AEG DK 9160 User manual

DK 9160-9190
DK 9360-9390
DK 9660-9690
DK 9960-9990
HC 5690-3360
Dunstabzugshaube
Afzuigkap
Hotte
Cooker Hood
Montage- und Gebrauchsanweisung
Installatie- en gebruiksaanwijzing
Notice d utilisation et d installation
Operating and Installation Instructions
Get other manuals https://www.bkmanuals.com

62
Contents
Printed on recycled paper
AEG - putting words into action
Safety warnings .............................................................................. 63
For the user ...................................................................................... 63
For the installer ................................................................................. 63
Description of the Appliance ......................................................... 65
Extractor ersion ............................................................................... 65
Filter Version ..................................................................................... 65
Control Panel
DK 9160 - DK 9190 - DK 9360 - DK 9390 - HC 3360 ......................... 66
Control Panel
DK 9660 - DK 9690 - HC 5690 .......................................................... 67
Control Panel
DK 9960 - DK 9990 ........................................................................... 68
Control device for grease and charcoal filters
DK 9660 - DK 9690 - DK 9960 - DK 9990 - HC 5690 ......................... 70
Maintenance and care ................................................................... 71
Cleaning the hood ............................................................................. 71
Metal grease filter ............................................................................. 71
Remo ing the metal grease filter........................................................ 71
Charcoal filter .................................................................................... 72
Changing the light bulb ...................................................................... 73
What to do if ................................................................................... 74
Special accessories........................................................................ 75
Technical assistance service ......................................................... 75
Technical Details ............................................................................ 76
Mounting accessories included ..................................................... 76
Electrical connection ..................................................................... 77
Wall unit mounting ............................................................................ 78
Get other manuals https://www.bkmanuals.com

63
Safety warnings
For the user
 The cooker hood is designed to extract unpleasant odours from the
kitchen, it will not extract steam.
 Always co er lighted elements, to pre ent excess heat from
damaging the appliance. In the case of oil, gas and coal fired
cookers it is essential to a oid open flames.
 Also, when frying, keep the deep frying pan on the cooker top/
cooker under careful control.
 The hot oil in the frying pan might ignite due to o erheating.
 The risk of self-ignition increases when the oil being used is dirty.
 It is extremely important to note that o erheating can cause a fire.
Never carry out any flambé cooking under the hood.
Always disconnect the unit from the power supply before
carrying out any work on the hood, including replacing the
light bulb (take the cartridge fuse out of the fuse holder or switch
off the automatic circuit breaker).
It is very important to clean the hood and replace the filter at
the recommended intervals. Failure to do so could cause
grease deposits to build up, resulting in a fire hazard.
 The appliance is not intended for use by young children or infirm
persons without super ision.
 Young children should be super ised to ensure that they do not play
with the appliance.
 WARNING Ensure that the appliance is switched off before
replacing the lamp to a oid the possibility of electric shock.
For the insta er
 When used as an extractor unit, the hood must be fitted with a
150mm diameter hose.
 Should there already be a pipe of diameter 125 or 120 mm that
ducts to the outside through the walls or roof, it is possible to use
the 150/125-120 mm reduction flange pro ided.
In this case the hood will be slightly noisier.
When installing the hood, make sure you respect the following
minimum distance from the top edge of the cooking hob/ring
surfaces:
electric hobs 500 mm
gas hobs 650 mm
coal and oil cookers 700 mm min.
Get other manuals https://www.bkmanuals.com

