OVERVIEW

The D2061 has been specifically realized for ADSL lines and turns out to be

one of the smallest, lightest and easy to handle devices on the market.

Thanks to the ‘Universal Modem’ feature, this tester is able to simulate the

user’s modem and host checking each critical point of an ADSL connection

and obtaining a complete set of parameters such as line bit rate and

occupation capacity, but also connection bit rate both Fast and Interleaved

path, noise margin and bit per tone allocation.

Like all the measurement devices made by Aethra®, it offers helpful

features for the technician in installation, maintenance and troubleshooting

phases.

The graphic user interface, common to the test instruments family of new

generation made by Aethra®, satisfies all the user’s needs. Navigating

through the various menus is both easy and immediate thanks to the bright,

back-lit, high resolution display as well as the zoom feature.

The features PREDEFINED TESTS and HISTORY, are used to manage and

store personalized test setups and to recall the results of each test

performed. This, together with the possibility to create a personal most

used tests list, make the technician daily tasks simpler by avoiding possible

setup errors and allowing also subsequent analysis of the results obtained.

The Smart Status™ feature allows the modem, the line and the device

status to be displayed immediately. In particular, is shown the number of

bits per tone assigned both in graphical and tabular format, the error

count, events and anomalies on the line, the current and historical alarm

status and evolved statistics about ATM level.

Thanks to Smart Status™the user has all the necessary information at a

glance, just by pushing a button.

D2061ADSL TESTER

Smart troubleshooting tool

Powerful background monitor

Multi layer tester

ADSL, ATM and IP layer tests

Ideal companion for installers

Light weight, small footprint, robust,

OVER POTS – OVER ISDN

FEATURES AT A GLANCE

Specific ATM layer tests

Complete IP layer feature including PPP

and file transfer simulation

Ethernet 10Base-T port for through (Bridge) mode

Multi-protocol monitor and analysis including frames

decoding

Predefined test set-ups to save time on site

Test results saving for subsequent analysis

Includes PC108 for WindowsTM software for

powerful analysis and remote management

In field upgradable

firmware

BACKGROUND MONITOR

The device captures and decodes all

modem events. During the active phase of

the connection, all the AAL-5 packets are

captured as well.

Moreover, it is possible to capture and

decode communication protocol events

over ISDN D channel1.

In POTS mode, the D2061 is able to perform

high impedance monitoring of POTS2events.

Advanced analysis through the PC software3

issued with the device, helps to solve

also more complex ADSL connections

problems.

•Physical layer monitoring with alarms

and error checks

•Line events analysis

•AAL-5 encapsulation decoding

•D

1channel and POTS2line monitoring

•Real time and off-line decoding

•Capturing filters

•G.826/M.2100 statistics information

CONNECTION

Through this test, it is possible to control all

ADSL connection data both for Upstream

and Downstream sides.

The costumer’s contractual parameters

verification is immediate and easily

interpretable.

•ATM Fast/Interleaved bit rate

•ATM maximum line rate

•Relative capacity

•Noise margin

•Attenuation

•Output power

ATM 5

Whit the use of this test, it is possible to

verify the correct working of the ATM layer,

up to the ATM termination unit.

This test allows OAM as well asAAL-5 cells

generation to be performed with response

times (ms), errors and statistics5.

•OAM cells generation, F4 and F5 type

•AAL-5 packets generation test

•Loop-back OAM cells management

•Programmable number of Ping requests

•Errors and statistics

•Waiting response time (sec.)

IP 6

Thanks to IP PING test, the D2061, checks

the connection to the Internet Provider,

whether a remote host is reachable or not

and the relative response times6.

Moreover, all the information from the

server such as messages, local, remote

and server IP addresses and IP TRACE

ROUTING is provided. This allows the

correct connection settings of the user to be

checked. The IPGENERATE TRAFFIC test,

allows a data transfer between hosts to be

simulated. This test, more exhaustive than

IP PING, is able to measure the throughput

of the connection in progress.

•IPBridge, IP Router, PPPoE, PPPoA

•

PPP, IP, UDP, DHCP, DNS, ICMP, TFTP support

•PAP and CHAP (MD5) authentication

•Static and Dynamic IP address

•Gateway management and address

•Settable packet length and testing file

•IPstatistics and response times

•Throughput calculation

•IPaddress book, password and User ID

for immediate login to Internet

•IPTrace Routing with 30 hops disovering

BER

Equipped with an appropriate option1, the

D2061 can perform specific tests over S/T-

Bus for line quality verification (BERT) and

for ISDN basic access general control.

