Adveco EB0025 User manual

Installation,
Operation and
Maintenance Manual
PRODUCT MANUAL
TR500010
EB0025/EB0028/EB0030
Control Panels with Automatic Changeover, SMS and HR
PRACTICAL, EFFICIENT & SUSTAINABLE
BUILDING SERVICES SOLUTIONS

PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
2
Warnings
This manual should be read and understood carefully prior to installation or operation of any part of the
EB0025, EB0028 or EB0030 control panel. Failure to read this manual or to follow its printed instructions may
lead to personal injury, damage to the panel and damage to the water heating installation. These instructions
should be kept in a safe and accessible place near the water heating unit.
The EB0025, EB0028 or EB0030 control panel should be stored in a safe place prior to installation to prevent
damage.
Copyright © 2016 Adveco Limited. All rights reserved.
No part of this publication may be copied, reproduced, altered and/or published by any means without the prior
written approval of Adveco Limited.
Any brand names mentioned within this publication are registered trademarks of their respective owners.
Adveco Limited reserve the right to modify specifications in this manual at any time and without notification.
Adveco Limited accept no liability for third party claims arising from unauthorised use and/or use other than
that as directed within this manual.
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

page
4
5
5
6
7
8
9
13
21
22
Contents
Product Description
Installation Instructions
1. Requirements of the Installer
2. Location
3. Installation Procedure
Contact and Warranty Information
3
58
27
57
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual
EB0025
1. Technical Details
2. Wiring Diagram
3. Troubleshooting
Maintenance Instructions
Components & Terminology
41
42
47
EB0028
1. Technical Details
2. Wiring Diagram
3. Troubleshooting
EB0030
1. Technical Details
2. Wiring Diagram
3. Troubleshooting

Product Description
The Adveco range of EB0025, EB0028 and EB0030 control panels are complete wiring stations for a water
heating installation, providing power to primary and secondary heat sources to ensure a reliable supply of hot
water. Delivered prewired and ready to wall mount in an IP65-rated protective box, the panels include
automatic changeover functions from duty to a backup heat sources in response to a fault, a change in hot water
demand or differential tariff supplies.
All control panels include a system isolator, internal aerial, overload protection and volt-free contacts for BMS
error signal support. Optional heat recovery controls are included within the panels as standard, for use with the
Adveco HR001 Heat Recovery Box and Danfoss condenser units, or Scutts condenser units. Also included in
each panel is a GSM module designed to keep off-site facilities management informed of any appliance faults;
this will automatically send text and/or email alerts to the relevant service contacts immediately upon failure of a
primary heat source, as well as delivering a periodic healthy status report.
Adveco EB0025 Control Panel:
The EB0025 control panel includes a gas to electric auto-changeover function and is designed for use with an
SGE, SGS or BFC condensing gas-fired water heater with an electric backup heating element of up to 9kW
capacity. This produces a highly efficient and reliable water heating solution, with a gas-fired primary heat
source optionally supporting a fridge/freezer heat recovery process with additional electric immersion heater
backup.
Adveco EB0028 Control Panel:
The EB0028 control panel includes an electric to electric changeover function and is designed for use with
systems containing an ITE indirect electric water heater, or an IT indirect tank plus ST storage tank, with an
EB0027 dual-circuit 18kW/9kW electric immersion heater. The primary electric immersion heater can be used
to support an optional heat recovery process or provide the entire heating load, and contains an inbuilt 9kW
backup to ensure a reliable supply of hot water. The control panel also includes a seven-day timeclock and
controls for use with a destratification pump to be used for anti-Legionella purge cycling.
Adveco EB0030 Control Panel:
The EB0030 control panel includes a gas to electric auto-changeover function and is designed for use with a
BFC or SGS condensing gas-fired water heater in addition to an IT indirect tank with backup electric immersion
heater. The primary gas burner serves as a highly efficient source of hot water and can support preheating by
optional fridge/freezer heat recovery processes, with up to 9kW of backup electric heating capacity. The
control panel additionally includes a seven-day timeclock and controls for use with a destratification pump to be
used for anti-Legionella purge cycling.
This system is available as a fully packaged, prefabricated solution, enclosed within purpose-built GRP housing
for rooftop installation.
Available Ancillaries:
Adveco strive to offer a complete range of water heating solutions to meet the needs of an end user. The
following ancillaries are available and are compatible with the EB0028:
PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
4
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

