Sentry ISOLOK SAL-Q Instruction manual

Original Instructions
Installation, Operation
&Maintenance Manual
ISOLOK SAL-Q Sampler
Point Samplers
S-LS-IOM-00304-6 9-17

2 Sentry Equipment Corp
Do not install, maintain, or operate this equipment without reading, understanding, and following the
appropriate Sentry Equipment Corp instructions. Otherwise, injury, damage, or both may result.
Copyright
© 2017 by Sentry Equipment Corp. All rights reserved. All product and company names are property of their respective
owners. This document contains proprietary information. No part of this document may be photocopied or reproduced
without the prior written consent of Sentry Equipment Corp.
Limit of Liability
Sentry Equipment Corp, its employees, agents, and the authors and contributors to this document specically disclaim
all liabilities and warranties, express or implied (including warranties of merchantability and tness for a particular
purpose), for the accuracy, currency, completeness, and/or reliability of the information contained herein and/or for the
tness for any particular use and/or for the performance of any material and/or equipment selected in whole or part
with the user of/or in reliance upon information contained herein. Selection of materials and/or equipment is at the
sole risk of the user of this publication.
Note
The information contained in this document is subject to change without notice.

ISOLOK SAL-Q Sampler 3
Table of Contents
Safety Information .........................................4
General Safety Precautions .................................5
General Description ........................................6
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Receiving............................................................7
Selecting an Installation Location ....................................7
Operation..................................................8
Maintenance ...............................................8
Process Seals Change-Out ...........................................8
Air Cylinder Seals Change-Out .......................................9
Troubleshooting ...........................................10
Parts & Accessories .........................................12
Standard Warranty .........................................13
Customer Support..........................................14

4 Sentry Equipment Corp
Safety Information
Please read the entire manual before attempting to unpack, set up, or operate this product. Pay careful attention to all
Warnings, Cautions, and Notes. Failure to do so could result in serious personal injury and/or equipment damage.
Use of Hazard Information
If multiple hazards exist, the signal word corresponding to the greatest hazard shall be used.
Denitions
DANGER indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION, used with the safety alert symbol, indicates a
hazardous situation which, if not avoided, could result in
minor or moderate injury.
NOTICE is used to address practices not related to personal
injury.
ÂNOTE
Information that requires special emphasis.
ÂTIP
Alternate techniques or clarifying information.
SHALL:
This word is understood to be mandatory.
SHOULD:
This word is understood to be advisory.

ISOLOK SAL-Q Sampler 5
General Safety Precautions
Product Selection, Installation, and Use
Improper selection, installation, or use can cause personal injury or property damage. It is solely the responsibility of users,
through their own analysis and testing, to select products suitable for their specic application requirements, ensure they are
properly maintained, and limit their use to their intended purpose.
Follow proper local, state, and federal regulations for proper installation and operational requirements.
Always use caution and common sense when working with any chemical. Read the product label and Material Safety Data
Sheets (MSDS) carefully and follow the instructions exactly.
Potential Equipment Hazards
Hot surfaces! This equipment may have very hot surfaces. If an operator contacts a hot surface, injury may occur. Use
protective clothing to prevent injury. If other equipment comes in contact with a hot surface, damage to the equipment may
occur. Ensure the area around this equipment is kept clear to prevent damage from occurring.
High pressures! This equipment may contain uids at very high pressures. Prior to installing, removing or maintaining this
equipment, ensure that the equipment is isolated from all connecting piping, the equipment is depressurized, the contents
have been drained, and the equipment is cool.
Moving parts! This equipment may contain moving parts. All drive guards and doors must be secured in place when this
machine is being operated.
Equipment rated TX. Equipment maximum surface temperature depends
on operating conditions. Ensure maximum surface temperature shall stay
below ignition temperature of dust or gas atmosphere where it is installed
based on process conditions. Failure to comply could result in an explosion,
causing serious injury or death to personnel and damage to equipment.
If the sampler is mounted directly to a non-electrically conductive surface,
sampler shall be bonded to a grounding electrode. Failure to comply
could result in sparking, which could lead to an explosion, causing harm to
personnel and equipment.
If the sample container is removed from the sampler, do not insert any
body part or other item into the sample discharge port. Crushing will
occur.
To ensure proper sampler operation, be sure
the sampler is installed in a pipe large enough
for the sampler plunger to extend without
impacting the pipe. Failure to comply will
result in equipment damage and poor sample
quality.

