AGA ACMPLP-SI User manual

Love Good Food Love Warmth Love One For A Lifetime

2 Oven Electric
with Module

The Aga Isn’t an Appliance.
It’s a Way of Life
That is what you will hear from any of over 750,000 Aga owners
worldwide. Go into any Aga owner’s home and you will find them
in the kitchen. Probably comfortably leaning against their cooker
with a glass of wine in hand. Why? Because for over eighty
years, the Aga has been considered a member of the family. It
has heated kettles and warmed hearts. It has gathered family and
friends. It has become the heart of the home. This is why Aga
owners over the world say they couldn’t imagine life without one.
We invite you to experience the Aga lifestyle and we will
show you how an Aga can help you cook better, eat better
and live better. Join your local Aga retailer for a One-to-One
Demonstration and you’ll soon understand why Aga owners truly
do dine best at home.

No Knobs. No Timers.
No Stress. No Comparison.
Beneath the glossy enamel of every Aga beats a heart of cast iron...
and it’s the cast iron that makes a difference. From deep within
the Aga a patented burner heats the metal, which retains the heat.
Meanwhile a unique temperature regulation system continually
transfers the heat to the ovens and hotplates at precise pre-set
levels, so the Aga is always ready to cook when you are - no need to
waste time waiting for ovens to preheat. Its efficient insulated design
minimizes fuel consumption.
This is called radiant cooking, a much gentler process than the
fierce direct heat from exposed elements or flames in most ovens. It’s
this dependable radiant heat that locks in juices, preserving flavour,
nutrients and texture and ensures delicious results, without the stress.
In the ovens that are vented straight to the flue, you can even cook
sweet and savory dishes, at the same time, without one flavouring the
other. So you see, the Aga is designed to cope with the demands of
even the busiest households.

4 Oven Direct Vent
with Module

Roast The Turkey, Steam The
Asparagus, Simmer The Gravy,
Broil The Hors D’oeuvre, Warm
The Bread, And Bake The Pumpkin
Pie. All Without Frying Yourself.
Warming Plate (4 Oven Model Only)
The Warming Plate is a source of gentle heat,
ideal for warming a teapot or plates, even
melting butter.
Simmering Oven (4 Oven Model Only)
The Simmering Oven is the perfect slow
cooker and offers great versatility in
meal preparation. The 2 Oven Aga has a
Simmering/Warming Oven.
Warming Oven (4 Oven Model Only)
The Warming Oven provides gentle heat to
warm serving dishes and to keep cooked
dishes warm without drying them out — a
typically “forgiving” feature of Aga Cooking.
Burner Unit or Heat Source
The Aga is designed to run on gas or electric
power. Although the Aga is always ready
for use, it isn’t always using fuel. After the
initial startup, a thermostatic control only
allows the burner to use fuel when needed
to maintain oven and hotplate temperature.
Combined with the heat retaining properties
of the cast iron body, fuel usage is minimized.

Boiling Plate
The Boiling Plate is a source of instant
heat for very quick cooking, stir frying,
and for boiling water. It is big enough to
accommodate three average-sized
saucepans, and can also be used with
the Aga Toaster.
Insulated Covers
An Aga hallmark: two distinctive round
insulated covers. Left closed when not in
use, they retain the heat within the cooker.
Simmering Plate
The Simmering Plate can be used for
slower cooking, as well as for delicate
sauces and gravies. The surface can hold
three average- sized saucepans, and can
even be used as a griddle for pancakes,
eggs and toasted sandwiches.
Roasting Oven
The Roasting Oven is large and always ready
for cooking. Radiant heat ensures that roasts
and other dishes are cooked to perfection, with
maximum moisture retention and minimum
shrinkage. The 2 Oven Aga comes with a
combination Roasting/Baking Oven. Acts as a
brick oven. Perfect for making bread and pizzas.
Baking Oven (4 & 3 Oven Models Only)
Ideal for pastries, cakes, cookies and slow
roasting.

