AEG DGE5660HM User manual

User manual
Cooker Hood
EN
Gebrauchsanleitung
Dunstabzugshaube
DE
Manuel d’utilisation
Hotte de Cuisine
FR
Gebruiksaanwijzing
Dampkap
NL
Manual de uso
Campana
ES
Livro de instruções
para utilização
Exaustor
PT
Libretto di uso
Cappa
IT
Användningshandbok
Spisfläkt
SV
Bruksveiledning
Kjøkkenvifte
NO
Käyttöohjeet
Liesituuletin
FI
Brugsvejledning
Emhætte
DA
Руководство по
Эксплуатации
Вытяжкa
RU
ET Kasutusjuhend
Pliidikumm
LV Lietošanas pamācība
Tvaiku Nosūcējs
LT Naudotojo vadovas
Dangtis
UK Інструкція з експлуатації
Витяжка
Használati útmutató
Motorháztetõ
HU
DGE5660HM
DGE5860HM
DGE5160HM

2www.aeg.com
CONTENTS
1. RECOMMENDATIONS AND SUGGESTIONS .................................................................. 3
2. USE ........................................................................................................................................... 5
3. MAINTENANCE ...................................................................................................................... 5
4. CONTROLS ............................................................................................................................. 6
5. REMOTE CONTROL ............................................................................................................. 7
6. LIGHTING ................................................................................................................................ 7
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not nd on ordinary appliances. Please spend a few minutes reading
to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.

3
ENGLISH
1. RECOMMENDATIONS AND SUGGESTIONS
• The Instructions for Use apply to several versions of this ap-
pliance. Accordingly, you may nd descriptions of individual
features that do not apply to your specic appliance.
• The manufacturer will not be held liable for any damages result-
ing from incorrect or improper installation.
• The minimum safety distance between the cooker top and the
extractor hood is 650 mm (some models can be installed at a
lower height, please refer to the paragraphs on working dimen-
sions and installation).
• Check that the mains voltage corresponds to that indicated on
the rating plate xed to the inside of the hood.
• For Class I appliances, check that the domestic power supply
guarantees adequate earthing. Connect the extractor to the
exhaust ue through a pipe of minimum diameter 120 mm.
The route of the ue must be as short as possible.
• Do not connect the extractor hood to exhaust ducts carrying
combustion fumes (boilers, replaces, etc.).
• If the extractor is used in conjunction with non-electrical appliances
(e.g. gas burning appliances), a sufcient degree of aeration must
be guaranteed in the room in order to prevent the backow of
exhaust gas. The kitchen must have an opening communicat-
ing directly with the open air in order to guarantee the entry of
clean air. When the cooker hood is used in conjunction with
appliances supplied with energy other than electric, the negative
pressure in the room must not exceed 0,04 mbar to prevent
fumes being drawn back into the room by the cooker hood.
• The air must not be discharged into a ue that is used for
exhausting fumes from appliances burning gas or other fuels
(not applicable to appliances that only discharge the air back
into the room).
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
• If the instructions for installation for the gas hob specify a greater
distance specied above, this has to be taken into account.
Regulations concerning the discharge of air have to be fullled.
• Use only screws and small parts in support of the hood.
Warning: Failure to install the screws or xing device in accord-
ance with these instructions may result in electrical hazards.
• Connect the hood to the mains through a two-pole switch hav-

4www.aeg.com
ing a contact gap of at least 3 mm.
• Allow disconnection of the appliance from the supply after in-
stallation. The disconnection may be achieved by having the
plug accessible or by incorporating a switch in the xed wiring
in accordance with the wiring rules.
• Do not ambè under the range hood; risk of re.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appli-
ance by a person responsible for their safety.
“CAUTION: Accessible parts may become hot when used with
cooking appliances.”
• The symbol on the product or on its packaging indicates that
this product may not be treated as household waste. Instead it
shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help prevent po-
tential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about
recycling of this product, please contact your local city ofce,
your household waste disposal service or the shop where you
purchased the product.
• Switch off or unplug the appliance from the mains supply before
carrying out any maintenance work.
• Clean and/or replace the Filters after the specied time period
(Fire hazard).
2. USE
• The extractor hood has been designed exclusively for domestic
use to eliminate kitchen smells.
• Never use the hood for purposes other than for which it has
been designed.
• Never leave high naked ames under the hood when it is in