6 Sentry Equipment Corp
General Description
The Sentry® ISOLOK® SAL-Q automatic isolatable sampler is designed to obtain samples of liquid and slurry owing
in a process stream, into which extends a plunger with an annulus for sampling. The ISOLOK SAL-Q sampler has been
congured specically for use in sampling the process media at the process conditions provided by the user at time of
manufacture.
Each sampler cycle consists of a plunger extension and a plunger retraction. During plunger extension, the volume of
the annulus is lled with a sample of the process stream. The plunger is then retracted into the body of the sampler,
thereby capturing a volume of sample. This sample is then deposited into a sample collection container.
The ISOLOK SAL-Q automatic xed volume sampler is pneumatically operated. Pressurized air (or other gas) is used to
provide the force to extend and retract the plunger. When in the retracted position, air or other inert gas may be used
to assist the displacement of the sample material from the plunger annulus.
The maximum rated temperature of the ISOLOK SAL-Q sampler is dened by the plunger seals. The plunger seals are
selected based on material compatibility and temperature of the process being sampled. Reference the following
chart:
TX plunger seal material max temperature
T2 Peruoronated elastomer (FFKM) 550°F (288°C)
T3 Filled PTFE 500°F (260°C)
Fluoroelastomer (FKM) 400°F (204°C)
T4 ECTFE 325°F (163°C)
T5
Ethylene propylene 250°F (121°C)
95 Duro polyurethane 230°F (110°C)
Nitrile 225°F (107°C)
75 Duro polyurethane 212°F (100°C)
T6 UHMW PE 200°F (93°C)
ÂNOTE:
Figures in this manual may dier from actual purchased equipment. Please refer to the drawings in the appendices of this
document.
Read these instructions completely before proceeding to assemble, install or operate this machine. This machine should
be installed, operated and serviced by qualied individuals. All drive guards and doors must be secured in place when
this machine is being operated. Follow proper local, state and federal regulations for proper installation and operational
requirements.

ISOLOK SAL-Q Sampler 7
Installation
Receiving
Examine the crate and all contents for any shipping damage immediately after receipt.
Take pictures of any suspected damage.
Report damages to the delivery company at once. This is the responsibility of the consignee.
Selecting an Installation Location
Select a location to install the sampler where the material in the process stream is well mixed. Location of the sampler
and controller is very important for accurate sampling results. They should be as close together as practical, within
sight of each other, and protected from weather, trac damage and normal work activities in the area.
When selecting a sampler location, ensure the sample collection container will clear vertical lines (or other
obstructions) when mounted onto the sampler. The sampler can be used on a pipe or tank running horizontally,
vertically or at an angle, but the preferred position is with the axis of the sampler horizontal.
Filtered compressed air supply, plant standard electrical power (to operate a control box) or DCS cabling to operate a
suitable solenoid valve, and tradesman’s hand tools are all that is required for installation.
1. The sampler is tted onto the pipeline via a weld-on drilled and tapped adapter. When welding the adapter
onto the pipeline, ensure the end of the adapter is ush with the internal diameter of the pipeline and verify the
orientation and position is correct. Weld the adapter into place, making sure to protect the bore and face from
weld spatter.
Use industry code procedures to protect adapter from distortion. Major distortion cannot be corrected and will prevent
installation of sampler.
2. The sampler is best positioned on a vertical section of pipeline just after a 90-degree bend where the product
is owing upwards, but it can be placed on a horizontal pipeline where the product ow will be well mixed,
such as after the discharge of a pump or a 90-degree bend. Whenever possible, the sampler should not be
positioned closer than 3 meters from the discharge of a pump. When the sampler is to be positioned on the side
of a horizontal pipeline, the pipe must be completely full of owing product, with the sampler’s discharge tube
pointing down. It is not recommended that the sampler be placed into a partially lled pipeline, as this can give a
biased or incomplete sample.
3. Place the o-ring over the hub on the adapter plate (as shown on the accompanying drawings) and slide it through
the weld-on adapter. Use the provided four (4) 3/8 inch counter sunk head S/S screws to t the adapter plate to
the weld-on adapter. Ensure the heads of the screws are below the ange face and use suitable thread locking
uid.
4. Install knife gate valve assembly with attached rails to the adapter plate using the provided four (4) 3/8in hex head
bolts.
5. Install sampler actuator onto knife gate valve assembly using the rails to support the unit and attach the end plate
to the rails using the provided four (4) 3/8in button head bolts. Rotate the handwheel to insert the sleeve into the
knife gate valve until the chamber is ush with the valve. Fasten the chamber to the knife gate valve using the
provided four (4) 3/8in hex head bolts.
6. Connect all airlines, ushing lines and any required piping to the discharge tube. The sampler’s installation is now
complete.

