Aerotrak 7010 User manual
AEROTRAK®+
REMOTE ACTIVE AIR SAMPLER
MODEL 7010
OPERATION MANUAL
P/N 6014704 REVISION A
JULY 2020
SHIP TO/MAIL TO:
TSI Incorporated
500 Cardigan Road
Shoreview, MN 55126-3996
USA
U.S.
Technical Support:
(800) 680-1220/(651) 490-2860
Fax:
(651) 490-3824
E-mail address:
Website:
http://www.tsi.com
INTERNATIONAL
Technical Support:
(001 651) 490-2860
Fax:
(001 651) 490-3824
ii
Manual History
The following is a manual history of the AeroTrak®+ Active Air Sampler
Model 7010 Operation Manual (P/N 6014704).
Revision
Date
A
July 2020
iii
Warranty
Part Number
6014704 / Revision A / July 2020
Copyright
©TSI Incorporated / 2020 / All rights reserved.
Address
TSI Incorporated / 500 Cardigan Road / Shoreview, MN 55126 / USA
E-mail Address
Limitation Of Warranty And Liability
(effective April 2014)
(For country-specific terms and conditions outside of the USA, please visit www.tsi.com.)
Seller warrants the goods, excluding software, sold hereunder, under normal use and
service as described in the operator's manual, to be free from defects in workmanship and
material for 24 months, from the date of shipment to the customer. This warranty period is
inclusive of any statutory warranty. This limited warranty is subject to the following
exclusions and exceptions:
a. Hot-wire or hot-film sensors used with research anemometers, and certain other
components when indicated in specifications, are warranted for 90 days from the date of
shipment;
b. Pumps are warranted for hours of operation as set forth in product or operator’s
manuals;
c. Parts repaired or replaced as a result of repair services are warranted to be free from
defects in workmanship and material, under normal use, for 90 days from the date of
shipment;
d. Seller does not provide any warranty on finished goods manufactured by others or on
any fuses, batteries or other consumable materials. Only the original manufacturer's
warranty applies;
e. This warranty does not cover calibration requirements, and seller warrants only that the
instrument or product is properly calibrated at the time of its manufacture. Instruments
returned for calibration are not covered by this warranty;
f. This warranty is VOID if the instrument is opened by anyone other than a factory
authorized service center with the one exception where requirements set forth in the
manual allow an operator to replace consumables or perform recommended cleaning;
g. This warranty is VOID if the product has been misused, neglected, subjected to
accidental or intentional damage, or is not properly installed, maintained, or cleaned
according to the requirements of the manual. Unless specifically authorized in a
separate writing by Seller, Seller makes no warranty with respect to, and shall have no
liability in connection with, goods which are incorporated into other products or
equipment, or which are modified by any person other than Seller.
The foregoing is IN LIEU OF all other warranties and is subject to the LIMITATIONS stated
herein. NO OTHER EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR
PARTICULAR PURPOSE OR MERCHANTABILITY IS MADE. WITH RESPECT TO
SELLER’S BREACH OF THE IMPLIED WARRANTY AGAINST INFRINGEMENT, SAID
WARRANTY IS LIMITED TO CLAIMS OF DIRECT INFRINGEMENT AND EXCLUDES
CLAIMS OF CONTRIBUTORY OR INDUCED INFRINGEMENTS. BUYER’S EXCLUSIVE
REMEDY SHALL BE THE RETURN OF THE PURCHASE PRICE DISCOUNTED FOR
REASONABLE WEAR AND TEAR OR AT SELLER’S OPTION REPLACEMENT OF THE
GOODS WITH NON-INFRINGING GOODS.
TO THE EXTENT PERMITTED BY LAW, THE EXCLUSIVE REMEDY OF THE USER OR
BUYER, AND THE LIMIT OF SELLER'S LIABILITY FOR ANY AND ALL LOSSES,
INJURIES, OR DAMAGES CONCERNING THE GOODS (INCLUDING CLAIMS BASED
ON CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR OTHERWISE) SHALL BE
THE RETURN OF GOODS TO SELLER AND THE REFUND OF THE PURCHASE PRICE,
OR, AT THE OPTION OF SELLER, THE REPAIR OR REPLACEMENT OF THE GOODS.