5
ENGLISH
operation.
• Adjust the ame intensity to
direct it onto the bottom of the
pan only, making sure that it
does not engulf the sides.
• Deep fat fryers must be con-
tinuously monitored during
use: overheated oil can burst
into ames.
3. MAINTENANCE
- The Activated charcoal lter is
not washable and cannot be re-
generated, and must be replaced
approximately every 4 months of
operation, or more frequently for
particularly heavy usage (W).
W
- The Grease lters must be cleaned
every 2 months of operation, or
more frequently for particularly
heavy usage, and can be washed
in a dishwasher (Z).
ZZ
- Control lights, if present.
• Clean the hood using a damp cloth
and a neutral liquid detergent.

6www.aeg.com
4. CONTROLS

    
Button Function Led
LTurns the lights on/off at maximum strength. -
T1 Turns the motor on/off at speed one. Fixed.
T2 Turns the Motor on at speed two. Fixed.
Press and hold the button for approximately 3 seconds, with
all the loads turned off (Motor and Lights), to turn the Activated
Charcoal Filter alarm on. The relevant LED ashes twice to conrm.
To turn the alarm off, press the button again and hold for at least
3 seconds. The relevant LED ashes once.
-
T3 Turns the Motor on at speed three. Fixed.
Press and hold the button for approximately 3 seconds, with all
the loads turned off (Motor and Lights), to perform a reset. The
LED S1 ashes three times.
-
T4 Turns the Motor on at INTENSIVE Speed. Fixed.
This speed is timed to run for 6 minutes. At the end of this time,
the system returns automatically to the speed that was set before.
If it is activated with the motor turned off, the hood will switch to
OFF at the end of the time.
Press and hold for 3 seconds to enable the remote control,
indicated by the LED ashing twice.
Press and hold for 3 seconds to disable the remote control,
indicated by the LED ashing just once.
-
S1 Signals the Metal Grease Filter saturation alarm, indicating that it
is necessary to wash the lters. The alarm is triggered after the
Hood has been in operation for 100 working hours.
Fixed.
When this is activated, it signals the Activated Charcoal Filter
saturation alarm, indicating that the lter must be changed; the
Metal Grease Filters must also be washed. The Activated Charcoal
Filter saturation alarm comes into operation after the Hood has
been working for 200 hours.
Flashing.

7
ENGLISH
5. REMOTE CONTROL
The appliance can be controlled using a remote
control powered by a 1.5 V carbon-zinc alkaline
batteries of the standard LR03-AAA type (not
included).
• Do not place the remote control near to
heat sources.
• Used batteries must be disposed of in the
proper manner.
Motor Motor On / Off
Decreases the
working speed each
time it is pressed.
Increases the
working speed each
time it is pressed.
Intensive Activates the Intensi-
ve function
--
Light Lights On / Off
6. LIGHTING
• For replacement contact technical support
(“To purchase contact technical support”).

