Advantech PCI-7031 User manual

User Manual
PCI-7031
Intel
®
Atom™ Dual-Core D510/
Fanless N450 CPU, PCI Half-size
SBC with on-board DDR2 / VGA /
LVDS / Dual-GbE / SATA / COM

PCI-7031 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2009
by WKHPDQXIDFWXUHU. All rights are reserved. 7KHPDQXIDFWXUHU reserves the right
to make improvements in the products described in this manual at any time without
notice.
No part of this manual may be reproduced, copied, translated or transmitted in any
form or by any means without the prior written permission of WKHPDQXIDFWXUHU.
Information provided in this manual is intended to be accurate and reliable. However,
WKHPDQXIDFWXUHU assumes no responsibility for its use, nor for any infringements
of the rights of third parties, which may result from its use.
Acknowledgements
PICMG®and the PICMG®logos are trademarks of the PCI Industrial Computers
Manufacturers Group.
All other product names or trademarks are properties of their respective owners.
Certifications
CE
FCC Class A
Part No. 2002703101 Edition 2
Printed in Taiwan December 2009

iii PCI-7031 User Manual
A Message to the Customer
Technical support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are nor-
mally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from RXU engineers every busi-
ness day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.

PCI-7031 User Manual iv
Product Warranty (2 years)
7KHPDQXIDFWXUHU warrants to you, the original purchaser, that each of its products
ZLOOEHfree from defects in materials and workmanship for two years from the date
RISXUchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by WKHPDQXIDFWXUHU, or
ZKLFKKDYHEHHQsubject to misuse, abuse, accident or improper installation.
7KHPDQXIDFWXUHassumes noliability under the terms of this warranty as a
consequence ofsuch events.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Before you begin installing your single board computer, please make sure that the
following materials have been shipped:
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately.
We have carefully inspected the PCI-7031 mechanically and electrically before ship-
ment. It should be free of marks and scratches and in perfect working order upon
receipt.
As you unpack the PCI-7031, check it for signs of shipping damage. (For example,
damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifica-
tions, notify our service department or your local sales representative immediately.
Also notify the carrier. Retain the shipping carton and packing material for inspection
by the carrier. After inspection, we will make arrangements to repair or replace the
unit.

v PCI-7031 User Manual
Initial Inspection
Before you begin installing your single board computer, please make sure that the
following materials have been shipped:
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately.
We have carefully inspected the PCI-7031 mechanically and electrically before ship-
ment. It should be free of marks and scratches and in perfect working order upon
receipt.
As you unpack the PCI-7031, check it for signs of shipping damage. (For example,
damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifica-
tions, notify our service department or your local sales representative immediately.
Also notify the carrier. Retain the shipping carton and packing material for inspection
by the carrier. After inspection, we will make arrangements to repair or replace the
unit.
1 PCI-7031D(N)-S6A1E single board computer
1 CPU Cooler for Atom D510 CPU (Only Available for D SKU) P/N: 1960046526N001
1 PCI-7031 Startup Manual
1 CD with driver utility and manual (in PDF format)
1 FDD cable P/N: 1700340640
1 Ultra ATA 66/100 HDD cables P/N: 1701400452
2 Serial ATA HDD data cable P/N: 1700003194
2 Serial ATA HDD power cable P/N: 1703150102
1 Printer (parallel) port cable kit P/N: 1701260301
1 Dual COM ports cable kit P/N: 1700008762
1 ATX Feature Cable P/N: 1700002343
1 4-Port USB cable kit P/N: 1700008887
1 Y cable for PS/2 keyboard and PS/2 mouse P/N: 1700060202
1 AT/ATX PSU 20-Pin to 12-Pin Cable Kit P/N: 1700000265
1 Jumper Pack P/N: 9689000068
1 Warranty card
Note! Using PCI-7031D's proprietary CPU cooler included in its package is a
must. Other brands of CPU coolers are NOT compatible with PCI-7031.
PCI-7031N is of fanless CPU type and does not need installing a CPU
cooler by user.

