AEG GM18EX2 User manual
GM18EX2
Original instructions
2
2
Important!
This appliance is not intended to be used or cleaned by persons
with reduced physical, sensory or mental capabilities, or lack
of experience or knowledge, unless they have been given
instructions concerning the safe use of the appliance by a person
legally responsible for their safety. They should be supervised
whilst using the appliance.
Children shall not use, clean or play with this appliance, which
when not in use should be secured out of their reach.
33
21 3
6
4 5
1. Inflator nozzle
2. Rubber tube
3. Trigger
4. Speed selector
5. Handle, insulated gripping surface
6. Battery port
4
4
Remove the battery pack before
starting any work on the machine.
8
14
55
START
STOP
6
14
10
12
6
6
Remove the battery
pack before starting any
work on the machine.
1
1
2
2
Click
77
75-100 %
50-75 %
25-50 %
0-25 %
8
8
1
2
Remove the battery
pack before starting any
work on the machine.
99
Remove the battery
pack before starting any
work on the machine.
Attach the inflator nozzle
to the air inlet for deflating
purposes.
Attach the inflator nozzle
to the air outlet for
inflating purposes.
10
10
START
STOP
11 11
3
1
2
12
12
ca. 3 cm
Do not cover air inlet.
Keep air inlet clear of dirt.
13 13
Not to be used as a
vacuum device.
Not to be used for
vacuuming liquids.
14
14
BATTERY AND CHARGER
Compatible battery pack
(not included)
Compatible charger
(not included)
L1815R
L1820R
L1825R
L1830R
L1840R
L1850R
L1860R
L1860B
L1860R-X5
L1890R
AL18G
AL1218G
BL1218
BLK1218
BL18DP-X5
BL18DP2-X5
Use AEG 18V battery and charger only
WARNING! Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock, fire and/or
serious injury. Save all warnings and instructions for future reference.
BLOWER SAFETY WARNINGS
Failure to keep loose clothing or long hair from being drawn into air intake could
result in personal injury.
Ensure you have proper footing, especially in case of slanted surfaces.
The blower shall not be used as a vacuum device.
Do not blow hot, flammable or explosive material.
Never allow children, persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge or people unfamiliar with these
instructions to use the machine. Local regulations may restrict the age of the
operator.
The operator or user is responsible for accidents or hazards occurring to other
people or their property.
Never operate the machine while people, especially children or pets, are nearby.
Use the machine only in daylight or good artificial light.
If the product is dropped, suers heavy impact or begins to vibrate abnormally,
immediately stop the product and inspect for damage or identify the cause
of the vibration. Any damage should be properly repaired or replaced by an
authorised service centre.
Do not touch moving hazardous parts before the product is disconnected from
the battery pack and the moving hazardous parts have come to a complete stop.
Repairs should only be carried out by an authorised service centre.
Do not operate the product with defective guard or enclosure or shields.
Wear protective goggles while operating.
To prevent dust irritation the wearing of a face mask is recommended.
Do not operate the machine when barefoot or wearing open sandals, always
wear substantial footwear and long trousers.
Failure to keep loose clothing from being drawn into air intake could result in
personal injury.
Failure to keep long hair away from the air inlet could result in personal injury.
Always be sure of your footing on slopes.
Never blow debris in the direction of bystanders. Do not operate without tubes
in place.
Do not overreach and keep your balance at all times.
Walk, never run.
Keep all cooling air inlets clear of dirt.
Do not modify this blower. Unauthorized modifications may impair the safety of
TECHNICAL DATA CORDLESS BLOWER GM18EX2
Rated voltage 18 V
No-load speed
level 1
level 2
level 3
18700 min-1
13300 min-1
11500 min-1
Air speed max.
level 1
level 2
level 3
200 km/h
155 km/h
112 km/h
Air flow rate
level 1
level 2
level 3
2.9 m3/min
2.2 m3/min
1.8 m3/min
Rated current 16 A
Weight - not including battery pack 1.15 kg
Measured values determined according to EN 50636-2-100 Annex CC.
A-weighted sound pressure level (at operators ear) L
pA
= 84 dB(A)
Uncertainty K 2.5 dB(A)
A-weighted sound power level LWA + KWA = 94.5 dB(A)
Uncertainty K 1.74 dB(A)
Wear ear protectors.
