AEG ABL18F User manual

ABL18F
Original instructions

Important!
It is essential that you read the instructions in this manual before
assembling, operating and maintaining the product.
Subject to technical modifications.

33
1. Handle, insulated gripping surface
2. Trigger switch
3. Lower guard
4. Upper guard
5. Cutting wheel
6. Chip deflector
7. Cutting depth adjustment screw
8. Cutting depth lock nut
9. Work clamp
10. Work clamp lock lever
11. Work table
12. Work clamp adjustment crank
13. Rubber foot
14. Mitre guide lock lever
15. Mitre guide
16. Top handle
17. Spindle lock
18. Saw head lock chain
19. Wrench
20. Mounting hole
21. Carbon brushes
x 1 x 1
x 1
ABL18F

4
4
CRUISE CONTROL
TURBO BOOST BUTTON
LOWER TUBE
UPPER TUBE
HANDLE
TRIGGER
BATTERY

55
CRUISE CONTROL
TURBO BOOST BUTTON
LOWER TUBE
UPPER TUBE
HANDLE
TRIGGER
BATTERY

6
6
8
13
9
START
STOP
10
11
12
TURBO BOOST
Correct turbo button use
Correct cruise control use
Attaching the lower tube
Correct operating techniques

77
8
13
9
START
STOP
10
11
12
TURBO BOOST
Inserting and removing the battery
Correct trigger use

8
8
1
2
2
1
Attaching the lower tube

99
1
2
2
1
click
Inserting and removing the battery
NOTE: This AEG fusion blower is optimised
for use with FORCE battery packs. For the
best possible performance, use with AEG
18V FORCE battery packs.

10
10
START
STOP
START
STOP
Correct trigger use

11 11
START
STOP
START
STOP
Correct cruise control use

12
12
START
STOP
TURBO
BOOST
1
2
3
4
Correct turbo button use
NOTE: The turbo boost button
provides the highest performance
for the tool, but will also drain the
battery capacity more quickly. Use
turbo boost only when required to
maximise runtime.

13 13
START
STOP
TURBO
BOOST
1
2
3
4
Correct operating techniques

14
14
1
2
3
1
2
3
4
Maintenance

15 15
1
2
3
4
Storage

16
16
5
NOTE: Always store the unit in a cool, dry,
and well ventilated area.

17 17
5
TECHNICAL DATA CORDLESS BLOWER ABL18F/ABL18FF6
Rated voltage 18 V DC
Rated current turbo mode 39 A
Turbo mode
Air velocity turbo mode 200 km/h
Air volume turbo mode 465 CFM
Fan loaded speed turbo mode 19600 rpm
Weight 2.3 kg
Noise emission level (in accordance with EN 50636-2-100 Annex CC)
A-weighted sound pressure level at the operator’s position LPA = 94.4 dB (A)
Uncertainty K= 2.5 dB
A-weighted sound power level LPA= 107 dB (A)
LWA + KWA 110 dB
Vibration level (in accordance with EN 50636-2-100 Annex BB) ah= 0.6 m/s2
Uncertainty K = 1.5 m/s2
BATTERY AND CHARGER
Model ABL18F ABL18FF6
Battery pack Not included L1860R-X5
Charger Not included BL1218-X4
Compatible battery packs L1830R-X5, L1860R-X5, L1890R
Compatible chargers BLK1218, BL18DP2-X5, AL18G, BL1418, BL1218, BL1218LE, BL18DPS,
AL1218G, BL18DP, BL18DP-LE, BL18DP-X5
VIBRATION LEVEL
WARNING!
The declared vibration value has been measured with a standard test method and may be used to compare one tool with another. The declared
vibration value may be used in a preliminary assessment of exposure.
The vibration emission during actual use of power tool can dier from the declared total value depending on the ways in which the tool is used.
Identify safety measures to protect yourself based on an estimation of exposure in the actual conditions of use, taking account of all parts of the
operating cycle such as the times when the tool is switched o and when it is running idle in addition to the trigger time.
Safety, performance, and dependability have been given top priority
in the design of your cordless blower.
INTENDED USE
The cordless blower is intended only for outdoor use, in dry, and well-
illuminated conditions.
The product is not intended to be used by children or persons with
reduced physical, mental, or sensory capabilities.
The product is designed for blowing light debris, such as leaves, grass,
and other garden refuse.
Do not use the product for any other purpose.
GENERAL SAFETY WARNINGS
WARNING!
Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire, and/or
serious injury. Save all warnings and instructions for future reference.
WARNING!
Never allow children or people unfamiliar with these instructions to
use the product. Local regulations may restrict the age of the operator.
TRAINING
Read the instructions carefully. Be familiar with the controls and the
correct use of the product.
Keep in mind that the operator or user is responsible for accidents or
hazards occurring to other people or their property.
Do not use the product while tired, ill, or under the influence of alcohol,
drugs, or medication.
PREPARATION
Some regions have regulations that restrict the use of the product to
some operations. Check with your local authority for advice.
Wear hearing protection at all times while operating the product.
Strictly adhere to precautions to reduce noise to prevent permanent
hearing injury.
Wear full eye protection at all times while operating the product.
Wear a full face mask or fully enclosed goggles. Normal spectacles
or sunglasses are not adequate protection. Objects can be thrown at
high speed by the powerful air jet at any time and may rebound from
hard surfaces toward the operator.
While operating the product, always wear substantial footwear and

