AEV Bison User manual

INSTALLATION GUIDE
BISON WINCH KIT
FOR WARN 9.5 XPS WINCH
AEV30350AC
Last Updated: 09/06/19

ii
PLEASE READ BEFORE YOU START
To guarantee a quality installation, we recommend reading these instructions thoroughly
before beginning any work. These instructions assume a certain amount of mechanical
ability and are not written nor intended for someone not familiar with auto repair.
INCLUDED PARTS QTY REQUIRED TOOLS
Bison Winch Fairlead 1Common Hand Tools
Controller Mount Bracket 1
Wiring Harness 1
Hardware Pack 1

1
AMERICAN EXPEDITION VEHICLES
I. DISASSEMBLY
1. Disconnect and isolate the negative battery cable.
2. Remove Front Bumper Skid.
A. Remove the 4 M4 torx screws attaching the license plate bracket (fig. 1).
B. Remove the 2 M10 bolts in middle of Front Bumper Skid (fig. 2).
C. Remove the 4 torx bolts from bottom and sides of Front Bumper Skid (fig. 2).
Figure 1 Figure 2
3. Remove Skid 1B by removing the 6 bolts (fig. 3).
Figure 3

2
AMERICAN EXPEDITION VEHICLES
4. Remove the 6 M10 torx bolts attaching the center section of bumper (fig. 4).
5. Remove the 12 push clips attaching the air diverter (fig. 5).
Figure 4 Figure 5
6. Remove LH and RH wheel liner closeouts (fig. 6).
Figure 6
7. Remove Cage nuts in bumper for winch fairlead (fig. 7).
Figure 7

3
AMERICAN EXPEDITION VEHICLES
8. Remove 1 M10 bolt on radiator support and SAVE (fig. 8).
9. Remove 1 M6 bolt on radiator support and SAVE (fig. 8).
10. Un-clip radiator overflow hose (fig. 8).
Figure 8
II. CONNECTING AEV WIRING HARNESS
1. Open Warn winch controller by removing QTY 4 bolts on bottom corners of controller (fig. 9).
Figure 9

4
AMERICAN EXPEDITION VEHICLES
2. Disconnect the leads labeled A, F1, and F2 and remove the Warn harness from the controller (fig. 10).
A
F1 F2
Figure 10
3. Route AEV harness through the AEV bracket and into the controller through the same openings the
Warn harness was removed from.
4. Connect AEV leads. Yellow = A, Green = F1, Blue = F2
5. Isolate the small black motor ground wire inside the controller. Cut and splice in the new motor ground
wire from the AEV harness. NOTE: Make sure the splice will be located within the winch controller
enclosure when reassembled.
6. Mount the controller to the bracket using QTY 2 flange nuts provided. (fig. 11).
7. Reinstall QTY 4 bolts to reassemble controller housing.
Figure 11

5
AMERICAN EXPEDITION VEHICLES
III. WINCH INSTALLATION
1. Set bracket into place in front of the airbox.
2. Position the controller bracket in place and loosely install the radiator support bolts removed earlier (fig. 12).
Figure 12
3. Install supplied bolt through the tab at the bottom of the bracket into the existing hole shown and
secure with supplied flange nut (fig. 13). NOTE: Some vehicles may have plastic clip that will need to be
removed.
FRONT OF VEHCILE
FRONT OF VEHCILE
Figure 13
4. Route motor leads between the radiator shroud and inner frame rail, then through the gap between the
radiator and the lower radiator support.

6
AMERICAN EXPEDITION VEHICLES
5. Run the positive cable across the front of the vehicle. Detach the radiator supports to run the loom un-
derneath as shown (fig. 14) then reinstall fasteners.
Figure 14
6. Remove ground cable from winch motor and route through the bottom of the engine bay in location
shown (fig. 15).
Figure 15
7. Route the battery leads toward the battery. DO NOT hook up at this time.
8. Install winch body (fig. 16).
A. You will need to mount the WARN winch feet forward as opposed to feet down. To make the clutch
handle easily accessible, stand the winch up on end so the housing is straight up. Remove the 10
screws from the end housing, lift the winch up about a 1/4”, and rotate it every two holes to the de-
sired position. Reinstall the screws.
B. Start 2 AEV supplied M10 x 4” bolts at the top of the winch.
C. Start 2 WARN supplied M10 bolts at the bottom of the winch.
D. Tighten bottom bolts.
E. Remove top winch bolts for now.

7
AMERICAN EXPEDITION VEHICLES
A A
BB
Figure 16
9. Connect wiring to winch.
A. Run the leads along the top side of the lower radiator support, securing with zip ties.
B. Connect the motor leads to the proper studs using the color to letter guide.

8
AMERICAN EXPEDITION VEHICLES
C. Attach ground wire.
10. Run the winch cable through the Bison fairlead and drop into place (fig. 20).
Figure 20
11. Trimming the air diverter (fig. 21).
A. Using scribe line to cut air diverter for spool
B. Reinstall air diverter with 12 clips
Figure 21

9
AMERICAN EXPEDITION VEHICLES
12. Reinstall Center section of bumper
13. Reinstall Wheel Liner Closeouts
14. Reinstall Skid 1B (fig. 3).
15. Reinstall Front Bumper Skid (fig. 2).
16. If you live in a State requiring a front license plate, you will need to drill holes for the fasteners.
NOTE: Mid-year 2020 vehicles will have holes for the ¼ turn fasteners and push-in fasteners.
Option A: Mount license plate over fairlead. (fig. 22A).
Option B: Mount license plate curved under fairlead (fig. 22B).
A. Center license plate and mark holes for drilling.
B. Drill 7/16” holes, de-burr, and treat with rust preventative.
C. Insert supplied push-in fasteners and attach license plate.
Figure 22A Figure 22B
17. Install winch hook per manufacturers recommendations.
18. Trim the battery box and lid to make space for the positive winch connection (fig. 23).
Figure 23

10
AMERICAN EXPEDITION VEHICLES
19. Attached positive line to battery.
20. Route the negative lead alongside the battery and connect to the negative terminal (fig. 24).
Figure 24
21. Spool winch according to manufacturers recommendations
