. 47
Figure 3.32Console Redirection setup screen ........................... 48
Figure 3.33PCI Latency Timer setup screen .............................. 49
Figure 3.34VGA Palette Snoop setup screen............................. 49
Figure 3.35SR-IOV Support setup screen.................................. 50
Figure 3.36Network Stack setup screen..................................... 51
Figure 3.37CSM Support setup screen ...................................... 51
Figure 3.38GateA20 setup screen.............................................. 52
Figure 3.39Option ROM Message setup screen ........................ 52
Figure 3.40INT19 Trap Response setup screen ........................ 53
Figure 3.41Boot option filter setup screen.................................. 53
Figure 3.42Network setup screen............................................... 54
Figure 3.43Storage setup screen ............................................... 54

ix PCA-6029 User Manual
Figure 3.44Video setup screen................................................... 55
Figure 3.45Other PCI devices setup screen............................... 55
Figure 3.46NVME controller and Driver information ................... 56
Figure 3.47Legacy USB Support setup screen .......................... 57
Figure 3.48XHCI Hand-off setup screen..................................... 57
Figure 3.49USB Mass Storage Driver Support setup screen ..... 58
Figure 3.50USB transfer time-out setup screen ......................... 58
Figure 3.51Device reset time-out setup screen .......................... 59
Figure 3.52Device power-up delay setup screen ....................... 59
Figure 3.53Mass Storage Devices setup screen ........................ 60
Figure 3.54Serial Port 1 Configuration setup screen.................. 60
Figure 3.55Serial Port setup screen-1 ........................................ 61
Figure 3.56Serial Port setup screen-2 ........................................ 61
Figure 3.57Serial Port setup screen-3 ........................................ 62
Figure 3.58Case Open Warning setup screen ........................... 63
3.2.3 Chipset........................................................................................ 64
Figure 3.59System Agent (SA) Configuration setup screen ....... 64
Figure 3.60VT-d setup screen .................................................... 64
Figure 3.61Above 4GB MMIO BIOS assignment setup screen.. 65
Figure 3.62Graphics Configuration setup screen ....................... 65
Figure 3.63Memory Configuration setup screen......................... 66
Figure 3.64PCH-IO Configuration setup screen ......................... 67
Figure 3.65SATA Configuration setup screen ............................ 67
Figure 3.66USB Configuration setup screen .............................. 68
Figure 3.67HD Audio Configuration setup screen ...................... 68
Figure 3.68LAN1 Controller setup screen .................................. 69
Figure 3.69LAN1 Option-ROM setup screen.............................. 69
Figure 3.70Wake on LAN Enable setup screen.......................... 70
Figure 3.71LAN2 Controller setup screen .................................. 70
Figure 3.72LAN2 Option-ROM setup screen.............................. 71
Figure 3.73PCIE Wake setup screen ......................................... 71
Figure 3.74High Precision Timer setup screen........................... 72
Figure 3.75Restore AC Power loss setup screen....................... 72
Figure 3.76PCIE Device Initial Delay setup screen .................... 73
Figure 3.77Administrator Password setup screen ...................... 74
Figure 3.78User Password setup screen.................................... 74
Figure 3.79Bootup Numlock State setup screen ........................ 75
Figure 3.80Quiet setup screen ................................................... 75
Figure 3.81Boot Option #1 setup screen .................................... 76
Figure 3.82Boot Option #2 setup screen .................................... 76
Figure 3.83Hard Drive BBS Priorities setup screen.................... 77
Figure 3.84Save Changes and Exit setup screen ...................... 78
Figure 3.85Discard Changes and Exit setup screen .................. 78
Figure 3.86Save Changes and Reset setup screen ................... 79
Figure 3.87Discard Changes and Reset setup screen ............... 79
Figure 3.88Save Changes setup screen .................................... 80
Figure 3.89Discard Changes setup screen ................................ 80
Figure 3.90Restore setup screen ............................................... 81
Figure 3.91Save as User Defaults setup screen ........................ 81
Figure 3.92Restore User Defaults setup screen......................... 82
Figure 3.93UEFI setup screen.................................................... 82
Figure 3.94Launch EFI Shell from file system setup screen ...... 83
Chapter 4 Value-Added Software Services.......85
4.1 Value-Added Software Services ............................................................. 86
4.1.1 Software API ............................................................................... 86
4.1.2 Software Utility ............................................................................ 86

