AEMC MN251T User manual

AC Current Probe
Model MN251T
User Manual
DESCRIPTION
The MN251T is the latest in compact AC Current probes. Designed to meet the most stringent demands
in industry and electrical contracting, it also meets the latest safety and performance standards. The
probe has a measurement range up to 240 Arms which makes it the perfect tool for measurement with
DMMs, recorders, power and harmonic meters. The Model MN251T is compatible with any AC
voltmeter, multimeter, or other voltage measurement instrument that is capable of displaying 1mV of
output per amp of measured current, voltmeter accuracy of 0.75% or better and an input impedance of ≥
1 MΩ.
WARNING
The safety warnings are provided to ensure the safety of personnel and proper operation of the
instrument. Read the instruction completely.
• Use caution on any circuit: potentially high voltages and currents may be present and may pose
a shock hazard.
• Do not use the probe if damaged. Always connect the current probe to the measuring device
before it is connected around the conductor.
• Do not use on non-insulated conductor with a potential to ground greater than 600V CAT III
pollution 2. Use extreme caution when clamping around bare conductors or bus bars.
• Before each use, inspect the probe; look for cracks in housing or output cable insulation.
• Do not use clamp in wet environment or in locations that hazardous gases exist.
• Do not use the probe anywhere beyond the tactile barrier.
INTERNATIONAL ELECTRICAL SYMBOLS
This symbol signifies that the current probe is protected by double or reinforced insulation. Use
only factory specified replacement parts when servicing the instrument.
This symbol signifies CAUTION! and requests that the user refer to the user manual before
using the instrument.
This is a type A current sensor. This symbol signifies that application around and removal from
HAZARDOUS LIVE conductors is permitted.
DEFINITION OF MEASUREMENT CATEGORIES
CAT II: For measurements performed on circuits directly connected to the electrical distribution system.
Examples are measurements on household appliances or portable tools.
CAT III: For measurements performed in the building installation at the distribution level such as on
hardwired equipment in fixed installation and circuit breakers.
CAT IV: For measurements performed at the primary electrical supply (<1000V) such as on primary
overcurrent protection devices, ripple control units, or meters.
RECEIVING YOUR SHIPMENT
Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify
your distributor of any missing items. If the equipment appears to be damaged, file a claim immediately
with the carrier and notify your distributor at once, giving a detailed description of any damage.
www. .com [e-mail]1.800.561.8187

ELECTRICAL SPECIFICATIONS
Nominal Range: 200A
Measurement Range: 0.1 to 240A
Transformation Ratio: Voltage output
Output Signal: 1mV/A
Accuracy and Phase Shift*:
Accuracy: 0.5 to 10A: 3.0% Reading ± 0.5mV
10 to 40A: 2.5% Reading ± 0.5mV
40 to 100A: 2.0% Reading ± 0.5mV
100 to 240A: 1.0% Reading ± 0.5mV
Phase Shift: 0.5 to 10A: Not Specified
10 to 40A: ≤ 5°
40 to 100A: ≤ 3°
100 to 240A: ≤ 2.5°
(*Reference conditions: 64 to 82°F (18 to 28°C), 20 to 75%
RH, external magnetic field < 40 A/m, 48 to 65Hz sine wave,
distortion factor less than 1%, no DC component, no external
current carrying conductor, test sample centered.)
Load impedance > 1MΩ.
Frequency Range: 40 to 10kHz
Limit Operating Conditions:
200A permanently to 1kHz
Derating above 3kHz: 200 A x (1/0.333 F), F in kHz
www. .com [e-mail]1.800.561.8187

