AES 7788F-C User manual

7788F-C
RF Subscriber
Unit
Installation and Operation Manual
AES Corporation
285 Newbury Street
Peabody, MA 01960-1315 USA
Tel [phone] •Fax [phone]
www.aes-corp.com
Copyright 2008-2016 All Rights Reserved
P/N 40-7788FC
Rev 3.2
August 30, 2016

AES 7788C Series RF Subscriber Unit -- Installation and Operation Manual
AES Corporation 2 40-7788F-C, Rev 3.2, August 30, 2016
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING
JURISDICTION, AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply
with the requirements in theStandard for Control Units and Accessories for Fire Alarm
Systems, ULC –S527, certain programming features or options must be limited to specific
values or not used at all as indicated below.
Program Permitted in Possible functional
Group Feature or Option ULC-S527 (Y/N) settings Settings permitted in ULC-S527
Timing Parameters
AC Fail Report Delay Y 0-60 Min or Random R (Random) or 0-60 (Minutes)
Reporting Delay Y 0 –80 Seconds 10 –20 Seconds
Zone Programming
Fire/Trouble PKT Y Y or N Y
Zone Programming Y S, F or B If zone is in use F
If not in use B
Restoral Y X or R R
Set Modes Enable Repeating Y Y or N Y
Suppress AC Fail N Y or N N
By Remote programming only
Acknowledge Delay * Y 60 –330 Seconds Not greater than 60 Seconds
* Acknowledge delay is used in detecting the existence of a functional antenna and therefore affects antenna cut detection.
Note: ULC and NFPA do not allow remote programming of an installed 7788FC unless an
authorized person is present at the unit to temporarily enable this capability. Selecting
“Y” for Fire/Trouble PKT in Zone Programming function disables remote programming.
Entering one of the programming modes accessed with a directly attached programmer by
<Ctrl> <F1>, <Ctrl> <F2> or <Ctrl> <F3> enables remote programming for 10 minutes.
This is a list of ULC listed control units for Fire applications.
Siemens-XLS-500
Siemens-MXL
Firelite-MS-25
MS-9600LS (DACT-UD2 is required for this panel)
Notifier-NFS 3200
Notifier-NFS2-640
Notifier-NFS2-3030
Notifier-Fire Warden-50C
NSP-25C
This is a list of ULC listed control units for Security applications.
Notifier-NFS 3200 Notifier-NFS2-640 Notifier-NFS2-3030

AES 7788C Series RF Subscriber Unit -- Installation and Operation Manual
AES Corporation 3 40-7788F-C, Rev 3.2, August 30, 2016
TABLE OF CONTENTS
1AES 7788F-C RF Subscriber Unit Enclosure Label.......................................................... 5
1.1 Description...................................................................................................................... 6
1.2 New features ................................................................................................................... 6
1.3 Easy Installation.............................................................................................................. 6
1.4 Power Requirements....................................................................................................... 6
1.5 RF Module (Transceiver)................................................................................................ 7
1.6 Optional Accessories ...................................................................................................... 7
1.7 Safety Considerations ..................................................................................................... 7
1.8 Technical Specifications................................................................................................. 8
1.9 UHF Antenna Options: ................................................................................................... 9
1.10 Coaxial Cable Options and Installation Tips .................................................................. 9
1.11 Coax Cable Installations Tips:...................................................................................... 10
2Commercial Fire and Burglary Installation Notes .......................................................... 10
2.1 Power Requirements: 16.5 VAC, 40VA;...................................................................... 11
2.2 Backup Battery requirement, Commercial Fire............................................................ 11
2.2.1 Battery Calculations.................................................................................................. 11
2.3 ULC –S302:................................................................................................................. 11
2.4 ULC-S304 Communication Requirements................................................................... 11
2.5 7788FC EOL Inputs / Zones:........................................................................................ 12
3Installation........................................................................................................................... 13
3.1 Overview....................................................................................................................... 13
3.2 Physical Installation...................................................................................................... 13
3.3 Wiring - General ........................................................................................................... 16
3.4 Wiring –Antenna Cut / Trouble Output (J4)................................................................ 17
3.5 Wiring - Zone Inputs..................................................................................................... 19
3.6 Wiring the FACP with PSTN and 7788F-C ................................................................. 22
3.7 Power Up ...................................................................................................................... 23
3.8 SELF-TEST / STATUS ERROR CODES..................................................................... 24
3.9 Status (LED) Indicators ................................................................................................ 25
3.10 ALM LED Blink Pattern Chart..................................................................................... 25
3.11 77LED Board................................................................................................................ 26
3.12 77LED Board Blink Pattern.......................................................................................... 26
4Programming....................................................................................................................... 27
4.1 Remote Programming Limitations (Enable/Disable).................................................... 27
4.2 Program ID# and System Cipher Code......................................................................... 28
4.3 Timing Parameters (Check-In Time and Reporting Delays)........................................ 28
4.4 Zone Programming ....................................................................................................... 30
4.5 Set Modes –Enable Repeating and Suppress AC Fail................................................. 31
4.6 Reset RAM.................................................................................................................... 32
4.7 Initializing and System test of the Subscriber Unit ...................................................... 32
4.8 Local Status Check ....................................................................................................... 33
4.9 Monitor and Key Transmitter Functions....................................................................... 35
4.10 Text Messages............................................................................................................... 36
4.11 Handheld Programmer –Quick Command Guide........................................................ 36
4.12 Reconnect Cables after Programming .......................................................................... 36
4.13 Programming the Subscriber Unit from a PC............................................................... 37
5Testing.................................................................................................................................. 38
5.1 Installation Site Checks................................................................................................. 38

