Advantech SKY-8132S-11 User manual

Quick Start Guide for
SKY-8132S-11
Hardware installation and BIOS set-up
December 08, 2021
Cloud-IoT Business Group
Advantech Confidential –covered by NDA

Advantech Confidential –covered by NDA
•Hardware removal and installation
•BIOS setup and FAQ
•Using your own OS
Contents

Top view of SKY-8132S-11
Advantech Confidential –covered by NDA

Opening Top Cover (1/2)
1. Use a M2 Phillips head screw driver
2. Notice there are 6 M2 screws (red marked) to be removed before opening the top
cover
3. Lift the top cover of extended heatsink(yellow marked)
Advantech Confidential –covered by NDA

Opening Top Cover (2/2)
1. Remove the 2 M2 screws behind the cover of extended heatsink (red marked)
2. Slide the top cover toward you and lift it
Advantech Confidential –covered by NDA

After removing the top cover
PCIe slots
(for FHHL cards)
Silicom FEC
acceleration card
Advantech Confidential –covered by NDA
2.5” HDD
4028 High speed fan
CPU heatsink

Removing FHHL PCIe card cage
1
1. Loose the thumb screw (red marked)
2. Hold yellow areas and lift up gently
2
2
PCIe card cage
Advantech Confidential –covered by NDA

Installing FHHL PCIe card cage
1. Make sure front groove has matched 2
red circled spot.
2. Make sure rear pillar matched another
red circle
3. Hold yellow areas and press down to
engage the PCIe connector on the MB
3
3
Advantech Confidential –covered by NDA
1
1
2

Removing LP PCIe card Cage
1
2
1. Loose the thumb screw (red marked)
2. Remove right screw(red marked)
3. Hold yellow area and lift
Advantech Confidential –covered by NDA

Installing LP PCIe card cage
1. Make sure front groove has matched
2 red circled spot.
2. Make sure rear pillar matched
another red circle
3. Hold yellow area and press to the
end
1
1
2
2
3
3
Advantech Confidential –covered by NDA

•Accessory box
1. System mounting ears*2
2. M2 screws for ear wings*6
(3 for each)
3. RJ45-USB console cable*1
4. Spare M2 screws*4
5. DC Power cable*2
Accessories
Advantech Confidential –covered by NDA
1
2
3
4
56

•Console setting on your laptop
•Connect the console port and your laptop PC with
the RJ45-USB cable
•Connect both power cables to a set of redundant
DC power sources (-48VDC), following by
connecting the cables (blue connectors) to your
system to power up
•Check power module LED are all green(blue circle)
•Check network link LED is blinking green (red circle)
•For the first time boot up, waiting for 3~5 minutes
for console display
Starting your SKY-8132S-11 System
Example for connecting power supply through
power cable
Advantech Confidential –covered by NDA

•Please refer to SKY-8132S-11 BIOS Manual (double click)
•[Quick Start Guide #1] How to get device power on and display?
•[Quick Start Guide #2] How to setup remote monitoring and
controlling to the device?
•How to install operating system remotely through BMC Web UI?
(Remote Storage)
BIOS setup and FAQ

Using your own OS-with bootable USB
Advantech Confidential –covered by NDA
•Text mode:
–1. setup PuTTY on PC with baud rate 115200, 8, N, 1
–2. plug-in USB bootable disk
–3. select USB bootable disk in BIOS menu then save
•GUI (Graphical User Interface) mode
–1. setting BMC IP via BIOS setup menu
–2. using internet browser (recommended Google Chrome) from another PC to connect to BMC ip
–3. login with default credential
account: administrator / password: advantech
–4. using iKVM to access to OS

•Text mode:
–1. setup PuTTY on PC with baud rate 115200, 8, N, 1
–2. plug-in USB installation disk
–3. select USB installation disk in BIOS menu then save
–4. running OS installation process
•GUI (Graphical User Interface) mode
–1. setting BMC IP via BIOS setup menu
–2. using internet browser (recommended Google Chrome) from another PC to connect to BMC ip
–3. login with default credential
account: administrator/ password: advantech
–4. using iKVM to access to OS
Using your own OS-Installing on SSD
Advantech Confidential –covered by NDA