64
 The national Standard on fuel-burning systems specifies a maximum
depression of 0.04 mbar in such rooms.
 The air outlet must not be connected to chimney flues or combus-
tion gas ducts. The air outlet must under no circumstances be
connected to entilation ducts for rooms in which fuel-burning
appliances are installed.
 The air outlet installation must comply with the regulations laid down
by the rele ant authorities.
 When the unit is used in its extractor ersion, a sufficiently large
entilation hole must be pro ided, with dimensions that are approxi-
mately the same as the outlet hole.
 National and regional building regulations impose a number of
restrictions on using hoods and fuel-burning appliances connected
to a chimney, such as coal or oil room-heaters and gas fires, in the
same room.
 Hoods can only be used safely with appliances connected to a
chimney if the room and/or flat (air/en ironment combination) is
entilated from outside using a suitable entilation hole approxi-
mately 500-600 cm2 large to a oid the possibility of a depression
being created during operation of the hood.
 If you ha e any doubts, contact the rele ant controlling authority or
building inspectors office.
 Since the rule for rooms with fuel burning appliances is outlet hole
of the same size as the entilation hole, a hole of 500-600 cm2,
which is to say a larger hole, could reduce the performance of the
extractor hood.
 If the hood is used in its filtering function, it will operate simply and
safely in the abo e conditions without the need for any of the
aforementioned measures.
 When the hood is used in its extractor function, the following rules
must be followed to obtain optimal operation:
 short and straight outlet hose
 keep bends in outlet hose to a minimum
 ne er install the hoses with an acute angle, they must always
follow a gentle cur e.
 keep the hose as large as possible (preferably the same diam-
eter as the outlet hole).
 Failure to obser e these basic instructions will drastically reduce the
performance and increase the noise le els of the extractor hood.
Get other manuals https://www.bkmanuals.com

65
Description of the Appliance
 The hood is supplied as an extractor unit and
can also be used with a filtering function
by fitting one charcoal filter.
 You will need an original AEG charcoal
filter for this function (A ailable from your
local AEG Ser ice Force Centre).
Extractor version
 In this ersion fumes are extracted to the
outside ia a hose connected to the
coupling ring A. Fig. 1.
 In order to obtain the best performance
the hose should ha e a diameter equal
to the outlet hole.
 Should there already be a pipe of diameter 125 mm that ducts to
the outside through the walls or roof, it is possible to use the 150/
125 mm reduction flange pro ided. In this case the hood will be
slightly noisier.
Fi ter Version
 The air is filtered through an charcoal filter and returned to the
kitchen through the top grill of the outlet pipe.
 You will need an original AEG charcoal filter for the filtering function.
(See Special Accessories).
 Fix the deflector using 2 screws Ø 2,9x13 mm. Fig. 2.
 Optionally, the position of the chimney
elements can be changed.
When using the hood in the filter
ersion the chimney must be fixed at
the top, with the air outlet grill at the
side.
Fig. 1
Fig. 2
Get other manuals https://www.bkmanuals.com

66
Control Panel
 Best results are obtained by using a low speed for normal conditions
and a high speed when odours are more concentrated.
Turn the hood on a few minutes before you start cooking, you will
then get an under pressure in the kitchen. The hood should be left
on after cooking for about 15 minutes or until all the odours ha e
disappeared. The control switches are located on the units front
panel:
DK 9160 D - 9190 D
the light switch switches the hood lamp on and off
 the motor switch switches the motor on and off, enabling you to
select one of the three different speeds.
Light switch Motor switch
DK 9360 - DK 9390 - HC 3360
the light switch switches the hood lamp on and off
the motor switch switches the motor off
 Speed 1: Speed 1 push-button
 Speed 2: Speed 2 push-button
 Speed 3: Speed 3 push-button
Light switch
Motor switch Speed 1 Speed 2
Speed 3
Get other manuals https://www.bkmanuals.com

67
Control Panel
DK 9660 - DK 9690 - HC 5690
 Best results are obtained by using a low speed for normal conditions
and a high speed when odours are more concentrated.
Turn the hood on a few minutes before you start cooking, you will
then get an under pressure in the kitchen. The hood should be left
on after cooking for about 15 minutes or until all the odours ha e
disappeared. The control switches are located on the units front
panel:
A- OFF  ON push button
Press once or more to obtain the function desired:
ON: the hood switches on to the last speed selected.
OFF: all the functions are switched off except the illumination.
B - Speed selection push button (extraction power).
Press this push button once or more to select the most suitable
extraction speed (power) (1-2-3).
C - The display shows the extraction power selected, signalling the
saturation of the filters (F).
D- Intensi e speed on/off. The Intensi e speed runs for 5 minutes:
If the hood is on when the Intensi e speed is acti ated, the hood
re erts to pre ious speed after 5 minutes.
If the hood is off when the Intensi e speed is acti ated, the hood
will be turned off after 5 minutes.
To interrupt the Intensi e speed, press button A or B.
H- Light ON/OFF
Should the hood or the controls fail to operate: disconnect the power
supply for at least 5 seconds, then turn the hood back on again.
i
AB CDE
Get other manuals https://www.bkmanuals.com

