PCA-5650 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 PCA-5650 Dual VGA Output Mini PCI Express Graphic
Card
• 1 PCA-5650 Start up Manual
• 1 CD with driver
• 1 Dual VGA cable kit P/N:1700018579
• Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Standard Functions
•GPU: Silicon Motion SM750
•Bus: PCI Express x1 500 MB
•Memory: 32 bit, 166 MHz, 16 MB DDR SDRAM
•CRT1/CRT2 output: supports display resolution up to
1920 x 1080 and supports vertical refresh rate up to 75
Hz
•Dual display mode: CRT+CRT, supports single, clone
and dual mode
•O.S. support: Windows 7, Windows XP, Windows Server
2003, Windows Server 2008
Mechanical
•Dimensions: 64.3 mm x 67.3 mm
PCA-5650 Dual VGA Output Mini PCI Express
Graphic Card for Multimedia Applications
Startup Manual
Connectors
Label Function
VGA1/VGA2 12 pin VGA connector by pin header
VGA1/VGA2
Pin Signal Pin Signal
1 GND 2 CRT_R
3 CRT_G 4 CRT_B
5 GND 6 N/A
7 CRT_SDA 8 CRT_SCL
9 GND 10 CRTHS
11 CRTVS 12 GND
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit
our support website at:
http://www.advantech.com.tw/support
This manual is for the PCA-5650 series.
Part No. 2002565000
Printed in China
1st Edition
April 2011
Specications
Connectors
VGA2 VGA1

2 PCA-5650 Startup Manual
The CD disc contains a driver installer program that will lead
you through the installation of various device drivers needed
to take full advantage of your CPU card.
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions.
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion.
1. Please connect the VGA1 and VGA2 connector on Mini
PCI Express VGA card with VGA cable.
2. Please connect Mini PCI Express card to connector of
host CPU board as shown below.
3. Push Mini PCI Express VGA card into the connector lock
as shown below.
Board Dimensions
Installation Guide
Software Installation
Safety Information
