AEG Perfekt Insert?24 User manual






PerfektInsert‐24,PerfektInsert‐30,PerfektInsert‐36
RangeHoodInstructionManual

























Thankyouforthepurchaseofthisproduct.Pleasereadthe
manualcarefullybeforeoperatingtheappliance.


1|Page


Contents

ImportantSafetyInstructions2
Introduction3
Features3
Installation4‐5
HowtoUse
GroundingInstruction
6
7
SafetyInformation8
TroubleShooting9
ElectricalDiagram10
Specifications11
Cleaning&Maintenance12
InstallationDiagram13
Warranty14








14|Page



Warranty

AEGAppliancesareimportedanddistributedinNorth
AmericabyEuro‐LineAppliancesInc.
Formoreinformationvisitwww.euro‐line‐appliances.com
orcontact:

2278SpeersRoad
Oakville,ONL6L2X8
Canada

1‐800‐421‐6332–Euro‐LineAppliancesInc.
1‐800‐ELA‐WEST–Euro‐LineAppliancesWest

marketing@euro‐line‐appliances.com

AllAEGAppliancesarebackedbyacomprehensive2‐year
partandlabourwarranty.Informationonserviceandparts
availablefromEuro‐Partsat1‐800‐678‐8352





13|Page



InstallationDiagram




600,762,900mm
2|Page

ImportantSafetyInstructions

○Readandsavetheseinstrucons
○Warning‐Toreducetheriskoffireorelectricshock,do
notusethisfanwithanysolid‐statespeedcontroldevice.
○CAUTION:Forgeneralvenlatinguseonly.Donotuseto
exhausthazardousorexplosivematerialsandvapors.
○Warning‐Toreducetheriskofarangetopgreasefire:
Neverleavesurfaceunitsunattendedathighsettings.
Boiloverscausesmokingandgreasyspilloversthat
mayignite.Heatoilsslowlyonlowormediumsettings.
AlwaysturnhoodONwhencookingathighheator
whenflambéingfood(i.e.CrepesSuzette,Cherries
Jubilee,PeppercornBeefFlambé)
Cleanventilatingfansfrequently.Greaseshouldnotbe
allowedtoaccumulateonfanorfilter.
Useproperpansize.Alwaysusecookwareappropriate
forthesizeofthesurfaceelement.
○ Warning‐Toreducetheriskofinjurytopersonsinthe
eventofarangetopgreasefire,observethefollowing:
Smotherflameswithaclose‐fittinglid,bakingsheet,or
metaltray,andthenturnofftheburner.Becarefulto
preventburns.Iftheflamesdonotgooutimmediately,
evacuateandcallthefiredepartment.
Neverpickupaflamingpan‐youmaybeburned.
Donotusewater,includingwetdishclothsortowelsa
violentsteamexplosionmayresult.
UseanextinguisherONLYif:A)Youknowyouhavea
classABCextinguisher,andyoualreadyknowhowto
operateit.B)Thefireissmallandcontainedinthearea
whereitstarted.C)Thefiredepartmentisbeingcalled.
D)Youcanfightthefirewithyourbacktoanexit.



3|Page


Introduction

oThisappliancehasbeenmanufacturedwithmaterials
andprocessesthatrespecttheenvironment.Wehope
thatyouwillcontinuethisimportantconsiderationin
theoperationofthisapplianceandthedisposalofthe
packagingmaterials–thankyou.
oTheinstallationworkmustbeundertakenbya
qualifiedtechnicianexperiencedinrangehood
installation.Pleaseconnectthecorrectpowerrating
(seepage10)
oThemanufacturerdisclaimsallliabilityforanydamage
orinjurycausedasaresultofnotfollowinginstructions
forinstallationcontainedinthefollowingtext
oTheapplianceisnotintendedforusebyyoungchildren
orinfirmpersonswithoutsupervision
oYoungchildrenshouldbesupervisedtoensurethat
theydonotplaywiththeappliance
oThemaximumnumberofburnerscoveredbyarange
hoodshouldnotexceed5
oAnymodificationstotheappliance,electricwireand
plugisdangerousandvoidsthewarranty

Features

oThisapplianceismanufacturedfromtopquality
materials,andofferssuperbstreamlinedeffects
oWithhighsuctionpowerandlownoise,itisdesigned
toremovecookingfumesfromyourkitchenquietly
andeffectively

12|Page



Cleaning&Maintenance

1. Cleanthesurfaceofthehoodeveryweekwithmild
soapordetergent.Avoidsolvents,acid,alkali,scouring
padsorpowderthatcouldirreparablydamagethe
stainlesssteelsurface
2. Thegreasefiltersmaybewashedusingmildsoap,
detergentordegreasingagents
3. Thecharcoalfilterscannotbecleanedandmustbe
replacedgenerallyafter6monthsofuse


















11|Page



Specifications

Perfekt‐Insert‐24
PowerSupply115V,60Hz
RatedInputPower97W
LightingPower1x2W
MotorPower95W
Airflow300CFM
OutletDiameter150mm

Perfekt‐Insert‐30
PowerSupply115V,60Hz
RatedInputPower97W
LightingPower1x2W
MotorPower95W
Airflow300CFM
OutletDiameter150mm

Perfekt‐Insert‐36
PowerSupply115V,60Hz
RatedInputPower99W
LightingPower2x2W
MotorPower95W
Airflow300CFM
OutletDiameter150mm





4|Page

Pic1

Installation(ductisnotsupplied)

1. Therangehoodshouldbemounted
atadistanceof600mmfroman
electricorinductioncooktop,and
762mmaboveagascooktopfor
safetyandoptimumperformance.If
theinstructionsforinstallationofthe
gascooktopspecifyagreater
distance,thishastobetakeninto
account.(seepic1)Theexhaustairmust
notbedischargedintoachimneywhichisusedfor
exhaustingfumesfromotherappliancesburninggasor
otherfuels.







