AEMC 1110 User manual

ENGLISH User Manual
■
LIGHTMETER DATA LOGGER
1110

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An N.I.S.T. traceable certificate may be
requested at the time of purchase, or obtained
by returning the instrument to our repair and
calibration facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer. For recalibration, please
use our calibration services. Refer to our repair and
calibration section at www.aemc.com.
Serial #:
Catalog #: 2121.71
Model #: 1110
Please fill in the appropriate date as indicated:
Date Received:
Date Calibration Due:
Chauvin Arnoux®, Inc.
d.b.a AEMC®Instruments
www.aemc.com

CONTENTS
PRECAUTIONS...............................................................................................................................................................4
RECEIVING YOUR SHIPMENT.......................................................................................................................................5
ORDERING INFORMATION............................................................................................................................................5
1. GETTING STARTED ...................................................................................................................................................6
1.1. Battery Installation............................................................................................................................................6
1.2. Instrument Front Panel......................................................................................................................................7
1.3. Instrument Functions........................................................................................................................................7
1.4. Turning the Instrument ON/OFF.......................................................................................................................8
1.5. Function Buttons..............................................................................................................................................8
1.6. Display.............................................................................................................................................................9
2. SETUP.........................................................................................................................................................................10
2.1. DataView Installation......................................................................................................................................10
2.2. Connecting the Instrument to a Computer .....................................................................................................10
2.3. Instrument Date/Time.....................................................................................................................................11
2.4. Auto OFF........................................................................................................................................................11
2.5. Measurement Units........................................................................................................................................11
2.6. Light Source Type..........................................................................................................................................11
3. STANDALONE OPERATION......................................................................................................................................12
3.1. Making Measurements...................................................................................................................................12
3.1.1. HOLD Function...................................................................................................................................12
3.1.2. MAX AVG MIN Function......................................................................................................................12
3.1.3. MAP Function......................................................................................................................................13
3.2. Recording Measurements..............................................................................................................................14
3.3. Errors.............................................................................................................................................................14
4. DATAVIEW..................................................................................................................................................................15
5. TECHNICAL CHARACTERISTICS.............................................................................................................................16
5.1. Reference Conditions.....................................................................................................................................16
5.2. Optical Specifications.....................................................................................................................................16
5.2.1. Illumination Measurements.................................................................................................................16
5.2.2. Other Optical Specifications................................................................................................................16
5.2.3. Spectral Response Curve V(λ) ...........................................................................................................17
5.2.4. Variation According to the Type of Light Source.................................................................................17
5.3. Memory..........................................................................................................................................................17
5.4. USB................................................................................................................................................................18
5.5. Bluetooth........................................................................................................................................................18
5.6. Power Supply.................................................................................................................................................18
5.7. Environmental Conditions..............................................................................................................................18
5.8. Mechanical Specifications..............................................................................................................................18
5.9. Compliance with International Standards.......................................................................................................18
5.10. Electromagnetic Compatibility (CEM)...........................................................................................................18
6. MAINTENANCE ..........................................................................................................................................................19
6.1. Cleaning.........................................................................................................................................................19
6.2. Maintenance...................................................................................................................................................19
6.3. Battery Replacement......................................................................................................................................19
6.4. Firmware Update............................................................................................................................................19
APPENDIX.......................................................................................................................................................................20
A.1. Spectral Distributions of Illumination Sources................................................................................................20
A.1.1. Incandescent (Illuminant A) Illumination Spectral Distribution............................................................20
A.1.2. Fluorescent (F11) Illumination Spectral Distribution ...........................................................................20
A.1.3. LED Illumination Spectral Distribution.................................................................................................21
A.2. Illumination Values.........................................................................................................................................21
REPAIR AND CALIBRATION...........................................................................................................................................22
TECHNICAL AND SALES ASSISTANCE.......................................................................................................................22
LIMITED WARRANTY......................................................................................................................................................23

