AEMC MR6292 User manual

AC/DC CURRENT PROBE MR6292
ENGLISH User Manual
www. .com [e-mail]1.800.561.8187

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An NIST traceable certificate may be
requested at the time of purchase, or obtained
by returning the instrument to our repair and
calibration facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer.
Serial #: ______________________________
Catalog #: 2129.86
Model #: MR6292
Please fill in the appropriate date as indicated:
Date Received: _________________________________
Date Calibration Due: _______________________
Chauvin Arnoux®, Inc.
d.b.a AEMC®Instruments
www. .com [e-mail]1.800.561.8187

AC/DC Current Probe Model MR6292 1
Table of Contents
1. INTRODUCTION ........................................................................ 2
1.1 International Electrical Symbols.....................................................2
1.2 DenitionofMeasurementCategories...........................................3
1.3 ReceivingYourShipment...............................................................3
1.4 OrderingInformation ......................................................................3
2. PRODUCT FEATURES ............................................................... 4
2.1 Description .....................................................................................4
2.2 MR6292 Features ..........................................................................5
3. SPECIFICATIONS ...................................................................... 6
3.1 Electrical ........................................................................................6
3.2 Mechanical.....................................................................................6
3.3 Environmental ................................................................................7
3.4 Safety.............................................................................................7
4. OPERATION............................................................................... 8
4.1 MakingMeasurements...................................................................8
4.2 OperationExamples ......................................................................9
5. MAINTENANCE ....................................................................... 10
5.1 Cleaning.......................................................................................10
5.4 Limited Warranty..........................................................................12
5.5 WarrantyRepairs .........................................................................12
www. .com [e-mail]1.800.561.8187

2 AC/DC Current Probe Model MR6292
CHAPTER 1
INTRODUCTION
Warning
Thesesafetywarningsareprovidedtoensurethesafetyofpersonnel
andproperoperationoftheinstrument.
• Readthisinstructionmanualcompletelyandfollowallthesafetyinfor-
mationbeforeattemptingtouseorservicethisinstrument.
• Usecautiononanycircuit:Potentiallyhighvoltagesandcurrentsmay
bepresentandmayposeashockhazard.
• ReadthesafetyspecicationssectionbeforeusingtheModelMR6292.
Neverexceedthemaximumworkingvoltageratingsgiven.
• Safetyistheresponsibilityoftheoperator!
• Neveropenthebackoftheinstrumentwhileconnectedtoanycircuit
orinput.
• ALWAYSconnecttheModelMR6292totheMicro-OhmmeterModel
6292 instrument before clamping the probe onto the sample under
test.
• Alwaysinspecttheprobeandleadpriortouse.Replaceanydefective
partsimmediately.
• NEVERusetheModelMR6292onelectricalconductorsratedabove
600V.
1.1 International Electrical Symbols
Thissymbolsigniesthattheinstrumentisprotectedbydoubleorrein-
forcedinsulation.Useonlyspeciedreplacementpartswhenservicing
theinstrument.
This symbol on the instrument indicates a WARNING and that the
operatormustrefertotheusermanualforinstructionsbeforeoperat-
ingtheinstrument.Inthismanual,thesymbolprecedinginstructions
indicatesthatiftheinstructionsarenotfollowed,bodilyinjury,installa-
tion/sampleandproductdamagemayresult.
Riskofelectricshock.Thevoltageatthepartsmarkedwiththissymbol
maybedangerous.
ThisisatypeAcurrentsensor.Thissymbolsigniesthatapplication
aroundandremovalfromHAZARDOUSLIVEconductorsispermitted.
www. .com [e-mail]1.800.561.8187

AC/DC Current Probe Model MR6292 3
1.2 Definition of Measurement Categories
CAT I: FormeasurementsoncircuitsnotdirectlyconnectedtotheAC
supply wall outlet such as protected secondaries, signal level,
andlimitedenergycircuits.
CAT II: For measurements performed on circuits directly connected to
the electrical distribution system. Examples are measurements
onhouseholdappliancesorportabletools.
CAT III: For measurements performed in the building installation at
the distribution level such as on hardwired equipment in xed
installation and circuit breakers.
CAT IV: For measurements performed at the primary electrical supply
(<1000V) such as on primary overcurrent protection devices,
ripplecontrolunits,ormeters.
1.3 Receiving Your Shipment
Uponreceivingyourshipment,makesurethatthecontentsareconsistent
withthepackinglist.Notifyyourdistributorofanymissingitems.Iftheequip-
mentappearstobedamaged,leaclaimimmediatelywiththecarrierand
notifyyourdistributoratonce,givingadetaileddescriptionofanydamage.
Savethedamagedpackingcontainertosubstantiateyourclaim.
1.4 Ordering Information
AC/DC Current Probe Model MR6292
(forusewithMicro-OhmmeterModel6292only) ................ Cat. #2129.86
Includes user manual.
www. .com [e-mail]1.800.561.8187

