AEMC Simple Logger II Series User manual

ENGLISH User Manual

VOLTAGE AND CURRENT DATA LOGGERS
Simple Logger®II
Series

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An NIST traceable certificate may be
requested at the time of purchase, or obtained
by returning the instrument to our repair and
calibration facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer. For recalibration, please
use our calibration services. Refer to our repair
and calibration section at www.aemc.com.
Serial #: ________________________________
Catalog #: _______________________________
Model #: ________________________________
Please fill in the appropriate date as indicated:
Date Received: _________________________________
Date Calibration Due: _______________________
Chauvin Arnoux®, Inc.
d.b.a AEMC®Instruments
www.aemc.com

Table of Contents
1. INTRODUCTION............................................................................... 3
1.1 International Electrical Symbols................................................3
1.2 DenitionofMeasurementCategories .....................................4
1.3 ReceivingYourShipment..........................................................4
1.4 OrderingInformation.................................................................4
1.4.1 RecommendedProbesforModelsL101/L102/L562 ....5
1.4.2 RecommendedProbesforModelL111.........................5
1.4.3 AccessoriesandReplacementParts............................6
2. PRODUCT FEATURES ...................................................................... 7
2.1 Description................................................................................7
2.2 ControlFeatures .......................................................................8
3. SPECIFICATIONS........................................................................... 10
4. OPERATION .................................................................................. 17
4.1 LEDControlOperationandStatusFunction ..........................17
4.2 ConnectingtheSimpleLogger®IItoaComputer ...................19
4.3 TurningtheUnitOn.................................................................19
4.4 RecordingData.......................................................................20
4.4.1 StartingaRecordingSession .....................................20
4.4.2 StoppingaRecordingSession ...................................21
4.5 DownloadingRecordedData..................................................21
4.6 ClearingAlarmIndication........................................................21
4.7 ErasingDatafromMemory.....................................................22
4.8 DataStorage...........................................................................22
4.8.1 TrendMeasurements..................................................23
4.9 NormalOperation ...................................................................23
4.10ResetSwitchOperation ..........................................................25
5. MAINTENANCE ............................................................................. 27
5.1 ChangingtheBatteries ...........................................................27
5.2 Cleaning..................................................................................27

APPENDIX A: TROUBLESHOOTING....................................................... 28
APPENDIX B: GLOSSARY.................................................................... 29
RepairandCalibration...........................................................................30
TechnicalandSalesAssistance ............................................................30
Limited Warranty ...................................................................................31
WarrantyRepairs...................................................................................31

Simple Logger®II Series 3
CHAPTER 1
INTRODUCTION
WARNING
Thesesafetywarningsareprovidedtoensurethesafetyofpersonnel
andproperoperationoftheinstrument.
• Readtheinstructionmanualcompletelyandfollowallthesafetyinfor-
mationbeforeattemptingtouseorservicethisinstrument.
• Neverexceedthemaximumworkingvoltageratingsgiven.
• NEVERopenthebackoftheinstrumentwhileconnectedtoanycircuit
orinput.
• Always inspect the instrument accessories and leads prior to use.
Replaceanydefectivepartsimmediatelywithfactoryparts.
1.1 International Electrical Symbols
Signifies that the instrument is protected by double or reinforced insulation.
Indicates a WARNING and that the operator must refer to the user manual for instructions
before operating the instrument. Failure to follow or carry out any instructions preceded
by this symbol in the user manual may result in personnel injury or damage to the
instrument and installations.
Risk of electric shock. The voltage at parts marked with this symbol may be dangerous.
Refers to a type A current sensor. This symbol signifies that application around and
removal from HAZARDOUS LIVE conductors is permitted.
Refers to a type B current sensor. Do not apply around or remove from HAZARDOUS
LIVE conductors without additional protective means (de-energizing the circuit or
wearing protective clothing suitable for high voltage work).
In conformity with WEEE 2002/96/EC

