AEG BE1003001 User manual

BE1003001
EN
OVEN USER MANUAL

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG
appliances looking spotless and working perfectly. Along with a wide range of
accessories designed and built to the high quality standards you would expect,
from specialist cookware to cutlery baskets, from bottle holders to delicate
laundry bags…
Visit the webshop at:
www.aeg.com/shop
2

CONTENTS
4 Safety information
5 Safety instructions
8 Product description
9 Before first use
10 Daily use
11 Clock functions
12 Using the accessories
12 Additional functions
13 Helpful hints and tips
21 Care and cleaning
24 What to do if…
25 Environment concerns
The following symbols are used in this user
manual:
Important information concerning your
personal safety and information on how to
avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice.
Contents 3

SAFETY INFORMATION
Before the installation and use of the appliance, carefully read the
supplied instructions. The manufacturer is not responsible if an incor-
rect installation and use causes injuries and damages. Always keep the
instructions with the appliance for future reference.
Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they are supervised by an adult
or a person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance when it operates
or when it cools down. Accessible parts are hot.
• If the appliance has a child safety device, we recommend that you
activate it.
• Cleaning and user maintenance shall not be made by children with-
out supervision.
General Safety
• Internally the appliance becomes hot when in operation. Do not
touch the heating elements that are in the appliance. Always use
oven gloves to remove or put in accessories or ovenware.
• Do not use a steam cleaner to clean the appliance.
• Before maintenance cut the power supply.
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean
the glass door since they can scratch the surface, which may result
in shattering of the glass.
• To remove the shelf supports first pull the front of the shelf support
and then the rear end away from the side walls. Install the shelf
supports in the opposite sequence.
4Safety information

SAFETY INSTRUCTIONS
Installation
WARNING!
Only a qualified person must install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied with the appliance.
• Always be careful when you move the appliance because it is heavy. Always wear safety
gloves.
• Do not pull the appliance by the handle.
• Keep the minimum distance from the other appliances and units.
• Make sure that the appliance is installed below and adjacent safe structures.
• The sides of the appliance must stay adjacent to appliances or to units with the same
height.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• All electrical connections should be made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical information on the rating plate agrees with the power sup-
ply. If not, contact an electrician.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and to the mains cable. Contact the
Service or an electrician to change a damaged mains cable.
• Do not let mains cables to come in touch with the appliance door, specially when the
door is hot.
• The shock protection of live and insulated parts must be fastened in such a way that it
cannot be removed without tools.
• Connect the mains plug to the mains socket only at the end of the installation. Make
sure that there is access to the mains plug after the installation.
• If the mains socket is loose, do not connect the mains plug.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses re-
moved from the holder), earth leakage trips and contactors.
• The electrical installation must have an isolation device which lets you disconnect the
appliance from the mains at all poles. The isolation device must have a contact opening
width of minimum 3 mm.
Safety instructions 5

Use
WARNING!
Risk of injury, burns or electric shock or explosion.
• Use this appliance in a household environment.
• Do not change the specification of this appliance.
• Make sure that the ventilation openings are not blocked.
• Do not let the appliance stay unattended during operation.
• Deactivate the appliance after each use.
• Internally the appliance becomes hot when in operation. Do not touch the heating ele-
ments that are in the appliance. Always use oven gloves to remove or put in accessories
or ovenware.
• Be careful, when you open the appliance door while the appliance is in operation. Hot air
can release.
• Do not operate the appliance with wet hands or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work surface or as a storage surface.
• Always keep the appliance door closed when the appliance is in operation.
• Open the appliance door carefully. The use of ingredients with alcohol can cause a mix-
ture of alcohol and air.
• Do not let sparks or open flames to come in contact with the appliance when you open
the door.
• Do not put flammable products or items that are wet with flammable products in, near
or on the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the enamel:
– Do not put ovenware or other objects in the appliance directly on the bottom.
– Do not put aluminium foil directly on the bottom of the appliance.
– do not put water directly into the hot appliance.
– do not keep moist dishes and food in the appliance after you finish the cooking.
– be careful when you remove or install the accessories.
• Discoloration of the enamel has no effect on the performance of the appliance. It is not
a defect in the sense of the warranty law.
• Use a deep pan for moist cakes. Fruit juices cause stains that can be permanent.
Care and Cleaning
WARNING!
Risk of injury, fire or damage to the appliance.
6Safety instructions