18
18
long trousers. Do not operate the product when barefoot or wearing
open sandals. Avoid wearing clothing with loose fitting or that has
hanging cords or ties.
Do not wear loose clothing or jewellery that can be drawn into the
air inlet. Secure long hair so it is above shoulder level to prevent
entanglement in moving parts.
Before each use, ensure that all controls and safety devices function
correctly. Do not use the product if the o switch does not stop the
product.
Operate the product in a recommended position and only on a firm
and level surface.
Do not operate the product on a paved or gravel surface where
ejected material could cause injury.
Before each use, always inspect the housing for damage. Ensure
that guards and handles are in place and properly secured. Replace
worn or damaged components in sets to preserve balance. Replace
damaged or unreadable labels.
Never operate the product while people, especially children, or pets
are nearby.
Keep all cooling air inlets clear of debris.
Use rakes and brooms to loosen debris before blowing.
Clear the work area before each use. Remove all objects such as rocks,
broken glass, nails, wire, or string which can be blown a considerable
distance by high velocity air.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk
of fire when used with another battery pack.
Use powe tools only with specifically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects,
like paper clips, coins, keys, nails, screws or other small metal objects
that can make a connection from one terminal to another. Shorting
the battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery
pack; avoid contact. If contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery pack may cause irritation or burns.
Do not use a battery pack or tool that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable behaviour
resulting in fire, explosion, or risk of injury.
Do not expose a battery pack or tool to fire or excessive temperatures.
Exposure to fire or excessive temperature above 130°C may cause
explosion.
Follow all charging instructions and do not charge the battery pack
or tool outside the temperature range specified in the instructions.
Charging improperly or at temperatures outside the specified range
may damage the battery and increase the risk of fire.
OPERATION
Operate the product only at reasonable hours—not early in the
morning or late at night when people might be disturbed.
Never operate the product in an explosive atmosphere.
Avoid using the product in bad weather conditions especially when
there is a risk of lightning.
Keep bystanders, children, and pets 15 m away from the area of
operation. Stop the product if anyone enters the area.
Do not operate the product in poor lighting. The operator requires a
clear view of the work area to identify potential hazards.
Operatingsimilar tools nearby increases both the risk of hearing injury
and the potential for other persons to enter your working area.
Always be sure of your footing on slopes. Walk, never run.
Keep proper footing and balance. Do not overreach. Overreaching can
result in loss of balance.
Never use the product with defective guards or shields, or without
safety devices in place.
Do not modify the product in any way or use parts and accessories
that are not recommended by the manufacturer.
WARNING!
If the product is dropped, suers heavy impact, or begins to vibrate
abnormally, immediately stop the product and inspect for damage or
identify the cause of the vibration. Any damage should be properly
repaired or replaced by an authorised service centre.
To reduce the risk of injury associated with contacting rotating parts,
always turn o the product and remove the battery pack. Make sure
that all moving parts have come to a complete stop:
■before leaving the product unattended
■before clearing blockages
■before checking, cleaning, or working on the product
■before inspecting the product after striking a foreign object
■whenever the product starts to vibrate abnormally (inspect
immediately)
Immediately turn o and remove the battery pack in the event of
accident or breakdown. Do not operate the product again until it has
been fully checked by an authorised service centre.
The product is provided with a cruise control lever near the trigger.
Cruise control sets the speed at a convenient level to provide enough
power to achieve the task. Low running speed will help reduce noise
and vibration. Cruise control helps reduce operator fatigue.
Press the turbo boost to increase the air flow to the maximum
velocity. The turbo boost will override the cruise control feature. The
blower will return to the previously selected speed when the button
is released.
WARNING!
Setting the cruise control will operate and lock the trigger. In this case,
the trigger will not release and turn o the blower. Turn o the cruise
control by pressing the lever fully forward to stop the motor of the
blower.
BLOWER SAFETY WARNINGS
Wear a face filter mask in dusty conditions to reduce the risk of injury
associated with the inhalation of dust.
Slightly dampen surfaces in dusty conditions.
Do not point the blower nozzle in the direction of people or pets.
Never place objects inside the blower tubes.
Do not operate the product near open windows.
Use the full blower nozzle extension so that the air stream can work
close to the ground and perform eectively.
Do not place the blower on top of or near loose debris. Debris can
be sucked into the intake vent, resulting in possible damage to the
product.

