Wen 10110 User manual

INSTRUCTION MANUAL
KNOW YOUR LASER DISTANCE MEASURE
MODEL 10110
DISTANCE MEASURE
POCKET LASER
Display
ON/Measure/Units
Battery Units
Laser Beam Outlet
PREPARATION
INSTALLING BATTERIES (FIG. 1)
Your Laser Distance Measure requires two (2) AAA
standard or rechargeable batteries.
1. Twist off the end cap (Fig. 1 - 1).
2. Insert two AAA batteries into the battery
compartment (Fig. 1 - 2). Follow the diagram inside
to place the batteries in the correct orientation.
3. Replace the end cap and twist back into place.
NOTE: Always replace both batteries at the same
time. Do not use different brands or types of
batteries/rechargeable batteries together.
2
Fig. 1
1
WARNING: Read and understand all warnings, cautions and operating instructions before
using this device. Failure to follow all instructions listed below may result in personal injury
and device damage.
SAFETY RULES
WARNING: Do not direct the laser beam at persons or animals. Do not stare into the direct
or reflected laser beam, not even from a distance. Looking into the laser beam or directing the
laser beam into someone’s eyes can cause eye damage, blindness, and cause accidents.
WARNING: Do not direct the laser beam at aircraft. This is a federal crime.
WARNING: LASER RADIATION. Class 2 laser. DO NOT STARE INTO THE BEAM.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
LASER CLASSIFICATION
The device produces visible laser beams, which are emitted from the instrument: It is a Class 2 laser
product in accordance with: IEC60825-1: 2014“Radiation safety of laser products”
INTENDED USE
The measuring tool is intended for measuring distance, lengths, heights, and clearances.
The measuring tool is suitable for indoor use.
Model 10110
Laser Type 620-690 nm, < 1 mW
Laser Class 2
Battery 2 x 1.5V (AAA)
Operating Temperature 32 to 104 °F (0 to 40 °C)
Measuring Distance 1.7 - 32 ft (0.5 - 10 m)
Measuring Accuracy ± 1/4" (± 6 mm)
Weight 36.6 g (1.3 oz)
Dimensions 5.75" x 0.87" x 0.87"
(146 x 22 x 22 mm)
Smallest Unit Displayed 1/16" (1 mm)
Reception Lens
WARRANTY
For full warranty statement, please visit WENPRODCUTS.COM and search the product number 10110.

OPERATION
SWITCHING ON & OFF (FIG. 2)
1. To turn the unit ON, press the orange “ON” button
once. The unit will turn on and automatically enter
CONTINUOUS measurement mode. It will display the
current distance measurement on the screen
2. To turn the laser distance measure off, press the
ON button and hold down for 5 seconds.
3. The device will automatically shut off after 2
minutes of inactivity to prolong battery life.
4. To turn the unit OFF, hold the ON button for
approximately five (5) seconds until the display
turns OFF.
UNIT SETTING
1. To switch between metric (meters) and imperial
(feet/inches) units, press and hold the ON button for
approximately three (3) seconds. Release the button
once the units on the display have changed.
CONTINUOUS MEASURING (FIG. 3)
1. To HOLD the current measurement, press
and release the ON button once while the unit
is already turned ON. It will HOLD the current
measurement and display it on the screen. To re-
enter CONTINUOUS measurement mode, press and
release the ON button once again.
NOTE: The measuring distance starts at the base of
the distance laser measure (Fig. 4).
NOTE: The unit is 5-3/4 inches (127mm) long. Use
this figure if you need to calculate offset distance.
NOTE: It may be difficult to obtain an accurate
reading when measuring distances to colorless
liquids, glass, styrofoam, semi-permeable surfaces,
or high-gloss surfaces. When measuring distances
to dark surfaces, the unit may need extra time to
take an accurate measurement.
Measuring Distance
MAINTENANCE
WARNING: To avoid accidents, turn OFF the laser before cleaning, adjusting, or performing
any maintenance or lubrication work.
WARNING: Any attempt to repair or replace electrical parts on this device may be
hazardous. Servicing of the device must be performed by a qualified technician. When
servicing, use only identical WEN replacement parts. Use of other parts may be hazardous or
induce product failure.
CLEANING & STORAGE
1. Wipe the device surfaces clean with a damp soft cloth. Make sure water does not get into the
device. Do not use any other solvents or cleaning agents to clean the device.
2. Maintain the reception lens with the same care as required for eye glasses or the lens of a
camera.
DISPOSAL
When the product reaches the end of its lifetime, please do not dispose of it with household waste.
Electrical and electronic products are hazardous to the environment and human health due to the
presence of hazardous substances. Take the product to your local recycling facility for it to be
responsibly recycled to minimize impacts on the environment.
Please recycle the packaging where facilities exist.
TROUBLESHOOTING
ISSUE CAUSE ACTION
Failure to
switch on
Internal protection activated Take out batteries and insert again
Low battery Replace with new batteries
Insufficient On/Measure/Units button
press
Press the On/Measure/Units button
firmly
All dashes shows
on display
Beam is moved too fast Move the measuring tool slowly
The object is out of rated range Measure within rated range
Received signal too weak/ Measuring
time too long
Change target surface
(e.g. white paper)
Received signal too strong
(target is too reflective)
Change target surface
(e.g. white paper)
Ambient light is too strong Do not use in direct sunlight
INSTRUCTION MANUAL
Fig. 2
Fig. 3
Fig. 4
