Advantech PCI-1737U User manual

PCI-1737U/1739U
24/48 Channel Digital
I/O Output Card
User Manual

PCI-1737U/PCI-1739U User Manual ii
Copyright
The documentation and the software included with this product are copy-
righted 2005 by Advantech Co., Ltd. All rights are reserved. Advantech
Co., Ltd. reserves the right to make improvements in the products
described in this manual at any time without notice. No part of this man-
ual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reli-
able. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result
from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of
Microsoft Corp.
All other product names or trademarks are properties of their respective
owners.
Part No. 2003173700 1st Edition
Printed in Taiwan April 2006

iii
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its prod-
ucts will be free from defects in materials and workmanship for two years
from the date of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper instal-
lation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous test-
ing, most of our customers never need to use our repair service. If an
Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will
be billed according to the cost of replacement materials, service time and
freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any
onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your man-
ual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows
us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for war-
ranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

PCI-1737U/PCI-1739U User Manual iv
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications
when shielded cables are used for external wiring. We recommend the use
of shielded cables. This kind of cable is available from Advantech. Please
contact your local supplier for ordering information.
CE
This product has passed the CE test for environmental specifications. Test
conditions for passing included the equipment being operated within an
industrial enclosure. In order to protect the product from being damaged
by ESD (Electrostatic Discharge) and EMI leakage, we strongly recom-
mend the use of CE-compliant industrial enclosure products.
FCC Class A
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful inter-
ference in which case the user will be required to correct the interference
at his own expense.

v
FCC Class B
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FM
The PCI-1737U/PCI-1739U has passed the FM certification. According
to the National Fire Protection Association, work sites are classified into
different classes, divisions and groups, based on hazard considerations.
PCI-1737U/PCI-1739U is compliant with the specifications of Class I,
Division 2, Groups A, B, C and D indoor hazards.
Technical Support and Assistance
Step 1. Visit the Advantech web site at www.advantech.com/support
where you can find the latest information about the product.
Step 2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional
assistance. Please have the following information ready before
you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (operating system, version, appli-
cation software, etc.)
- A complete description of the problem
- The exact wording of any error messages

PCI-1737U/PCI-1739U User Manual vi
Packing List
Before setting up the system, check that the items listed below are
included and in good condition. If any item does not accord with the
table, please contact your dealer immediately.
• PCI-1737U/PCI-1739U card
• Companion CD-ROM (Device Drivers included)
• This User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning.
Use a damp cloth. Do not use liquid or spray detergents for clean-
ing.
4. For plug-in equipment, the power outlet socket must be located
near the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Drop-
ping it or letting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before con-
necting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or elec-
trical shock.
13. Never open the equipment. For safety reasons, the equipment
should be opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked
by service personnel:
a. The power cord or plug is damaged.

vii
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work
according to the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
The sound pressure level at the operator's position according to IEC 704-
1:1982 is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1.
Advantech disclaims all responsibility for the accuracy of any statements
contained herein.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the
products from damage.
1. To avoid electrical shock, always disconnect the power from your
PC chassis before you work on it. Don't touch any components on
the CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The
sudden rush of power as you connect a jumper or install a card may
damage sensitive electronic components.
NOTE: Do not leave this equipment in an environment
where the storage temperature may go below
-20° C (-4° F) or above 60° C (140° F). This could
damage the equipment. The equipment should be
in a controlled environment.
CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equiva-
lent type recommended by the manufacturer, dis-
card used batteries according to the
manufacturer’s instructions.