PCA-6029 User Manual x
Chapter 5 Chipset Software Installation Utility 87
5.1 Before You Begin.................................................................................... 88
5.2 Introduction ............................................................................................. 88
5.3 Win7/Win8/Win10 Driver Setup .............................................................. 88
Chapter 6 Integrated Graphic Device Setup .... 89
6.1 Introduction ............................................................................................. 90
6.2 Win7/Win8/Win10 Driver Setup .............................................................. 90
Chapter 7 LAN Configuration ............................ 91
7.1 Introduction ............................................................................................. 92
7.2 Installation............................................................................................... 92
7.3 Win7/Win8/Win10 Driver Setup (LAN) .................................................... 92
Chapter 8 Intel ME .............................................. 93
8.1 Introduction ............................................................................................. 94
8.2 Installation............................................................................................... 94
Chapter 9 Intel USB 3.0 ...................................... 95
9.1 Introduction ............................................................................................. 96
9.2 Installation............................................................................................... 96
Appendix A Programming the Watchdog Timer . 97
A.1 Introduction ............................................................................................. 98
A.1.1 Watchdog timer overview ........................................................... 98
A.1.2 Programming the watchdog timer............................................... 98
Table A.1: Watchdog timer registers ......................................... 99
A.1.3 Example program ..................................................................... 100
Appendix B I/O Pin Assignments ....................... 105
B.1 Parallel Port Connector (LPT1)............................................................. 106
Table B.1: Parallel port connector (LPT1) ............................... 106
B.2 VGA Connector (VGA1)........................................................................ 106
Table B.2: VGA connector (VGA1) .......................................... 106
B.3 RS 232 Serial Port (COM12) ................................................................ 107
Table B.3: RS-232 serial port (COM2)..................................... 107
B.4 USB 2.0 Header (USB56 & 910)........................................................... 107
Table B.4: USB Header (USB56 & 910) .................................. 107
B.5 USB3.0 Header (USB12) ...................................................................... 108
Table B.5: USB 3.0 Header (USB12) ...................................... 108
B.6 PS/2 Keyboard/Mouse Connector (KBMS1)......................................... 108
Table B.6: PS/2 keyboard/mouse connector (KBMS1)............ 108
B.7 External Keyboard Connector (KBMS2) ............................................... 109
Table B.7: External keyboard connector (KBMS2) .................. 109
B.8 CPU Fan Power Connector (CPUFAN1) .............................................. 109
Table B.8: CPU fan power connector (CPUFAN1) .................. 109
B.9 Power LED and Keyboard Lock Connector (JFP3 / PWR_LED & KEY

xi PCA-6029 User Manual
LOCK) ................................................................................................... 109
Table B.9: Power LED and keyboard lock connector (JFP3 /
PWR_LED & KEY LOCK)....................................... 109
B.10 External Speaker Connector (JFP2 / SPEAKER) ................................. 110
Table B.10:External speaker connector (JFP2 / SPEAKER) .... 110
B.11 Reset Connector (JFP1 / RESET) ........................................................ 110
Table B.11:Reset connector (JFP1 / RESET)........................... 110
B.12 HDD LED (JFP2 / HDDLED)................................................................. 110
Table B.12:HDD LED (JFP2 / HDDLED) .................................. 110
B.13 ATX Soft Power Switch (JFP1 / PWR_SW) .......................................... 110
Table B.13:ATX soft power switch (JFP1 / PWR_SW) ............. 110
B.14 Hi-definition Audio Link Connector (HDAUD1)...................................... 111
Table B.14:Hi-definition audio link connector (HDAUD1) ......... 111
B.15 SM Bus Connector (JFP2 / SNMP)....................................................... 111
Table B.15:SM bus connector (JFP2 / SNMP) ......................... 111
B.16 LAN1 and LAN2 LED Connector (LANLED1) ....................................... 111
Table B.16:LAN1 and LAN2 LED connector (LANLED1) ......... 111
B.17 GPIO Header (GPIO1) .......................................................................... 112
Table B.17:GPIO header (GPIO1) ............................................ 112
B.18 Fixed I/O Ranges Decoded by Intel PCH.............................................. 112
Table B.18:Fixed I/O Ranges Decoded by PCH....................... 112
B.19 System I/O Ports ................................................................................... 114
Table B.19:System I/O Ports .................................................... 114
B.20 Interrupt Assignments ........................................................................... 114
Table B.20:Interrupt Assignments............................................. 114
B.21 1 MB Memory Map................................................................................ 115
Table B.21:1 MB memory map ................................................. 115
B.22 PCI Bus Map......................................................................................... 115
Table B.22:PCI Bus Map .......................................................... 115
Appendix C Programming the GPIO...................117
C.1 Supported GPIO Register ..................................................................... 118
C.2 GPIO Registers ..................................................................................... 118
C.3 GPIO Example Program-1 .................................................................... 118