IN THE CASE OF SOFTWARE, SELLER WILL REPAIR OR REPLACE DEFECTIVE
SOFTWARE OR IF UNABLE TO DO SO, WILL REFUND THE PURCHASE PRICE OF
THE SOFTWARE. IN NO EVENT SHALL SELLER BE LIABLE FOR LOST PROFITS,
BUSINESS INTERRUPTION, OR ANY SPECIAL, INDIRECT, CONSEQUENTIAL OR
INCIDENTAL DAMAGES. SELLER SHALL NOT BE RESPONSIBLE FOR INSTALLATION,
DISMANTLING OR REINSTALLATION COSTS OR CHARGES. No Action, regardless of
form, may be brought against Seller more than 12 months after a cause of action has
accrued. The goods returned under warranty to Seller's factory shall be at Buyer's risk of
loss, and will be returned, if at all, at Seller's risk of loss.
iv AeroTrak®+ Remote Active Air Sampler Operation Manual
Buyer and all users are deemed to have accepted this LIMITATION OF WARRANTY AND
LIABILITY, which contains the complete and exclusive limited warranty of Seller. This
LIMITATION OF WARRANTY AND LIABILITY may not be amended, modified or its terms
waived, except by writing signed by an Officer of Seller.
Service Policy
Knowing that inoperative or defective instruments are as detrimental to TSI as they are to
our customers, our service policy is designed to give prompt attention to any problems. If
any malfunction is discovered, please contact your nearest sales office or representative, or
call TSI’s Customer Service department at 1-800-680-1220 (USA) or +001 (651) 490-2860
(International).
Trademarks
TSI, the TSI logo, and AeroTrak are registered trademarks of TSI Incorporated in the
United States and may be protected under other country’s trademark registrations.
Modbus is a registered trademark of Modicon, Incorporated. Windows and Internet Explorer
are registered trademarks of Microsoft Corporation.
v
Contents
Manual History.........................................................................................ii
Warranty..................................................................................................iii
Contents...................................................................................................v
Safety......................................................................................................vii
Labels...................................................................................................... vii
Description of Caution/Warning Symbols ........................................... viii
Caution............................................................................................. viii
Warning............................................................................................ viii
Caution or Warning Symbols.............................................................. viii
Reusing and Recycling ....................................................................... viii
Getting Help..............................................................................................ix
CHAPTER 1 Introduction and Unpacking......................................... 1-1
Unpacking the AeroTrak®+ Remote Active Air Sampler ....................... 1-2
Optional Accessories ......................................................................... 1-3
CHAPTER 2 Installation and Getting Started ................................... 2-1
Indicator LEDs....................................................................................... 2-1
Electrical Connections........................................................................... 2-2
Device Connections........................................................................... 2-2
12-24 VDC / Relay Connector........................................................ 2-2
Ethernet Connector.............................................................. 2-3
USB-C Connector................................................................ 2-3
Installation.............................................................................................. 2-3
Determine the Installation Location.................................................... 2-3
Mounting the Control Box................................................................... 2-4
Supplying Power to the Air Sampler.................................................. 2-4
Using Power-Over-Ethernet (PoE) ................................................. 2-5
Using DC Power ............................................................................. 2-5
Connecting the Air Sampler to a Computer....................................... 2-6
Vacuum Tubing Installation................................................................ 2-6
Connecting the Sample Head to the Control Box........................... 2-6
CHAPTER 3 Communications and Configurations.......................... 3-1
Setting the IP Address of the Air Sampler............................................. 3-1
Viewing Device Information................................................................... 3-2
Title Bar.............................................................................................. 3-2
Main Page—Instrument Tab.............................................................. 3-3
Main Page—Communication Tab...................................................... 3-4
Configuring the Air Sampler.................................................................. 3-4
Tech Page—Instrument (Instr) Tab ................................................... 3-6
Tech Page—Password (Passwd) Tab............................................... 3-7