Installation Instructions
1. Requirements of the Installer
All installation work for this immersion heater kit must be carried out by an individual with the relevant
qualifications and experiences to work with electrical systems and who is registered with an electrical regulatory
body such as NICEIC, and should be compliant to:
• BS 7671:2008 IEE Wiring Regulations 17th Edition.
• BS EN 806 all parts.
• BS EN 60335-2-74, IEC 60335-2-74.
• Building Regulation Part G.
• Building Standards (Scotland) Regulations.
• Water Regulations.
• Health and Safety and Work Act 1974.
• Local Byelaws.
And any complementing or superseding documentation.
Adveco Limited accept no responsibility for failure to comply with the above or with safe working practices.
2. Location
For GSM module responsiveness, it is recommended that the control panel should be sited in an above ground
area with good signal reception . Basement installations may require a remote antenna (not included).
The control panel should be mounted at an accessible height on a wall adjacent to the water heater. The wall
should be strong enough to hold the panel and constructed of a suitable material to accommodate the panel
fixings. Should the control panel be installed away from the water heater, additional isolators must be included
near the heater and its components.
Cable connections for all panels enter through the floor of the enclosure and require 100mm of exterior
clearance. All panel dimensions are included in the technical details on pages 7-9 and should be consulted prior
to installation.
The EB0025 features a removable front panel and is suited for installation within cupboards or tight spaces. A
minimum frontal clearance of 300mm is recommended for access.
The EB0028 and EB0030 models feature a hinged front panel. A frontal clearance of no less than 500mm must
be present in order to open the panel door.
5
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

• Remove the back panel and its mounted components from the enclosure, resulting in an empty box in
order to prevent accidental damage to the components. Mark out and drill the necessary number of
holes for glands on the floor of the panel. One gland is required for each cable feeding into the panel.
Gland sizes must be correct for the cable they will accommodate.
• Mark out the mounting location on the wall using the supplied brackets. Drill and plug the wall, then
reaffix the back panel to the box and mount the complete assembly. Ensure the box is properly
assembled and securely fixed to the wall.
• A 400V rotary isolator should be installed feeding the control panel to provide means for safe isolation
of the system.
• Cable sizes should be dictated by the electrical load of each component. The terminals within the
control panel are of sufficient size to accommodate the largest cables that may be required.
• All cables must have correctly sized ferrules on the ends. A double ferrule must be used when two
cables are used in one connection.
• All cable glands must provide mechanical protection against pull-out. Within the box the cable insulation
should be cut back to near the gland.
• Unused heat recovery connections should be left empty.
• No additional link wires are required. All needed links are pre-installed.
• Following installation, the panel should be tested to and meet the requirements of NICEIC.
Installation Instructions
3. Installation Procedure
Warning: 400V circuits are present within the control panel. Suitable caution should be taken during the
installation process.
PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
6
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

Maintenance Instructions
At minimum, the control panel should be checked annually by a qualified engineer. The unit must be fully
isolated from the mains electricity supply prior to any inspection or maintenance work being carried out. The
maintenance procedure should include at least the following checks:
• Visually inspect the interior of the panel for signs of overheating or distress. Any visible dust and dirt
should be removed with careful use of compressed air only.
• Press the test buttons of all contactors to ensure free travel.
• Check the tightness of every terminal connection within the control panel, including building cable
connections.
• With the panel still open, turn on the isolator and return power to the system. Warning: 400V/3ph
power will now be live within the panel. Exercise suitable caution.
• Confirm that the lead heat source is still operational.
• Simulate a fault within the lead heat source. For an electrical unit, trip the circuit breaker supplying the
primary heater. For a gas appliance, put the water heater in to fault.
• Confirm that a fault notification has been received from the GSM module. This can be done by checking
with the manager of the store. Fault messages may take several minutes to arrive by email.
• Check the settings and operation of all thermostats within the system.
• Isolate the system and close the panel door.
• Check the time and programme of the programmable clock (if installed). The clock controls the
destratification pump which should run no less frequently than twice per week, for two hours per cycle.
7
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