• Before maintenance, deactivate the appliance and disconnect the mains plug from the
mains socket.
• Make sure the appliance is cold. There is the risk that the glass panels can break.
• Replace immediately the door glass panels when they are damaged. Contact the Service.
• Be careful when you remove the door from the appliance. The door is heavy!
• Clean regularly the appliance to prevent the deterioration of the surface material.
• Remaining fat or food in the appliance can cause fire.
• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use
abrasive products, abrasive cleaning pads, solvents or metal objects.
• If you use an oven spray, obey the safety instructions on the packaging.
• Do not clean the catalytic enamel (if applicable) with any kind of detergent.
Internal light
• The type of light bulb or halogen lamp used for this appliance, is only for household ap-
pliances. Do not use it for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect the appliance from the power supply.
• Only use lamps with the same specifications.
Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children and pets to get closed in the appliance.
Safety instructions 7

PRODUCT DESCRIPTION
4 632 5
1
11
7
8
9
10
5
4
3
2
1
1Control panel
2Control knob for oven functions
3Power lamp/symbol
4Electronic programmer
5Control knob for temperature
6Temperature lamp/symbol/indicator
7Heating element
8Oven lamp
9Bottom heat
10 Shelf support, removable
11 Shelf positions
8Product description

Accessories
•Wire shelf
For cookware, cake tins, roasts.
•Combi pan
For cake and biscuits. To bake and roast or as
pan to collect fat.
BEFORE FIRST USE
WARNING!
Refer to "Safety information" chapter.
Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
Refer to chapter "Care and Cleaning".
Setting the time
The oven only operates after time set.
When you connect the appliance to the electrical
supply or in case of a power cut, the Time func-
tion indicator flashes automatically.
To set the current time use " +" or " - " button.
After approximately 5 seconds, the flashing stops
and the display shows the time of day set.
For time change you must not set an automatic
function (Duration or End ) at the same
time.
Before first use 9

DAILY USE
WARNING!
Refer to "Safety information" chapter.
Activating and deactivating the appliance
1. Turn the control knob for the oven functions to select an oven function.
2. Turn the control knob for the temperature to select a temperature.
3. To deactivate the appliance turn the control knobs for the oven functions and temper-
ature to off position.
Knob symbol, indicator or lamp (depends on the model - refer to the appliance
overview):
• The indicator comes on when the oven heats up.
• The lamp comes on when the appliance operates.
• The symbol shows whether the knob controls one of the cooking zones, the oven func-
tions or the temperature.
Oven Functions
Oven function Application
Light To activate the oven lamp without a cooking function.
Conventional Cooking To bake and roast on one oven level. The top and bottom
heating elements operate at the same time.
Top Heat To brown bread, cakes and pastries. To finish cooked dishes.
Only the top heating element operates.
Bottom Heat To bake cakes with crispy or crusty bottom. To preserve
food. Only the bottom heating element operates.
Grilling To grill flat food items in small quantities in the middle of
the shelf. To make toast.
Fast Grilling To grill flat food items in large quantities. To make toast.
The full grill element operates.
10 Daily use

Electronic programmer
1Function indicators
2Function indicators
3Time display
4Button "+"
5Selection button
6Button "-"
456
1 2 3 2
CLOCK FUNCTIONS
Clock function Application
Time of day Shows the time. To set, change or check the time.
Minute minder To set a countdown time.
A signal sounds, after the time period is completed.
This function has no effect on the operation of the oven.
Duration To set how long the oven has to be in operation.
End To set the switch-off time for an oven function.
Duration and End can be used at the same time, if the oven is to be switched on and
off automatically later. In this case first set Duration , then End .
Setting the clock functions
1. Set an oven function and temperature (necessary only for Duration and End).
2. Push the Selection button again and
again until necessary function indicator
flashes.
3. To set the time for Minute minder ,
Duration or End , use "+" or "-"
button.
The related function indicator comes on.
When the time period is completed, the
function indicator flashes and an acous-
tic signal sounds for 2 minutes.
With the functions Duration and End the oven stops automatically.
4. Push any button to stop the signal.
Clock functions 11

5. Turn the oven functions control knob and the temperature control knob to off posi-
tion.
Cancelling the clock functions
1. Push the Selection button again and again until necessary function indicator flashes.
2. Push and hold button "-".
After some seconds the clock function goes out.
USING THE ACCESSORIES
WARNING!
Refer to "Safety information" chapter.
Installing the Oven Accessories
The deep pan and the wire shelf have side edges.
These edges and the shape of the guide-bars cau-
ses the anti-tilt safety for the oven accessories.
Installing the wire shelf and the deep pan to-
gether
Put the wire shelf on the deep pan. Push the deep
pan between the guide-bars of one of the oven
levels.
ADDITIONAL FUNCTIONS
Cooling fan
When the appliance operates, the cooling fan activates automatically to keep the surfaces
of the appliance cool. If you deactivate the appliance, the cooling fan can continue to oper-
ate until the appliance cools down.
12 Using the accessories