Tech Page—Reset Tab...................................................................... 3-7
Loading or Saving a Configuration..................................................... 3-8
Air Sampler Report Page....................................................................... 3-8
Saving a Configuration Report........................................................... 3-9
About Page.......................................................................................... 3-10
vi AeroTrak®+ Remote Active Air Sampler Operation Manual
CHAPTER 4 Operation........................................................................ 4-1
Load Plate for Sampling........................................................................ 4-1
Unload Plate and Obtain Results .......................................................... 4-1
CHAPTER 5 Maintenance ................................................................... 5-1
Cleaning and Disinfection...................................................................... 5-1
Sanitization and Sterilization ................................................................. 5-1
CHAPTER 6 Troubleshooting............................................................. 6-1
CHAPTER 7 Contacting Customer Service ...................................... 7-1
Technical Contacts................................................................................ 7-1
International Contacts........................................................................ 7-1
Service............................................................................................ 7-1
Technical Support........................................................................... 7-2
Returning for Service............................................................................. 7-2
APPENDIX A Specifications...............................................................A-1
Compliance............................................................................................A-2
Dimensional Diagram - Model 7010......................................................A-3
Index
vii
Safety
This section provides instructions to promote safe and proper handling of
the AeroTrak®+ Remote Active Air Sampler Model 7010.
I M P O R T A N T
There are no user-serviceable parts inside the instrument. Refer all
repair and maintenance to a qualified factory-authorized technician. All
maintenance and repair information in this manual is included for use by
a qualified factory-authorized technician.
Labels
Advisory labels and identification labels are attached to the outside of the
control box housing.
1. Serial number label
(left-side panel)
2. Serial number label
(back)
3. Calibration label
(right-side panel)
4. European symbol for non-
disposable item. Item must
be recycled.
viii AeroTrak®+ Remote Active Air Sampler Operation Manual
Description of Caution/Warning Symbols
Appropriate caution/warning statements are used throughout this manual
and on the instrument. They require you to take cautionary measures
when working with the instrument.
Caution
C A U T I O N
Caution means be careful. Not following the procedures prescribed in
this manual may result in irreparable equipment damage. Caution also
indicates important information about the operation and maintenance of
this instrument is included.
Warning
WARNING
Warning means unsafe use of the instrument could result in serious
injury or cause irrevocable damage to the instrument. Follow the
procedures prescribed in this manual to use the instrument safely.
Caution or Warning Symbols
The following symbols may accompany cautions and warnings to
indicate the nature and consequences of hazards:
Warns that uninsulated voltage within the instrument may
have sufficient magnitude to cause electric shock.
Therefore, it is dangerous to come into contact with any
part inside the instrument.
Warns that the instrument is susceptible to electro-static
dissipation (ESD) and ESD protection procedures should
be followed to avoid damage.
Indicates the connector is connected to earth ground and
cabinet ground.
Reusing and Recycling
As part of TSI Incorporated’s effort to have a minimal
negative impact on the communities in which its products
are manufactured and used:
•DO NOT dispose of used batteries in the trash.
•Follow local environmental requirements for battery
recycling.
•If instrument becomes obsolete, return to TSI for
disassembly and recycling.
Safety ix
Getting Help
To obtain assistance with this product or to submit suggestions, please
contact Customer Service:
TSI Incorporated
500 Cardigan Road
Shoreview, MN 55126 U.S.A.
Fax: (651) 490-3824 (USA)
Fax: 001 651 490 3824 (International)
Telephone: 1-800-680-1220 (USA) or (651) 490-2860
International: 001 651 490-2860
E-mail Address: technical.services@tsi.com
Web site: www.tsi.com
x AeroTrak®+ Remote Active Air Sampler Operation Manual
(This page intentionally left blank)
1–1
C H A P T E R 1
Introduction and
Unpacking
The AeroTrak®+ Active Air Sampler is appropriate for use in monitoring
airborne biocontamination in critical environments. The sampler is a
sieve impactor that draws a specified volume of air through the
perforations in a cap and around a plate of nutrient media. Viable
particles with sufficient mass contained in the drawn in air fall out of the
air stream and impact on the surface of the media. The media is then
incubated for a specified time under appropriate conditions to allow for
the growth of visible colonies.