PCI-7031 User Manual vi
Verified Memory List
Brand Size Speed Type ECC Vendor PN
 Memory
Tran-
scend
256
MB DDR2 667 SODIMM DDR2 N TS32MSQ64V6M  Hynix HY5PS121621B FP-Y5 (32x16)
512
MB DDR2 667 SODIMM DDR2 NTS6QSJ23002-6S/ TS64MSQ64V6J



SAMSUNGK4T51083QCZCE6
(64x8)
512
MB DDR2 667 SODIMM DDR2 NHynix
HY5PS121621B
FP-Y5  Hynix HY5PS121621B FP-Y5
(32x16)
1 GB DDR2
667 SODIMM DDR2 N TS128MSQ64V6J  SAMSUNGK4T51083QCZCE6 (64x8)
2 GB DDR2
667 SODIMM DDR2 N TS5QSU27300-6M   Micron D9HNL (128x8)
Apacer
512
MB DDR2 667 SODIMM DDR2 N 78.92G63.422  ELPIDA E5108AG-6E-E (64x8)
1 GB DDR2
667 SODIMM DDR2 N 78.02G63.423  ELPIDA E5108AGBG-6E-E (64x8)
DSL
256
MB DDR2 667 SODIMM DDR2 N NA ELPIDA E5116AF-6E-E (32x16)
512
MB DDR2 667 SODIMM DDR2 NNA ELPIDA E5108AGBG-6E-E (64x8)
1 GB DDR2
667 SODIMM DDR2 NN
AELPIDA E5108AGBG-6E-E
(64x8)
2 GB DDR2
667 SODIMM DDR2 NN
AELPIDA E1108ACSE-6E-E
(128x8)
1 GB DDR2
800 SODIMM DDR2 N TS64MSQ64V6M Hynix HY5PS121621B FP-Y5 (32x16)
2 GB DDR2
800 SODIMM DDR2 N TS256MSQ64V8U Micron D9HNP (128x8)
1 GB DDR2
800 SODIMM DDR2 NN
AELPIDA TWN E5108AHSE-8E-
E (64x8)
2 GB DDR2
800 SODIMM DDR2 NN
AELPIDA JPN E1108ACSE-8E-E
(128x8)

vii PCI-7031 User Manual
Certification and Safety Instructions
This device complies with the requirements in part 15 of the FCC rules: Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation
This equipment has been tested and found to comply with the limits for a Class A dig-
ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this device in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his/her own expense. The
user is advised that any equipment changes or modifications not expressly approved
by the party responsible for compliance would void the compliance to FCC regula-
tions and therefore, the user's authority to operate the equipment.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.

PCI-7031 User Manual viii

ix PCI-7031 User Manual
Chapter 1 Hardware Configuration......................1
1.1 Introduction ...............................................................................................2
1.2 Features....................................................................................................3
1.3 Specifications............................................................................................3
1.3.1 System..........................................................................................3
1.3.2 Memory.........................................................................................3
1.3.3 Input/Output..................................................................................4
1.3.4 Graphic interface...........................................................................4
1.3.5 Ethernet LAN ................................................................................4
1.3.6 Industrial features .........................................................................4
1.3.7 Mechanical and environmental specifications...............................4
1.4 Jumpers and Connectors..........................................................................5
Table 1.1: Jumper descriptions ...................................................5
Table 1.2: Connector descriptions...............................................5
1.5 Board Layout: Jumper and Connector Locations......................................7
Figure 1.1 Board Layout..............................................................7
1.6 PCI-7031 Block Diagram...........................................................................8
Figure 1.2 Block Diagram............................................................8
1.7 Safety Precautions....................................................................................8
1.8 System Memory ........................................................................................9
1.9 Memory Installation Procedures................................................................9
1.10 Processor Installation..............................................................................10
1.11 CPU Cooler Installation...........................................................................10
Chapter 2 Connecting Peripherals & Jumper
Settings ..............................................11
2.1 Introduction .............................................................................................12
2.2 IDE Connector (IDE1).............................................................................12
Figure 2.1 PCI-7031 IDE1 location............................................12
2.3 Floppy Drive Connector (FDD1)..............................................................13
Figure 2.2 PCI-7031 FDD1 location...........................................13
2.4 Parallel Port (LPT1).................................................................................14
Figure 2.3 PCI-7031 LPT1 location ...........................................14
2.5 VGA Connector (VGA1)..........................................................................15
Figure 2.4 VGA Connector (VGA1) ...........................................15
2.6 Serial Ports (COM12)..............................................................................15
Figure 2.5 Serial Ports (COM12)...............................................15
2.7 PS/2 Keyboard/Mouse Connector (KBMS1)...........................................16
Figure 2.6 PS/2 Keyboard/Mouse Connector (KBMS1) ...........16
2.8 External Keyboard Pin Header (KBMS2)................................................16
Figure 2.7 External Keyboard Connector (KBMS2)..................16
2.9 CPU Fan Connectors (CPUFAN1)..........................................................17
Figure 2.8 CPU Fan Connectors (CPUFAN1) ..........................17
2.10 Front Panel Connectors (JFP1) .............................................................17
Figure 2.9 Front Panel Connectors (JFP1)...............................17
2.10.1 ATX Power Button (JFP1 Pin 1~2) .............................................18
2.10.2 Reset (JFP1 Pin 3~4) .................................................................18
2.10.3 Suspend LED (JFP1 Pin 5~6).....................................................18
2.10.4 Power LED and keyboard lock connector (JFP1 Pin 7~8)..........18
Table 2.1: ATX power supply LED status (No support for AT pow-
er).............................................................................18
2.10.5 HDD LED (JFP1 Pin 9~10).........................................................18
2.11 Watch Dog Timer (JWDT1) / Infrared (JIR1)...........................................19
Figure 2.10Watch Dog Timer (JWDT1) / Infrared (JIR1)............19
2.11.1 Watchdog timer output (JWDT1) ................................................19