PCA-6029 User Manual xii

Chapter 1
1Hardware
Configuration

PCA-6029 User Manual 2
1.1 Introduction
PCA-6029 is a PICMG 1.0 form-factor single host board which is designed with
Intel® H110 PCH for industrial applications that need high computing power and
strong I/O capability.PCA-6029 supports 22nm manufacturing technology, LGA1151
socket Intel® Core™ i7/i5/i3 and Pentium® processors that integrate memory and
graphic controllers and support DDR4 2133/2400 MHz SDRAM up to 32 GB. By sup-
porting advanced computing technology, PCA-6029 is suitable for computing power
hungry industrial applications.
PCA-6029 has excellent graphic processing capability with its integrated Intel® HD
graphics core with shared system memory dependent upon OS configuration. With
this feature, PCA-6029 provides strong 2D/3D graphic processing power without a
discrete graphic card to save extra cost, power consumption and thermal design
effort.
PCA-6029 also has multiple I/O interfaces, and can support Advantech PICMG 1.0
compatible backplanes to offer various expansion slots such as PCI and ISA slots.
New SATA Gen3 (600MB/sec) ports meet high data transfer requests, like storage
and DVR. Three SATA ports, two USB 3.0 ports reach 5Gbps high data transfer
application, the two on-board RS-232 serial ports are COM ports for industrial control
applications. With flexible I/O and graphic expansibility, PCA-6029 is an excellent,
cost effective graphic or I/O oriented workstation class platform. With outstanding
performance and exceptional features, PCA-6029 is the ideal computing platform for
advanced industrial applications.
1.2 Features & Benefits
Features Benefits
PCA-6029 supports Intel 6th/7th genera-
tion processors
Intel’s Skylake Core i7/i5/i3/Pentium processor
cores with quad/dual-core computing power brings
quantum-leap performance improvement.
PCA-6029 supports DDR4 2133/2400
SDRAM up to 32 GB
Provides higher memory data transmission and
processing efficiency, bringing higher system per-
formance.
Fully supports Advantech SUSI APIs and
Utilities.
Reduces customer S/W development effort with
more reliable S/W, also provides value-added utili-
ties such as system monitor and Embedded Secu-
rity ID.
SATA Gen3
Provides high performance storage interface.
SATA Gen3 is 6Gb/s which is double bandwidth
with SATA Gen2.
USB 3.0
Provides high transfer data performance interface;
USB 3.0 data transfer rate is 5Gbps which is 10
times faster than USB2.0.

3 PCA-6029 User Manual
Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
CPU: LGA1151-socket Core i7/i5/i3 and Pentium series processors.
L3 Cache: Please refer to CPU specification for detail information.
BIOS: AMI SPI BIOS (128 Mb SPI).
System Chipset: Intel H110.
SATA hard disk drive interface: Four SATA3 (600MB/s) with blue connectors.
These interfaces can be enabled/disabled in the BIOS.
1.3.2 Memory
RAM:
–PCA-6029: Up to 32 GB in two 240-pin DIMM sockets. Supports dual-chan-
nel DDR4 2133/2400 MHz SDRAM WITHOUT ECC function.
1.3.3 Input/Output
ISA bus: HISA (ISA high driver).
PCI bus: Four PCI masters to the backplane, 32-bit, 33 MHz PCI 2.2 compliant.
Serial ports: Two RS-232 serial ports.
PS/2 keyboard and mouse connector: One 6-pin mini-DIN connectors is
located on the mounting bracket for easy connection to a PS/2 keyboard and
mouse via the Y-cable included in the package.
USB port: Supports 8 USB 2.0 ports with transfer rate up to 480 Mbps. (5 ports
are on the CPU card and 4 ports are on the backplane), and 3 USB 3.0 ports
with transfer rate up to 5 Gbps.
LPC: One LPC connector to support Advantech TPM LPC modules.
GPIO: Supports 8-bit GPIO from super I/O for general purpose control applica-
tion.
1.3.4 Graphics
Controller: Intel® HD Graphics embedded in the processor.
Display memory: Shared memory is subject to OS (Please install 2 GB or
above memory for basic system configuration).
CRT: Up to 1920 x1080 resolution, 400 MHz RAMDAC.
DVI-D: One DVI-D pin header supports resolution up to 1920 x 1200 @ 60 Hz.
PCI slot on the backplane: An external graphic card can be installed on PCI
slots for stronger 2D/3D graphic capability.
1.3.5 Ethernet LAN
Supporting single/dual 10/100/1000 Mbps Ethernet port(s) via the dedicated
PCI Express x1 bus which provides 500 MB/s data transmission rate.
Controller:
–LAN 1: Intel® i219-V.
–LAN 2: Intel® i211-AT.
Note! PCA-6029 does NOT support PATA (IDE) interface.

