Product Overview
About Power
Redundant power inputs accept 44-57 VDC.
Power consumption is 255 W.
If redundancy is desired, you may connect two separate
power supplies by using the two DC inputs on the terminal
blocks.
About the Ports
The RJ-45 ports auto-negotiate for
10/100/1000Mbps device connections. The
Auto Cross feature allows connections to switches,
workstations, and other equipment without changing
straight through or crossover cabling.
PoE+ Ports
The PoE+ ports on this switch follow Alternative A standards
and support up to 30 Watts of power output per port.
Ports 1 thru 8 support the IEEE802.3at standard and are
classified as PSE power sourcing equipment, which means
they can be used to power (PD) powered devices.
LED Status
LEDS
RJ-45 Ports
SFP Ports
10/100/1000
Copper
POE+ Ports PoE Reset Function
Power
SFP Ports
POE ON/OFF RESET : To reset/disable PoE, set DIP
switch #1 to ON. (The default setting is OFF.)
POE AUTO RESET : To enable/disable the PoE auto
reset function, set DIP switch #2 to ON. (The default
setting is OFF.)
When Auto RESET is ON, the PoE function will shut
down if both SFP ports lose link, to save power.
The SFP ports support 1000 Mbps Single-mode or
Multi-mode Fiber SFP’s and 1000Mbps copper SFP’s
as long as they are MSA-compliant.
Device Discovery
When the network cables are attached and power
is applied, installation is complete. The switch will
automatically discover network devices, populate
its MAC address table, and pass traffic to the
appropriate ports.
Frame or
Earth Ground
LED Status Description
FAULT
Green
On Relay Closed
Green
Off Relay Open
STA
Green
Flashing System ON
Green
On/Off System down
PWR
(P1, P2)
Green
On Power Applied
Green
Off No Power
10/100
/1000
Copper
SPD LED
Green
On 1000 Mbps
Orange
On 100 Mbps
LED Off 10Mbps
10/100
/1000
Copper
LNK LED
Green
On Link
Green
Flashing Activity
Green
Off Not connected to network
SFP LED
Green
On Link
Green
Flashing Activity
Green
Off Not connected to network
PoE+
Green
On PWR Supplied
Green
Flashing
Port overload/short circuit
or fail at startup
Green
Off PWR Not Supplied
1
2
5
3
4

Troubleshooting
Verify that you are using 44-57 VDC for power.
Applying more than 57 VDC could cause damage to
the switch.
The switch can be monitored through the LED
indicators on the front panel of the switch. The LEDs
can help identify common problems.
If the power indicators do not light up when power is
applied you may have a problem with the power
supply. Check for loose power connections, power
losses or surges at the power outlet.
If the switch LEDs display normal operating mode,
the cable connections are correct ,and no data
is transmitted or received through the switch. Contact
your Network Administrator for network
configuration and status help. The product is a
transparent, unmanaged switch.
Doc number – 710-10454-00_R1_ESWGP510-2SFP-T_4915qsg
Recommended Accessories
and Power Supplies
Power Supply
SDR-240-48
Ethernet Cables
1-888-948-2248 | Europe: [phone]
www.advantech-bb.com
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: [phone] | Fax: [phone]
www.advantech-bb.com | E-mail: [e-mail]
ESWGP510-2SFP-T
DIN rail and panel mount brackets
Console cable
Required but not included:
Power supply
Before you begin, be sure you have
the following:
First Things First...
ESWGP510-2SFP-T
PoE+ Ethernet Switch
Fast and easy on the web: www.advantech-bb.com
http://www.advantech-bb.com/
Products/Power-Supplies-Accessories/
DIN-Power-Supplies.aspx
Fast, Easy Answers
• First, check LEDs.
• Then use your smart
phone to access complete
documentation on our
web site. Simply scan
the code to the right.
Set your PC’s IP address to 192.168.118.X
(X is any value from 2 to 254 except 100)
Subnet Mask: 255.255.255.0
Gateway: 192.168.118.1.
Open your web browser and enter the switch’s default
IP address.
Switch Default IP address: 192.168.118.100
Switch Username: admin
Switch Password: admin
Detailed information about switch configuration via Telnet
and the web interface can be found in the User Manual on
the B+B website:
http://www.advantech-bb.com.
Telnet configuration is allowed for:
Username: admin
Password: admin
5Log Into the Switch