The sampler is comprised of two parts, a sample head and a control box.
The sample head includes the perforated cap and holds a standard size
(90 mm) agar plate. The control box contains the electronic components
and a critical orifice. When connected to an appropriate vacuum source,
the critical orifice controls the flow at 1.0 cfm (28.3 L/min).
Sampling is controlled by TSI Incorporated’s Facility Monitoring System
Software. Communication with the software is via integrated Ethernet
(TCP/IP) and serial Modbus RTU.
The following table shows the active air sampler models covered by
this manual.
Part Number
Flow Rate
Plate Size (mm)
No. of
Heads
7010-090-1
28.3 L/min (1 cfm)
90 mm
1
1–2 AeroTrak®+ Remote Active Air Sampler Operation Manual
Unpacking the AeroTrak®+ Remote Active
Air Sampler
Carefully unpack the AeroTrak®+ Remote Active Air Sampler from the
shipping container and check the contents of the shipment against the
tables below. If any parts are missing or broken, notify TSI immediately.
Keep the shipping container for returning the device for service.
Qty.
Item Description
Part/Model
Reference Picture
1
AeroTrak®+ Remote
Active Air Sampler
Control Box
ARS-010-1
1
AeroTrak®+ Remote
Active Air Sampler
Sample Head Base
ARS-B010-
090-V
1
AeroTrak®+ Remote
Active Air Sampler
Sample Head Cap
ARS-C010-
090-V
1
Operation Manual
(6014704) and
Configuration Utility
on USB drive
7004239
1
Calibration Certificate
N/A
1
12-24 VDC / Relay
Connector
6003398
Introduction and Unpacking 1–3
Optional Accessories
The following table lists optional accessories. If you ordered optional
accessories, make certain they have been received and are in
working order.
Item Description
Part/Model
Reference Picture
Power Supply
PSU-ARWP
USB-C Cable
700360
AeroTrak®+ Calibration
Accessory
700220
Tri-clamp with Gasket
700211
Containment Filter
700214
Wall Mounting Bracket
700008-1
Sanitary Inlet Adapter
700212
Sanitary to 1/2” barb adapter
700213
Tubing, Superthane,
1/2”ID x 5/8“OD, 100 ft
700108
1–4 AeroTrak®+ Remote Active Air Sampler Operation Manual
Item Description
Part/Model
Reference Picture
Attachable agar plate /
sample head cap holder*
700210
*The Attachable agar plate / sample head cap holder is a purpose-built
accessory that securely holds one agar plate and its lid (together or separately),
or one sample head cap when removed from the sample head base. One or
more holders can be attached to the sample head base to simplify settle plate
deployment and/or store the sample cap during the agar plate change process.
2–1
C H A P T E R 2
Installation and
Getting Started
This chapter describes the features, connections, and installation of the
AeroTrak®+ Remote Active Air Sampler.
Indicator LEDs
The three LEDs on the front of the air sampler provides an indication of
the air sampler’s operation as described in the table below.
Indicator
Status
Function
Status
Green
No errors are detected
Blinking Red
Power loss occurred during sampling
Red
Device is in a service alert from 1 or
more of the following conditions:
•Volume error
•Flow error
•Calibration error
•Ambient condition error
Flow
Yellow—solid
Device flow is good
Yellow—flashing
Device has a flow error
Off
No flow detected
Sample
Blue—solid
Device is sampling
Blue—off
Device is not sampling
2–2 AeroTrak®+ Remote Active Air Sampler Operation Manual
Electrical Connections
The state-of-the art AeroTrak®+ Remote Active Air Sampler supports
multiple communications and connectivity options. A brief description of
each of the connections is listed below.