8 Sentry Equipment Corp
ÂNOTE
If the actuator assembly (as shown on the accompanying drawings) needs to be axed to the gate valve assembly prior to
installation, please see the accompanying sampler assembly drawing for component orientation and fastener installation
details.
Operation
The ISOLOK SAL-Q sampler is directly controlled by a 1 x 5/3 double-coil, spring return solenoid valve (solenoid 1) and
a 1x3-way single coil spring return solenoid valve (solenoid 2). The solenoid valves need to be operated either by the
customer plant’s own DCS/PLC or a sampler controller. The sampler requires two (2) standard cubic feet per minute
(SCFM) at normal recommended regulated pressures of 60 psig (4.0 barg) to 100 psig (6.9 barg).
1. Connect the airlines from the 5/3 solenoid valve (solenoid 1) described above to ports B and C of the sampler,
having port B be normally open. Connect the single solenoid (solenoid 2) to port A of the sampler with it normally
closed.
2. The sampler is operated per the Port Energizing Scheme below. Note that port D is only for exhaust air from the
neutral cylinder.
Port Energizing Scheme
Position Ports Pressurized Solenoid Energized
Extend A and C 1 and 2
Retract B None
Neutral (Park) C 1
3. The Sampler can be stroked up to a maximum of 10 times per minute continuously. We recommend this minimum
stroke to help lessen any product buildup that might occur on the end of the sampler. The sample volume size is
directly proportional to the amount of strokes taken.
4. A technician now can program the plant’s DCS/PLC or the Sentry sampler controller to obtain the desired sample
over the preferred time frame. If a Sentry sampler controller has been purchased, please refer to the supplied
instruction manual.
Maintenance
Sampler must not be disassembled or removed from the gate valve until the gate valve is completely closed and any excess
pressure inside the gate valve or sampler’s wear sleeve has been released.
Process Seals Change-Out
To replace the process seals, withdraw the actuator assembly from the process line. The actuator assembly is still
inserted through and bolted to the gate valve.
1. First, ensure the insertion/extraction tool end plate is still securely bolted to the side rails.
2. Turn o and/or disconnect the compressed air supply to the sampler’s solenoid valve(s) or the sampler controller.
Remove all airlines into the actuator assembly and disconnect any sample discharge and ushing lines.