EB0025
1. Technical Details
EB0025
415V/3ph/50Hz
10kA
16A/phase
Internal
400mm
300mm
160mm
5kg
Adveco Order Code:
Supply:
Fault level:
Max load current:
Aerial:
Height:
Width:
Depth:
Weight:
• E0047: Control panel with gas to electric auto-changeover function. Includes main isolator feeding a
gas-fired water heater and an immersion heater, plus circuit breakers, volt-free contacts for BMS
support and heat recovery options.
• E0012: GSM modem for automatic SMS or email notification of faults.
Included Parts:
•EB0029: 9kW electric immersion heater assembly for use with BFC and SGS 30-60 water heaters
• 0304296S: 7.5kW electric immersion heater for use with SGE water heaters
Compatible Ancillaries:
•SGE, SGS and BFC condensing gas-fired water heaters
• HR001 Heat Recovery Box
Suitable for use with:
8
PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

© Copyright
9
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual
EB0025
2. Wiring Diagrams

EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual
© Copyright
PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
10
EB0025
2. Wiring Diagrams

© Copyright
11
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual
EB0025
2. Wiring Diagrams

EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual
© Copyright
PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
12
EB0025
2. Wiring Diagrams

Is there hot water?
NO –
Does the water heater have power?
No – Test Main Isolator on Control Panel and CB2 then SGE thermocontroller.
Yes –
Is the SGE water heater displaying a fault?
No – SGE is working, check for plumbing faults in system.
Yes –
Did the restaurant receive an email fault notification?
No – Test SMS device, CB3, KA1, K1T, Error Relay.
Yes –
Is the Standby Immersion on? (is the LED on?)
Yes – Repair SGE water heater fault, test Immersion heater.
No – Test Immersion Heater, K1M, CB1, K1T and Error Relay.
YES –
Is the SGE water heater displaying a fault?
Yes –
Did the restaurant receive an email fault notification?
No – Test SMS device, CB3, KA1, K1T, Error Relay.
Yes –
Is the Standby Immersion on? (is the LED on?)
Yes – Repair SGE water heater fault, test Immersion heater.
No – Test Immersion Heater, K1M, CB1, K1T and Error Relay.
No –
Did the restaurant receive an email fault notification?
Yes – is the restaurant running on a generator, had power cuts, or had an engineer on
site carrying out any servicing activities?
No –
Does the Heat Recovery system run when the chiller or freezer runs?
No – Test Heat Recovery System.
Yes – Hot water system operating correctly.
EB0025
3. Troubleshooting
13
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