PCI-7031 User Manual x
Table 2.2: Watchdog timer output (JWDT1).............................. 19
2.11.2 Infrared Connector (JIR1)........................................................... 19
2.12 Dual Giga LAN RJ45 connector (LAN12) ............................................... 20
Figure 2.11Dual Giga LAN RJ45 connector (LAN12)................. 20
2.13 High Definition Audio Interface (HDAUD1) ............................................. 20
Figure 2.12High Definition Audio Interface (HDAUD1)............... 20
2.14 Serial ATA interface (SATA1 ~ SATA3).................................................. 21
Figure 2.13Serial ATA interface (SATA1 ~ SATA3)................... 21
2.15 LAN1 and LAN2 LED connector (LANLED1).......................................... 21
Figure 2.14LAN1 and LAN2 LED connector (LANLED1) ........... 21
2.16 GPIO header (GPIO1) ............................................................................ 22
Figure 2.15 GPIO header (GPIO1)............................................. 22
2.17 CMOS clear (CMOS1) ............................................................................ 23
Table 2.3: CMOS (CMOS1) ...................................................... 23
2.18 ATX Feature connector(ATXF1)............................................................. 24
2.19 ATX power control connector (ATX1) ..................................................... 24
2.20 System FAN connector (SYSFAN1)....................................................... 25
2.21 LVDS Signal and Power Connectors (LVDS1/VP1) ............................... 25
2.22 USB Ports (USB 1~6 & 8)....................................................................... 26
2.23 CF Card Socket ...................................................................................... 26
2.24 Low Pin Count Device Connection Pin Header ...................................... 27
Chapter 3 AMI BIOS Setup................................. 29
Figure 3.1 Setup Program Initial Screen ................................... 30
3.1 Entering Setup........................................................................................ 31
3.2 Main Setup.............................................................................................. 31
Figure 3.2 Main Setup Screen................................................... 31
3.2.1 System time / System date......................................................... 31
3.3 Advanced BIOS Features Setup............................................................. 32
Figure 3.3 Advanced BIOS Features Setup Screen.................. 32
3.3.1 CPU Configuration...................................................................... 33
Figure 3.4 CPU Configuration Settings ..................................... 33
3.3.2 IDE Configuration ....................................................................... 34
Figure 3.5 IDE Configuration..................................................... 34
3.3.3 Super I/O Configuration.............................................................. 35
Figure 3.6 Super I/O Configuration............................................ 35
3.3.4 Hardware Health Function.......................................................... 36
Figure 3.7 Hardware Health Configuration................................ 36
3.3.5 APM Configuration...................................................................... 37
Figure 3.8 APM Configuration ................................................... 37
3.4 PCI/PNP Setup....................................................................................... 38
Figure 3.9 PCI/PNP Setup......................................................... 38
3.5 Boot Setup Utility .................................................................................... 39
Figure 3.10Boot Settings Configuration...................................... 39
3.6 Security Setup......................................................................................... 40
Figure 3.11Password Configuration ........................................... 40
3.7 Advanced Chipset Settings..................................................................... 41
Figure 3.12Advanced Chipset Settings ...................................... 41
Figure 3.13Souh Bridge Configuration....................................... 43
3.8 Exit Options............................................................................................. 44
Figure 3.14Exit Options.............................................................. 44
3.8.1 Save Changes and Exit.............................................................. 44
3.8.2 Discard Changes and Exit.......................................................... 44
3.8.3 Discard Changes........................................................................ 44
3.8.4 Load Optimal Defaults................................................................ 45
3.8.5 Load Failsafe Defaults................................................................ 45