Device Connections
•12-24 VDC/Relay Connector
•Ethernet Connector
•USB-C Connector
12-24 VDC / Relay Connector
This connector can be used as either a 12–24 VDC power connection
when Power-Over-Ethernet (PoE) is not available and as a relay
connection.
If used as a power connector, only a TSI-supplied 12 VDC power supply
(such as TSI model PSU-ARWP) should be used.
Terminal
Direction
1
GND
2
12–24 VDC
3
RELAY1 –Contact 1 for internal relay
4
RELAY2 –Contact 2 for internal relay
If used as a relay, the alarm contact is used to indicate an alarm
condition. The alarm contact closure is normally open. The contact is
controlled by FMS. The relay contact is rated for a 2A @ 30 VDC load.
This relay can be controlled by external software (i.e. FMS) and is
configured on the Configuration Utility.
Installation and Getting Started 2–3
Ethernet Connector
The air sampler should be connected to a 10/100 Mbps network that
supports Power-Over-Ethernet (802.3af PoE). The green LED indicates
that the network is connected. The yellow LED indicates activity on the
network cable.
The Ethernet LAN connector is a standard 10/100 Mbps 8-Position
8-Contact (8P8C, often called RJ45) modular plug connection that
supports Power-Over-Ethernet (802.3af PoE) devices.
USB-C Connector
This connection is used to communicate with the air sampler via a
USB-C cable connected to a Windows®operation system computer
running the Configuration Utility. The air sampler can be powered by
USB-C for configuration. The air sampler cannot be powered by USB-C
for sampling.
Installation
Installation of the AeroTrak®+ Remote Particle Counter consists of:
•Determine the Installation Location
•Mounting the Control Box
•Supplying Power to the Air Sampler
•Connecting the Air Sampler to a Computer
•Vacuum Tubing Installation
Determine the Installation Location
Determine the installation location according to your monitoring needs.
The remote active air sample head should be located close to a critical
location as determined by risk analysis. The control box should be
located such that the tube length to the sample head is kept to a
minimum (see Warning on page 2-7) and it does not pose a risk to the
process. It is generally convenient to mount the control box to a vertical
flat surface such as a wall, but it can also be mounted below the critical
work area or a convenient location close to the point of sampling. Access
to the control box for calibration should be considered.
2–4 AeroTrak®+ Remote Active Air Sampler Operation Manual
Mounting the Control Box
The AeroTrak®+ Remote Active Air
Sampler can be mounted using a
variety of mounting brackets and
schemes.
TSI provides an optional mounting
bracket (TSI P/N 700008-1) that
allows the control box to be easily
mounted and removed on a surface
(see figures).
To install the mounting bracket:
1. The bracket is provided with two
0.169-inch (4.30 mm) diameter
holes, suitable for a #6 or M4
screw. Screw the bracket to the
mounting surface using
appropriate screws.
2. Slide the particle counter onto
the mounting tabs at the top of
the bracket and snap it into the
locking tab (circled in figure).
To remove the AeroTrak®+ Active
Air Sampler from the mounting
bracket:
1. Press the locking tab at the top
of the bracket.
2. Lift the particle counter off the
mounting tabs.
Mounting Bracket (optional)
Remote Active Air Sampler
Mounted on Optional Bracket
Supplying Power to the Air Sampler
The AeroTrak®+ Remote Active Air Sampler may be powered in one of
two ways. For easy installation, the air sampler is designed to work
primarily with Power-Over-Ethernet (802.3af PoE). Alternatively, the air
sampler can be powered by the optional TSI Model PSU-ARWP power
supply or with a user supplied 12–24-volt supply. The air sampler can
operate with both PoE and AUX connected at the same time for
redundancy and backup continuous monitoring.
W A R N I N G
If the AeroTrak®+ Remote Active Air Sampler is powered by a network,
it should be connected only to a standard 10/100 Mbps Ethernet
network that supports Power-Over-Ethernet according to the IEEE
802.3af PoE or IEEE 802.3at PoE+ standard. Use of power supplied
over a network that does not comply with this standard could seriously
damage your air sampler.