•G.821

•Different test pattern

•Test modes End-to-End and Selfcall

•Errors injection

ETHERNET 7

The D2061 is able to replace the user‘s

modem and to permit the Internet navigation

by the use of a PC with 10Base-T network

connection.

With this option, it is possible to verify the

connection throughput thanks to the exaustive

statistics features available for physical,

ATM and Ethernet layers.

The powerful capturing feature of the single

AAL-5 frames and the analysis facilities of

PC108 software, allow to solve all the

problems regarding connections to ISPs,

without using expensive systems

•Internet access troubleshooting

•Host and Modem simulation

•Advanced statistics information

MISCELLANEOUS

Thanks to the integrated microphone and

loudspeaker the D2061 is able to simulate

both analogue POTS2and ISDN1telephones.

With the AUTOMATIC TESTS the user can

quickly verify the ISDN line under control

and, if not otherwise specified, the device

generates automatically a series of calls

and verifies the complete status of the line.

•Loopbox

•Evolved POTS terminal simulation

•Line Noise test

•Physical layer settings control

•Layer 2 configuration

•Availability status of the several bearer

services, tele and supplementary services

•Availability check of single B channels

1 ST2061

2AB2001N

3 PC108 for Windows™

4MF206x

5ATM2061

6IP2061

7ETH2061

TELECOM INTERFACES

•ADSL access

ATU-R ITU-T (CCITT) Rec. ITU-T-I.361,

ITU-T- I.363.5, ITU-T- I.432,

ITU-T- I.610, ITU-T-I.731

•ISDN Basic Rate [ST2061]

S/T ITU-T (CCITT) Rec.I.430,

ETS 300 012

ADSL LAYER

•D2061 over POTS1

Full Rate ANSI T1.413 issue 2

G.DMT G.992.1,Annex A (ADSL over POTS)

G.Lite G.992.2

Multimode

•D2061-I over ISDN2

G.DMT G.992.1, Annex B (ADSL over ISDN)

Others ADSL over POTS/ISDN

U-R2 (T-DSL)

Alcatel ADSL over ISDN ETSI DTS/TM

•Handshake G.994.1 (ex G.Hs)

1-2Only one module at time is

available from the factory

ATM LAYER [ATM2061 OPTION]

•Stack

OAM Implementation F4 and F5 OAM loopback cells

OAM ITU-T I.610

ATM Adaptation Layer AAL-5

VC channel selection Settable by the User

•Multiplexing methods LLC/SNAP or VC Multiplexed

IP/PPP LAYER [IP2061 OPTION]

•Stack

Data encapsulation methods IP over ATM Bridged, IP over

ATM Routed, PPP over ATM,

PPP over Ethernet

RFC number RFC2684 (ex 1483), 2225,

2364, 2516

•PPP Client, Server

OPERATING MODES

•ADSL

ATU-R

ATU-R + Host

Through mode (BRIDGE) ETH2061 option

•ETHERNET

Host ETH2061 option

•ISDN

TE-S (BRI) ST2061 option

•POTS

TE AB2001N option

MON AB2001N option

BACKGROUND MONITOR

•Events ADSL parameters, alarms,

errors, AAL-5 packets

•ISDN D channel monitor ST2061 option

•POTS line monitor AB2001N option

•Programmable filters Independent filters capturing

and displaying

•Analysis of the results stored into PC with PC108 for Windows™

SMART STATUS™

•Physical layer G.826 / M.2100

•ADSL line ES, SES, BBER, UAS, DMT bit per

tone, graphic and table format,

alarms and errors

•ATM layer Tx/Rx cells counters,

AIS-RDI-LB OAM cells

counters, unmapped cells

counter, VCs (VCI/VPI) of

unmapped cells [ATM2061]

•ISDN line Status levels ISDN 1, 2 and

3 clearly displayed [ST2061]

ADSL MONITOR ANALYSIS

•Stand alone decoding ADSL and AAL-5

•ADSL events decoding Graphical and tabular format

•ATM header decoding

•AAL-5 decoding

Hexadecimal decoding LLC, PPPoE discovery,

grouped by levels ARP and MAC discovery

Address Payload, Trailer

CONNECTION

•ADSL line mode

•ADSL maximum bit rate Kbps (DW/UP)

•Operative ATM speed rate (DW/UP)

•Relative Capacity % (DW/UP)