xi PCI-7031 User Manual
Chapter 4 Value-Added Software Services.......47
4.1 Value-Added Software Services .............................................................48
4.1.1 Software API...............................................................................48
4.1.2 Software Utility............................................................................50
Chapter 5 Chipset Software Installation Utility 51
5.1 Before You Begin....................................................................................52
5.2 Introduction .............................................................................................52
5.3 Windows XP/XP Embedded/CE Driver Setup.........................................53
Chapter 6 Integrated Graphic Device Setup.....55
6.1 Introduction .............................................................................................56
6.2 Windows XP/XP Embedded/CE Driver Setup.........................................56
Chapter 7 LAN Configuration.............................57
7.1 Introduction .............................................................................................58
7.2 Installation...............................................................................................58
7.3 Windows XP/XP Embedded/CE Driver Setup.........................................58
Appendix A Programming the Watchdog Timer..59
A.1 Watchdog Timer......................................................................................60
A.1.1 Watchdog Timer Overview..........................................................60
A.1.2 Reset/ Interrupt Selection ...........................................................60
A.1.3 Programming the Watchdog Timer.............................................61
Table A.1: Watchdog Timer Registers.......................................62
A.1.4 Example Program.......................................................................63
Appendix B I/O Pin Assignments..........................67
B.1 Front Panel Connectors (JFP1) ..............................................................68
Table B.1: Front Panel Connectors (JFP1)................................68
B.2 USB Ports (USB12/USB34/USB56)........................................................68
Table B.2: USB Ports (USB12/USB34)......................................68
B.3 IR Connector (JIR1) ................................................................................69
Table B.3: IR Connector (JIR1)..................................................69
B.4 Serial Ports (COM12)..............................................................................69
Table B.4: Serial Ports (COM12)...............................................69
B.5 PS/2 Keyboard / Mouse connector (KBMS2)..........................................70
Table B.5: PS/2 Keyboard / Mouse connector (KBMS2)...........70
B.6 LAN LED connector (LANLED1/LANLED2)............................................70
Table B.6: LAN LED connector (LANLED1/LANLED2) .............70
B.7 ATX Feature connector(ATXF1) .............................................................71
Table B.7: ATX Feature connector(ATXF1)...............................71
B.8 CPU FAN connector (CPUFAN1) ...........................................................71
Table B.8: CPU FAN connector (CPUFAN1).............................71
B.9 System FAN connector (SYSFAN1) .......................................................71
Table B.9: System FAN connector (SYSFAN1).........................71
B.10 Audio Interface Connector (HDAUD1)....................................................72
Table B.10:Audio Interface Connector (HDAUD1)......................72