68
Control Panel
DK 9960 - DK 9990
 Best results are obtained by using a low speed for normal conditions
and a high speed when odours are more concentrated.
Turn the hood on a few minutes before you start cooking, you will
then get an under pressure in the kitchen. The hood should be left on
after cooking for about 15 minutes or until all the odours ha e
disappeared. The control switches are located on the units front
panel:
A- ON (stand-by - illuminated key) / OFF push button.
Press once or more to obtain the function desired:
Stand-by (illuminated push button): the hood is ready to function,
the safety procedure is acti ated (see under  safety procedu
re).
OFF: all the functions are switched off except the illumination.
B - Speed selection push button (extraction power).
Press this push button once or more to select the most suitable
extraction speed (power) (1 2 3 i).
Attention: the i (intensi e) speed is limited to a few minutes after
which the system automatically sets itself to speed 2.
C - The display indicates the selected extraction power (1-2-3-i) and
signals the saturation of the filters (F).
D - Manual function selection push button (OFF)/automatic
(sensors  ON).
In automatic function (ON) the hood enters into function
(extraction) on the basis of the change in the normal
environmental conditions that the hood notices through its
sensors.
The display shows the extraction speed (power) set.
Attention! The hood is equipped with an automatic system that
establishes what the normal en ironmental conditions are.
SENSOR
AB CDE
Get other manuals https://www.bkmanuals.com

69
In the case of abnormal operation, calibration can be carried out
manually:
Manual calibration
Carry out manual calibration in the following cases:
When the hood is installed for the first time.
When power is cut off for many hours or days (e.g. during
prolonged holidays).
When a ery rapid change in temperature and/or humidity in the
kitchen takes place.
Carry out calibration with the hob off, at normal ambient tempera-
ture and in the absence of an appreciable amount of steam:
- press push button A and set the hood OFF (A key OFF)
- press push buttons A and D simultaneously for 3 secs. The
hood emits a sound signal to indicate calibration taking place.
Sensors test
When functioning in automatic, the system continuously tests the
efficiency of the sensors. In case of damage, it signals the fault,
making the D push button flash the word SENSOR. Contact
technical assistance.
In this situation the hood can, in any case, be used in the manual
mode.
Safety procedure
Self-acti ation of automatic SAFETY functioning in particular
conditions: if the sensors reveal an excessive increase in
temperature, e en if the hood is in manual functioning mode,
the system self selects automatic functioning and the extraction
motor starts. The hood can be turned off by pressing push button A.
H- Light ON/OFF
Should the hood or the controls fail to operate: disconnect the power
supply for at least 5 seconds, then turn the hood back on again.
Get other manuals https://www.bkmanuals.com

70
Contro device for grease and charcoa fi ters
DK 9660 - DK 9690 - DK 9960 - DK 9990 - HC 5690
This hood is fitted with a de ice that signals when it is necessary to
clean the grease filter or the charcoal filter (if the hood is used in the
recirculation ersion with a charcoal filter).
On deli ery, the hood is not supplied with a charcoal filter, so the
saturation indicator will be disabled.
If the hood is to be used with a charcoal filter, the saturation
indicator light must be enabled as follows:
Pressing keys B and D simultaneously for three seconds, LED F lights
up and begins to flash the 1st speed led. After 1 second the 2nd speed
led also flashes and the system emits a sound signal (-Beep-) to
indicate setting taking place.
To remo e the charcoal filter signal press push buttons B and D
simultaneously for 3 seconds. LED F lights up and begins to flash the
1st speed led (grease filter) and the 2nd speed led. After 1 second, only
the 1st speed led continues to flash. The system emits a sound signal
(-Beep-) to indicate setting taking place.
Grease filter LED
The 1st speed led (+ led F) flashes, when it is time to clean the grease
filter.
Always comply with the maintenance instructions for the grease filter.
Charcoal filter LED
The 2nd speed led (+ led F) flashes, when the charcoal filter needs to
be cleaned or replaced.
Resetting the saturation indicator
After cleaning or replacing the filters, press button 1 for 3 seconds until
the 1st speed led or the second speed led stops flashing.
The F LED also turns off..
Warning! The resetting of the saturation indicator MUST be done in
stand-by, ne er disconnect the hood from the mains.
Get other manuals https://www.bkmanuals.com

