Advantech PCM-9388 Installation and operation manual

PCM-9388 Startup Manual 1
Before installation, please make sure that you have received
the following:
1 PCM-9388 SBC
1 Startup Manual
1 Utility CD
1 Mini jumper pack p/n: 9689000002
1 Audio cable p/n: 1703100152
1 IDE 44 pin connector p/n: 1701440504
1 USB 2 port cable p/n: 1703100121
1 Parallel port cable p/n: 1700260250
1 Keyboard/Mouse cable p/n: 1700060202
1 Second serial port cable p/n: 1701140201
If anything is missing or damaged, contact your distributor
or sales representative immediately.
Note1: For detailed contents or the PCM-9388, please
refer to the enclosed CD Disc (in PDF format).
Note2: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/reader-
step2.html (Acrobat is a trademark of Adobe).
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
PCM-9388 Celeron® M 3.5” SBC with PC/104, VGA/
TTL/LVDS Ethernet/USB 2.0 and SSD
Startup Manual
Standard PC functions
CPU:
-Embedded Intel ULV Celeron M 600 MHz
(512 K L2 cache)
-Embedded Intel ULV Celeron M 1.0 GHz
(0 K L2 cache )
System Memory: 1 x SODIMM socket, supports Double
Data Rate (DDR) 128 MB to 1 GB, DDR 200/266 DRAM
2nd Cache Memory: Depends on CPU type from 0 to
512 KB
System Chipset: Intel 852GM GMCH/ICH4 chipset
BIOS: Award 4-Mbit Flash BIOS
Watchdog Timer: 255 level timer interval
Expansion Interface: PC/104
Battery: Lithium 3 V/210 mAH
Enhanced IDE interface: One channel supports up to
two EIDE devices. BIOS auto-detect, PIO Mode 3 or
Mode 4, supports UDMA 33 mode
Serial ports: Two serial RS-232 ports, COM1: RS-232,
COM2: RS-232/422/485
Parallel port: One parallel port, supports SPP/EPP/ECP-
mode, shared with FDD
Keyboard/mouse connector: Supports one standard
PC/AT keyboard and a PS/2 mouse
Audio: Supports AC97 Audio stereo sound
USB: Two USB 2.0 compliant universal serial bus ports
IrDA: 115Kbps, SIR, IrDA 1.0 complaint (optional)
GPIO: 8-bit general purpose Input/Output
Solid State Disk
Supports one 50-pin socket for CFC type I
VGA/LVDS Interface
Chipset: Intel 852GM GMCH
Memory Size: Optimized Shared Memory Architecture,
supports up to 64 MB frame buffer using system memory
Resolution:
-CRT display Mode: pixel resolution up to 1600 x 1200
@85 Hz; up to 1920 x 1440 @ 60 Hz
-LVDS display mode: up to UXGA panel resolution with
frequency range from 25 MHz to 112 MHz
TTL LCD: supports 18-bit TTL LCD
LVDS LCD: supports 2 channel (2 x18-bit) LVDS LCD
Panel (2 x 24-bit optional)
Dual Independent Display:
-CRT + LVDS
-CRT + TTL
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support/
This manual is for the PCM-9388 Series Rev. A2.
Part No. 2006938803
Printed in China
4th Edition,
April 2009

2 PCM-9388 Startup Manual
Specications (cont.)
Ethernet Interface
Chipset supports: 10/100 Mbps - Realtek RTL8100CL
(With Wake on LAN)
Ethernet interface: IEEE 802.3u (100 BASE-T) protocol
compatible
Built-in boot ROM
Temperature: 0 ~ 40° C (32 ~ 104° F)
Audio Function
Chipset: Intel(r) 82801DB I/O Controller Hub 4 (ICH4)
and ALC203 codec
Audio controller: Supports AC97 3D Audio stereo sound
Audio interface: line in, line out, Microphone in
Mechanical Environment
Dimensions: 145 x 102 mm (5.9” x 4.2”)
Mechanical Drawing (dxf file) is available.
Power Supply Type: AT/ATX
Power Requirement: +5 V ±5%, +12 V ±5% (Optional), 5
V standby for ATX mode, or supports single +5 V only
Power Consumption: ULV Celeron M 600 MHz@ 256
MB DDR 266 Max (HCT): +5 V@ 2.21 A, +12 V@ 0.17 A
Operating Temperature: 0 ~ 60° C (32 ~ 140° F)
Weight: 0.85 kg (reference weight of total package)
Jumpers and Connectors
The board has a number of jumpers that allow you to
configure your system to suit your application.
The table below lists the function of each of the jumpers and
connectors.
Jumpers
Label Function
J1
AT/ATX selector
J2 Audio power selector
J3/J5/J4 COM2
J6 LCD power selector
•
•
•
•
•
•
•
•
•
•
•
•
•
Connectors
Label Function
CN1 AT power connector
CN2 ATX POWER Standby Connector
CN3 SMBus
CN4 FAN Connector (SPEED Detect)
CN5 ATX Power Button Connector
CN6 GPIO
CN7 AUDIO Connector
CN8 IDE Connector
CN9 CompactFlash
CN10 HDD & PWR LED
CN11 VGA
CN12 COM1
CN13 LPT Connector
CN14 IR Connector
CN15 COM2 RS-232/RS-422/RS-485 Connector
CN16 USB Connector
CN17 PS2 (KB & MS)
CN19 LAN Connector
CN20 PC/104 SOLDER Connector
CN21 Negative POWER Input
CN22* LVDS LCD 40-Pin HIROSE
CN23 Invert Power Connector
CN24* TTL LCD 40-Pin HIROSE
*Note: Please do not put more than 15 kg pressure on
top of the LVDS connector during the LVDS cable as-
sembly with PCM-9388.
J1 AT/ATX selector
Description PIN HEADER 2*1P 180D (M) SQUARE
2.0 mm DIP W/O Pb
Setting Function
(1-2) AT Power
none ATX Power
1 21 2
1 2

PCM-9388 Startup Manual 3
J2 Audio Power Source
Description PIN HEADER 3*1P 180D (M) SQUARE
2.0 mm
Setting Function
1-2 (*) Audio Power from 12 V-input & 5 V-
output LDO
2-3 Audio Power from 5 V
*: Default
123
J3/J4/J5 COM2 Setting (RS-232 Default)
Description PIN HEADER 2*1P 180D (M) SQUARE
2.0 mm
Setting Function
J3(1-2) RS-422
J4(1-2) RS-485
J5(1-2) RS-232
J6 LCD Power
Pin Signal
1-2 +5 V
2-3 (*) +3.3 V
*: Default
123
123
1 2 3

4 PCM-9388 Startup Manual
Figure 1: PCM-9388 Layout (Component Side)
Figure 2: PCM-9388 Layout (Solder Side)

PCM-9388 Startup Manual 5
Figure 3: PCM-9388 Mechanical Drawing (Component Side)
Figure 4: PCM-9388 Mechanical Drawing (Solder Side)