PCI-7031 User Manual xii
B.11 GPIO Header (GPIO1)............................................................................ 72
Table B.11:GPIO Header (GPIO1)............................................. 72
B.12 LVDS Connector (LVDS1) ...................................................................... 73
Table B.12:LVDS Connector (LVDS1)........................................ 73
B.13 LCD Inverter Connector (VP1)................................................................ 73
Table B.13:LCD Inverter Connector (VP1)................................. 73
B.14 SM Bus Connector (SMBUS1)................................................................ 74
Table B.14:SM Bus Connector (SMBUS1)................................. 74
B.15 Low Pin Count Header (LPC1) ............................................................... 74
Table B.15:Low Pin Count Header (LPC1)................................. 74
B.16 ATX Power Control Connector (ATX1) ................................................... 75
Table B.16:ATX Power Control Connector (ATX1)..................... 75
B.17 VGA Connector (VGA1).......................................................................... 75
Table B.17:VGA Connector (VGA1)........................................... 75
Appendix C Programming the GPIO....................77
C.1 Supported GPIO Register....................................................................... 78
C.1.1 GPIO Registers........................................................................... 78
C.1.2 GPIO Example Program-1.......................................................... 79

Chapter 1
1Hardware
Configuration

PCI-7031 User Manual 2
1.1 Introduction
PCI-7031 is an Atom dual-core D510 / fanless N450 CPU based PCI-interface half-
size PICMG single board computer. With high performance Atom D510 dual-core
computing power, it is ideal for intense data or graphic processing applications; with
fanless Atom N450 CPU and on-board memory feature, it has ultra high reliability to
resist heat, dust, vibration and shock in any application environment.
PCI-7031 is designed with an Intel© Atom™ D510/N450 CPU and ICH8M I/O control
hub. The Atom D510 dual core CPU brings new generation computing capability into
the half-size SBC application field. Compact size, low power consumption (Total
power consumption ≤17.796 W) and dual-core parallel computing power and maxi-
mum 2 GB of DDR2 667 MHz memory capacity makes the PCI-7031D a powerful
small form-factor computer platform for modern industrial applications that require
high computing power. The fanless Atom N450 CPU (Total power consumption ≤
15.264 W) and on-board memory design eliminate moving fan parts and memory
socket connections; this makes PCI-7031N ultra reliable to conduct its mission under
various kinds of high-temperature, vibrating, shocking and dusty harsh environments.
PCI-7031 has an integrated graphic core of Intel Embedded Gen3.5+ graphic tech-
nology with 224 MB shared memory. This feature makes PCI-7031 is capable of han-
dling complex and intense 2D/3D graphic processing without an add-on graphic card;
its VGA and LVDS dual video outputs also makes it suitable for applications requiring
dual display or digital panel display capabilities.
PCI-7031 is rich in I/O interfaces: it has three SATA ports (300 MB/sec) for main-
stream SSD (solid state disk), HDD, and ODD connections, one legacy IDE port for
the ODD connection. It also has a CF socket to support an economical, easy-to-
maintain SSD device. Additionally, the dual Gigabit Ethernet LANs with teaming func-
tions offer strong networking capability; the two serial ports (COM ports) can be used
as reliable legacy device control interfaces.

3 PCI-7031 User Manual
Chapter 1 Hardware Configuration
1.2 Features
Complies with PICMG®1.0
Ultra low power ( Total Power Consumption ≤15.264 W), fanless N450 CPU and
1 GB on-board DDR2 667 memory (Only for N SKU)
Dual-core high performance D510 CPU and maximum 2 GB DDR2 667 memory
(Only for D SKU)
Intel® Embedded Gen3.5+ graphics core with 224 MB of shared memory with
VGA/LVDS dual video outputs (supporting mirror (clone) and extension modes)
Supports Dual-Gigabit Ethernet LANs with teaming capability
Supports Embedded Software SUSI APIs and Utilities. (SUSI APIs: watchdog,
hardware monitor, brightness control, programmable GPIO, backlight On/Off;
Utilities: BIOS flash, eSOS, system monitoring, Flash Lock, software protection)
1.3 Specifications
1.3.1 System
CPU: Soldered-down (BGA type) Intel Atom 1.66GHz D510 dual-core CPU or
1.66GHz N450 fanless CPU
L2 Cache: CPU built-in 512 KB / 1 MB L2 cache
BIOS: AMI Flash BIOS
System Chipset: Intel®ICH8M
SATA/EIDE hard disk drive interface: Supports up to 3 independent Serial
ATA hard drives (up to 300 MB/s) as well as one IDE port (maximum 2 devices)
Floppy disk drive interface: Supports up to two floppy disk drives, 51/4(360
KB and 1.2 MB) and/or 31/2(720 KB, 1.44 MB). BIOS enabled/disabled.
1.3.2 Memory
RAM:
–N SKU: 1GB on-board DDR2 667 MHz memory
–D SKU: Maximum 2 GB DDR2 667 MHz memory in SO-DIMM socket
Note! PCI-7031 is ONLY compatible with DDR2 memory modules that are
assembled with x16 (16-bit) memory chips and NOT compatible with
those that are assembled with x8 (8-bit) memory chips. Using wrong
memory modules may cause unexpected system instability.