ISOLOK SAL-Q Sampler 9
3. Next, remove the four (4) 3/8 in. hex head bolts holding the sampler to the gate valve. Turn the insertion/
extraction handle at the end of the actuator assembly in a counter clockwise direction. The actuator assembly
should now start to withdraw from the Gate Valve. When the air cylinder’s end cap has stopped against the
insertion/extraction tool’s end plate, the sampler’s wear sleeve should be clear of the travel path of the valve’s
“knife,”but still sealing inside the bore of the Gate Valve. Now turn the handle on top of the Gate Valve until the
Gate Valve is completely closed.
4. Open any bleed port valves on the gate valve to allow any excess pressure inside the gate valve or sampler’s wear
sleeve to be released.
5. Remove the four (4) 3/8 inch button head screws holding the end plate to the side rails. The actuator assembly,
complete with the insertion/extraction tool, now can be removed. Remove the rails and install the blanking ange
on the valve.
6. Remove the four (4) 316 SS dome head nuts holding the sample chamber to the rod gland. The air cylinder
assembly, complete with the process seals assembly still connected to the piston rod, now can be removed from
the main sample chamber. Using a suitable spanner, separate the spool assembly by unscrewing the end process
seal mount/nut while holding the piston rod with another spanner.
7. Clean the disassembled spool assembly and replace any worn parts. Fit new process seals back onto the seal
mounts. Thread each seal mount back onto the M16 stud and tighten it down by gripping it with a pair of
multigrips pliers while holding the end seal mount with a wrench. Refer to the accompanying actuator assembly
drawing for lubricants, sealants and torque values.
8. Inspect and clean the sample chamber wear sleeve. Fine grade emery paper can be used on the bore to remove
any light scratches or product build-up. If a new process seal will slide easily through the old wear sleeve with any
clearance, the wear sleeve needs to be replaced. To replace it, loosen the set screw located on the side of the main
sample chamber behind the sampler’s discharge port, then remove the wear sleeve out the front of the sampler.
Replace the wear sleeve o-rings located in the bore of the main sample chamber if required. Ensure the discharge
port and ush port openings on the wear sleeve align with those in the sample chamber.
9. Insert the completed air cylinder assembly back into the wear sleeve/sample chamber and reinstall the four
(4) 316 SS dome head nuts in accordance with the accompanying actuator assembly drawing. The seal/spool
assembly will be tight and may require use of a suitable process compatible lubricant.
10. Slide the now fully reassembled actuator assembly back onto the side rails and insert the actuator partially back
into the gate valve until the 3/8 in. tapped holes in the endplate align with the holes on the side rails. Screw in and
tighten the four (4) 3/8 inch button head bolts in accordance with the accompanying actuator assembly drawing.
Do not open the gate valve yet. Continued insertion is a reversal of steps 2, 3 and 4. Refer to the accompanying
actuator assembly drawing for lubricants, sealants and torque values.
Air Cylinder Seals Change-Out
Change-out of the air cylinder seals is completed in much the same way as the process seals change-out; however,
these seals should not need replacing as often as the process seals and should be replaced only on an as-needed
basis.
1. To remove the actuator assembly from the process line, please refer to and follow steps 1-6 of the Process Seals
Change-Out section of this manual.
2. Remove the four 316 SS dome head nuts and remove the cylinder end cap. Separate the barrel(s) and the piston/
rod assembly from the rod gland. When servicing a neutral position actuator, the middle rod gland slides o the
end of the four (4) tie rods, allowing access to the rst air cylinder. Remove the worn seals from the rod gland,
piston(s) and end cap. Usually only the piston and rod gland seals need replacing.