4 AC/DC Current Probe Model MR6292
CHAPTER 2
PRODUCT FEATURES
2.1 Description
TheAC/DCCurrentProbeModelMR6292isanaccessoryforthe
AEMC®Micro-OhmmeterModel6292.TheModelMR6292probeis
requiredforusingtheModel6292totakemeasurementsinBSG(both
sidesgrounded)mode.
Theprobeisdesignedtomeetthelatestsafetyandperformance
standards.Theprobe’shook-shapedjawsenableyouto“pry”intoor
“hook”ontocables(itwillaccept2x500MCM)orsmallbusbars.
TheModelMR6292usesHalleffecttechnology.Allelectronicsareself-
containedinthehandle.Theoutputoftheprobeis10mV/A.Nobatteryis
required;theprobeoperatesviavoltageprovidedbytheModel6292.
TheprobehasaproportionalmVoutputfordirectreadingontheModel
6292.
www. .com [e-mail]1.800.561.8187

AC/DC Current Probe Model MR6292 5
2.2 MR6292 Features
1
2
3
4
6
5
Ø = 1.18" (30mm)
Cable max.
Ø = 0.95" (24mm)
Dual Cable max.
POWER
600V CAT III
OUTPUT:
50ADC: 10mV/ADC
For use only with
Micro-ohmmeter
Model 6292
AC/DC CURRENT PROBE
MODEL MR6292
Figure 1
1. Jaws
2. Conductor
3. Protectivenon-slipguard
4. Greenlight(ONwhen
connectedtotheModel6292)
5. Lead,5ft(1.5m)
6. 5-pinXLRconnector
www. .com [e-mail]1.800.561.8187

6 AC/DC Current Probe Model MR6292
CHAPTER 3
SPECIFICATIONS
3.1 Electrical
Measurement Range: 1 to 50ADC
Accuracy: 1 to 50ADC:1.5%reading±0.2A
Output Signal: 10mV/ADC
Load Impedance: >100kΩ/100pF
Insertion Impedance: 0.39mΩ@50Hz,58mΩ@1000Hz
Working Voltage: 600Vrms
Common Mode Voltage: 600Vrms
Inuence of Adjacent Conductor:
<10mA/Aat50Hzat23mmfromtheprobe
Inuence of Conductor in Jaw Opening:0.5%reading
Power Source: PoweredbyMicro-OhmmeterModel6292
3.2 Mechanical
Jaw Opening: 1.2" (31mm)
Maximum Cable Diameter: One1.18"(30mm)ortwo0.95”(24mm)or
twobusbars1.2x0.4"(31.5x10mm)
Dimensions:8.8x3.82x1.73"(224x97x44mm)
Weight: 15oz(440g)
Output: 4-conductorshieldedcablewith5-pinXLRconnector
Zero Adjustment: AutomaticzerobyModel6292
Case Protection: IP30perIEC529
Drop Test: 1.0mon38mmofoakonconcrete;testaccordingtoEN61010
www. .com [e-mail]1.800.561.8187

AC/DC Current Probe Model MR6292 7
Mechanical Shock: 100G,testperIEC68-2-27
Vibration: TestperIEC68-2-6
Handle: UL 94 V0
Jaws: UL 94 V0
3.3 Environmental
Operating Temperature Range: 14° to 131°F (-10° to +55°C)
Storage Temperature Range: -40° to 176°F (-40° to +80°C)
Temperature Inuence: ≤300°ppm/°Kor1%/10°K
≤0.2A/°KonZero
Operating Relative Humidity:
10°to35°C:90±5%RH(withoutcondensation)
40°to55°C:70±5%RH(withoutcondensation)
Humidity Inuence: 10to90%RH@referencetemperature≤0.1% R
Altitude: Operating:0to2000m
 Non-operating:0to12,000m
3.4 Safety
Electrical:
EN61010-2-32,600VCATIII,Pollution:2
Electromagnetic Compatibility:
EN 50081-1 Class B
EN50082-2ElectrostaticdischargeIEC1000-4-2
RadiatedeldIEC1000-4-3
Fast transients IEC 1000-4-4
Magneticeldat50/60HzIEC1000-4-8
www. .com [e-mail]1.800.561.8187