19 19
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING!
To reduce the risk of fire, personal injury, and product damage due
to a short circuit, never immerse your tool, battery pack or charger in
fluid or allow a fluid to flow inside them. Corrosive or conductive fluids,
such as seawater, certain industrial chemicals, and bleach or bleach-
containing products, etc., can cause a short circuit.
TRANSPORTATION AND STORAGE
Turn o the product, remove the battery pack, and allow it to cool
before storing or transporting.
Clean all foreign materials from the product. Store the product in a
cool, dry, and well-ventilated place that is inaccessible to children.
Keep the product away from corrosive agents, such as garden
chemicals and de-icing salts. Do not store the product outdoors.
For transportation in a vehicle, secure the product against movement
or falling to prevent injury to persons or damage to the product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery pack in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling when
transporting batteries by a third party. Ensure that no batteries can
come in contact with other batteries or conductive materials while
in transport by protecting exposed connectors with insulating, non-
conductive caps or tape. Do not transport batteries that are cracked
or leaking. Check with the forwarding company for further advice.
MAINTENANCE
WARNING!
Use only original manufacturer’s replacement parts, accessories, and
attachments. Failure to do so can cause possible injury, can contribute
to poor performance, and may void your warranty.
WARNING!
Servicing requires extreme care and knowedge and should be
performed only by a qualified service technician. Have the product
serviced by an authorised service centre only. When servicing, use
only original replacement parts.
Do not make adjustments and repairs that are not described in this
manual. For other repairs, contact an authorised service centre.
After each use, clean the product with a soft, dry cloth.
Check all nuts, bolts, and screws at frequent intervals for proper
tightness to ensure that the product is in safe working condition. Any
part that is damaged should be properly repaired or replaced by an
authorised service centre.
Bring the product to an authorised service centre to replace damaged
or unreadable labels.
CLEARING A BLOCKAGE
To reduce the risk of injury associated with contacting rotating parts,
always turn o the product, remove the battery pack, and make sure
that all moving parts have come to a complete stop.
Remove the blower tubes to inspect for blockage. Clear the tubes if
required.
Re-install the blower tubes before starting the product.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still impossible
to completely eliminate certain residual risk factors. The following
hazards may arise and the operator should pay special attention to
avoid the following:
■injury caused by vibration
–Always use the right tool for the job, hold the product by the
designated handles and use the lowest speed necessary to
achieve the task.
■injury caused by exposure to noise
–Wear ear protection and limit exposure.
■injury caused by flying objects from the blow tube airflow
–Wear eye protection at all times.
RISK REDUCTION
It has been reported that vibrations from handheld tools may
contribute to a condition called Raynaud’s Syndrome. Symptoms
may include tingling, numbness, and blanching of the fingers, usually
apparent upon exposure to cold. Hereditary factors, exposure to
cold and dampness, diet, smoking, and work practices are all thought
to contribute to the development of these symptoms. There are
measures that can be taken by the operator to possibly reduce the
eects of vibration:
■Keep your body warm in cold weather. When operating the
product, wear gloves to keep the hands and wrists warm. It is
reported that cold weather is a major factor contributing to
Raynaud’s Syndrome.
■After each period of operation, exercise to increase blood
circulation.
■Take frequent work breaks. Limit the amount of exposure per day.
If you experience any of the symptoms of this condition, immediately
discontinue use and see your physician.
WARNING!
Injuries may be caused or aggravated by prolonged use of the
product. When using any tool for prolonged periods, ensure to take
regular breaks.
SYMBOLS
Read and understand all instructions before
operating the product. Follow all warnings and
safety instructions.
Wear ear protection.
Wear eye protection.
Do not expose the product to rain or damp
condition.

20
20
Beware of thrown or flying objects. Keep all
bystanders, especially children and pets, at least 15m
away from the operating area.
Rotating fans. Keep hands and feet out of openings
while the product is running.
Remove the battery pack before starting any work on
the product.
Regulatory Compliance Mark (RCM). The product
meets applicable regulatory requirements.
The guaranteed sound power level is 110 dB.
Do not dispose of electric tools together with
household waste material! In observance of
European Directive 2002/96/EC on waste electrical
and electronic equipment and its implementation
in accordance with national law, electric tools that
have reached the end of their life must be collected
separately and returned to an environmentally
compatible recycling facility.
The following signal words and meanings are intended to explain the
levels of risk associated with this product.
DANGER
Indicates an imminently hazardous situation, which, if not avoided,
will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
CAUTION
Without safety alert symbol
Indicates a situation that may result in property damage.