•Noise Margin dB (DW/UP)

•Attenuation dB (DW/UP)

•Output Power dBm (DW/UP)

•ATU-C manufacturer & version ANSI mode

BIT PER TONE

•Number of bits per tone, frequency and bit per tone value

•Cursors Moved along the graphic,

provide information for each tone

•Display 128, 256 tones

•Results format Table, Graphic

TECHNICAL SPECIFICATIONS

ATM [ATM2061 OPTION]

•VCI / VPI Statistics and Errors

•Type of cell F4 end-to-end, F4 segment,

F5 end-to-end, F5 segment

•Location ID (end-to-end) User defined

•ATM OAM cell Management

•Type of Test ATM PING, OAM & AAL-5

packets test, Traffic Generator

IP [IP2061 OPTION]

•IP address supported Static, Dynamic (DHCP)

•Authentication protocol PPP PAP, CHAP (MD5)

•Gateway selection IP Bridged mode

•LLC/SNAP encapsulation User defined

•Type of Test

IP Ping (ICMP), IP generate

traffic (TFTP)

LOOP-BOX FEATURE [ST2061 OPTION]

AUTOMATIC ACCESS TEST [ST2061 OPTION]

•Fully automated Access test

•Automatic supplementary services test

•Programmable test sequence

BIT ERROR RATE TEST [ST2061 OPTION]

•G.821 statistics ES, SES, US, DM, PASS/FAIL

•Pseudo-Random bit sequence User definable 211-1,2

15-1,

223-1,16 bits octet

•Error Injection Manual, Single, Automatic

HISTORY AND PREDEFINED TESTS FEATURES

•Saving and recalling of 10 different setup and results for each

kind of test

CONNECTORS

•ADSL line interface 2 wires RJ11

•AUX DB15-HD

•RS232 Mini - DIN 4 (ISO 4902)

•Handset 4 wires RJ9. Balanced

•Power in External AC/DC adapter 4 wires

ENVIRONMENTAL CHARACTERISTICS

•Dimension

Weight, with battery

≈

500 gr.

Dimensions, with holster (mm) 100 (w) x 180 (l) x 50 (d)

•Power

Battery Type Rechargeable, Ni-MH

Battery life

≈

3 hrs @ 25°C, LCD back-lit off

External AC/DC adapter 115/230Vac ±10% @ 50/60Hz

•Temperature

Storage/Transport -40oC to +70 oC

Operating, nominal -5oC to +45 oC

Operating, limits -10oC to +55 oC

•Humidity, non-condensing ≤93% RH @ 40 oC

≤70% RH @ 55 oC

•User's Safety Aspects EN 61010-1, EN 60950, EN 41003

•EMC Aspects EN 55022, EN 55024,

EN 61000-3-2 / -3-3

•CE Marking Class B (residential devices)

MISCELLANEOUS

•LCD display 320x200 Graphic display wide

bright and back-lit, with

Zoom function

•Internal microphone & loudspeaker

•Upgradable firmware By RS232 port

•MF206x, POTS Microfilter Option

OPTIONS

•ATM2061 ATM Stack and Statistics

•IP2061 IP Suite Test

•ETH2061 Bridge mode adapter

•ST2061 ISDN BRI-S/T terminal simulator

•AB2001N POTS Terminal Simulator

and Monitor

Aethra, the Aethra logo and D2061 are trademarks, registered trademarks, or service marks of Aethra SpA Telecommunications in Italy, the United States, and/or other countries. All other company and product names may be registered

trademarks or trademarks of their respective owners. Information furnished by Aethra SpA Telecommunications and Aethra, Inc. in this datasheet is believed to be accurate. Products sold and licensed by Aethra SpA

Telecommunications and Aethra, Inc. are covered by warranty and patent indemnification provisions appearing in its purchase and license agreements. Aethra SpA Telecommunications and Aethra, Inc. reserve the right to discontinue

production and change specifications and prices at any time without notice. Copyright ©2004 Aethra SpA Telecommunications - All rights reserved. Additional regional offices are located on our website: www.aethrausa.com. For further

details about technical specifications please see “Products” on www.aethra.com

Code 071062009GB Rev.1 (10/04)

Aethra SpA

Telecommunications

via Matteo Ricci 10

60020 Ancona - Italy

Telephone +39.071.218981

Fax +39.071.887077

Video 1 +39.071.2189160

Video 2 +39.071.2189701

Email: [email protected]

www.aethra.com