4 Simple Logger®II Series
1.2 Definition of Measurement Categories
Cat. I: For measurements on circuits not directly connected to theAC
supplywalloutletsuchasprotectedsecondaries,signallevel,and
limitedenergycircuits.
Cat. II: For measurements performed on circuits directly connected to
the electrical distribution system. Examples are measurements
onhouseholdappliancesorportabletools.
Cat. III:For measurements performed in the building installation at the
distributionlevelsuchasonhardwiredequipmentinxedinstalla-
tionandcircuitbreakers.
Cat. IV: For measurements performed at the primary electrical supply
(<1000V) such as on primary overcurrent protection devices,
ripplecontrolunits,ormeters.
1.3 Receiving Your Shipment
Uponreceivingyourshipment,makesurethatthecontentsareconsistent
with the packing list. Notify your distributor of any missing items. If the
equipmentappearstobedamaged,leaclaimimmediatelywiththecarrier
and notify your distributor at once, giving a detailed description of any
damage.Savethedamagedpackingcontainertosubstantiateyourclaim.
1.4 Ordering Information
Simple Logger®II Model L101 ......................................... Cat. #2126.02
(1-Channel,TRMS0to1VAC)
Includes a USB cable, DataView®CD-ROM, 2x1.5V AA-cell alkaline batteries, user manual
and warranty card. Probes purchased separately.
Simple Logger®II Model L102 ......................................... Cat. #2126.03
(2-Channel,TRMS0to1VAC)
Includes a USB cable, DataView®CD-ROM, 2x1.5V AA-cell alkaline batteries, user manual
and warranty card. Probes purchased separately.
Simple Logger®II Model L111.......................................... Cat. #2126.04
(1-Channel,TRMS0to1AAC)
Includes a USB cable, DataView®CD-ROM, 2x1.5V AA-cell alkaline batteries, user manual
and warranty card. Probes purchased separately.

Simple Logger®II Series 5
Simple Logger®II Model L261 ........................................ Cat. #2126.05
(1-Channel,TRMS600VAC)
Includes USB cable, DataView®CD-ROM, 2x1.5V AA-cell alkaline batteries, one set of leads,
one set of alligator clips, user manual and warranty card.
Simple Logger®II Model L322 ........................................ Cat. #2126.06
(2-Channel,4-20mADCCurrentModule)
Includes USB cable, DataView®CD-ROM, 2x1.5V AA-cell alkaline batteries, user manual
and warranty card.
Simple Logger®II Model L432 ........................................ Cat. #2126.07
(2-Channel,DC±100mV / 1V / 10VDC)
Includes USB cable, DataView®CD-ROM, 2x1.5V AA-cell alkaline batteries, user manual
and warranty card.
Simple Logger®II Model L642 ........................................ Cat. #2126.08
(TemperatureThermocoupleModule)
Includes USB cable, DataView®CD-ROM, 2x1.5V AA-cell alkaline batteries, user manual
and warranty card.
Simple Logger®II Model L562 ........................................ Cat. #2126.35
(2-Channel,TRMSVoltage&CurrentModule)
Includes USB cable, DataView®CD-ROM, 2x1.5V AA-cell alkaline batteries, one set of leads,
one set of alligator clips, user manual and warranty card. Probes purchased separately.
1.4.1 Recommended Probes for Models L101, L102 & L562
ACCurrentProbeModelMN261
(24A-100mV/A, 240A-10mV/A, BNC) ............................................. Cat. #2115.82
NOTE: The MN261 current probe should not be used on applications above
10 or 100 Amps (depending on range) when used with either the L101 or L102
data loggers. Clipping of the input signal could result.
ACCurrentProbeModelSR661
(10A-100mV/A, 100A-10mV/A, 1000A-1mV/A, BNC) .......................... Cat. #2113.49
ACCurrentProbeModelJM861
(30A-10mV/A, 300A-1mV/A, 3000A-0.1mV/A, BNC)........................... Cat. #2110.90
1.4.2 Recommended Probes for Model L111
ACCurrentProbeModelMN313
(150A, 1mA/A, Lead).................................................................. Cat. #2116.25
ACCurrentProbeModelSR604
(1000A, 1mA/A, Lead) ................................................................ Cat. #2113.44

