aFe Power 51-12032 User manual

advanced FLOW engineering
Instruction Manual P/N: 51-12032 / 54-12032 / 75-12032 & 75-12032-0V
Make: Dodge Model: RAM 2500/3500 Year: 2010-2012 Engine: L6-6.7L (td) Cummins

Label Qty. Description Part Number
A1 1 Pro DRY S Air Filter 21-91046 (Gray Media)
A2 1 Pro 5R Air Filter 24-91046 (Blue Media)
A3 1 Pro Guard-7 Air Filter 72-91046 (Gold Media)
B 1 Housing 05-12032B2
C 1 Tube 05-12032B1
D 2 Washer, Flat M6 03-50070
E 2 Screw, Hex Head M6 05-50052
F 1 Washer, Lock 03-50071
G 2 Clamp, T-bolt 03-50499
H 3 Screw, Slotted 03-50045
I 1 Gasket, MAF sensor 05-01177
J 1 Gasket, Temp Sensor 05-01176
K 1 Coupling, Straight 05-00715
L 1 Seal, Trim (22.5 Inches) 05-00007
M 1 Seal, Trim (11 Inches) 05-00007
N 1 Grommet 03-50167
Note: Legal in California for use on race vehicles only. The use of this device on vehicles used on public streets or high-
ways is strictly prohibited in California and others states that have adopted California
emission regulations.
• Please read the entire instruction manual before proceeding.
• Ensure all components listed are present.
• If you are missing any of the components, call customer support at 951-493-7100.
• Ensure you have all necessary tools before proceeding.
• Do not attempt to work on your vehicle when the engine is hot.
• Disconnect the negative battery terminal before proceeding.
• Retain factory parts for future use.
Page 2

aFepower.com
A1 A2
Page 3
B
A3
C
J
F
G
I
H
L
N
M
E D
K

Refer to Figure A for Steps 1-2
Step 1: Remove the bolt holding the air box down. 1
Step 2: Disconnect the wiring harness from the Mass air flow sensor and temperture sensor. 2
REMOVAL
Page 4
2
2
1
Figure A

Refer to Figure B for Steps 3-4
Step 3: Disconnect the crank case vent line 3 using pliers.
Step 4: Loosen the clamp holding the intake tube to the turbocharger 4 and lift the entire intake
system out of the vehicle.
aFepower.com
Page 5
REMOVAL
3
4
Figure B

Refer to Figure C for Steps 5-6
Step 5: Remove screw that holds the battery mount to the vehicle 5 with a 13mm socket.
Step 6: Loosen rear screw that holds the battery mount to the vehicle 6 with a 13mm wrench.
Figure C
REMOVAL
Page 6
5
6

Refer to Figure D for Steps 7-9
Step 7: Install supplied trim seal onto your aFe housing 7 .
Step 8: Place your housing into position like shown while lifting the battery rack tap 8 and slide the
mounting tab under the battery rack tab and install and tighten bolts removed in step 5 & 6.
Step 9: With the M6 hardware supplied, mount the housing to the radiator mount like shown 9 .
Figure D
INSTALL
aFepower.com
Page 7
7
8
9
7
8

Refer to Figure E for Steps 10-13
Step 10: Remove the Mass air flow sensor and temperature sensor from your oe intake tube and install
them to your new aFe intake tube with the gaskets supplied 10 .
Step 11: Remove the crank case vent line from your factory intake tube by prying open the metal clamp
with a flat blade screwdriver.
Step 12: With the clamps provided, install the silicone coupling onto the end of the intake tube 11
Step 13: Install the supplied grommet into the intake tube and firmly push the crank 12 case
fitting into it for a snug seal.
Page 8
Figure E
INSTALL
10 10
11 12

aFepower.com
Page 9
Refer to Figure F for Steps 14-15
Step 14: Place the intake tube into position and push the lower tube onto the turbo.
Step 15: With the M6 screw and washer, hard-mount the intake tube to the heat shield 13 .
Figure F
INSTALL
13

Refer to Figure G for Steps 16-18
Step 16: Tighten both clamps to secure the intake tube to the turbocharger 14 .
Step 17: Re-attach the crank case line you removed in step 3 15 .
Step 18: Connect the Mass air flow sensor and temperature harnesses.
Figure G
Page 10
INSTALL
14
15