AES 7788C Series RF Subscriber Unit -- Installation and Operation Manual
AES Corporation 4 40-7788F-C, Rev 3.2, August 30, 2016
6Maintenance, Compliance, Warranty and Repair........................................................... 39
6.1 Troubleshooting............................................................................................................ 39
6.2 Parts List ....................................................................................................................... 39
6.3 Contact Information...................................................................................................... 39
6.4 Warranty and Service Procedure .................................................................................. 40

AES 7788C Series RF Subscriber Unit -- Installation and Operation Manual
AES Corporation 5 40-7788F-C, Rev 3.2, August 30, 2016
1AES 7788F-C RF Subscriber Unit Enclosure Label

AES 7788C Series RF Subscriber Unit -- Installation and Operation Manual
AES Corporation 6 40-7788F-C, Rev 3.2, August 30, 2016
1.1 Description
The 7788F-C Subscriber Unit is an AES-IntelliNet RF Communicator, which is typically
used to link an alarm panel to an alarm monitoring central station. This series unit is ULC
listed and compliant for commercial fire alarm monitoring. This unit has 8 wired inputs.
All 8 inputs are of the end of line resistor (EOL) type
1.2 New features
This section is included for those customers familiar with other AES IntelliNet ULC
Subscriber products. Listed below are the new features incorporated into the unit.
This section is included for those customers familiar with other AES IntelliNet
ULC Subscriber products. Listed below are the new features incorporated into the
unit.
Normally Open Relay on Board for Acknowledge Delay / Antenna Cut / Low
Battery / Charger Fail Output. Formally was an open collector output and only for
Antenna Cut / Acknowledge Delay. Relay energized for normal condition, de-
energized for any fault or loss of power.
Separate power no longer required for the Zone Input Module as required on the
7750-F-4X4 and 7750-F-8.
AC Failure Random Reporting Delay. AC failure/restore messages are generated
when they exist continuously for 100 minutes. The actual transmission of the
generated message is delayed a random number of minutes between 0 and 60. The
delay is set at the time the event is generated.
Transceiver power PTC is added. It is installed in series with the power line to the
transceiver disconnecting power if the transceiver draws too much current.
Remote programming using software at the central station is disabled when
Trouble Packets are enabled. Trouble Packets are enabled by entering [Y] to the
“Fire Zones? Y/N:” prompt in Zone Programming. This can temporarily be
enabled using a directly attached programmer in the Programmer Jack.
77 LED Status Board provides visual information on the status of the unit.
707 LBD Board ensures that a low battery, that cannot be changed, will not be
used, affecting the unit RF communications.

1.3 Easy Installation
The 7788FC unit is housed in a rugged lockable steel box for long lasting protection and
easy installation. The alarm panel’s alarm outputs are connected to the 7788FC Unit. A
supplied AES-IntelliNet tamper resistant 2.5 dB flexible antenna can be secured to the
subscriber enclosure in the provided hole, or use a remotely installed antenna, purchased
separately. Once powered and properly configured, the 7788FC RF Subscriber self-
enrolls into the AES-IntelliNet wireless network, receives signals from the alarm panel
and transmits them via wireless mesh radio to the AES-IntelliNet central receiver.
1.4 Power Requirements
The steady state DC current draw is only 150mA (210mA with optional accessories).
The peak current draw of 1.2A (1.3A with optional accessories) for RF power output
levels of 2W, is only for a very short transmit duration of less than 1/3 second.