6 Simple Logger®II Series
ACCurrentProbeModelJM800A
(1000A, 1mA/A, Lead) ................................................................ Cat. #2110.79
ACCurrentProbeModelJM830A
(3000A, .333mA/A, Lead) ............................................................ Cat. #2110.83
1.4.3 Accessories and Replacement Parts
Lead-Setof2,Color-coded5ftw/color-codedalligatorclips
(Rated600VCatIV,15A) .................................................... Cat. #2140.62
Lead-Setof2,Color-coded10ftw/color-codedalligatorclips
(Rated600VCatIV,15A) .................................................... Cat. #2140.63
Replacement-Ato5-pinmini-B2MUSBcable.................. Cat. #2126.49
Fuse-Setof5,2A(250V)FAforSLIIModelL111................ Cat. #2126.48
Order Accessories and Replacement Parts Directly Online
Check our Storefront at www.aemc.com/store for availability

Simple Logger®II Series 7
CHAPTER 2
PRODUCT FEATURES
2.1 Description
The Simple Logger®II Series includes one and two channel recording
devices (model dependent) powered by an alkaline battery pack. Line
tracking is performed such that 64 samples over one line cycle are taken.
Frequency tracking is performed over the range of ±2Hz around the nominal
line frequency (50 or 60Hz). Harmonic measurements are calculated from
these 64 samples (Harmonics are only available from the Simple Logger®
II Control Panel within the DataView®software).
The Simple Logger®II records TRMS at a rate of up to eight times per
second. The measurement process is performed no more than eight times
per second. TRMS calculations are performed on 64 samples of a single
line cycle for AC measurements. This means that the input(s) are ignored
between measurement intervals. DC measurements are performed 8
times for each sample taken.
The main advantage of the logger is its ability to perform a variety of
recording tasks with easy and intuitive setup from a computer using
DataView®software.
Analog information on the input is sampled and converted to a digital
signal. This digital signal is processed and stored along with scale and
time information. An optically isolated Universal Serial Bus (USB) port
provides for the transfer of data from the instrument’s internal memory to
the computer for analysis.

8 Simple Logger®II Series
2.2 Control Features
3
1
2
4
Figure 2-2. Key Components and Features
1. Input (model dependent)
L101/L102 - BNCInputTermination
L261/L111 - Tworecessed4mmsafetybananajacks
L322/L432 -One4-positionremovablescrew-typeterminalblock
L562 - BNC/Tworecessed4mmsafetybananajacks
L642-Twominiaturethermocoupleconnectors
2. Five LED Indicators
 TheLEDsontheloggerservetwofunctions:Control Operation and
Status Function.
The control operation (when holding down the PRESS button) is•
indicatedwithtexttotheleftofeachLED.
Thestatusfunction(whenPRESSisnotbeinghelddown)associ-•

Simple Logger®II Series 9
atedwitheachLEDisindicatedwithtexttotherightofeachLED.
Referto§4.1fordetaileddescriptionsofeachLED.•
3. Control Button (PRESS)
Thisbuttonmarked“PRESS”selectsthemodeofoperation.Usethis
buttontostartorstoprecordings,erasethememory,clearalarmsand
turntheinstrumentON/OFF.
4. Female Type Mini-B USB Connector
Thisconnectorislocatedonthebottomoftheinstrument.
5. Reset Switch (not shown)
 TheRESETswitchresetstheCPUandislocatedunderthetopcover.
To access this switch remove the battery compartment cover, then
removethefourscrewsholdingthetwohalvesofthecasetogether.
TheresetswitchislocatedontheexposedPCBneartheinputs.
6. Flash Upgrade Switches (not shown)
 Thesetwoswitches(accessiblefromunderthetopcover),alongwith
theRESETbutton(andPCsoftware),areusedtorecoverfromafailed
ashupgradeprocedure.
WARNING: If the RESET button is pressed when the logger is recording, it
will stop recording and data in memory may be lost.