Thank you for purchasing the Lightmeter Data Logger Model 1110. For best results from your instrument:
 read these operating instructions carefully,
 comply with the precautions for use.
WARNING, risk of DANGER! The operator must refer to these instructions whenever this danger
symbol appears.
Information or useful tip.
Battery.
Magnet.
The product has been declared recyclable after analysis of its life cycle in accordance with the
ISO14040 standard.
AEMC has adopted an Eco-Design approach in order to design this appliance. Analysis of the
complete lifecycle has enabled us to control and optimize the effects of the product on the
environment. In particular this appliance exceeds regulation requirements with respect to recycling
and reuse.
Indicates conformity with European directives and with regulations covering EMC.
Indicates that, in the European Union, the instrument must undergo selective disposal in compliance
with Directive WEEE 2002/96/EC. This instrument must not be treated as household waste.
Precautions
This instrument is compliant with safety standard IEC 61010-2-030, for voltages up to 5V with respect toground.
Failure to observe the following safety instructions may result in electric shock, fire, explosion, and damage to
the instrument and/or the installation in which it is located.
 The operator and/or the responsible authority must carefully read and clearly understand all
precautions to be taken prior to using the instrument. Thorough knowledge and awareness of
electrical hazards are essential when using this instrument.
 Observe the conditions of use, including temperature, relative humidity, altitude, pollution degree, and
location of use.
 Do not use the instrument if it appears damaged, incomplete, or improperly closed.
 Before each use, check the condition of the housing and accessories. Any item on which the
insulation is deteriorated (even partially) must be set aside for repair or disposal.
 All troubleshooting and metrological checks must be done by accredited personnel.

Receiving Your Shipment
Upon receiving your shipment, make sure that the contents are consistent with the packing list. Notify your
distributor of any missing items. If the equipment appears to be damaged, file a claim immediately with the
carrier and notify your distributor at once, giving a detailed description of any damage. Save the damaged
packing container to substantiate your claim.
Ordering Information
Lightmeter Data Logger Model 1110………………………………………………………………….…Cat. #2121.71
Includes soft carrying pouch, three AA alkaline batteries, 6 ft. USB cable, quick start guide, USB thumb-drive
with DataView®software and user manual.
Replacement Parts:
Cable – Replacement 6 ft. (1.8m) USB………………………….…………….........................….......Cat. #2138.66
Pouch – Replacement Carrying Pouch……………………....…...………………….…..…................Cat. #2118.65
Accessories:
Multifix Universal Mounting System …...….…………....……………..…..........................................Cat. #5000.44
Adapter – US Wall Plug to USB….…………....…..………..……….…...…….….……....……….......Cat. #2153.78
Shock Proof Housing……………………………………….….…………...…….…..……...……..…....Cat. #2122.31
For the accessories and replacement parts, visit our web site: www.aemc.com
5 Lightmeter Data Logger Model 1110

1. GETTING STARTED
1.1. Battery Installation
The instrument accepts three AA or LR6 alkaline batteries.
1. “Tear-drop” notch to hang instrument
2. Non-skid pads
3. Magnets for mounting to a metallic surface
4. Battery compartment cover
To change the batteries:
1. Press the tab of the battery compartment cover and lift it clear.
2. Remove the battery compartment cover.
3. Insert the new batteries, ensuring correct polarity.
4. Close the battery compartment cover; ensuring it is completely and correctly closed.
Lightmeter Data Logger Model 1110 6

1.2. Instrument Front Panel
1. Spiral-wound extension cable
2. Sensor cover (captive)
3. Illumination sensor
4. Magnets for securing sensor to housing
5. Backlit LCD display
6. Keypad
7. ON/OFF button
8. Type B micro-USB connector
1.3. Instrument Functions
The Model 1110 measures illumination from 0.1 to 200,000 lux. The instrument measures visible light only, and
excludes non-visible wavelengths (infrared, ultraviolet, and so on). It measures illumination in accordance with
the recommendations of the AFE (Association Française de l’Éclairage - French Association of Illumination).
The instrument also measures decrease in illumination over time due to aging or dusty light sources.
The Model 1110 can:
 Display illumination measurements in lux (lx) or foot-candles (fc).
 Record minimum, average (mean), and maximum measurements within a specified period.
 Record minimum/average/maximum for a surface or room.
 Record and store measurements.
 Communicate with a computer via Bluetooth or USB cable.
DataView with the Data Logger Control Panel software can be installed on a computer to allow you to configure
the instrument, view measurements in real time, download data from the instrument, and create reports.
7 Lightmeter Data Logger Model 1110