PCI-7031 User Manual 4
1.3.3 Input/Output
Bus interface: PICMG®1.0 compliant bus interface
PCI Bus: Four 32bit / 33 MHz PCI masters to backplane
Enhanced parallel port: Configurable to LPT1, LPT2, LPT3, or disabled. Stan-
dard DB-25 female connector provided. Supports EPP/SPP/ECP
Serial ports: Two RS-232 ports
Keyboard and PS/2 mouse connector: One 6-pin mini-DIN connector is
located on the mounting bracket for easy connection to a keyboard or PS/2
mouse. An on board keyboard pin header connector is also available
High Definition Audio: PCI-7031 can provide audio function with the optional
audio extension module PCA-AUDIO-HDA1E
USB ports: PCI-7031 supports up to 7 USB 2.0 ports with transmission rates up
to 480 Mbps
1.3.4 Graphic interface
Controller: Integrated graphic core of Embedded Gen3.5+ technology
VRAM: 224 MB shared system memory
Output Interfaces:
–VGA: Supports up to SXGA 1400 x 1050 @ 60Hz for Atom N450, up to 2048
x 1536 @ 60 Hz for Atom D510
–LVDS: Supports 18-bit single channel and up to WXGA 1366 x 768 or 1280 x
800 for both Atom D510 and N450 CPUs
–Dual Display: CRT + LVDS, supports extended mode and clone mode
1.3.5 Ethernet LAN
Supports dual10/100/1000 Mbps Ethernet networking
Controller: LAN 1: Intel®82567V; LAN 2: Intel®82583V
1.3.6 Industrial features
Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second or one minute (255 levels). You
can find programming details in Appendix A
Fanless N450 CPU and on-board 1GB DDR2 memory for N SKU for ultra high
reliability and long MTBF
1.3.7 Mechanical and environmental specifications
Operating temperature: 0 ~ 60° C (32 ~ 140° F, depending on CPU)
Storage temperature: -20 ~ 70° C (-4 ~ 158° F)
Humidity: 20 ~ 95% non-condensing
Demanded Power supply voltage: +12 V, +5 V, +5 VSB
Power consumption:
–D SKU:
CPU: Dual-core Atom D510 CPU 1.66 GHz
Memory: 1 Piece of 2 GB DDR2 667 MHz SO-DIMM
Storage: One IDE HDD and one SATA CD ROM
Test program: BurnIn Test 6.0
+12 V: 0.228 A
+5 V: 2.952 A

5 PCI-7031 User Manual
Chapter 1 Hardware Configuration
+3.3 V: 0 A
+5 VSB: 0.06 A
-12 V: 0 A
-5 V: 0 A
Total Power Consumption: 17.796 W
–N SKU:
CPU: Single Core Atom N450 CPU 1.66 GHz
Memory: On-board 1GB DDR2 667 Memory
Storage: One IDE HDD and one SATA CD ROM
Test Program: BurnIn Test 6.0
+12 V: 0.192 A
+5 V: 2.532 A
+3.3 V: 0 A
+5 VSB: 0.060 A
-12 V: 0 A
-5 V: 0 A
Total Power Consumption: 15.264 W
Board size: 185 mm (L) x 122 mm (W) (7.3" x 4.8")
Board weight: 0.5 kg (1.2 lb)
1.4 Jumpers and Connectors
Connectors on the PCI-7031 single board computer link it to external devices such as
hard disk drives and a keyboard. In addition, the board has a number of jumpers
used to configure your system for your application.
Below, Tables 1.1 and 1.2 list the jumper and connector functions. Later sections in
this chapter give instructions on setting jumpers. Chapter 2 gives instructions for con-
necting external devices to your single board computer.
Table 1.1: Jumper descriptions
Label Function
CMOS1 CMOS Clear
JWDT1 Watchdog timer output option
Table 1.2: Connector descriptions
Label Function
IDE1 Primary IDE connector
FDD1 Floppy drive connector
LPT1 Parallel port
VGA1 VGA connector
LVDS1 LVDS Pin-header
COM12 Serial port 1~2 (2.00 pitch box header)
KBMS1 PS/2 keyboard and mouse connector
KBMS2 External keyboard/mouse pin header
JIR1 Infrared port pin header
CPUFAN1 3-pin Atom D510 CPU fan connector