71
Maintenance and care
The hood must always be disconnected from the electricity
supply before beginning any maintenance work.
C eaning the hood
 Clean the outside of the hood using a damp cloth and a mild deter-
gent.
 Ne er use corrosi e, abrasi e or flammable cleaning products.
 Ne er insert pointed objects in the motors protecti e grid.
 Wash the outside surfaces using a delicate detergent solution.
Ne er use caustic detergents or abrasi e brushes or powders.
 Only e er clean the switch panel and filter grille using a damp cloth
and delicate detergents.
 It is extremely important to clean the unit and change the filters at
the recommended inter als. Failure to do so will cause grease
deposits to build up that could constitute a fire hazard.
Meta grease fi ter
 The purpose of the grease filters is to absorb grease particles which
form during cooking and it must always be used, either in the
external extraction or internal recycling function.
Attention: the metal grease filters must be remo ed and washed,
either by hand or in the dishwasher, e ery four weeks.
Removing the meta grease fi ter
 First, push the metal grease filter stop backwards, then extract the
filter, pulling downwards. Fig. 3.
Hand washing
Soak grease filters for about one hour in hot water with a little
washing-up liquid, then rinse off
thoroughly with hot water. Repeat the
process if necessary. Refit the grease
filters when they are dry.
Dishwasher
Place grease filters in the
dishwasher. Select most
powerful washing
programme and highest
temperature, at least 65°C.
Repeat the process. Refit
the grease filters when
they are dry.
When washing the metal grease filter in the dishwasher a slight
discolouration of the filter can occur, this does not ha e any impact
on its performance.
 Clean the inner housing using a hot detergent solution only (ne er
use caustic detergents, abrasi e powders or brushes).
Fig. 3
Get other manuals https://www.bkmanuals.com

72
Charcoa fi ter
 The charcoal filter should only be used if you want to use the hood in
the recirculation function.
 To do this you will need an original AEG charcoal filter (a ailable
from your local Ser ice Force Centre).
Cleaning/replacing the charcoal filter
Unlike other carbon filters, the LONGLIFE carbon filter can be cleaned
and reacti ated. At normal use the filter should be cleaned e ery
second month (when using the hood 2,5 hours per day, in a arage).
The best way to clean the filter is in the dishwasher. Use normal
detergent and choose the highest temperature (65º C). Wash the filter
separately so that no food parts gets stuck on the filter and later
causes bad odours. To reacti ate the charcoal, the filter should be dried
in an o en for 10 minutes with a temperature of maximum 100º C.
After approximately three years of use, the charcoal filter should be
replaced with a new, as the odour reduction capacity will be reduced.
Mounting Fig. 4
Put the charcoal filter frame in place and fix it with 5 screws.
Fit the charcoal filter first from the rear side and fix it frontwards
using the two red keys A.
To remove proceed in the re erse order.
 Always specify the hood model code number and serial number
when ordering replacement filters. This information is shown on the
registration plate located on the inside of the unit.
 The charcoal filter can be ordered from your local AEG Ser ice
Force Centre.
Fig. 4
Get other manuals https://www.bkmanuals.com