PCA-6029 User Manual 4
1.3.6 Industrial features
Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second (255 levels).
1.3.7 Mechanical and environmental specifications
Operating temperature: 0 ~ 60° C (32 ~ 140° F, depending on CPU and ther-
mal solution)
Storage temperature: -40 ~ 85° C (-40 ~ 185° F)
Humidity: 20 ~ 95% non-condensing
Power supply voltage: +5 V, +12 V, +5 VSB
Power consumption:
Test Environment: i7-6700 CPU, 32G 2Rx8 DDR4 3200U*2, SEAGATE
500GB*1
Voltage: +V12, +V5, +V5_SB, +V12_4P
Current: 0.13A, 0.94A, 0.08A, 1.33A
Board size: 338.58 mm (L) x 126.39 mm (W) (13.3" x 4.98")
Board weight: 0.5 kg

5 PCA-6029 User Manual
Chapter 1 Hardware Configuration
1.4 Jumpers and Connectors
Connectors on the PCA-6029 single host board link it to external devices such as
hard disk drives and a keyboard. In addition, the board has a number of jumpers
used to configure your system for your application.
The tables below list the function of each of the board jumpers and connectors. Later
sections in this chapter give instructions on setting jumpers. Chapter 2 gives instruc-
tions for connecting external devices to your motherboard.
Table 1.1: Jumper list
Label Function
JCMOS1 CMOS clear
JME1 Clear ME data
JWDT1 Watchdog timer output selection
JOBS1 HW Monitor Alarm
Table 1.2: Connectors
Label Function
LPT1 Parallel port, Parallel port x 1, supports SPP/EPP/ECP mode
LAN1 Intel i219-V
LAN2 Intel i211-AT
VGA1 VGA connector
KBMS1 PS/2 keyboard and mouse connector
KBMS2 External keyboard/mouse connector
COM1 Serial port: COM1; RS-232 (9-pin Box Header)
COM2 Serial port: COM2; RS-232 (9-pin Box Header)
JIR Infrared connector
JFP3
(Keyboard Lock and
Power LED)
Power LED
Suspend: Fast flash (ATX/AT)
System On: ON (ATX/AT)
System Off: OFF ((ATX/AT))
JFP2 External speaker / SATA HDD LED connector
JFP1 Power Switch / Reset connector
JCASE1 Case Open
CPUFAN1 CPU FAN connector (4-pin)
LANLED1 LAN1/2 LED extension connector
HDAUD1 HD audio extension module connector
USB01 USB port 0,1 (3.0)
USB23 USB port 2,3
USB45 USB port 4,5
USB8 USB port 8 (G2 sku only)
USB1011 USB port 10,11
SATA1 Serial ATA1 (3.0)
SATA2 Serial ATA2 (3.0)
SATA3 Serial ATA3
CPU1 CPU Socket
DIMMA1 Memory connector channel A
DIMMB1 Memory connector channel B

PCA-6029 User Manual 6
1.5 Board Layout: Jumper and Connector
Locations
Figure 1.1 Jumper and connector locations
GPIO1 GPIO pin header (SMD pitch-2.0 mm)
LPC1 COM port module expansion pin-header
DVI1 DVI connector
MINIPCIE1 mSATA connector
SMBUS1 SMBus connector
ATX12V1 12V connector
ATXF1 ATX power connector