PCI-1737U/PCI-1739U User Manual viii

ix Table of Contents
Contents
Chapter 1 General Information ...................................... 2
1.1 Features ............................................................................ 2
1.2 Applications ..................................................................... 3
1.3 Installation Guide .............................................................. 3
Figure 1.1:Installation Flow Chart ................................. 4
1.4 Software Overview............................................................ 5
1.5 Device Driver Programming Roadmap............................. 6
1.5.1 Programming Tools ....................................................... 6
1.5.2 Programming with Device Drivers Function Library .... 7
1.5.3 Troubleshooting Device Drivers Error .......................... 7
1.6 Accessories........................................................................ 7
Chapter 2 Installation ..................................................... 10
2.1 Unpacking ....................................................................... 10
2.2 Driver Installation ........................................................... 11
Figure 2.1: Advantech Automation Software Setup .... 12
Figure 2.2:Different Options for Driver Setup ............ 12
2.3 Hardware Installation ...................................................... 13
2.4 Device Configuration ...................................................... 14
Figure 2.3:The Device Manager Dialog Box ............... 14
Figure 2.4:The Device Setting Dialog Box ................. 15
Figure 2.5:Digital Input Test Utility ............................ 15
Chapter 3 Signal Connections ........................................ 18
Figure 3.1:PCI-1737U Board Layout .......................... 18
Figure 3.2:PCI-1739U Board Layout .......................... 19
3.1 Switch and Jumper Settings ............................................ 19
3.1.1 Port Status Setting ........................................................ 20
Table 3.1:Port Status Setting ....................................... 20
3.1.2 Output Status Setting ................................................... 20
Table 3.2:Output Status Setting ................................... 20
3.1.3 BoardID Setting ........................................................... 21
Table 3.3:BoardID Setting ........................................... 21
3.2 Signal Connections.......................................................... 21
3.2.1 Pin Assignment For PCI-1737U .................................. 21
Figure 3.3:Connector 1 ................................................ 22
Figure 3.4:Connector 2 & 3 (Optional) ....................... 23
3.2.2 I/O Connector Signal Description For PCI-1737U ...... 23
Table 3.4:I/O Connection signal Description .............. 23
3.2.3 Pin Assignment For PCI-1739U .................................. 24
Figure 3.5:PCI-1739U Pin Assignments ..................... 24
3.2.4 I/O Connector Signal Description For PCI-1737U ...... 24
Table 3.5:I/O Connection signal Description .............. 24
Chapter 4 Operation ....................................................... 26

MIC-3780 User Manual x
4.1 Configuration ................................................................. 26
4.2 8255 Mode 0 Function Definitions ................................ 26
4.2.1 Interrupt Function of the DIO Signals ......................... 27
4.2.2 Input/Output Control .................................................... 27
Table 4.1:Bit map of port configuration register ......... 27
4.2.3 Initial Configuration .................................................... 28
4.3 Interrupt Handling .......................................................... 28
4.3.1 IRQ Level .................................................................... 28
4.3.2 Interrupt Control Register (Base + 8) .......................... 28
Table 4.2:Interrupt control register bit map ................. 28
4.3.3 Interrupt Source Control .............................................. 29
Table 4.3:Interrupt mode bit values ............................. 29
4.3.4 Interrupt Triggering Edge Control ............................... 29
Table 4.4:Triggering edge control bit values ............... 29
4.3.5 Interrupt Flag Bit ......................................................... 30
Table 4.5: Interrupt flag bit values ............................... 30
Appendix A Specifications ................................................. 32
A.1 PCI-1737U ...................................................................... 32
A.2 PCI-1739U ...................................................................... 33
Appendix B Function Block............................................... 36
Figure B.1:PCI-1737U ................................................. 36
Figure B.2:PCI-1739U ................................................. 36

2
CHAPTER
1
General Information
Sections include:
• Features
• Applications
• Installation Guide
• Software Overview
• Device Driver Programming Roadmap
• Accessories

PCI-1737U/PCI-1739U User Manual 2
Chapter 1 General Information
The PCI-1737U/PCI-1739U is a 24/48-bit DI/O card with PCI bus. It pro-
vides you with 24/48 bits of parallel digital input/output. It emulates
mode 0 of the 8255 PPI chip, but the buffered circuits offer a higher driv-
ing capability than the 8255. The I/O bits are divided into three 8-bit I/O
ports: A0, B0, and C0.( Six for PCI-1739U, A0, A1, B0, B1, C0, C1) You
can configure each port as either input or output via software.
The interrupt handling capability provides users the flexibility to generate
interrupt to a PC. One pin in the connector can output a digital signal
simultaneously with the card's generating an interrupt. (Two pin for PCI-
1739U)
The other features give the PCI-1737U/PCI-1739U practical advantages
in an industrial setting. When the system is hot reset or power on, the I/O
port settings and output values of PCI-1737U/PCI-1739U will be deter-
mined by switch.
1.1 Features
• Function Compatible with PCL-724/731 (24/48 TTL digital I/O lines)
• Emulates mode 0 of 8255 PPI
• Buffered circuits provide higher driving capability
• Output status readback
• Programmable interrupt handling
• Pin compatible with Opto-22 I/O module racks
• PCI universal card (both 3.3V and 5V signaling)