PCI-7031 User Manual 6
SYSFAN1 3-pin System fan connector
JFP1 Power and Reset Button connector
LAN12 Dual Giga LAN RJ45 connector with Transformer
HDAUD1 High Definition Audio interface connector
SATA1 Serial ATA1
SATA2 Serial ATA2
SATA3 Serial ATA3
USB 12 USB port 1 and port 2 pin-header
USB 34 USB port 3 and port 4 pin-header
USB 56 USB port 5 and port 6 pin-header
USB8 The 7th USB port on rear bracket
LANLED1 LAN1 and LAN2 LED connector
GPIO1 GPIO header
Note! USB7 is reserved and can not be used.
Table 1.2: Connector descriptions

7 PCI-7031 User Manual
Chapter 1 Hardware Configuration
1.5 Board Layout: Jumper and Connector
Locations
Figure 1.1 Board Layout
SATA1~3
(300MB/Sec)
FDD1
COM12
COMLED1
VGA1
JIR1
JWDT1
JACSE1
SYSFAN1
LAN12
USB8
KBMS1
KBMS2
USB1~6
Note: USB7 is reserved
and can NOT be used. LANLED1 GPIO1 LVDS1 HDAUD1 ATXF1
CPUFAN1
VP1
J1
JFP1
Intel Atom
D510/N450 CPU
On-board 1GB
DDR2 667 Memory
(Only on N SKU)
Intel ICH8
I/O Control Hub
IDE1LPT1
DIMMA1
(Only on D SKU)
CMOS1
ATX1
CF1
LPC1
On-board 1GB
DDR2 667 Memory
(Only on N SKU)

PCI-7031 User Manual 8
1.6 PCI-7031 Block Diagram
Figure 1.2 Block Diagram
1.7 Safety Precautions
Atom D510
Atom N450
CPU
2GB SODIMM DDR2 667
512MB On-board DDR2 667
CRT
LVDS
LVDS
VGA
ICH8M
3SATA
7USB
Ports
CFC
ALC 888 Codec
PCA-AUDIO-HDA1E
(Optional)
BIOS
HDAudio
IDE IDE
300MB/s
USB 2.0
SPI
G-LAN2 :
Intel 82583V
Super IO
W83627DHG
LPCBus
2COM
To Backplane
(Connector A)
PS2 LPTFDD
G-LAN1 :
Intel 82567V
X4 DMI
Optional
Extension
Module
Single Channel
PCI-Express x 1
PCI-Express x 1
Four 32-bit/33-MHz
PCI Masters
4 RS-485 withAuto
Flow Control
PCA-COM485-00A1E
Warning! Always completely disconnect the power cord from your chassis when-
ever you work with the hardware. Do not make connections while the
power is on. Sensitive electronic components can be damaged by sud-
den power surges. Only experienced electronics personnel should open
the PC chassis.
Caution! Always ground yourself to remove any static charge before touching the
single board computer. Modern electronic devices are very sensitive to
electrostatic discharges. As a safety precaution, use a grounding wrist
strap at all times. Place all electronic components on a static-dissipative
surface or in a static-shielded bag when they are not in the chassis.
Caution! The computer is provided with a battery-powered real-time clock circuit.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended by the manufacturer.
Discard used batteries according to manufacturer's instructions.
Note! Before installing your PCI-7031 into a chassis, make sure that no com-
ponents on either side of the CPU card can touch any metal parts, espe-
cially the chassis wall and add-on card in the adjacent slot.