Crest Factor:
3 @ 200Arms with an error (due to CF) of 3%
Working Voltage: 600Vrms
Common Mode Voltage: 600Vrms
Influence of Adjacent Conductor:
< 15mA/A at 50Hz
Influence of DC on AC signal:
DC Current < 20A, < 5%
Influence of Conductor Position in Jaw:
0.5% of mV output @ 50/60Hz
Influence of Frequency:
40Hz to 1kHz: 3% of mV output
1kHz to 10kHz: 12% of mV output
Influence of Load:
< 3% of mA output from 40Hz to 1kHz
< 12% of mA output from 1kHz to 10kHz
Influence of Temperature:
Mechanical Shock:
Test per IEC 68-2-27
Vibration:
Test per IEC 68-2-6
Dimensions:
5.47 x 2.00 x 1.18" (139 x 51 x 30 mm)
Weight: 180 g (6.5 oz)
Polycarbonate Material:
Jaws: Polycarbonate with 10% fiberglass charge,
Red UL 94 V0
Case: Polycarbonate 920A Gray
Opening Operations - Life: > 50,000
Output:
10 ft (3m) insulated lead with BNC connector
SAFETY SPECIFICATIONS
≤ 150 ppm/°K, or 0.15% of mV output per 10°K
Influence of Humidity (10 - 90% RH):
≤ 0.2% of mV output per 10°K @ 18°C to 28°C
MECHANICAL SPECIFICATIONS
Operating Temperature:
14° to 131°F (-10° to +55°C)
Storage Temperature:
-40° to 158°F (-40° to +70°C)
Operating Relative Humidity:
50° to 95°F (10° to 35°C) 85% RH (without roll-off
above 95°F [35°C])
Maximum Cable Diameter:
One Ø 0.78" (20mm), bus bar 0.78 x 0.2” (20 x
5mm)
Case Protection:
IP 40 (IEC 529)
Drop Test:
Test per IEC 68-2-32: 1.0m drop on 38mm of oak
on concrete.
Electrical:
Double insulation or reinforced insulation between
the primary or secondary and the outer case of the
handle conforms to IEC 1010-2-32.
Common Mode Voltage:
600V CAT III, Pollution Degree 2
Dielectric Strength:
5550V, 50/60 Hz between primary, secondary
and the outer case of the handle
Electromagnetic Compatibility:
EN 50081-1 Class B
EN 50082-2 Electrostatic discharge
IEC 1000-4-2
Radiated field IEC 1000-4-3
Fast transients IEC 1000-4-4
Magnetic field at 50/60 Hz IEC 1000-4-8
ORDERING INFORMATION
AC Current Probe MN251T................Cat #2132.59
www. .com [e-mail]1.800.561.8187

OPERATION
Please make sure that you have already read and fully understand the WARNING section on page 1.
Making Measurements with the AC Current Probe Model MN251T:
• Connect the BNC connector to your voltage-measuring instrument. The AC current probe has an output of
1mV/A. This means that for 200A AC in a conductor around which the probe is clamped, 200 mV AC will
come out of the probe leads to your DMM or instrument. Select the range which corresponds to the
measured current. If the current magnitude is unknown, start with the highest range and work down until
the appropriate range and resolution are reached. Clamp the probe around the conductor. Take the
reading on the meter and multiply it by 1000 to obtain the measured current (e.g, 150mV reading = 150 x
1000 = 150,000mA or 150A).
• For best accuracy, avoid if possible, the proximity of other conductors which may create noise.
Tips for Making Precise Measurements:
• When using a current probe with a meter, it is important to select the range that provides the best
resolution. Failure to do this may result in measurement errors.
• Make sure that probe jaw mating surfaces are free of dust and contamination. Contaminants cause air
gaps between the jaws, increasing the phase shift between primary and secondary. It is very critical for
power measurement.
MAINTENANCE
Warning:
• For maintenance use only original factory replacement parts.
• To avoid electrical shock, do not attempt to perform any servicing unless you are qualified to do so.
• To avoid electrical shock and/or damage to the instrument, do not get water or other foreign agents into
the probe.
Cleaning:
To ensure optimum performance, it is important to keep the probe jaw mating surfaces clean at all times.
Failure to do so may result in error in readings. To clean the probe jaws, use very fine sand paper (fine 600)
to avoid scratching the jaw, then gently clean with a soft oiled cloth.
REPAIR AND CALIBRATION
You must contact our Service Center for a Customer Service Authorization number (CSA#). This will ensure
that when your instrument arrives, it will be tracked and processed promptly. Please write the CSA# on the
outside of the shipping container.
Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments
(Or contact your authorized distributor)
NOTE: All customers must obtain a CSA# before returning any instrument.
TECHNICAL AND SALES ASSISTANCE
If you are experiencing any technical problems, or require any assistance with the proper use or application
of this instrument, please contact our technical hotline:
LIMITED WARRANTY
The current probe is warranted to the owner for a period of two years from the date of original purchase
against defects in manufacture. This limited warranty is given by AEMC®Instruments, not by the distributor
from whom it was purchased. This warranty is void if the unit has been tampered with, abused or if the defect
is related to service not performed by AEMC®Instruments.
Please print the online Warranty Coverage Information for your records.
99-MAN 100455.v1 09/17