Immersion Heater - 7.5kW / 9kW
7.5kW: 0304296S / 9kW: EB0016
Immersion Heater 7.5kW provides electrical backup water heating.
The 9kW immersion heater is 3 phase and has the control and overheat stat
built into the housing. It has a green LED to indicate running.
If there is a fault with the immersion heater 9kW it will not operate.
Part Name:
Adveco Part Number:
Function:
Specifics:
Fault:
Testing:
1. With the power off, Measure resistance between 1L1/1N1, 1L2/1N1, and 1L3/1N1 in the control panel. The
correct reading is 21Ω for the 7.5kW heater and 18Ω for the 9kW heater. If any phase is open circuit, replace the
Immersion heater.
2. With the power on, CB1, CB2, and CB3 on, put the SGE in fault and wait 5 minutes then measure voltage
between 1L1/E, 1L2/E, and 1L3/E. The correct reading is 230V. If 0V at these points, test K1M.
3. With the power on, CB1, CB2, and CB3 on, and the temperature control dial on the immersion heater turned all
the way clockwise, put the SGE in fault and wait 5 minutes then measure current in cables from 1L1, 1L2, and 1L3.
The correct reading is approximately 11A (but this will vary with the site voltage). If 0A to all phases then:
With the power off remove the lid from the Immersion Heater Housing and locate the control and overheat
stats. Press the reset button on the overheat stat and repeat current test. If 11A/phase found, remove the
stats from the immersion housing and calibrate them with warm water. Replace if either is faulty. If still 0
Amps to all phases then:
With the power off, and the temperature in the tank below the control and overheat set points, test continuity
between terminals of the stats. The correct reading is closed circuit. If open circuit, replace faulty stat.
EB0025
3. Troubleshooting
14
PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

BFC Error Relay Error
Relay Gas Heater
Relay within SGE/BFC water heater. Normally open, closes on fault with gas
side of the water heater.
Part Name:
Wiring Diagram Key:
Function:
Testing:
1. With the power off, test continuity between terminals 1,2 in the control panel. The correct reading is open
circuit. If closed circuit, check to see if a link has been added between 1,2 in the control panel, or X1, X2 in the
water heater terminal box. If not, investigate water heater.
2. With the power on and CB3 on, measure voltage between terminal 1 and Earth. The correct reading is 230V. If
0V, test CB3.
3. With the power on, CB2 and CB3 on, confirm that the BFC water heater is on and healthy. If the BFC is off,
measure voltage between 2L1 and Earth. The correct reading is 230V. If 0V, test CB2. If 230V, test BFC water
heater (refer to BFC manual).
4. With the power on, CB2 and CB3 on and BFC healthy, trip BFC by turning off the gas isolation valve. When the
SGE goes into fault and displays an error code on the screen, measure voltage between terminal 2 and Earth. The
correct reading is 230V. If 0V, test BFC thermocontroller (refer to BFC Manual).
Timer Relay
K1T
E00TIM M/F
Timer relay used to create 5 minute delay after the error relay closes
before the immersion heater switches on and sends a fault text message to
reduce nuisance messages from minor self-resetting blocking codes.
When set to Op, 60s, and 5, the unit is set to close the relay after 5
minutes (five lots of 60 seconds).
Part Name:
Wiring Diagram Key:
Adveco Part Number:
Function:
Correct Operation:
Testing:
1. With the power off, confirm the timer relay is set to Op, 5, 60s, set correctly if necessary.
2. With the power off, test continuity between terminal 15/18 of K1T. The correct reading is open circuit. If
closed circuit, replace K1T.
3. With the power off, test continuity between A2 of K1T and the neutral of the isolator. The correct reading is
closed circuit. If open circuit, investigate the wiring.
4. With the power on, CB2 on, and CB3 on, fault out the SGE water heater and measure the voltage between A1
and Earth, 15 and Earth, and Y1 and Earth. The correct reading is 230V. If 0V, test CB3, and Error Relay.
5. With the power on, CB2 on, CB3 on, and the SGE water heater having been at fault for at least 5 minutes,
measure the voltage between 18 and Earth. The correct reading is 230V. If 0V, replace K1T.
EB0025
3. Troubleshooting
15
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