HELPFUL HINTS AND TIPS
The temperature and baking times in the tables are guidelines only. They depend on the
recipes, quality and quantity of the ingredients used.
Baking
General instructions
• Your new oven may bake or roast differently to the appliance you had before. Adapt your
usual settings (temperature, cooking times) and shelf positions to the values in the ta-
bles.
• With longer baking times, the oven can be switched off about 10 minutes before the end
of baking time, to use the residual heat.
When you use frozen food, the trays in the oven can twist during baking. When the
trays get cold again, the distortion will be gone.
How to use the Baking Tables
• We recommend to use the lower temperature the first time.
• If you cannot find the settings for a special recipe, look for the one that is almost the
same.
• Baking time can be extended by 10 -15 minutes, if you bake cakes on more than one
level.
• Cakes and pastries at different heights do not always brown equally at first. If this oc-
curs, do not change the temperature setting. The differences equalize during the baking
procedure.
Tips on baking
Baking results Possible cause Remedy
The cake is not browned
enough underneath. Wrong shelf position. Place the cake lower.
The cake sinks (becomes soggy,
lumpy, streaky).
The oven temperature is too
high.
The next time you bake set a
slightly lower oven tempera-
ture.
The cake sinks (becomes soggy,
lumpy, streaky). The baking time is too short.
Set a longer baking time. Bak-
ing times cannot be reduced
by setting higher tempera-
tures.
The cake sinks (becomes soggy,
lumpy, streaky).
There is too much liquid in the
mixture.
Use less liquid. Pay attention to
mixing times, especially if you
use a mixing machine.
The cake is too dry. The oven temperature is too
low.
The next time you bake set a
higher oven temperature.
The cake is too dry. The baking time is too long. The next time you bake set a
shorter baking time.
Helpful hints and tips 13

Baking results Possible cause Remedy
The cake browns unevenly.
The oven temperature is too
high and the baking time is too
short.
Set a lower oven temperature
and a longer baking time.
The cake browns unevenly. The mixture is unevenly distrib-
uted.
Spread the mixture evenly on
the baking tray.
The cake is not ready in the
baking time given.
The oven temperature is too
low.
The next time you bake set a
slightly higher oven tempera-
ture.
Baking in tins
Type of baking Oven function Shelf position Temperature °C Time in min.
Ring cake or brio-
che
Conventional
Cooking 1160 -180 50 -70
Madeira cake /
fruit cakes
Conventional
Cooking 1150 -170 70 -90
Fatless sponge
cake / Fatless
sponge cake
Conventional
Cooking 2160 -180 30 -45
Flan base -short
pastry
Conventional
Cooking 2190 -210
1)
10 -25
Flan base -
sponge mixture
Conventional
Cooking 2170 -190 20 -25
Apple pie / Apple
pie (2 tins Ø 20
cm, diagonally off
set)
Conventional
Cooking 1180 70 -90
Savoury flan (e. g,
quiche lorraine)
Conventional
Cooking 1180 -200 40 -60
Cheesecake Conventional
Cooking 1160 -180 60 -90
1) Preheat the oven
Cakes / pastries / breads on baking trays
Type of baking Oven function Shelf position Temperature °C Time in min.
Plaited bread /
bread crown
Conventional
Cooking 2170 -190 40 -50
Christmas stollen Conventional
Cooking 2160 -180
1)
50 -70
14 Helpful hints and tips