3 Chapter1
1.2 Applications
• Industrial AC/DC I/O module monitoring and control
• Relay and switch monitoring and control
• Parallel data transfer
• Sensing the signals of TTL, DTL, CMOS logic
• Driving indicator LED's
1.3 Installation Guide
Before you install your PCI-1737U/PCI-1739U card, please make sure
you have the following necessary components:
• PCI-1737U/PCI-1739U DA&C card
• PCI-1737U/PCI-1739U User Manual
• Driver software Advantech DLL drivers (included in the companion
CD-ROM)
• Personal computer or workstation with a PCI-bus slot (running Win-
dows 2000/XP)
Please refer to Section 1.6 for the relevant wring boards and cables.
Some other optional components are also available for enhanced opera-
tion: ActiveDAQ, ActiveDAQ Pro, LabView or other 3rd-party software
packages
After you get the necessary components and maybe some of the accesso-
ries for enhanced operation of your multifunction card, you can then
begin the installation procedure. Figure 1.1 on the next page provides a
concise flow chart to give users a broad picture of the software and hard-
ware installation procedures:

PCI-1737U/PCI-1739U User Manual 4
Figure 1.1: Installation Flow Chart

5 Chapter1
1.4 Software Overview
Advantech offers a rich set of DLL drivers, third-party driver support and
application software to help fully exploit the functions of your PCI-
1737U/PCI-1739U card:
• Device Drivers (on the companion CD-ROM)
• LabVIEW driver
• Advantech ActiveDAQ
• Advantech ADAQView
Programming choices for DA&C cards
You may use Advantech application software such as Advantech Device
Drivers. On the other hand, advanced users can use register-level pro-
gramming, although this is not recommended due to its laborious and
time-consuming nature.
Device Drivers
Advantech Device Driver software is included on the companion
CDROM at no extra charge. It also comes with all Advantech DA&C
cards. Advantech’s Device Drivers features a complete I/O function
library to help boost your application performance. Advantech Device
Drivers for Windows 2000/XP works seamlessly with development tools
such as Visual C++, Visual Basic, Borland C++ Builder and Borland Del-
phi.
Register-level Programming
Register-level programming is available for experienced programmers
who find it necessary to write code directly at the level of the device reg-
ister. Since register-level programming requires much effort and time, we
recommend that you use the Advantech Device Drivers instead. How-
ever, if register-level programming is indispensable, you should refer to
the relevant information in Chapter 4, Register Structure and Format, or
to the example codes included on the companion CD-ROM.

PCI-1737U/PCI-1739U User Manual 6
1.5 Device Driver Programming Roadmap
This section will provide a roadmap to demonstrate how to build an appli-
cation from scratch using Advantech Device Drivers with your favorite
development tools such as Visual C++, Visual Basic, Delphi, or C++
Builder. The step-by-step instructions on how to build your own applica-
tions using each development tool will be given in the Device Drivers
Manual. Moreover, a rich set of example source code is also given for
your reference.
1.5.1 Programming Tools
Programmers can develop application programs with the following devel-
opment tools:
• Visual C++
• Visual Basic
• Delphi
• C++ Builder
For instructions on how to begin programming in each development tool,
Advantech offers a Tutorial Chapter in the Device Drivers Manual for
your reference. Please refer to the corresponding sections in this chapter
on the Device Drivers Manual to begin your programming efforts. You
can also look at the example source code provided for each programming
tool, since they can get you very well oriented.
The Device Drivers Manual can be found on the companion CD-ROM.
Alternatively, if you have already installed the Device Drivers on your
system, The Device Drivers Manual can be readily accessed through the
Start button:
Start/Programs/Advantech Automation/Advantech Device Manager
/Device Driver’s Manual
The example source code can be found under the corresponding installa-
tion folder such as the default installation path:
\Program Files\Advantech\ADSAPI\Examples
For information about using other function groups or other development
tools, please refer to Creating Windows 2000/XP Applications with
Device Drivers chapter and the Function Overview chapter in the Device
Drivers Manual.