3 Phase Contactor
K1M
E00CONT18230
Schneider
K1M switches Immersion Heater 7.5kW / 9kW on when the coil is energised.
K1M Contactor should operate 5 minutes after the BFC/SGE water heater
goes into fault mode.
If K1M is faulty the backup immersion heater will not switch.
Part Name:
Wiring Diagram Key:
Adveco Part Number:
Manufacturer's Part Details:
Function:
Specifics:
Fault:
Testing:
1. With the power off, test continuity between terminals 1L1 and 2T1 of K1M. The correct reading is open circuit.
Next test continuity between terminals 1L1 and 2T1 while pressing the contactor test button. The correct reading
is closed circuit. Repeat tests for 3L2/4T2 and 5L3/6T3. If the continuity is not correct, does not change or the
test button is stuck, replace K1M.
2. With the power off, test continuity between A2 of K1M and the neutral of the isolator. The correct reading is
closed circuit. If open circuit, investigate the wiring.
3. With the power on and CB1 on, measure the voltage between 1L1/E, 3L2/E, and 5L3/E. The correct reading is
230V. If 0V, test CB1.
4. With the power on, CB2 on, and CB3 on, fault out the BFC/SGE water heater, wait 5 minutes and measure the
voltage between A1 and Earth. The correct reading is 230V. If 0V, test CB3, K1T, Error Relay, and the link or stat
between terminals 3/4.
5. With the power on, CB2 on, CB3 on, the BFC/SGE water heater in fault and 230V on A1, measure the voltage
between 2T1/E, 4T2/E, and 6T3/E. The correct reading is 230V. If 0V, replace K1M.
EB0025
3. Troubleshooting
16
PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

240V Relay
KA1
E00P REL 230
KA1 changes state when there is a fault. This causes the SMS device to
send out fault notification. It also closes the BMS fault contacts.
Relay KA1 becomes energised 5 minutes after a BFC/SGE fault.
Part Name:
Wiring Diagram Key:
Adveco Part Number:
Function:
Specifics:
Testing:
1. With the power off, test continuity between terminal 11 to 12 of KA1. The correct reading is closed circuit. If
open circuit, replace KA1.
2. With the power off, test continuity between terminal 21 to 24 of KA1. The correct reading is open circuit. If
closed circuit, replace KA1.
3. With the power off, test continuity between A2 of KA1 and the neutral of the isolator. The correct reading is
closed circuit. If open circuit, investigate the wiring.
4. With the power on, CB2 on, and CB3 on, fault out the SGE water heater, wait 5 minutes and measure the
voltage between A1 and Earth. The correct reading is 230V. If 0V, test K1T.
5. With the power on, CB2 on, and CB3 on, fault out the SGE water heater, wait 5 minutes and test continuity
between 11 and 12. The correct reading is open circuit. If closed circuit, replace KA1.
SMS Module
E0012
Enfora MT1200, MT2500 or MT4000
To send a text message to a prearranged number when a system fault occurs
which is turned into an email and sent to the store and other places.
Systems sold before January 2016 are likely to contain MT2500 models. From
January 2016 onwards, systems are likely to contain MT4000 models. Newer
systems may contain the MT1200.
Operation and maintenance is the same in both cases.
Part Name:
Adveco Part Number:
Manufacturer's Part Details:
Function:
Specifics:
Testing:
1. With the power on and CB3 on, confirm there are two green LED’s on the SMS device. If there are none, test
Power Supply. If there is only one, the SMS device has no mobile service.
2. With the power on, CB3 and CB2 on, put the BFC/SGE into fault and ask the store manager if a fault email is
received within 10 minutes. If not, pull the connector cable from the SMS device and see if the store receives an
email within 10 minutes. If an email is received, test KA1. If an email is not received, call AO Smith to check if a
text message has been received and take advice from there.
EB0025
3. Troubleshooting
17
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