10 Simple Logger®II Series
CHAPTER 3
SPECIFICATIONS
ReferenceConditions:23°C±3°C,30to50%RH,DCor50/60Hz,batteryvoltage:3V±10%.
MODEL L101 L102
ELECTRICAL
Channels One Two
Input BNC
Current Probe Output
Voltage Range 0 to 1V
Resolution 0.1mV
Accuracy
(50/60Hz)
0 to 10mV unspecified
10 to 50mV: ±(0.5% of Reading +1mV)
50 to 1000mV: ±(0.5% of Reading +0.5mV)
Maximum Input Voltage*** 5Vrms (-7.07Vd c to +7.07Vd c )
Input Impedance 800kW
Sample Rate 64 samples/cycle
Storage Rate Programmable from 125mS to 1 day
Storage Modes Start/Stop, FIFO and Extended Recording Mode*(XRM™)
Recording Length 15 minutes to 8 weeks, programmable using DataView®
Memory 240,000 measurement (512KB). Recorded data is stored in non-
volatile memory and retained even if battery is low or removed.
Communication USB 2.0 optically isolated
Power Source** 2x1.5V AA (LR6) alkaline batteries
Battery Life 100 hrs to >45 days (dependent on storage rate/recording length)
MECHANICAL
Dimensions 5.38 x 2.75 x 1.28" (136 x 70 x 32mm)
Weight (with battery) 6.4 oz (180g)
Case UL94-V0
Vibration IEC 68-2-6 (1.5mm, 10 to 55Hz)
Shock IEC 68-2-27 (30G)
Drop IEC 68-2-32 (1m)
ENVIRONMENTAL
Operating Temperature 14° to 122°F (-10° to 50°C)
Storage Temperature -4° to 140°F (-20° to 60°C)
Relative Humidity Up to 85% @ 95°F (35°C), Non-condensing
Altitude 2000m
SAFETY
Safety Rating EN 61010-1; 50V Cat. III; Pollution Degree 2
Environmental IP40

Simple Logger®II Series 11
MODEL L111
ELECTRICAL
Channels One
Input Two recessed banana jacks
Current Probe Output
Current Range 0 to 1A
Resolution 0.1mA
Accuracy
(50/60Hz)
0 to 10mA unspecified
10 to 50mA: ±(0.5% of Reading +1mA)
50 to 1000mA: ±(0.5% of Reading +0.5mA)
Maximum Input Voltage*** 1.2An (An=nominal current)
Input Impedance 1W
Sample Rate 64 samples/cycle
Storage Rate Programmable from 125mS to 1 day
Storage Modes Start/Stop, FIFO and Extended Recording Mode*(XRM™)
Recording Length 15 minutes to 8 weeks, programmable using DataView®
Memory 240,000 measurement (512KB).
Recorded data is stored in non-volatile memory and
retained even if battery is low or removed.
Communication USB 2.0 optically isolated
Power Source** 2x1.5V AA (LR6) alkaline batteries
Battery Life 100 hrs to >45 days
(dependent on storage rate/recording length)
MECHANICAL
Dimensions 5.18 x 2.75 x 1.28" (132 x 70 x 32mm)
Weight (with battery) 6.64 oz (188g)
Case UL94-V0
Vibration IEC 68-2-6 (1.5mm, 10 to 55Hz)
Shock IEC 68-2-27 (30G)
Drop IEC 68-2-32 (1m)
ENVIRONMENTAL
Operating Temperature 14° to 122°F (-10° to 50°C)
Storage Temperature -4° to 140°F (-20° to 60°C)
Relative Humidity Up to 85% @ 95°F (35°C), Non-condensing
Altitude 2000m
SAFETY
Safety Rating EN 61010-1; 50V Cat. III; Pollution Degree 2
Environmental IP40

12 Simple Logger®II Series
MODEL L322
ELECTRICAL
Channels Two
Input One 4-position removable screw-type terminal block
Measurement Range -20mA to 20mADC
Resolution 0.01mA
Accuracy (0.25% of Reading +0.05mA)
Input Impedance 50W
Sample Rate Maximum of 8 samples taken at storage interval
Storage Rate Programmable from 125mS to 1 day
Storage Modes Start/Stop, FIFO and Extended Recording Mode*(XRM™)
Recording Length 15 minutes to 8 weeks, programmable using DataView®
Memory 240,000 measurement (512KB).
Recorded data is stored in non-volatile memory and
retained even if battery is low or removed.
Communication USB 2.0 optically isolated
Power Source** 2x1.5V AA (LR6) alkaline batteries
Battery Life 100 hrs to >45 days
(dependent on storage rate/recording length)
MECHANICAL
Dimensions 5.45 x 2.75 x 1.28" (136 x 70 x 32mm)
Weight (with battery) 6.4 oz (181g)
Case UL94-V0
Vibration IEC 68-2-6 (1.5mm, 10 to 55Hz)
Shock IEC 68-2-27 (30G)
Drop IEC 68-2-32 (1m)
ENVIRONMENTAL
Operating Temperature 14° to 122°F (-10° to 50°C)
Storage Temperature -4° to 140°F (-20° to 60°C)
Relative Humidity Up to 85% @ 95°F (35°C), Non-condensing
Altitude 2000m
SAFETY
Safety Rating EN 61010-1; 50V Cat. III; Pollution Degree 2
Environmental IP40