Type of baking Oven function Shelf position Temperature °C Time in min.
Bread (rye
bread):
1. First part of
baking proc-
ess.
2. Second part
of baking
process.
Conventional
Cooking 11. 230
1)
2. 160 -180
1. 25
2. 30 -60
Cream puffs /
eclairs
Conventional
Cooking 3190 -210
1)
20 -35
Swiss roll Conventional
Cooking 3180 -200
1)
10 -20
Cake with crum-
ble topping (dry)
Conventional
Cooking 3150 -160 20 -40
Buttered almond
cake / sugar cakes
Conventional
Cooking 3190 -210
1)
15 -30
Fruit flans (made
with yeast
dough / sponge
mixture)
2)
Conventional
Cooking 3170 35 -50
Fruit flans made
with short pastry
Conventional
Cooking 3170 -190 40 -60
Yeast cakes with
delicate toppings
(e.g.
quark,cream,cus-
tard)
Conventional
Cooking 3160 -180
1)
20 -40
Pizza (with a lot
of topping)
2)
Conventional
Cooking 1180 -200
1)
30 -50
Pizza (thin crust) Conventional
Cooking 1220 -250
1)
15 -25
Unleavened bread Conventional
Cooking 1230 -250 10 -15
Tarts (CH) Conventional
Cooking 1210 -230 35 -50
1) Preheat the oven
2) Use deep pan
Biscuits
Type of baking Oven function Oven level Temperature °C Time in min.
Short pastry bis-
cuits
Conventional
Cooking 3170 -190 10 -20
Helpful hints and tips 15

Type of baking Oven function Oven level Temperature °C Time in min.
Short bread /
Short bread / Pas-
try Stripes
Conventional
Cooking 3160
1)
20 -30
Biscuits made
with sponge
dough
Conventional
Cooking 3170 -190 20 -30
Pastries made
with egg white,
meringues
Conventional
Cooking 380 -100 120 -150
Macaroons Conventional
Cooking 3120 -130 30 -60
Biscuits made
with yeast dough
Conventional
Cooking 3170 -190 20 -40
Puff pastries Conventional
Cooking 3190 -210
1)
20 -30
Rolls Conventional
Cooking 3190 -210
1)
10 -25
Small cakes /
Small cakes (20
per tray)
Conventional
Cooking 3170
1)
20 -30
1) Preheat the oven
Bakes and gratins table
Dish Oven function Shelf position Temperature (°C) Time (min)
Pasta bake Conventional
Cooking 1180 -200 45 -60
Lasagne Conventional
Cooking 1180 -200 35 -50
Vegetables au
gratin
1)
Conventional
Cooking 1180 -200 15 -30
Baguettes topped
with melted
cheese
11)
Conventional
Cooking 1200 -220 15 -30
Sweet bakes Conventional
Cooking 1180 -200 40 -60
Fish bakes Conventional
Cooking 1180 -200 40 -60
Stuffed vegeta-
bles
Conventional
Cooking 1180 -200 40 -60
1) Preheat the oven
16 Helpful hints and tips

Bakes and gratins table
Dish Oven function Shelf position Temperature (°C) Time (min)
Pasta bake Conventional
Cooking 1180 -200 45 -60
Lasagne Conventional
Cooking 1180 -200 35 -50
Vegetables au
gratin
1)
Conventional
Cooking 1180 -200 15 -30
Baguettes topped
with melted
cheese
11)
Conventional
Cooking 1200 -220 15 -30
Sweet bakes Conventional
Cooking 1180 -200 40 -60
Fish bakes Conventional
Cooking 1180 -200 40 -60
Stuffed vegeta-
bles
Conventional
Cooking 1180 -200 40 -60
1) Preheat the oven
Roasting
Roasting dishes
• Use heat-resistant ovenware to roast (please read the instructions of the manufacturer).
• Large roasting joints can be roasted directly in the deep pan (if present) or on the wire
shelf above the deep pan.
• Roast lean meats in a roasting tin with a lid. This will keep the meat more succulent.
• All types of meat, that can be browned or have crackling, can be roasted in the roasting
tin without the lid.
Roasting with Conventional Cooking
Beef
Type of meat Quantity Oven func-
tion
Shelf position Temperature
(°C)
Time (min)
Pot roast 1 -1.5 kg Conventional
Cooking 1200 -230 105 -150
Roast beef or
fillet: rare
per cm of
thickness
Conventional
Cooking 1230 -250
1)
6 -8
Roast beef or
fillet: medium
per cm of
thickness
Conventional
Cooking 1220 -230
1)
8 -10
Roast beef or
fillet: well
done
per cm of
thickness
Conventional
Cooking 1200 -220
1)
10 -12
1) Preheat the oven
Helpful hints and tips 17