7 PCA-6029 User Manual
Chapter 1 Hardware Configuration
1.6 Block Diagram
Figure 1.2 PCA-6029 Block Diagram
Gen 1.0
Gen 1.0
PCIe Bridge
IT8896E
PCIeX1 Lane20
Gen 1.0
USB 3.0
SPI Bus
23 x 23 mm
Gen 3.0
LQFP 128P 14x14 mm
LQFP 128P 16 x 16 m m
Gen 3.0
PCIeX4 Lane5~8
Gen 2.0
SATA 0 ~ 3 CONN.
Rear Panel
6 Pin Header
1 Int Type A
1 Rear Panel
2 Pin Header
Rear Panel
Rear Panel
USB 3.0 X 3
RJ45 CONN.
RJ45 CONN.
PICMG 1.0
CPU
Skylake-S
LGA1151
65W/35W (4+2)
35W/65W (2+2)
PCH
SKL PCH-H
FCBGA-837
DDR4 240 PIN UDIMM
1866/2133 ECC, Max 8GB
Intel Jacksonville
I219LV GbE (PHY)
Intel Pearsonville
I211AT GbE (NIC)
DMI X 4
PCIeX1 Lane4
PCIeX1 Lane10
600MB/s
DDI1
VGA
CONN. VGA
HD Audio
Pin Header
USB 2.0 X 7 USB 2.0
LPC Bus Super I/O
NCT6776D
37.5 x 37.5 mm
9 x 9 mm
6 x 6 mm
LPC CONN.
SPI BIOS (SKT)
128M-bit
33MHz
PCI
Channel A
Channel B
10/100/1G
10/100/1G
I/O Voltage of 1.2(V),Vtt is 0.6(V),Vpp is 2.5(V),
DDI3
Converter
CHRONTEL CH7517A-BF
mm 5 x 5P04 NFQVH
LPT
Box Header
WDT
CASE OPEN
FAN - CPU / SYS1 / SYS2
Voltage - +V12 / +V5 / +V5_SB / +VCORE / +V3.3 / +VBAT
TEMP. - CPU / MB
RS-232 X 2
PS/2 KB, MS
H/W Monitor
8 bit GPIO
W83782G
LQFP48 9 x 9 mm
FAN - CPU / SYS1 / SYS2
Voltage - +V12 / +V5 / +V5_SB / +VCORE / +V3.3 / +VBAT
TEMP. - CPU / MB
I2C I/F To JFP1+JFP2
Audio
BOX Header
H/W Monitor
LAN1
LAN2
Gold Finger_PCI
DP/DVI BtB
DDR4 240 PIN UDIMM
1866/2133 ECC, Max 8GB
DP
DP+HDMI/DVI
M.2(M-key 2280 type)
Fintek
F85226AF-I
ISA PICMG 1.0
Gold Finger_ISA
USB 2.0

PCA-6029 User Manual 8
1.7 Safety Precautions
1.8 Jumper Settings
This section provides instructions on how to configure your motherboard by setting
the jumpers. It also includes the motherboard’s default settings and your options for
each jumper.
1.8.1 How to set jumpers
You can configure your motherboard to match the needs of your application by set-
ting the jumpers. A jumper is a metal bridge that closes an electrical circuit. It consists
of two metal pins and a small metal clip (often protected by a plastic cover) that slides
over the pins to connect them. To “close” (or turn ON) a jumper, you connect the pins
with the clip. To “open” (or turn OFF) a jumper, you remove the clip. Sometimes a
jumper consists of a set of three pins, labeled 1, 2 and 3. In this case you connect
either pins 1 and 2, or 2 and 3. A pair of needle-nose pliers may be useful when set-
ting jumpers.
Warning! Always completely disconnect the power cord from your chassis when-
ever you work with the hardware. Do not make connections while the
power is on. Sensitive electronic components can be damaged by sud-
den power surges. Only experienced electronics personnel should open
the PC chassis.
Caution! Always ground yourself to remove any static charge before touching the
motherboard. Modern electronic devices are very sensitive to static
electrical discharges. As a safety precaution, use a grounding wrist
strap at all times. Place all electronic components on a static-dissipative
surface or in a static-shielded bag when they are not in the chassis.
Caution! The computer is provided with a battery-powered Real-time Clock.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended by the manufacturer.
Discard used batteries according to manufacturer's instructions.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer’s
instructions.