Simple Logger®II Series 13
MODEL L432
ELECTRICAL
Channels Two
Input One 4-position removable screw-type terminal block
Measurement Range
(3 ranges/channel)
Range 1: -100mV to 100mVDC
Range 2: -1V to 1VDC
Range 3: -10V to 10VDC
Resolution Range 1: 0.1mV
Range 2: 1mV
Range 3: 10mV
Accuracy
(50/60Hz)
Range 1: ±(0.5% of Reading +1mV)
Range 2: ±(0.5% of Reading +1mV)
Range 3: ±(0.5% of Reading +10mV)
Input Impedance 100mV/1V: 80K; 10V: 800K
Sample Rate Maximum of 8 samples taken at storage interval
Storage Rate Programmable from 125mS to 1 day
Storage Modes Start/Stop, FIFO and Extended Recording Mode*(XRM™)
Recording Length 15 minutes to 8 weeks, programmable using DataView®
Memory 240,000 measurement (512KB).
Recorded data is stored in non-volatile memory and
retained even if battery is low or removed.
Communication USB 2.0 optically isolated
Power Source** 2x1.5V AA (LR6) alkaline batteries
Battery Life 100 hrs to >45 days
(dependent on storage rate/recording length)
MECHANICAL
Dimensions 5.45 x 2.75 x 1.28" (136 x 70 x 32mm)
Weight (with battery) 6.4 oz (181g)
Case UL94-V0
Vibration IEC 68-2-6 (1.5mm, 10 to 55Hz)
Shock IEC 68-2-27 (30G)
Drop IEC 68-2-32 (1m)
ENVIRONMENTAL
Operating Temperature 14° to 122°F (-10° to 50°C)
Storage Temperature -4° to 140°F (-20° to 60°C)
Relative Humidity Up to 85% @ 95°F (35°C), Non-condensing
Altitude 2000m
SAFETY
Safety Rating EN 61010-1; 50V Cat. III; Pollution Degree 2
Environmental IP40

14 Simple Logger®II Series
MODEL L562
ELECTRICAL
Channels Two
Connection Current Channel Voltage Channel
Input BNC Two recessed banana jacks
Measurement Range 0 to 1V (for use with current
probes with a voltage output) 0 to 600VAC/DC
Resolution 0.1mV 0.1V
Accuracy
50 or 60 Hz
0 to 10mV unspecified
10 to 50mV:
±(0.5% of Reading + 1mV)
50 to 1000mV:
±(0.5% of Reading + 0.5mV)
0 to 5V unspecified
5 to 50V:
±(0.5% of Reading + 1V)
50 to 600V:
±(0.5% of Reading + 0.5V)
Maximum Input
Voltage***
5Vrms
(-7.07V peak to +7.07V peak) 1.2Vn (Vn=nominal voltage)
Input Impedance 800kW40MW
Sample Rate 64 samples/cycle
Storage Rate Programmable from 125mS to 1 day
Storage Technique Start/Stop, FIFO and Extended Recording Mode* (XRM™)
Recording Length 15 minutes to 8 weeks, programmable using DataView®
Memory 240,000 measurements (512KB).
Recorded data is stored in non-volatile memory and retained
even if battery is low or removed.
Communication USB 2.0 optically isolated
Power Source** 2x1.5V AA-cell alkaline batteries
Battery Life 100 hours to >45 days
(dependent on storage rate/recording length)
MECHANICAL
Dimensions 5.38 x 2.75 x 1.28" (136 x 70 x 32mm)
Weight (with battery) 6.4 oz (180g)
Case UL94-V0
Vibration IEC 68-2-6 (1.5mm, 10 to 55Hz)
Shock IEC 68-2-27 (30G)
Drop IEC 68-2-32 (1m)
ENVIRONMENTAL
Operating Temperature 14° to 122°F (-10° to 50°C)
Storage Temperature -4° to 140°F (-20° to 60°C)
Relative Humidity Up to 85% @ 95°F (35°C), Non-condensing
Altitude 2000m
SAFETY
Safety Rating EN61010-1; 600V Cat. III; 300V Cat. IV; Pollution Degree 2
Environmental IP40