Pork
Type of meat Quantity Oven func-
tion Shelf position Temperature (°C) Time (min)
Shoulder,
neck, ham
joint
1 -1.5 kg Conventional
Cooking 1210 -220 90 -120
Chop, spare
rib 1 -1.5 kg Conventional Cooking 1180 -190 60 -90
Meat loaf 750 g -1 kg Conventional
Cooking 1170 -190 50 -60
Porkknuckle
(precooked) 750 g -1 kg Conventional Cooking 1200 -220 90 -120
Veal
Type of meat Quantity Oven func-
tion Shelf position Temperature (°C) Time (min)
Roast veal 1 kg Conventional
Cooking 1210 -220 90 -120
Knuckle of
veal 1.5 -2 kg Conventional Cooking 1200 -220 150 -180
Lamb
Type of meat Quantity Oven func-
tion Shelf position Temperature (°C) Time (min)
Leg of lamb,
roast lamb 1 -1.5 kg Conventional Cooking 1210 -220 90 -120
Saddle of
lamb 1 -1.5 kg Conventional Cooking 1210 -220 40 -60
Game
Type of meat Quantity Oven func-
tion Shelf position Temperature (°C) Time (min)
Saddle of
hare, leg of
hare
up to 1 kg Conventional
Cooking 1220 -240
1)
30 -40
Saddle of ven-
ison 1.5 -2 kg Conventional Cooking 1210 -220 60 -90
Haunch of
venison 1.5 -2 kg Conventional Cooking 1200 -210 90 -120
1) Preheat the oven
18 Helpful hints and tips

Poultry
Type of meat Quantity Oven func-
tion Shelf position Temperature (°C) Time (min)
Poultry por-
tions
200 -250 g
each
Conventional
Cooking 1220 -250 20 -40
Half chicken 400 -500 g
each
Conventional
Cooking 1220 -250 35 -50
Chicken, pou-
lard 1 -1.5 kg Conventional Cooking 1220 -250 50 -70
Duck 1.5 -2 kg Conventional
Cooking 1210 -220 80 -100
Goose 3.5 -5 kg Conventional
Cooking 1200 -210 150 -180
Turkey 2.5 -3.5 kg Conventional
Cooking 1200 -210 120 -180
Turkey 4 -6 kg Conventional
Cooking 1180 -200 180 -240
Fish
Type of meat Quantity Oven func-
tion Shelf position Temperature (°C) Time (min)
Whole fish 1 -1.5 kg Conventional
Cooking 1210 -220 40 -70
Grilling
Always grill with the maximum temperature setting.
Set the shelf into the shelf position as recommended in the grilling table.
Always set the pan to collect the fat into the first shelf position.
Grill only flat pieces of meat or fish.
Always preheat the empty oven with the grill functions for 5 minutes.
CAUTION!
Always grill with the oven door closed.
Grilling
Food to be gril-
led Shelf position Temperature Time in min.
1st side 2nd side
Roast beef 2210 -230 30 -40 30 -40
Filet of beef 3230 20 -30 20 -30
Back of pork 2210 -230 30 -40 30 -40
Back of veal 2210 -230 30 -40 30 -40
Back of lamb 3210 -230 25 -35 20 -25
Helpful hints and tips 19

Food to be gril-
led Shelf position Temperature Time in min.
1st side 2nd side
Whole Fish, 500 -
1000 g 3 / 4 210 -230 15 -30 15 -30
Fast Grilling
Food to be grilled Shelf position Time in min.
1st side 2nd side
Burgers / Burgers 48 -10 6 -8
Pork fillet 410 -12 6 -10
Sausages 410 -12 6 -8
Fillet steaks, veal steaks 47 -10 6 -8
Toast / Toast
1)
51 -3 1 -3
Toast with topping 46 -8 -
1) Preheat the oven
Preserving - Bottom Heat
Things to note:
• Use only preserve jars of the same dimensions available on the market.
• Do not use jars with twist-off and bayonet type lids, or metal tins.
• Use the first shelf from the bottom for this function.
• Put no more than six one-litre preserve jars on the baking tray.
• Fill the jars up to the same level and close with a clamp.
• The jars cannot touch each other.
• Put approximately 1 / 2 litre of water into the baking tray to give sufficient moisture in
the oven.
• When the liquid in the jars starts to simmer (after approx. 35 -60 minutes with one-litre
jars), stop the oven or decrease the temperature to 100°C (see the table).
Soft fruit
Preserve Temperature in °C Cooking time until
simmering in min.
Continue to cook at
100°C in mis.
Strawberries, blueber-
ries, raspberries, ripe
gooseberries
160 -170 35 -45 -
Stone fruit
Preserve Temperature in °C Cooking time until
simmering in min.
Continue to cook at
100°C in min.
Pears, guinces, plums 160 -170 35 -45 10 -15
20 Helpful hints and tips