73
Warning
 Failure to obser e the instructions on cleaning the unit and changing
the filters will cause a fire hazard. You are therefore strongly
recommended to follow these instructions.
 The manufacturer declines all responsibility for any damage to the
motor or any fire damage linked to inappropriate maintenance or
failure to obser e the abo e safety recommendations.
Changing the ight bu b
 Disconnect the cooker hood from the mains supply.
DK 9160 D DK 9190 D
 Remo e the lamp co er. Fig. 5.
 Replace the old bulb with a new
one of the same type.
 Remount the lamp co er.
DK 9360 DK9390 DK 9660 HC 5690
DK 9690 DK 9960 DK9990 HC 3360
 Press (1) the lamp co er (2) and
open it. Fig. 6.
 Replace the old bulb with a new
one of the same type (3).
 Close the lamp co er.
 If the light does not come on,
make sure the bulb has been
inserted correctly before
contacting your local Ser ice
Force Centre.
3
1
2
Fig. 6
1
2
Fig. 5
Get other manuals https://www.bkmanuals.com

74
What to do if
If your appliance fails to work properly please carry out the following
checks.
Symptom Solution
The cooker hood will not start... Check that:
The hood is connected to
the electricity supply.
Check that a fan speed has
been selected
The cooker hood is not working Check that:
effecti ely.. The fan speed is set high
enough for the task.
The grease filters are clean.
The kitchen is adequately ented
to allow the entry of fresh air.
If set up for recirculation, check
that the charcoal filter is still
effecti e.
If set up for extraction, check that
the ducting and outlets are not
blocked.
The cooker hood has The safety cut-out de ice has been
switched off during operation... tripped.
Turn off the hob and then wait for
the de ice to reset.
If the hood has been installed
below the heights indicated in the
installation instructions the motor
will cut-out frequently which will
damage the hood.
If after all these checks, the problem persists, contact your local
Ser ice Force Centre, quoting the model and serial number.
Please note that it will be necessary to pro ide proof of purchase for
any in-guarantee ser ice calls.
In-guarantee customers should ensure that the abo e checks ha e
been made as the engineer will make a charge if the fault is not a
mechanical or electrical breakdown.
Get other manuals https://www.bkmanuals.com

75
Special accessories
Charcoal KF8 E-Nr. 942 118 648
Technica assistance service (not for UK)
You are welcome to telephone our technical assistance ser ice (see list
of technical assistance centres) whene er you need information or in
the unlikely e ent of a fault.
For ser ice in Australia call 1300 650 020.
When calling, please be ready to specify:
1. The model code number
2. The serial number (E Nr.)
3. The manufacturing number (F Nr.)
This information is shown on the registration plate inside the unit
behind the grease filter.
We reser e the right to change specifications and colours as a result of
our policy of continuing technological de elopment.
Service and spare parts for UK
In the e ent of your appliance requiring ser ice, or if you wish to
purchase spare parts, contact your local AEG Ser ice Force Centre by
telephoning: 08705 929 929
Your telephone call will be automatically routed to the Ser ice Centre
co ering your post code area. For the address of your local Ser ice
Force Centre and further information about Ser ice Force, please isit
the website at www.ser iceforce.co.uk
Please ensure that you ha e read the section What to do if.... as the
engineer will make a charge if the fault is not a mechanical or electri-
cal breakdown e en the appliance is under warranty. Please note that
proof of purchase is required for in guarantee service calls.
Help us to help you
Please determine your type of enquiry before writing or telephoning.
When you contact us we need to know:
 Your name  Clear and concise details of the fault
 Address and post code  Name and model of the appliance*
 Telephone number  E number*
* This information can be found on the rating plate, which can be seen
when the grease filters are remo ed.
Get other manuals https://www.bkmanuals.com

