Aethra Video-Payphone User manual

FEATURES AT A GLANCE
Conforms to H.320 ISDN and H.323 IP networks
64-128 kbps over ISDN
64-384 kbps over IP
15 fps frame rate
Full-duplex with echo cancellation
1/4” CCD
TFT 10” LCD Monitor
Keypad Interface
OVERVIEW
Video-Payphone is the very first public telephone to offer high-quality
audio and video connectivity. Its unique technology is a joint project of
Tianjin Zhongtian Telecommunication Co., Ltd and Aethra
Telecommunications and combines the ease and low cost of public
telephones with the convenience of videoconferencing.
STANDARDS COMPLIANT
Video-Payphone fully conforms to H.320 and H.323 and can be used
over both ISDN and IP lines.
UBIQUITOUS ACCESS
Video-Payphone provides ubiquitous access to videoconferencing of
all kinds. By transmitting high quality images and high definition voice,
Video-payphone enables users to hold multi-point videoconferences
and talk “face to face” with relatives, friends and business associates,
wherever they are. Applicable in a variety of public areas, including
airports, hotels and shopping centers, wherever it is installed, it
enables users to integrate the advantages of video into their every day
lives.
UNIQUE APPLICATIONS
Video-Payphone offers extremely versatile uses. Keep an eye on your
home while you’re away, receive a short film, news or sports reports,
and perform videosurveillance
EASY TO USE
The videophone user interface is fully functional, with an easy-to-use
keypad that enables video display of all parties in a conversation.
Simple control keys increase and decrease volume. The display allows
users to see any incoming call and prompts users when a paycard
needs changing.
VIDEO-PAYPHONE
LARGE MEETING ROOMSPERSONAL VIDEOAUDIOCONFERENCING SMALL MEETING ROOMS MEDIUM MEETING ROOMS VERTICAL APPLICATIONS
Unique
The very first public videophone—ever!
Convenient
Talk “face to face” with anyone, wherever they
are
Versatile
Provides applications of all kinds: including
Videoconferencing and videosurveillance

Aethra and the Aethra logo are trademarks, registered trademarks, or service marks of Aethra Telecommunications in Italy, the United States, and/or other countries. All other company and product names may be
registered trademarks or trademarks of their respective owners. Information furnished by Aethra Telecommunications and Aethra, Inc. in this datasheet is believed to be accurate. Products sold and licensed by Aethra
Telecommunications and Aethra, Inc. are covered by warranty and patent indemnification provisions appearing in its purchase and license agreements. Aethra Telecommunications and Aethra, Inc. reserve the right to
discontinue production and change specifications and prices at any time without notice. Copyright ©2003Aethra Telecommunications - All rights reserved. Additional regional offices are located on our website:
www.aethrausa.com. For further details about technical specifications please see “Products” on www.aethra.com
SUPPORTED STANDARDS
ITU-T H.320: ISDN, networks
ITU-T H.323: IP networks
Video: H.261, H.263+
A dio: G.711, G.722, G.728, G723.1
MCU compatibility: H.243
TRANSMISSION
Bit-Rate: 56÷128 kbps over ISDN
64÷384 kbps over IP
VIDEO
Frame Rate: 15 fps
Video Resol tion: FCIF 352x288 pixels
QCIF 176x144 pixels
4CIF 704x576 pixels
for still images
(Annex D or H.263)
A dio Coding:
A dio Band Bit rate
G.711 300 ÷ 3400 Hz 56 kbps
G.722 50 ÷ 7000 Hz 48/56 kbps
G.723.1 300 ÷ 3400 Hz 5.3/6.3 kbps
G.728 50 ÷ 3400 Hz 16 kbps
AUDIO FEATURES
Echo Cancellation f ll-d plex
A tomatic Gain Control (AGC) ±12 dB
Echo Ret rn Loss Enhancement(ERLE): 30 dB
A tomatic Noise S ppression
NETWORK INTERFACES
ISDN
1 BRI: 1RJ-45
Ethernet
10/100BASE-T: 1RJ-45
BUILT IN INTERFACE
Keypad interface
BUILT IN CAMERA
Sensor: CCD 1/4 inch
Format: video composite
Pict re elements: 542 x 586 pixels
Resol tion: 380 TV lines
Focal lenght: f=3,7 mm
Iris: F=2.0
Foc s: man al
White Balance: a tomatic
Minim m ill mination: 0.5 l x
S/N: 52dB
BUILT IN DISPLAY
Type: color TFT-LCD
Size: 10"
Resol tion: 640x480 pixels
BUILT IN SMART CARDS READER
Payment system based on prepaid smart cards
C stomizable charge rate
USER INTERFACE
On-screen graphic ser interface
Context al help
Diagnostics and Management F nctions
Call Progress Monitoring
WEB MANAGEMENT
All config ration, call, diagnostics and
management f nctions are accessible sing
the web browsers: Microsoft®Internet
Explorer™, Netscape Navigator™)
REMOTE DIAGNOSTICS AND MANAGEMENT
Local Web Browser SNMP
Self Test Yes Yes Yes
Diagnostics Yes Yes Yes
Config ration Yes Yes Yes
Call Yes Yes Yes
Error Tracking Yes Yes Yes
POWER SUPPLY
AC adapter: 12V/2A
DIMENSION
•VIDEO-PAYPHONE
Width: 35.5 cm (14”)
Height: 62 cm (24.4”)
Depth: 10 cm (4”)
AETHRA TELECOMUNICAZIONI
via Matteo Ricci 10
60020 Ancona - Italy
Telephone [phone]
Fax [phone]
Video [phone]
[phone]
Email: [email protected]
www.aethra.com
Aethra, Inc.
701 Brickell Aven e
S ite 1390
Miami, FL 33131 USA
Telephone [phone]
Fax [phone]
Video [phone]
Email: info@aethra sa.com
To Contact a
U.S. Sales Representative
Call: 1-888-4-AETHRA
Email: sales@aethra sa.com
Code 071071069 GB Rev. 0 (02/03)
Telecom Organ zat ons
Call IP or ISDN a dio and video conferencing
systems.
Reach POTS telephones and third generation
mobiles.
Take advantage of interoperability in
sophisticated networks between H.323, H.320,
H.324 and UMTS.
News and Enterta nement
A veritable window on the world, the Aethra
Video-Payphone enables sers to receive
short films, incl ding the latest news and
sports events
Tour sm and Bus ness
Airports, railway stations, hotels, shopping
malls, health centers and convention centers
are ideal locations to install the Video-
Payphone, providing both to rists and
b siness travelers with immediate access to
video comm nication.
Commun t es L v ng Abroad
Connect those living, working and st dying
abroad with their families and friends by
providing the opport nity to interact
face-to-face
Advert s ng
A revol tionary advertising tool: when not in
se the screen can contin ally display
advertising to catch the attention of passers-by
Videos rveillance systems
Take action immediately when alerted by yo r
videos rveillance system: call and check on
the sit ation witho t traveling home.
FIELD APPLICATIONS
TECHNICAL SPECIFICATIONS
