Bogen ATP10 Guide

STEP ATTENUATION
10 0 dB (Full Volume)
9-3 dB
8-6 dB
7-9 dB
6-12 dB
5-15 dB
4-18 dB
3-21 dB
2-27 dB
1-33 dB
0Speaker Off
ATP10 and ATP35
Installation and Use Manual
Description
These 10-step plus “OFF” speaker attenuators allow the volume of a network of 25V or 70V speakers to be controlled
from a remote location. The ATP10 attenuator can handle speaker loads of up to 10W (max.) and the ATP35 attenuator
can handle speaker loads of up to 35W (max.). The ATP10 fits into a single gang electrical box and the ATP35 attenuator
fits into a double gang electrical box.
Each unit includes a bypass function for overriding the volume control knob setting when activated by 9V to 30V DC.
Applying 9V to 30V DC between pins labeled D+ and D- bypasses the volume control function and provides full
volume audio to the speakers.
© 2005 Bogen Communications, Inc.
All rights reserved.
Specifications subject to change without notice.
54-2149-01E 1202
Speaker
+
+
+
_
_
_
Power Supply
9V - 30V DC
+
_
Amplifier
ATP10 (or ATP35)
Customer Supplied
Contact Closure
SPEAKER
OUTPUTS
Rear
View
Pin Connections
Attenuators with Bypass
for 25V/70V Speaker Line
S+ Speaker Load Hot
S- Speaker Load COM
A+ Amp Hot
A- Amp COM
D+ +9V to 30V DC @ 22mA
D- Gnd DC
Attenuator Wiring
Attenuator
Settings
ATP10 ATP35

Bypass Connection Examples
In the example below, the AUX contacts of the Universal Telephone Interface (UTI1) are programmed to close when the
UTI1ʼs Override (Emergency) input becomes active. The AUX contacts switch 24V from the UTI1 power supply
terminals to the Bypass input of the ATP10 or ATP35, allowing a full volume page to be heard regardless of the volume
setting of the attenuator. See front page for amplifier and speaker wiring.
The bypass terminals override the volume control
setting whenever 9V to 30V DC (at 22 mA) is
applied to the D+ and D- terminals. See front
page for amplifier and speaker connections.
In this configuration the Bypass
feature activates when the zone is
being paged, but allows volume
control when the zone is inactive
and background music is playing.
See PCM Manual for amplifier
connections and front page for
speaker connections.
* Use a 12V regulated power
supply. Non-regulated supplies
may provide significantly more
than 12V when not fully loaded.
Greater than 12V supply will
cause relay driver to conduct
even when not active. A 9V
unregulated power supply will
typically work appropriately.
Power Supply
12V DC Max*
(9V Recommended)