Simple Logger®II Series 15
MODEL L642
ELECTRICAL
Channels Two
Input Two miniature thermocouple connectors
Measurement Type:
J
K
T
N
E
R
S
°F °C
-346 to +2192 -210 to +1200
-328 to +2501 -200 to +1372
-418 to +752 -250 to +400
-328 to +2372 -200 to +1300
-238 to 1742 -150 to +950
32 to 3212 0 to 1767
32 to 3212 0 to 1767
Resolution 0.1°C/F < 1000°C/F; 1°≥1000°C/F
Accuracy (J, K, T, N, E) ±(0.2% of Reading + 0.6° C) ≤(-100° C)
±(0.15% of Reading + 0.6°C) > (-100° C), ≤(+100°C)
±(0.1% of Reading + 0.6°C) > (+100°C)
Accuracy (R, S) ±(0.15% of Reading + 1.0°C) (0° to +100°C)
±(0.1% of Reading + 1.0°C) > (+100°C)
Temperature
Coefficient:
± (0.02% of Reading + 0.03°C)/ °C
or ± (0.02% of Reading + 0.03°F) / °F between operating
temperature of -10°C to +18°C and +28°C to +50°C
Maximum Differential
Voltage 1V (between T1 and T2)
Sample Rate Maximum of 8 samples taken at storage interval
Storage Rate Programmable from 5 sec to 1 day
Storage Modes Start/Stop, FIFO and Extended Recording Mode* (XRM™)
Recording Length 15 minutes to 8 weeks, programmable using DataView®
Memory 240,000 measurement (512KB). Recorded data is stored in non-
volatile memory and retained even if battery is low or removed.
Communication USB 2.0 optically isolated
Power Source** 2x1.5V AA (LR6) alkaline batteries
Battery Life 100 hrs to >45 days (dependent on storage rate/recording length)
MECHANICAL
Dimensions 4.94 x 2.75 x 1.28" (125 x 70 x 32mm)
Weight (with battery) 7 oz (200g)
Case UL94-V0
Vibration IEC 68-2-6 (1.5mm, 10 to 55Hz)
Shock IEC 68-2-27 (30G)
Drop IEC 68-2-32 (1m)
ENVIRONMENTAL
Operating Temperature 14° to 122°F (-10° to 50°C)
Storage Temperature -4° to 140°F (-20° to 60°C)
Relative Humidity Up to 85% @ 95°F (35°C), Non-condensing
Altitude 2000m
SAFETY
Safety Rating EN61010-1; 50V Cat. III; Pollution Degree 2

16 Simple Logger®II Series
MODEL L261
ELECTRICAL
Channels One
Input Two recessed banana jacks
Voltage Range 0 to 600V
Resolution 0.1V
Accuracy
(50/60Hz)
0 to 5V unspecified
5 to 50V: ±(0.5% of Reading +1V)
50 to 600V: ±(0.5% of Reading +0.5V)
Maximum Input Voltage*** 1.2Vn (Vn=nominal voltage)
Input Impedance 40MW
Sample Rate 64 samples/cycle
Storage Rate Programmable from 125mS to 1 day
Storage Modes Start/Stop, FIFO and Extended Recording Mode* (XRM™)
Recording Length 15 minutes to 8 weeks, programmable using DataView®
Memory 240,000 measurement (512KB). Recorded data is stored in non-
volatile memory and retained even if battery is low or removed.
Communication USB 2.0 optically isolated
Power Source** 2x1.5V AA (LR6) alkaline batteries
Battery Life 100 hrs to >45 days (dependent on storage rate/recording length)
MECHANICAL
Dimensions 4.94 x 2.75 x 1.28" (125 x 70 x 32mm)
Weight (with battery) 6.4 oz (180g)
Case UL94-V0
Vibration IEC 68-2-6 (1.5mm, 10 to 55Hz)
Shock IEC 68-2-27 (30G)
Drop IEC 68-2-32 (1m)
ENVIRONMENTAL
Operating Temperature 14° to 122°F (-10° to 50°C)
Storage Temperature -4° to 140°F (-20° to 60°C)
Relative Humidity Up to 85% @ 95°F (35°C), Non-condensing
Altitude 2000m
SAFETY
Safety Rating EN61010-1; 600V Cat. III; 300V Cat. IV; Pollution Degree 2
Environmental IP40
*This unique recording mode provides the opportunity to continuously record over long periods of time by
reducing the stored sample resolution of the oldest data and maintaining matching resolution for the newest
data. Each time the memory fills up using XRM
™
, every other of the oldest stored samples is discarded
making room for newer samples. This process continues until the recording is manually stopped.
**A memory backup capacitor provides backup power while the batteries are being changed. This
backup capacitor will maintain the instrument for up to 10 seconds without batteries installed. After 10
seconds the date and time will need to be reset (data and configuration will be maintained). If the unit is
connected to DataView®via a PC, the battery life is 100 hours regardless of the storage rate.
*** Voltages beyond this range may damage the instrument.
NOTE: Specications are subject to change at any time without notice.