The vibration total values (triaxial vector sum) determined according to EN 50636-2-100 Annex BB:
Handle Vibration ah= 3.4 m/s2
Uncertainty K 1.5 m/s2
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 50636-2-100 Annex BB and may
be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for di erent applications, with di erent accessories or
poorly maintained, the vibration emission may di er. This may signifi cantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched o or when it is running but not actually doing
the job. This may signifi cantly reduce the exposure level over the total working period. Identify additional safety measures to protect the operator from the e ects of
vibration such as: maintain the tool and the accessories, keep the hands warm, organisation of work patterns.
15 15
your product and may result in increased noise and vibration.
Store the appliance only in a dry place.
Remove the battery pack before starting any work on the machine.
Do not dispose of used battery packs in the household refuse or by burning
them. AEG Distributors oer to retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects (short circuit risk).
Only use AEG chargers for charging AEG batteries. Do not use battery packs
from other systems.
Battery acid may leak from damaged batteries under extreme load or extreme
temperatures. In case of contact with battery acid wash it o immediately with
soap and water. In case of eye contact rinse thoroughly for at least 10 minutes
and immediately seek medical attention.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING!To reduce the risk of fire, personal injury, and product damage
due to a short circuit, never immerse your tool, battery pack or charger in fluid or
allow a fluid to flow inside them. Corrosive or conductive fluids, such as seawater,
certain industrial chemicals, and bleach or bleach-containing products, etc., can
cause a short circuit.
SPECIFIED CONDITIONS OF USE
The cordless blower may be used as follows:
• Blowing of dirt, dust and leaves.
Do not use this product in any other way as stated for normal use.
BATTERIES
New battery packs reach full loading capacity after 4 - 5 chargings and
dischargings. Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance of the battery
pack. Avoid extended exposure to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged, after used.
To obtain the longest possible battery life remove the battery pack from the
charger once it is fully charged.
For battery pack storage longer than 30 days:
• Store the battery pack where the temperature is below 27°C and away
from moisture.
• Store the battery packs in a 30% - 50% charged condition.
• Every six months of storage, charge the pack as normal.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods Legislation
requirements.
Transportation of those batteries has to be done in accordance with local,
national and international provisions and regulations.
• The user can transport the batteries by road without further requirements.
• Commercial transport of Lithium-Ion batteries by third parties is subject
to Dangerous Goods regulations. Transport preparation and transport
are exclusively to be carried out by appropriately. trained persons and the
process has to be accompanied by corresponding experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and insulated to
prevent short circuit.
• Ensure that battery pack is secured against movement within packaging.
• Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice.
BATTERY PACK PROTECTION
The battery pack has overload protection that protects it from being overloaded
and helps to ensure long life. Under extreme stress the battery electronics
switch o the product automatically. To restart, switch the product o and then
on again. If the product does not start up again, the battery pack may have
discharged completely. In this case it must be recharged in the battery charger.
STORAGE
When not in use, store the product only in a dry place, out of reach of children.
MAINTENANCE
Check and empty the debris collector frequently.
Replace worn or damaged parts.
Keep all nuts, bolts and screws tight to ensure the product is in safe working
condition.
The ventilation slots of the machine must be kept clear at all times.
Use only AEG accessories and AEG spare parts. Should components need to be
replaced which have not been described, please contact one of our AEG service
agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state the Article
No. as well as the machine type printed on the label and order the drawing at
your local service agents or directly at:
Techtronic Industries (Australia) Pty. Ltd.
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia
Techtronic Industries N.Z. Ltd.
PO Box 12-806
Penrose AUCKLAND 1642
Tel. no. 0800 234 797(0800 AEGPWR)
New Zealand
SYMBOLS
Safety alert
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
Please read the instructions carefully before starting the
machine.
Always wear goggles when using the machine.
Wear ear protectors.
Wear a suitable dust protection mask.
Beware of thrown or flying objects.
Keep all bystanders, especially children and pets, at least
15m away from the operating area.
Do not expose to rain or damp condition.
Remove the battery pack before starting any work on the
machine.
Do not dispose of electric tools together with household
waste material. Electric tools and electronic equipment
that have reached the end of their life must be collected
separately and returned to an environmentally compatible
recycling facility.
Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley,
VIC, 3149, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
AEG is a registered trademark used under
license from AB Electrolux (publ).