AES 7788C Series RF Subscriber Unit -- Installation and Operation Manual
AES Corporation 7 40-7788F-C, Rev 3.2, August 30, 2016
1.5 RF Module (Transceiver)
Each 7788FC Unit includes an RF Module known as a transceiver along with a standard
tamper resistant 2.5 dB flexible omni-directional antenna. The standard antenna supplied
is for the frequency range of 450-480MHz. Contact AES for additional information on
available Models for use with other Non-ULC frequencies and antennas.
See UHF Antenna Options in Section 1.9
1.6 Optional Accessories
7041 –Hand Held Subscriber Programmer
7094 –AES IntelliPro module
7794 –AES IntelliPro Fire
1.7 Safety Considerations
All equipment must be installed in accordance with Canadian Electric Code,
NFPA 70, National Fire Code NFPA 72 and local building codes.
It is unlawful to operate this equipment in the USA without a valid FCC radio
station license. Other countries most likely require licensing through appropriate
authorities as well.
Be certain to properly ground the antenna, 7788F-C enclosure and any surge
protection devices to help dissipate surges away from the equipment and
personnel. The grounding of the antenna and surge protector is for your safety
and the safety of your equipment and should not be neglected.
If the antenna or cables connected to this equipment come in contact with
electrical power lines, DEATH or SERIOUS INJURY may result.
Test this system periodically for proper operation. AES assumes no responsibility
for this equipment's failure to operate. AES' sole responsibility is to repair or
replace any AES device found to be defective during the warranty period.
Exposure to extreme cold below 0ºC or extreme hot above 50ºC could damage
any Gel battery used in the installation of this product. Extreme temperatures can
also cause unexpected operation of the electronics.
Exposure of the electronics to excessive water or moisture (such as a rain, shower,
bath, pool, sauna, etc) could cause damage and unexpected operation.
Avoid dropping or other physical impact to the unit, which could damage the
enclosure or internal components.

AES 7788C Series RF Subscriber Unit -- Installation and Operation Manual
AES Corporation 8 40-7788F-C, Rev 3.2, August 30, 2016
1.8 Technical Specifications
SIZE: 13.25”h X 8.5”w X 4.3”d (34 cm X 21.5 cm X 11 cm) excluding antenna
WEIGHT: 5.8 pounds (2.6 kilograms) Without Battery (Add 6 pounds with Battery)
TRANSFORMER SECONDARY POWER INPUT: 16.5VAC, 40VA class 2 (dry) source
only
VOLTAGE: 12VDC nominal
MAINS INPUT CURRENT: 150 mA standby; 1.2A transmit
MAINS INPUT CURRENT with optional accessories: 210 mA standby; 1.3 A transmit (2
Watt Transceiver)
OPERATING TEMPERATURE RANGE: 0° to 49° C (32° to 120°F)
STORAGE TEMPERATURE RANGE: -10° to 60° C (14° to 140°F)
RELATIVE HUMIDITY RANGE: 0 to 93% RHC, Non Condensing
BACK-UP BATTERY: 12V, 10AH (Min) (24 Hour standby),
lead acid gel type; required for all installations
BATTERY FUSE: Onboard self-resetting fuse. Not serviceable
ALARM SIGNAL INPUTS: 8 Supervised individually programmable Zones:
All 8 are EOL type with, Trouble & Restore
LOW BATTERY REPORTING: Below 11.5V. 2.75 Minute Test Cycle (approx) –Low
battery disconnect 10V. Reconnect-12V
AC FAILURE REPORTING: AC Fail messages are queued for transmission to central
station after approximately 100 continuous minutes without AC power. Transmission to
central station is then delayed randomly between 0 to 60 minutes. Restore is similar with
Restore message queued for transmission after approximately 100 continuous minutes with
AC power restored. AC Fail/Restore messages will be sent between 100 and 160 minutes
after the failure or restore occurs that remains for 100 minutes. See Section 4.3 - Timing
Parameters for additional information and programming options.
ANTENNA CUT / LOW BATTERY / CHARGER FAIL LOCAL REPORTING:
Normally Open Relay contact at J4. Relay is engaged for normal operation. Disengages on
Reset, Antenna Cut/Acknowledge Delay, power loss condition, low battery or charger fail.
Contact rating –24 VDC 1-Amp max, Not Supervised.
RESET BUTTON: Located on the PCB.
TRANSCEIVER:
Standard UHF Frequency Ranges (410-440MHz, 440-470MHz, 470-512MHz)
TRANSCEIVER FUSE: 400 milliamp PTC, Not serviceable
STANDARD RF OUTPUT POWER: 5 Watts
Zones 1-8: dry contact supervised with 2.2K EOL resistor
GROUND FAULT: A ground fault as tested by ULC, is when an isolated ground terminal of
a Supervised zone labeled “G” is less than 0.1 Ohm impedance to Earth Ground.
A Zone 10 Trouble is transmitted for this fault. The CID message generated at alarm
automation for a Ground Fault in a 7788F-C is E370 C010.
BATTERY CHARGE FAIL: 7788F-C monitors Charger Voltage and reports a Fault when
the voltage from the charger gets too low.
A zone 9 Trouble is transmitted for this fault. The CID message generated at alarm
automation for a Charger Fault in a 7788F-C is E370 C009.