Circuit Breakers
CB1 through CB
Schneider
Circuit breakers protect the circuits from over current. They come in single phase or
three phase blocks. They are rated in Amps based on the load they supply.
Part Name:
Wiring Diagram Key:
Manufacturer's Part Details:
Function:
Testing:
1. With the power on and the circuit breaker switched to off, measure the voltage between the top terminals of
the breaker (terminal 1, plus terminals 3 and 5 for three phase breakers) and Earth, and then the bottom terminal
(terminal 2, plus terminals 4 and 6 for three phase breakers) and Earth. The correct readings are 230V on the
live side 1,3,5; and 0V on the load side 2,4,6. If 0V on the live side, test Main Isolator. If 230V on load side
replace circuit breaker.
2. With the power on and the circuit breaker switched to on, measure the voltage between the load terminal
(terminal 2) of the breaker and Earth, repeat for terminals 4,6 for three phase breakers. The correct reading is
230V. If 0V replace Circuit Breaker
3. Put a load on the breaker by switching on the immersion heater or other downstream component. If the
breaker trips investigate the components and the wiring for a short. Swap two equal rated breakers if no fault
can be found to test for breaker fault or system fault.
EB0025
3. Troubleshooting
18
PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

Power Supply Unit
PSU
E00PSU230/12
To provide 12V DC to the SMS device.
Part Name:
Wiring Diagram Key:
Adveco Part Number:
Function:
Testing:
1. With the power on and CB3 on, measure the voltage to the power supply at terminals L, N. The correct
reading is 230V. If 0V, test CB3.
2. With the power on and CB3 on, measure the voltage from the power supply between terminal +V and –V.
The correct reading is 12V DC. If outside of range of 12 ± 4V, then replace power supply.
Heat Recovery System – HR001
HR001
To reclaim heat from the fridge and freezer condenser units.
The control panel provides a permanent 230V supply to the heat
recovery box. The heat recovery box includes the controls and pumps
necessary to run the heat recovery system.
Part Name:
Adveco Part Number:
Function:
Specifics:
Testing:
1. With the power on and CB4 on, measure the voltage for the permanent live supply to the heat recovery box
between control panel terminal 3L1 and Earth. The correct reading is 230V. If 0V, test CB4.
2. With Voltage at terminal 3L1, the heat recovery system should operate. If not, tests must be carried out within
the HR001 on the controllers and pumps. Ensure there is fluid in the system.
EB0025
3. Troubleshooting
19
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual

Heat Recovery System – Fosters/Scutts
Scutt's Condender Units
To reclaim heat from the fridge and freezer condenser units.
The control panel provides a permanent 230V supply to the condenser.
When the compressor runs, it is wired to pull in a relay. This will cause
the motorised zone valve to open. When fully open the microswitch
within the motorised valve will close providing a switched live back to the
control panel. This switched live will operate the pump station PS1.
Part Name:
Manufacturer's Part Details:
Function:
Specifics:
Testing:
1. With the power on and CB4 on, measure the voltage for the permanent live supply to the heat recovery
system between control panel terminal 3L1 and Earth. The correct reading is 230V. If 0V, test CB4.
2. With the power on and CB4 on, and both Fosters condenser units isolated (off on both isolators), measure the
voltage for the switched live between terminal 9 and Earth. The correct reading is 0V. If 230V is present, check
the state of the motorised valve: If indicator is perpendicular with the pipe then replace the motorised valve. If the
indicator is in line with the pipe then further checks are necessary to see if the valve orientation is wrong (valve
moves opposite to the way it should), or if the valve is faulty (will not move).
3. With the power on, CB4 on, and one Fosters unit powered on and running, measure the voltage between
terminal 9 and Earth. The correct reading is 230V. If 0V, test relay and motorised valve in condenser unit.
4. With the power off, test continuity between terminals 6 and 7. The correct reading is closed circuit. If open
circuit, check dual stat over heat has not tripped, and tank temperature is below set point. Replace Dual Stat if
faulty.
5. With the power on, CB4 on, the fridge or freezer on, and 230V at terminal 9, measure the voltage between
terminal 8 and Earth. The correct reading is 230V. If 0V, further tests on the Dual Stat are necessary.
6. With Voltage at terminal 8 the pump station should run. If not, test the pump, also ensure system has fluid in it.
EB0025
3. Troubleshooting
20
PRACTICAL, EFFICIENT & SUSTAINABLE BUILDING SERVICES SOLUTIONS
EB0025-EB0028-EB0030 Control Panel - Installation and maintenance manual