10 Sentry Equipment Corp
ÂNOTE
There is no need to remove the four (4) tie rod bolts from the rod gland.
3. Clean all surfaces and t new seals using silicone/pneumatics grease. Reassemble the air cylinder and tighten the
end cap’s four dome head nuts. Replace the actuator’s process seal/spool assembly (see step 7 of the Process Seals
Change-Out section). Replace the completed assembly back into the sample chamber. The new process seals will
be tight and may require use of a suitable process compatible lubricant.
4. Fit and tighten the dome head nuts. Refer to the accompanying actuator assembly drawing for lubricants, sealants
and torque values.
5. Slide the now fully reassembled actuator assembly back onto the side rails and insert the actuator back into the
gate valve until the 3/8 in. tapped holes in the endplate align with the holes on the side rails. Screw in and tighten
the four (4) 3/8 inch button head bolts in accordance with the accompanying actuator assembly drawing. Do
not open the gate valve yet. Continued insertion is a reversal of steps 2, 3 and 4 of the Process Seals Change-Out
section. Refer to the accompanying actuator assembly drawing for lubricants, sealants and torque values.
Samplers, controllers and associated equipment can be inspected by Sentry Equipment and rebuilt if required. Please
send your sampler to the company, and recommendations and prices will be provided promptly after receipt and
inspection. Contact Sentry Equipment for specic instructions on returning equipment for repair prior to shipment.
All returned equipment must be accompanied by a MSDS (Material Safety Data Sheet) and a signed statement that the
equipment has been cleaned/decontaminated or is otherwise safe and does not impose a health hazard.
Troubleshooting
symptom possible problem(s) remedy
Sampler leaks product or
air out of bottom ports
Worn seals
Incorrect installation
Other worn parts
Thorough inspection is required
Replace worn seals
Check any recently replaced
seals against drawings for correct
installation
Replace other worn sampler parts:
Body, head, barrel or plunger
Sampler leaks product at pipe
connection
Installation misaligned
Fastener, clamp/gasket or seals
issue
Check installation for misalignment
If the installation is threaded,
replace locknut fastener and add
commercial grade Teon tape
when reinstalling
If the installtion is tri-clamp or
instrument hub, check the clamp/
gasket (TC) or o-rings/fasteners (IH)
attaching the sampler to the line
adapter
Replace seals if they are damaged
or show signs of chemical attack

ISOLOK SAL-Q Sampler 11
symptom possible problem(s) remedy
Sample discharge is decreasing Buildup in sample spool cavity or
sampler nose
Check sample spool cavity for
buildup; if present, add ush or air
eject provision to sampler body
Check sampler nose for buildup;
if present on nose or pipe wall
interior, remove the body from the
line frequently and clean it using
plant procedures
Sampler will not operate Issues with power source and/or air
connections
Check power source and air
connections; connect as required
Check air lines for proper
connection, as plunger must dwell
retracted; air lines connected
backwards will cause sampler to
dwell (pause) extended into the
process line
Check for air bind; depending
on the density of the product
sampled, this sometimes can be
resolved by opening a top port on
the sampler
Check sampler operating air
pressure and process line
pressures; operating air pressure
must be sucient to move
the plunger against process
pressure. Issue may be resolved
by increasing or decreasing air to
sampler or relocating sampler.
Controller does not operate Issues with pneumatic and/or
electric power source
Verify correct 115V or other
specied power to controller
If using a remote contact unit,
check the output signal to the
controller from the ow meter;
check purchase records, and
if an incorrect output signal
was specied, contact Sentry
Equipment
Secure a qualied technician to
run a complete operating check
of timing circuits, remote contact
inputs and/or counter inputs that
sequence the electric or pneumatic
power valve
If any issues persist, please contact Sentry Equipment.

12 Sentry Equipment Corp
Parts & Accessories
Sentry Equipment recommends on-hand stocking of the following items in a quantity adequate for one or more years
of normal operation. Most parts are available for immediate shipment and are conrmed upon request.
Stock Parts
Description Part Number
Process Seals Kit – Includes all plunger seals 4000-F05-4X XNBR - Black
4000-F05-4H HNBR - Green
4000-F05-4D DURA - Red
Air Cylinder Seals
Barrel Seal Kit – Includes two o-rings 4000-F02-1
Piston Seal 4000-F04-1
Rod Gland Seal Kit – Includes two o-rings and one rod seal 4000-F06-1
Wear Sleeve 4000-F09-1
Wear Sleeve Seal Kit – Includes two seals 4000-F32
Teon Wear Ring 4000-F30
For the Neutral position sampler, add the following:
Neutral Barrel Seal Kit – Includes two o-rings 4000-F38
Neutral Position Piston Seal 4000-F04-3
Double Gland Seal Kit – Includes one o-ring and two rod seals 4000-F37
Startup Parts
Description Part Number
Adapter Plate O-Ring 4000-F28
Mounting Hardware
Hex Screw Kit – Includes four bolts 4000-F24
Flat Washers 4-00411A (4)
Lock Washers 4-00412G (4)
Countersunk Screw Kit – Includes four screws 4000-F25
Commissioning Parts
Description Part Number
Process Seals Kit – Includes all plunger seals 4000-F05-4X XNBR - Black
4000-F05-4H HNBR - Green
4000-F05-4D DURA - Red
Barrel Seal Kit – Includes two o-rings 4000-F02-1
Piston Seal 4000-F04-1
Rod Gland Seal Kit – Includes two o-rings and one rod seal 4000-F06-1
Wear Sleeve O-Ring Kit – Includes two o-rings 4000-F10
Adapter Plate O-Ring 4000-F27
Adapter/Adapter O-Ring 4000-F28