1.4. Turning the Instrument ON/OFF
 ON: Press the button for >2 seconds.
 OFF: Press the button for >2 seconds when the instrument is
ON. Note that you cannot turn OFF the instrument when it is in
HOLD or in recording mode.
If the screen to the left appears during start-up, a recording session was
still in progress the last time the instrument was turned OFF. This screen
indicates the instrument is saving the recorded data.
Do not turn OFF the instrument while this screen is displayed; otherwise
the recorded data will be lost.
1.5. Function Buttons
Button
Function
 Short press selects the type of illumination source: incandescent (default), fluorescent, or
LED. (See Appendix §A.1.)
 Long press (>2 seconds) enters MAP mode.
 Short press stores the measurement and date in the instrument’s memory.
MAP mode: adds a measurement to the measurements in the MAP (§3.1.3).
 Long press starts/stops a recording session.
 Short press turns on back-lighting.
 Long press toggles between lux (lx) and foot-candles (fc).
 Short press freezes the display.

Long press activates/deactivates Bluetooth.
MAX
AVG
MIN
 Short press enters MAX AVG MIN mode (§3.1.2); measurement values continue to be
displayed.
Second press displays the maximum value.
Third press displays the average value.
Fourth press displays minimum value.
Fifth press returns to normal measurement operation.
 Long press exits MAX AVG MIN mode.
In MAP mode, pressing displays in turn the maximum, average (mean), and minimum of
the MAP measurements.
Lightmeter Data Logger Model 1110 8

1.6. Display
1. MAP function counter
2. Main display
OL indicates the measurement is outside the instrument limits (positive or negative).
indicates Auto OFF is disabled. This occurs when the instrument is:
 Recording, in MAX AVG MIN mode, in MAP mode, or in HOLD mode
 Connected via the USB cable either to an external power supply or for communication with a computer
 Communicating via Bluetooth
 Set to Auto OFF disabled (see §2.4)
1
2
9 Lightmeter Data Logger Model 1110

2. SETUP
Before using your instrument, you must set its date and time through DataView (see §2.3). Other basic setup tasks
include selecting:
 Auto OFF interval (requires DataView)
 lx or fc for measurement units (can be done on the instrument or via DataView)
 Light source type (can be done on the instrument or via DataView)
2.1. DataView Installation
1. Insert the USB drive that comes with the instrument into a USB port on your computer.
2. If Autorun is enabled, an AutoPlay window appears on your screen. Click “Open folder to view files” to
display the DataView folder. If Autorun is not enabled or allowed, use Windows Explorer to locate and open
the USB drive labeled “DataView.”
3. When the DataView folder is open, find the file Setup.exe and double-click it.
4. The Setup screen appears. This enables you to select the language version of DataView to install. You can
also select additional install options (each option is explained in the Description field). Make your selections
and click Install.
5. The InstallShield Wizard screen appears. This program leads you through the DataView install process. As
you complete these screens, be sure to check Data Loggers when prompted to select features to install.
6. When the InstallShield Wizard finishes installing DataView, the Setup screen appears. Click Exit to close.
The DataView folder appears on your computer desktop.
2.2. Connecting the Instrument to a Computer
You can connect the instrument to a computer either through USB cable (provided with the instrument) or
Bluetooth®. The first two steps of the connection procedure depend on the connection type:
USB:
1. Connect the instrument to an available USB port using the supplied cable.
2. Turn ON the instrument. If this is the first time this instrument has been connected to this computer, the
drivers will be installed. Wait for driver installation to finish before proceeding with step 3 below.
Bluetooth:
Connecting the instrument via Bluetooth requires a Bluegiga BLED112 Smart Dongle (sold separately) installed in
your computer. When the dongle is installed, do the following:
1. Turn ON the instrument by pressing the button.
2. Activate Bluetooth on the instrument by pressing thebutton until the symbol appears in the LCD.
After the USB cable is connected or Bluetooth is activated, proceed as follows:
3. Open the DataView folder on your desktop. This displays a list of icons for the Control Panel(s) installed
with DataView.
4. Open the DataView Data Logger Control Panel by clicking the icon.
5. In the menu bar at the top of the screen, select Help. In the drop-down menu that appears, click the option
Help Topics. This opens the Data Logger Control Panel Help system.
6. Use the Contents window in the Help system to locate and open the topic "Connecting to an Instrument."
This provides instructions explaining how to connect your instrument to the computer.
7. When the instrument is connected, its name appears in the Data Logger Network folder in the left side of
the Control Panel. A green check mark appears next to the name indicating it is currently connected.
Lightmeter Data Logger Model 1110 10