AES 7788C Series RF Subscriber Unit -- Installation and Operation Manual
AES Corporation 9 40-7788F-C, Rev 3.2, August 30, 2016
1.9 UHF Antenna Options:
(450-480 MHz; contact factory for other frequencies)
Antenna db
Construction
Usage
Length
P/N (6)
2.5 db Case Top Flex Tamper Resistant (1 & 2)
Vinyl Clad
Indoor
11 in
7214
3 db Stealth (Not shown below) (3)
Vinyl Clad
Indoor
1.5 ft
7211-(Freq)
3 db Standard Gain(4 & 5)
Steel Mast
Indoor
1.5 ft
7210-3-(Freq)
5 db High Gain (4 & 5)
Steel Mast
Indoor
3 ft
7210-5-(Freq)
6 db Rugged High Gain (4)
Fiberglass Mast
In/Outdoor
4.5 ft
7210-6-(Freq)
7 db Rugged Higher Gain (4)
Fiberglass Mast
In/Outdoor
6 ft
7210-7-(Freq)
9 db Central Station High Gain (4)
Fiberglass Mast
In/Outdoor
8 ft
7210-9-(Freq)
1. This antenna was evaluated by ULC and approved for use in a ULC S561-03 Edition 9
system.
2. Included standard Tamper Resistant antenna, mounts on Alarm Unit’s enclosure.
Includes cable.
3. Mounts in attics, vents, walls, behind drapes, etc. Includes 10-foot cable.
4. Requires cable (See Section 1.10). Usually requires user supplied mounting hardware
such as a pole with mounting brackets/hardware.
5. Antenna is intended for outdoor use, supplied mount is intended for indoor use as coax
connection is exposed. To use outdoors, connection must be sealed with a suitable
product such as a self-fusing tape to protect against moisture.
6. (Freq) to be replaced with the frequency range of the antenna appropriate for the
Subscriber’s Transceiver. (Freq) provided by AES order entry at time order is placed.
1.10 Coaxial Cable Options and Installation Tips
CABLES w/CONNECTORS, BNC ↔ N, for all AES Subscriber Units, high
performance, low loss cables for all -UM, -UC
and -US antennas above.
● 10 Ft RG-58 Cable, p/n 7220-10-N
●25 Ft RG-58 Cable, p/n 7220-25-N
BNC Plug/connector (male) crimp style for
RG-58 Coax, P/N 12-0102
● 100 Ft. RG-8 W/1 N male (on spool),
P/N 13-0345-100 - this coax is available for longer
runs, cut to length and installer terminated.
● Loose connectors required to complete RG-8
assembly, P/N 12-0101
● Crimp tool required for 12-0101, P/N 7244
● Cable Assembly; 18” RG-58 (N female, bulkhead ↔ BNC male) Used to connect
RG-8 with N male to Enclosure body, P/N 13-0346
Notes:

AES 7788C Series RF Subscriber Unit -- Installation and Operation Manual
AES Corporation 10 40-7788F-C, Rev 3.2, August 30, 2016
1.11 Coax Cable Installations Tips:
Avoid using a 25’ coax length if a 10’ will be sufficient.
Never use more than 25’ of RG-58 cable in any antenna installation.
Always use shortest length of coax possible.
Longer than necessary coax lengths translates into greater signal loss.
Always use most direct routing possible in any installation.
Unnecessary and tight bends adds to potential signal loss.
2Commercial Fire and Burglary Installation Notes
ULC Burglar Installations Tamper Protection: A ULC Listed tamper switch that
protects the cover against opening or removal is required on the 7788F-C installed in a
burglar alarm installation. If the 7788F-C is installed outside the protected area, a tamper
device is required to protect the enclosure against removal from the mounting surface.
Use a ULC approved plunger type tamper switch, installed using holes drilled by the
installer through the side and rear of the enclosure as suggested in Diagram below. Refer
to diagram below, actual selected ULC Listed tamper device and manufactures
documentation for installation instruction and required hole pattern.
Wire tamper devices to a zone as outlined in the tamper device manufactures
documentation and section 3.
The tamper devices must be installed and wired to activate a zone on the subscriber to
generate an alarm signal at the central station.
In addition to installing tamper devices on the 7788F-C, a motion detector connected to
the alarm control panel is required to protect the 7788F-C against attack.
The 5 shaded holes shown in the diagram to the left
indicate suggested locations for holes needed to
install a typical ULC Listed plunger type tamper
switch.
Actual dimensions are to be determined from the
actual switch and or switch installation instructions.
Although the typical switch has three mounting
holes available, two are sufficient to securely mount
the switch.
A typical plunger type switch requires a 3/8” hole
centered at the location where the plunger can
protrude unhindered through the rear of the
enclosure to make contact with the enclosure’s
mounted surface.