76
Technical Details
Mounting accessories inc uded
6 wall plugs Ø 8 mm (brick fixing only)
6 wood-screws 5 x 45 mm
2 metal screws 2,9 x 13
4 metal screws 2,9 x 6,5
5 metal screws 3,5 x 9,5
2 hooks
1 chimney support
2 clamps
1 deflector
1 reduction flange Ø 150-125 mm
1 charcoal filter frame
1 allen spanner
1 tube (DK 9960- DK 9990)
Models Dimensions - (in cm) Maximum Motor Lighting Length Electrical
Height Width Depth absorbed power of the cable connection
power
DK 9160 80-135 59,8 47 170 W 1 x 170W 1x11W (PL) 180 cm 220-240 V
DK 9190 82-137 89,8 48 170 W 1 x 170W 1x11W (PL) 180 cm 220-240 V
DK 9360 80-135 59,8 47 200 W 1 x 170W 2x20W (G4) 150 cm 220-240 V
HC 3360
DK 9390 82-137 89,8 48 200 W 1 x 170W 2x20W (G4) 150 cm 220-240 V
DK 9660 80-135 59,8 47 290 W 1 x 250W 2x20 W (G4) 150 cm 220-240 V
HC5690
DK 9690 82-137 89,8 48 290 W 1 x 250W 2x20 W (G4) 150 cm 220-240 V
DK 9960 80-135 59,8 47 290 W 1 x 250W 2x20 W (G4) 150 cm 220-240 V
DK 9990 82-137 89,8 48 290 W 1 x 250W 2x20 W (G4) 150 cm 220-240 V
Get other manuals https://www.bkmanuals.com

77
Electrical connection (not for UK)
Safety warnings for the e ectrician
Before connecting the appliance to the power supply, check that the
oltage indicated on the rating plate corresponds to the mains power
supply a ailable. Appliances fitted with a plug can be connected to
any standard power socket within easy access.
Should it be necessary to pro ide a fixed connection, the hood must
only be installed by an electrician authorised by the local electricity
board. When installing, an omnipolar disconnector with a distance of
at least 3 mm between contacts must be pro ided.
Fixed connection of the appliance must only be carried out by an
authorised electrician.
Electrical connection for UK only
Safety warnings for the e ectrician
Connect the hood to the mains supply ia a double pole switch
which has 3 mm minimum separation between the contacts.
The switch must be accessible at all times.
The following is alid in the United Kingdom only:
- the wire which is coloured green and yellow must be connected to
the terminal which is marked with the letter E or by the earth symbol
( ), or coloured green or green and yellow;
- the wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black, -
- the wire which is coloured brown must be connected to the terminal
which is marked with the letter L or coloured red.
Get other manuals https://www.bkmanuals.com

78
Wa unit mounting - Fig. 7
Position the template on the wall (1) and mark the position, and drill
(2) the holes (2 x Ø 8 mm).
Mount the two wall plugs with the hooks (3).
Hang the hood on the hooks and le el it with the adjustment screws
(4).
Remo e the grease filters (5) and mark for the two screws (6).
Remo e the hood and drill the holes (2 x Ø 8 mm).
Insert the rawl plugs (7) and hang the hood on the wall again. Adjust
it with the screws (8) and secure it with the screws (9).
Mount the chimney support (10) with the wall plugs (9) and the
screws (11). Be careful that it is centered o er the hood and
horizontally aligned.
 Extractor version (S): Connect a tube between the hood air outlet
and the wall or roof exhaust channel. Fix it with the tube clamps
supplied.
Filter version (K): Mount the deflector with the two screws supplied
(2,9x13 mm) (13).
Make the electrical connection (14) (see pre ious page)
Place the chimney (15) and fix it to the top chimney support with the
two screws (16) supplied (2,9x6,5 mm). Lower the bottom part of
the chimney (17) and fasten it to the top of the hood with two
screws, supplied (18) (2,9x6,5 mm).
Get other manuals https://www.bkmanuals.com

79
Electric hob 500 mm
Gas hob 650 mm
Fig. 7
Get other manuals https://www.bkmanuals.com

80
Exhaust tube
Power outlet
Electric hob 500 mm
Gas hob 650 mm
240
22
599-899
350
270
330
Wall bracket
Electric hob 500 mm
Gas hob 650 mm
DK 9190
DK 9390
DK 9690
DK 9990
HC5690
DK9160
DK9360
DK9660
DK9960
HC3360
Get other manuals https://www.bkmanuals.com