Simple Logger®II Series 17
CHAPTER 4
OPERATION
4.1 LED Control Operation and Status Function
TheON/OFFstateoftheinstrumentcanbedeterminedbypressingthe
PRESSbuttonforlessthan0.5seconds.IftheinstrumentisON,thestatus
oftheinstrumentwillbeshownbytheLEDs.IftheinstrumentisOFFno
indicationwillbegiven(theLEDswillnotblink).
TheinstrumentisturnedONbypressingthePRESSbuttonuntilallLEDs
light. At this point, the button can be released and the instrument will
remainintheONstate.IfthebuttonisreleasedbeforealltheLEDslight
(inunison),theinstrumentwillremainintheOFFstate.
WhenholdingthePRESSbuttonwhiletheinstrumentisON,eachLED
willlightinsequence.ContinuingtoholdthePRESSbuttonuntilthelast
LEDlights,turnstheinstrumentOFF.Atthispoint,releasingthebuttonwill
resultinnoactionbeingtaken.Thisprovidesamechanismtocancel(or
ignore)thebuttonpress.
ControloftheinstrumentisperformedbypressingandholdingthePRESS
button(whilethe instrument is ON)untilthe control LED corresponding
to the desired operation lights. Releasing the button when the desired
control LED is illuminated results in the corresponding operation being
performed.
TurningtheinstrumentOFF(pressingandholdingthePRESSbuttonuntil
theBlueLEDlights),willnotterminateanactive recordingorpreventa
scheduledrecordingfromstarting.
WhiletheinstrumentisOFF,itwillturnONforeachscheduledrecording.

18 Simple Logger®II Series
TheControl and Status OperationofeachLEDisasfollows:
GREEN LED:
CONTROL STARTS A RECORDING
STATUS
OFF Logger is turned OFF or in Low Power Standby state*
Single-blink Logger is in Standby Mode (and not recording)
Double-blink Logger is in Record Mode
ORANGE LED:
CONTROL STOPS A RECORDING
STATUS OFF Logger is not in an Overload condition
Single-blink One or more inputs are in an Overload condition
YELLOW LED:
CONTROL CLEARS THE ALARM STATE (see § 4.6)
STATUS
OFF No alarm has been seen on any input
Single-blink At least one channel has seen an alarm at least once
Double-blink At least one channel is currently in an alarm condition
Fast-blink Armed to clear alarm indication
RED LED:
CONTROL ERASES THE MEMORY (see § 4.7)
STATUS
OFF No data in memory
Single-blink Memory is partially filled
Double-blink Memory is full
Fast-blink Armed to erase memory
BLUE LED:
CONTROL TURNS THE INSTRUMENT OFF
STATUS
OFF Battery voltage is above 1.8 volts
Single-blink Battery voltage is below 1.8 volts
Double-blink Indicates a recording is scheduled
*To determine whether the unit is OFF or in SLEEP mode, press the PRESS button for 0.5
seconds. If all LEDs light, the logger is not OFF.
Note: Overload occurs when any input is 10% above its input range. When
the battery voltage goes below 1.7 volts the instrument will shut down
(terminating and saving the recording, if it is recording).