7 Chapter1
1.5.2 Programming with Device Drivers Function Library
Advantech Device Drivers offer a rich function library that can be utilized
in various application programs. This function library consists of numer-
ous APIs that support many development tools, such as Visual C++,
Visual Basic, Delphi and C++ Builder.
1.5.3 Troubleshooting Device Drivers Error
Driver functions will return a status code when they are called to perform
a certain task for the application. When a function returns a code that is
not zero, it means the function has failed to perform its designated func-
tion. To troubleshoot the Device Drivers error, you can pass the error
code to DRV_GetErrorMessage function to return the error message.
Alternatively, you can refer to the Device Drivers Error Codes Appendix
in the Device Drivers Manual for a detailed listing of Error Codes, Error
IDs and the Error Messages.
1.6 Accessories
Cable
PCL-10150-1.2 IDC-50 pin socket connector with flat cable, 1.2M
Wiring Board
PCLD-782B 24-channel Opto-isolated Digital Input Boards
The PCLD-782B digital input daughterboards feature high-voltage (1500
V DC ) optical isolation on all inputs. The PCLD-782B provides either 16
or 24 channels, depending on the connector you use. The PCLD-782B’s
20-pin connector lets you access 16 channels, similar to the PCLD-782.
The PCLD-782B also provides a 50-pin Opto-22 connector with access to
24 channels. Both cards have on-board screw terminals for easy input
wiring. Opticallyisolated signal conditioning provides isolation between
separate channels, as well as between each input channel and the PC. This
isolation prevents floating potential and ground loop problems while pro-
tecting the input lines from potentially damaging fault conditions. A red
LED on each input channel indicates its status. If the input signal is high,
the LED is on. You can configure each channel to work in either isolated
or non-isolated mode. A variable resistor adjusts the threshold level for
all 24 isolated input channels simultaneously.

PCI-1737U/PCI-1739U User Manual 8
PCLD-785B 16-channel Relay Output Boards
The PCLD-785B carry 16/24 SPDT electromechanical relays with a 20-
pin flat cable connector and an additional 50-pin Opto-22 connector (for
PCLD-785B only) compatible with the digital outputs of most I/O Cards.
The number of output channels available on the PCLD-785B depends on
the connector you use. The I/O card’s 50-pin connector accesses all 24
channels, while its 20-pin connector has access to 16 channels. The
PCLD-785B automatically selects the correct control logic for the con-
nector in use.
PCLD-885 16-channel Power Relay Output Board
The PCLD-885 provides 16 SPST power relay channels with a maximum
contact rating of 250 VAC @ 5 A or 30 VDC @ 5 A. The PCLD-885 can
be driven directly by the digital output from PC-LabCards through its 20-
pin box header or its 50-pin Opto-22 compatible connector.
ADAM-3950 50-pin Flat Cable Wiring Terminal for DIN-rail Mounting
The ADAM-3900 series consists of universal screw terminal modules
designed for field signal wiring in industrial applications. They can be
connected to the analog and digital ports of Advantech products such as
the PCL series.

2
CHAPTER
2
Installation
.Sections include:
• Unpacking
• Driver Installation
• Hardware Installation
• Device Configuration

PCI-1737U/PCI-1739U User Manual 10
Chapter 2 Installation
2.1 Unpacking
After receiving your PCI-1737U/PCI-1739U package, please inspect its
contents first. The package should contain the following items:
• PCI-1737U/PCI-1739U card
• Companion CD-ROM (Device Drivers included)
• User Manual
The PCI-1737U/PCI-1739U cards harbor certain electronic components
vulnerable to electrostatic discharge (ESD). ESD can easily damage the
integrated circuits and certain components if preventive measures are
ignored.
Before removing the card from the antistatic plastic bag, you should take
the following precautions to ward off possible ESD damage:
Touch the metal part of your computer chassis with your hand to dis-
charge the static electricity accumulated on your body. Alternatively, one
can also use a grounding strap.
Touch the anti-static bag to a metal part of your computer chassis before
opening the bag.
Take hold of the card only by the metal bracket when removing it out of
the bag.
After taking out the card, you should first:
Inspect the card for any possible signs of external damage (loose or dam-
aged components, etc.). If the card is visibly damaged, please notify our
service department or our local sales representative immediately. Do not
install a damaged card into your system.
Also, pay extra caution to the following aspects during installation:
Avoid physical contact with materials that could hold static electricity
such as plastic, vinyl and Styrofoam.
