Advantech ICR-2000 Guide

Start Guide
ICR-2000, ICR-2400, ICR-2500,
ICR-2600

Start Guide
Safety Instructions
Please take care to following instructions:
•Use the router in compliance with national and international law and compliance with any
special or additional restrictions regulating the use of the router in various applications
and environments.
•To avoid possible injury and/or damage to the device, observe the relevant provisions
and standards. Use only the original accessories as recommended. Unauthorized de-
vice or accessory modification or using accessories that have not been approved can
result in router damage and/or violation of the regulations.
•Unauthorized device or accessory modification or using accessories that have not been
approved can result in warranty termination.
•Do not open the router.
•Caution! Small children can swallow the SIM card.
•When connecting the device to a power supply, do not exceed the defined voltage.
•Do not expose the router to extreme ambient conditions. Protect the router against dust,
moisture, and high temperature.
•It is recommended that you do not use the router at petrol filling stations. We recommend
observing local restrictions concerning radio-based devices while working with explosive
material, such as petrol filling stations or in chemical plants.
•While using the router close to personal medical devices, such as cardiac pacemakers
or hearing aids, proceed with heightened caution.
•Operating the router too close to TV sets, radio receivers, personal computers, or tele-
phones can cause interference.
•It is recommended that you create a copy or backup of the basic settings stored in the
router’s memory.
QSG-0011-EN, October 5, 2022 1Released in the Czech Republic

Start Guide
Product Disposal Instructions
The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) di-
rective was introduced to ensure that electrical/electronic products are recycled
using the best available recovery techniques to minimize the environmental im-
pact. This product contains high-quality materials and components which can
be recycled. At the end of its life, this product MUST NOT be mixed with other
commercial waste for disposal. The device contains a battery. Remove the bat-
tery from the device before disposal. The battery in the device needs to be disposed of apart
accordingly. Check the terms and conditions of your supplier for disposal information.
Open Source Software License
The software in this device uses various pieces of open-source software governed by the
following licenses:
•GPL versions 2 and 3
•LGPL version 2
•BSD-style licenses
•MIT-style licenses
The list of components, together with complete license texts, can be found on the device
itself. See the Licenses link at the bottom of the router’s main Web page (General Status)
or point your browser to this address (replace the DEVICE_IP string with the real router’s IP
address):
https://DEVICE_IP/licenses.cgi
This is a written offer valid for three years since the device purchase, offering any third party
for a charge no more than the cost of physically performing source distribution, a complete
machine-readable copy of the corresponding source code on a flash drive medium. If you are
interested in obtaining the source, please get in touch with us at:
[email protected]
Modifications and debugging of LGPL-linked executables:
The device manufacturer with this grants the right to use debugging techniques (e.g., de-
compilation) and make customer modifications of any executable linked with an LGPL library
for its purposes. Note these rights are limited to the customer’s usage. No further distribution
of such modified executables and no transmission of the information obtained during these
actions may be done.
QSG-0011-EN, October 5, 2022 2Released in the Czech Republic

Start Guide
First Use
Before applying power to the router, connect all the components you need for your appli-
cations.
Do not run the router without an antenna connected to the main antenna connector. The
energy from the transmission is effectively reflected by the open end and can damage
the equipment.
1. Antenna
Use SMA connectors to connect the antennas to the router; see the figure below. First,
connect the main antenna to the ANT connector. Next, connect the second diversity antenna
to the DIV connector to improve the quality and reliability of a wireless link.
Note: Router ICR-2412 has just one antenna connector.
QSG-0011-EN, October 5, 2022 3Released in the Czech Republic

Start Guide
2. SIM Card
The SIM card reader for one or two, depending on the product type, Micro SIM cards (3FF
with the size of 15.0 x 12.0 x 0.76 mm) is located on the router’s right panel under a metal
cover. If you intend to use this device to communicate over a cellular network, please place
an activated data-provisioned SIM card into the SIM card reader. Push your SIM card into the
SIM slot until it clicks into place.
You can install two SIM cards simultaneously to utilize the SIM card switching feature.
Disconnect the router from the power supply before handling the SIM card.
QSG-0011-EN, October 5, 2022 4Released in the Czech Republic

Start Guide
3. Power
The router requires an external DC power supply. The DC voltage required is between
+9 and +48 V DC. The router has built-in protection against reverse polarity without signaling.
Connect the power supply cable to the PWR connector on the left panel of the router (see the
figure below) and tighten the locking screws.
4. Ethernet
For an initial configuration made in a web browser, connect a PC by an Ethernet cable to
the default LAN interface, use the ETH0 port; see the figure above. By default, this interface
has the following configuration:
Connector Purpose Default Setting
ETH0 LAN port (default)
Connect your PC to this port to get the
router web interface.
DHCP Server
IP Address: 192.168.1.1
NetMask: 255.255.255.0
QSG-0011-EN, October 5, 2022 5Released in the Czech Republic

Start Guide
Configuration
1. Configuring the Device Using the Web Browser
You can use a web browser running on your PC to access the router web interface. Here
you can perform router monitoring, configuration, and administration. First, connect the PC to
the default LAN interface described in the Ethernet chapter. To get the router interface, enter
the https://192.168.1.1 address in a web browser. Please note that usage of the HTTPS
protocol for secure communication over the network is required.
There is just the root user account created on the router by default. See the product label
on the router for its default password. Log in to the web interface by the root user and his
password. See the configuration manual of the router for a detailed description and examples
of the router configuration.
After logging on to the device for the first time, we strongly recommend changing the
default password due to security reasons.
For security reasons, we highly recommend updating the router’s firmware to the latest
version regularly. Downgrading the firmware to an older version than the production
version or uploading firmware intended for a different device may cause the device’s
malfunction.
2. Configuration Settings via WebAccess/DMP
Your router has been pre-installed with the WebAccess/DMP client, which has activated
the connection to the WebAccess/DMP server by default. You can disable this connection on
the Welcome page when logging into the router’s web interface or on the (Customization ->
Router Apps -> WebAccess/DMP Client) configuration page. For more information see the
configuration manual of your router, chapter Basic Information -> WebAccess/DMP Configu-
ration.
The activated client periodically uploads router identifiers and configuration to the Web-
Access/DMP server.
QSG-0011-EN, October 5, 2022 6Released in the Czech Republic

Start Guide
3. Restoring and Backing up the Router Configuration
The default factory settings will replace the current configuration if you reset the router.
Therefore, we recommend you back up the router configuration before resetting the device.
Refer to the configuration manual for more information.
You can restore the default router configuration once the router boots up and the PWR
LED starts blinking. To do so, press the reset

button on the router’s front panel for more
than 4 seconds. After you press this button, all settings reset to the default values, and the
router will reboot.
Support
All product-related manuals, documents, and software can be found and downloaded on
the website at icr.advantech.cz/download address.
We, Advantech Czech s.r.o., declare that the radio equipment type ICR-
2031,ICR-2412,ICR-2431,ICR-2432,ICR-2436,ICR-2437,ICR-2531 and ICR-
2631 comply with Directive Radio Equipment Regulations 2017 (S.I. 2017 No.
1206).
We, Advantech Czech s.r.o., declare that the radio equipment type ICR-2031,ICR-
2412,ICR-2431,ICR-2432,ICR-2436,ICR-2437,ICR-2531 and ICR-2631 comply
with Directive 2014/53/EU.
The full text of the EU Declaration of Conformity is available at the following internet address:
icr.advantech.cz/eudoc
QSG-0011-EN, October 5, 2022 7Released in the Czech Republic