8 AC/DC Current Probe Model MR6292
CHAPTER 4
OPERATION
TheModelMR6292probeisusedinconjunctionwiththeMicro-Ohmmeter
Model6292toperformmeasurementsinBSG(bothsidesgrounded)mode.
ForadditionalinformationaboutusingtheMicro-OhmmeterModel6292,
refertotheusermanualontheUSBStickthatshipswiththeinstrument.
4.1 Making Measurements
1. PlugtheprobeintotheModel6292.
3. TurnthepowertotheModel6292ON.
4. ThegreenLEDontheModelMR6292shouldbelit.IftheLEDdoes
notcomeONorgoesOFFafterafewminutes;checktoensurethat
theModel6292instrumentisstillpoweredON,andthattheModel
MR6292issecurelypluggedintotheinstrument’ssocket.
5. SetupatestontheMicro-ohmmeterModel6292,asinstructedby
theinstrument’susermanual(locatedontheUSBstick).
6. Clamptheprobeonthegroundconductortobetested,thenstartthe
test.TheModel6292willdisplaythemeasuredgroundconductor
currentasthe“Ig”readingontheinstrument’sLCDdisplaypanel:
R=100.0uΩ
It=142A Ig=8.0A
DURATION: 015/060s
10/20/13 03:25 PM
 In the preceding example, the Ig measurement provided by the
MR6292probeis8.0A.
www. .com [e-mail]1.800.561.8187

AC/DC Current Probe Model MR6292 9
4.2 Operation Examples
• Conductorcarrying25ADCinthedirectionofthearrow.
• Model6292displaysIg=25A.
25 ADC
POWER
600V CAT III
OUTPUT:
50ADC: 10mV/ADC
For use only with
Micro-ohmmeter
Model 6292
AC/DC CURRENT PROBE
MODEL MR6292
www. .com [e-mail]1.800.561.8187

10 AC/DC Current Probe Model MR6292
CHAPTER 5
MAINTENANCE
WARNING:
• Formaintenanceuseonlyspeciedreplacementparts.
• To avoid electrical shock, do not attempt to perform any servicing
unlessyouarequaliedtodoso.
• Toavoidelectricalshockand/ordamagetotheinstrument,donotget
waterorotherforeignagentsintothecase.TurnthecurrentprobeOFF
anddisconnecttheunitfromallthecircuitsbeforeopeningthecase.
5.1 Cleaning
• Cleanthebodyoftheclampwithaclothlightlymoistenedwithsoapy
water.
• Wipecleanwithaclothmoistenedwithcleanwateranddry.
• Do not use solvent.
www. .com [e-mail]1.800.561.8187

www. .com [e-mail]1.800.561.8187

12 AC/DC Current Probe Model MR6292
5.4 Limited Warranty
TheModelMR6292probeiswarrantedtotheownerforaperiodofoneyear
fromthedateoforiginalpurchaseagainstdefectsinmanufacture.Thislimited
warranty is given byAEMC® Instruments, not by the distributor from whom
itwaspurchased.This warrantyisvoidiftheunithasbeentamperedwith,
abusedorifthedefectisrelatedtoservicenotperformedbyAEMC®Instru-
ments.
Full warranty coverage and product registration is available on our
website at www.aemc.com/warranty.html.
Please print the online Warranty Coverage Information for your records.
What AEMC® Instruments will do:
Ifamalfunctionoccurswithintheone-yearperiod,youmayreturntheinstrument
tousforrepair,providedwehaveyourwarrantyregistrationinformationonle
oraproofofpurchase.AEMC®Instrumentswill,atitsoption,repairorreplace
thefaultymaterial.
5.5 Warranty Repairs
What you must do to return an Instrument for Warranty Repair:
First,requestaCustomerServiceAuthorizationNumber(CSA#)byphonefax
oremailfromourServiceDepartment(seeaddressbelow),thenreturnthe
instrumentalongwiththesignedCSAForm.Pleasewritethe CSA# onthe
outsideoftheshippingcontainer.Returntheinstrument,postageorshipment
pre-paidto:
Ship To: ChauvinArnoux®,Inc.d.b.a.AEMC®Instruments
 15FaradayDrive•Dover,NH03820USA
 Phone:(800)945-2362(Ext.360)
  (603)749-6434(Ext.360)
 Fax: (603)742-2346or(603)749-6309
 E-mail:[email protected]
Caution:Toprotectyourselfagainstin-transitloss,werecommendyouinsure
your returned material.
NOTE: You must obtain a CSA# before returning any instrument.
www. .com [e-mail]1.800.561.8187

www. .com [e-mail]1.800.561.8187

01/15
99-MAN 100402 v2
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
              
www. .com [e-mail]1.800.561.8187