ISOLOK SAL-Q Sampler 13
Teon Wear Ring 4000-F30
Sample Chamber O-Ring Kit – Includes two o-rings 4000-F31
Wear Sleeve Seal Kit – Includes two seals 4000-F32
Double Gland Seal Kit – Includes one o-ring and two rod seals 4000-F37
Neutral Barrel Seal 4000-F38
Neutral Piston Seal 4000-F04-3
Adapter Plate O-Ring 4000-F48
Two-Year Parts Kit
Description Part Number
Plunger Parts
End Seal Mount 4000-F05-2
Seal Mounts 4000-F05-3 (4)
Spool Assembly Stud 4000-F08-1
Spool
25cc 4000-F05-1-25
10cc 4000-F05-1-10
Delta Gate Valve 4000-F40-300
Standard Warranty
Sentry Equipment Corp (“Seller”) warrants products manufactured by it and supplied hereunder (“Products”) to be free
from defects in workmanship and, to the extent materials are selected by Seller, to be free from defects in materials, in
each case for a period as dened in the table below:
Brand Product Line Warranty Period
Sentry® Steam & Water Sampling Products and Systems
Solid & Powder Sampling Products and Systems
Gas Sampling Products and Systems
Liquid & Slurry Sampling Products and Systems
Corrosion Monitoring Products
Eighteen months from date of shipment
or twelve months from startup (whichever
occurs rst)
Waters Equipment Steam & Water Sampling Products and Systems Twelve months from date of shipment
To view the full warranty, go to
www.sentry-equip.com/warranty.

14 Sentry Equipment Corp
Customer Support
With proven sampling expertise since 1924, Sentry products and services provide business operations the critical
insights to optimize process control and product quality. We deliver true representative sampling and analysis
techniques to customers around the globe, empowering them to accurately monitor and measure processes for
improved production eciency, output, and safety. Standing behind our commitments, we are determined to tackle
any application, anywhere.
We know that running an ecient operation isn’t easy. It requires thorough, careful analysis of controlled, real-
time data achieved through reliable, accurate, and repeatable process monitoring, and measuring. By eectively
conditioning, sampling, and measuring gas, liquid, slurry, powder, solids, steam, or water within their production
environments, our customers obtain the critical insights they need to control and optimize their processes.
Yet, controlling your processes also means reliable customer support throughout the life cycle of your equipment.

Customer Service—General information, warranty claims, order management.

Installation Service—For systems that require specialized expertise upon installation.

Technical Support—Troubleshooting, training, and technical manuals.

Field Service & Retrots—When a problem needs immediate attention.

Replacements Parts & Consumables—Order your replacement parts and consumables.
Sentry ProShield Services – select from four ProShield Guardian service plans providing dierent levels of support to
protect your large system investments with regularly scheduled maintenance.
To learn more, go to
www.sentry-equip.com/support.

ISOLOK SAL-Q Sampler 15
This page is intentionally left blank.

sentry-equip.com
966 Blue Ribbon Circle North, Oconomowoc,WI 53066 U.S.A. | [phone] | [e-mail]
Serving customers
in more than 50 countries
across six continents worldwide.
