PCA-5612 Startup Manual 1
PCA-5612 Industrial VGA Card with XGI Volari™ Z9s
Before you begin installing your card, please make
sure that the following materials have been shipped:
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/products/acrobat/readstep2.html
The CD disc contains a driver installer program that
will lead you through the installation of your VGA card.
The computer is provided with a battery-powered
Real-time Clock circuit. There is a danger of explo-
sion if battery is incorrectly replaced. The battery
doesn’t need to be charged. Replace only with same
or equivalent type recommended by the manufacturer.
Discard used batteries according to manufacturer's
instructions.
This device complies with the requirements in part 15
of the FCC rule. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference,
and
2. This device must accept any interference
received, including interference that may cause
undesired operation.
Industrial VGA card specifications
• GPU: XGI Volari™ Z9s
• Bus: PCI 2.2
• Memory: 16bit, 350MHz 32MB DDRII SDRAM
• CRT1 output: 1600 x 1200, up to 60Hz vertical rate
• DVI: Single Link TMDS up to UXGA
(1600x1200@60Hz)
• Dual Display Mode: CRT + DVI in windows XP/2K/
Linux, supporting mirror only, NOT supporting extension
mode.
• OS’s Supported: Microsoft® Windows XP/2K/Linux/
Unix/FreeBSD.
The VGA card has a number of connectors that allow you
to configure your system to suit your application.
• 1 PCA-5612 Industrial VGA
card
• 1 PCA-5612 Startup Manual
• 1 CD with driver utility
• Warranty certificate
Software Installation
Caution
FCC
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/network
For technical support and service, please visit our
support website at:
http://www.advantech.com.tw/support
This manual is for the PCA-5612 series Rev. A1.
Part No. 2002561210
Printed in Taiwan
1st Edition
May 2006
1. Connectors
Label Function
CON2 Reserve for SDVO module (SDVO module NOT
available yet)
CRT1 VGA port
VCN4 DVI port
CRT1 : VGA connector
Pin Signal Pin Signal
1RED 9VCC
2 GREEN 10 GND
3BLUE 11 N/C
4N/C 12SDT
5 GND 13 H-SYNC
6 GND 14 V-SYNC
7 GND 15 SCK
8GND
DVI1: DVI port
Pin Signal Pin Signal
1 TMDS2- 2 TMDS2+
3 TMDSSD 4 N/C
5 N/C 6 DDC2_SCLOUT
7 DDC2_SDAOUT 8 N/C
9 TMDS1- 10 TMDS1+
11 TMDSSD 12 N/C
13 N/C 14 5V
15 GND 16 HP0_DETECT
17 TMDS0- 18 TMDS0+
19 TMDSSD 20 N/C
21 N/C 22 TMDSSD
23 TMDSCLK+ 24 TMDSCLK-
C1 N/C C2 N/C
C3 N/C C4 N/C
C5 N/C C6 N/C
5
15
1
11
10 6
PCA-5612 Industrial VGA Card with XGI Volari™ Z9s
2 PCA-5612 Startup Manual
Board Layout: Jumper and Connector Locations
2. Board Layout