This document sets out the terms and conditions of the product warranties for
AEG Appliances. It is an important document. Please keep it with your proof
of purchase documents in a safe place for future reference should there be a
manufacturing defect in your Appliance. This warranty is in addition to other
rights you may have under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the Competition and
Consumer Act 2010;
(b) ‘Appliance’ means any Electrolux product purchased by you and accompanied
by this document;
(c) ‘ASC’ means Electrolux’s authorised serviced centres;
(d) ‘AEG’ is the brand controlled by Electrolux Home Products Pty Ltd of 163
O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341 in respect of
Appliances purchased in Australia and Electrolux (NZ) Limited (collectively
“Electrolux”) of 3-5 Niall Burgess Road, Mount Wellington, in respect of
Appliances purchased in New Zealand;
(e) ‘Warranty Period’ means the period specified in clause 3 of this warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased the
Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased and used
in Australia or New Zealand and is in addition to (and does not exclude, restrict, or
modify in any way) other rights and remedies under a law to which the Appliances
or services relate, including any non-excludable statutory guarantees in Australia
and New Zealand.
3. Warranty Period: Subject to these terms and conditions, this warranty continues
for in Australia for a period of 60 months and in New Zealand for a period of 60
months, following the date of original purchase of the Appliance.
4. Repair or replace warranty: During the Warranty Period, Electrolux or its ASC
will, at no extra charge if your Appliance is readily accessible for service, without
special equipment and subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Electrolux may, in its absolute
discretion, choose whether the remedy oered for a valid warranty claim is repair
or replacement. Electrolux or its ASC may use refurbished parts to repair your
Appliance. You agree that any replaced Appliances or parts become the property
of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will bear the
reasonable cost of transportation, travel and delivery of the Appliance to and from
Electrolux or its ASC. Travel and transportation will be arranged by Electrolux as
part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this warranty.
7. Exclusions: You may not make a claim under this warranty unless the defect claimed
is due to faulty or defective parts or workmanship. This warranty does not cover:
(a) light globes, batteries, filters or similar perishable parts;
(b) parts and Appliances not supplied by Electrolux;
(c) cosmetic damage which does not aect the operation of the Appliance;
(d) damage to the Appliance caused by:
(i) negligence or accident;
(ii) misuse or abuse, including failure to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv) normal wear and tear;
(v) power surges, electrical storm damage or incorrect power supply;
(vi) incomplete or improper installation;
(vii) incorrect, improper or inappropriate operation;
(viii) insect or vermin infestation;
(ix) failure to comply with any additional instructions supplied with
the Appliance;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the Appliance
has been, used for purposes other than those for which the Appliance was
intended, including where the Appliance has
been used for any non-domestic purpose;
(b) the Appliance is modified without authority from Electrolux in writing;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced.
8. How to claim under this warranty: To enquire about claiming under this warranty,
please follow these steps:
(a) carefully check the operating instructions, user manual and the terms of
this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in Australia: Electrolux
goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
for compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the Appliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a major failure. ‘Acceptable
quality’ and ‘major failure’ have the same meaning as referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux in New
Zealand, the Appliances come with a guarantee by Electrolux pursuant to the
provisions of the Consumer Guarantees Act, the Sale of Goods Act and the Fair
Trading Act. Where the Appliance was purchased in New Zealand for commercial
purposes the Consumer Guarantee Act does not apply.
11. Confidentiality: You accept that if you make a warranty claim, Electrolux and
its agents including ASC may exchange information in relation to you to enable
Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
ALL AEG BRANDED APPLIANCES
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
FOR SERVICE
or to find the address of your nearest
authorised service centre in Australia
PLEASE CALL 1300 363 664
OR EMAIL
[email protected]
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
aeg.com/au
FOR SPARE PARTS
or to find the address of your nearest
spare parts centre in Australia
PLEASE 13 13 50
OR EMAIL
[email protected]
For the cost of a local call (Australia only)
FOR SERVICE
or to find the address of your nearest
authorised service centre in New Zealand
PLEASE CALL 0800 234 234
OR EMAIL [email protected]
(New Zealand only)
SERVICE NEW ZEALAND
aegnewzealand.co.nz
FOR SPARE PARTS
or to find the address of your nearest
spare parts centre in New Zealand
PLEASE 0800 10 66 20
OR EMAIL [email protected]
(New Zealand only)
AEG_Warr_May17

www.aeg.com/shop
991.0489.991_01 - 161123
D00XXXX_00