2. Toinstall,drill2holesofØ8mmonasturdywallandin
linewiththehood
3. Insertexpandingscrewsintotheholes
4. Fixdrillingtemplateonthewall(seepic2)
5. Theapplianceshouldbeembeddedintothewallunit
oranothersupport.Thisprocessshouldbecarriedout
by4screwssuitableforthekindofunitfollowingthe
instructionsforthedrillingoftheholesasshown(see
pic3)

600
–
762mm
FortheprovinceofBritishColumbia
ThebaseoftheAEGinserthoodismadeofstainlesssteelandusesa
stainlesssteelfilter.Therearenoplasticcomponentsonthelower
sideofthehood.Inaddition,thehousingofthemotorismetal.
Thesehoodsaretestedat24”abovegascooktopsintheproduction
testfacility.Atthisheight,ignitionisnotpossible.Thehoodscanbe
installed24”abovegascooktops.


5|Page





6. Attachtheducttotheonewayvalve,andconnectitto
thekitchenoutletvent(seepic4)
7. Ensurethatthewallthehoodistobeinstalledonis
sufficientlysturdytocarrytheweightofthehood.It
shouldbemountedlevelforbestperformance
8. Donotconnecttoacommonventwithanyother
appliancessuchasagasheater,waterheater,
washer/dryer,etc.
9. Theductshouldnotbebentmorethan120°fromthe
onewayvalveoutletinthekitchenvent
10. Makesurethattheelectricalcordisnotincontactwith
sharpedgesoftheappliance
11. Besurethattheplugisaccessibleafterinstallation





10|Page

saturated greaseresidueand
replaceaftercleaning

ElectricalDiagrams


Perfekt‐Insert‐24,Perfekt‐Insert‐30




Perfekt‐Insert‐36


115V,60Hz
115V,60Hz
L2
L2


9|Page




TroubleShooting

Ifanyproblemoccurs,pleasedetachtheplugfromthe
socketandcontactEuro‐Partsorasimilarlyqualified
personinordertoavoidahazard.

ProblemCauseSolution
Lighton,but
motordoesnot
work
Theoutletvalveis
blocked
Detachflueandduct
thenturnonthehood
tocheckifthevalves
open
Thecapacitorhas
failed
Callfortechnical
service
Thecontrolswitch
hasbroken
Callfortechnical
service
Lightdoesnot
work,motor
doesnotwork
Nopowersupply
Pluganotherappliance
intothesocketto
confirmthereispower
supply
FusehasblownOpenuptheplugand
replacehe13Afuse
Vibration
Thepropelleris
damagedor
unbalanced
Callfortechnical
service
Thehoodisnot
installedcorrectly
Reviewtheinstallation
instructionsandcheck
theinstallationagain
forloosescrews,
bracketsor
connections
Insufficient
suctioneffect
Thedistance
betweenthehood
andcooktopistoo
great
Checkthatthe
distanceisbetween
600mmand762mm
ThefiltersareCleanthefiltersfrom
6|Page




HowtoUse

3speedadjustment(seepic6)

oPushtheLowbutton,andthemotorwillrunatthe
lowestspeed
oPushtheMidbutton,andthemotorwillrunat
mediumspeed
oPushtheHighbutton,andthemotorwillrunatthe
highestspeed
oPushtheLightbutton,andthetwolightinglampswill
illuminate.Pushitagainandthelightswillturnoff
oPushtheStopbutton,andthemotorwillturnoff











Pic
6


7|Page




GroundingInstructions

oThisappliancemustbegrounded.Intheeventofan
electricalshortcircuit,groundingreducestheriskof
electricshockbyprovidinganescapewireforthe
electriccurrent.Thisapplianceisequippedwithacord
havingagroundingwirewithagroundingplug.The
plugmustbepluggedintoanoutletthatisproperly
installedandgrounded.
oWarning‐Impropergroundingcanresultinariskof
electricshock.
oConsultaqualifiedelectricianifthegrounding
instructionsarenotcompletelyunderstood,orifdoubt
existsastowhethertheapplianceisproperly
grounded.
oDonotuseanextensioncord.Ifthepowersupplycord
istooshort,havingaqualifiedelectricianinstallan
outletneartheappliance.

WARNING:TOREDUCETHERISKOFFIRE,USEONLYMETAL
DUCTWORK.






8|Page




SafetyInformation

oTheremustbepermanentandadequateventilationofthe
roomwhenoperatingtherangehoodwithappliances
burninggasorotherfuels
oDonotcheckthestatusofthefilterswhentherangehood
isoperating–waitatleast30minutesafterswitchingoff
toavoidscalding
oDonottouchtheLEDlightwithin30minutesafter
applianceuse
oAvoidoperatingagascooktopwhenthereisnopanonthe
stove.Itisafirehazardandmaycausedamagetothehood
filters
oDisconnecttheelectricalplugpriortoanymaintenance
oThisapplianceisnotintendedforusebyyoungchildren
unlesstheyhavebeenadequatelysupervisedbya
reasonablepersontoensurethattheycanusethe
appliancesafely
oTherangehoodisforhomeuseonlyandisnotsuitablefor
outdoor,barbeque,andothercommercialapplications
oTherangehoodanditsfiltershouldbecleanedregularly
forbestperformance
oBeforecleaning,pleaseconfirmthatthepowerisswitched
off
oBuildingregulationsconcerningthedischargeofexhaust
airhavetobefulfilled
oDon’tcookwithanopenflameundertherangehood
oForanytechnicalissuesensurethatasuitablyqualified
personhandlesanyrepairsorinspections