1. It Bakes.
Like a baker’s brick oven the all
around consistent heat of the Aga
creates feathery pastries, moist
cakes, crisp pizzas and hearth-
baked breads.
2. It Griddles.
The Aga Simmering Plate is the
perfect surface for pancakes,
grilled sandwiches, even eggs
— cook them directly on it. And
no need to preheat this griddle.
How’s that for quick and easy?
3. It Boils.
Water boils faster on the Aga than on
any ordinary range and most electric
kettles. The Aga Boiling Plate cooks
so rapidly that your fresh vegetables
will retain more of their natural
flavour, color and nutrients.
10 Essential Functions
Done With One Aga Cooker

9. It Fries.
You’ll create crunchier on the
outside, moister on the inside fried
chicken than ever before with the
Aga Boiling Plate and Roasting
Oven. It fries briskly, ensuring
crisp, golden skin every time.
7. It Broils.
Crisp bacon, succulent
sausages —broiled to
perfection in the top of
the Roasting Oven. Intense
heat sears the outside of
chops preserving the juicy
flavour inside.
5. It Toasts.
Even toast tastes better from the
Aga. Using the special toaster
provided with your Aga, you get
toast any way you like it. Evenly
browned and crisp all the way
through or crunch-on-the-outside
and fluffy-in-the-middle.
4. It Stews.
The gentle consistent heat of
the Aga Simmering Oven helps
you create richer sauces and
more flavorful casseroles. It
slow cooks for hours, allowing
you time to relax.
6. It Steams.
In the Simmering Oven you can
steam fish, rice and vegetables
— without steaming up the
kitchen.
8. It Roasts.
Your roasts will be superb — cooked
evenly throughout because the heat
comes from all directions. Shrinkage
and dryness are reduced because
there’s no flame or element inside
the ovens to dry out the meat —
another unique Aga feature.
10 . It Simmers.
The Aga Simmering Oven lets
you relax. It slow cooks for
hours — even overnight —
gently coaxing casseroles,
soups and stews to perfection.
All while you’re at work, running
errands or simply relaxing.

2 Oven
3 Oven with Module, Standard Vent, Color
Matched Lids and Custom Plinth
Note: Photo courtesy of Monetti Builders

2 Oven
Simple And
Elegantly Effective.

Companion
*You can order your Companion as a freestanding unit. When attached to your 2, 3 or 4 Oven Aga the
Module must be ordered with your Aga.

For Even More Versatility
The Aga Companion
Or Module Are
The Perfect Choice For You.
If you desire additional and more traditional cooking options, or if your
kitchen space is limited, the duel-fuel Aga Companion or Module could be
just your cup of tea.
Fabulously flexible, these dual-fuel ranges have four gas burners and
two electric ovens. They feature a top electric conventional oven with an
integral broiler, and a lower convection oven. The four gas burners (your
choice of natural gas or propane), include two semi-rapid (6,000 BTUs),
one rapid (11,000 BTUs), and one ultra-rapid/wok burner (12,000 BTUs).
The Module is the perfect complement to your 2, 3 or 4 Oven Aga, attaching
directly to either model. Available in all the same colors as the Cooker,
combining your Aga with a Module offers the ultimate in cooking versatility:
indirect radiant heat and duel-fuel cooking simultaneously.
Fits anywhere, the Companion can be used independently as a free-standing
range. Sized to fit standard kitchen cabinets, with the same renowned
British craftsmanship, like all Agas, the Companion is created entirely by
hand to exacting standards.

HEATHER PISTACHIO WHITE
AUBERGINE JADE
CHOCOLATE
Color Palette
Agas are available in your choice of six Standard colors
and eight Signature colors designed to complement
your kitchen and your personality.
Signature Collection
CREAM DARK BLUE BLACK
CLARET PEWTER
Standard Collection
BRITISH
RACING GREEN
*Colors shown
are printed
representations.
Due to the unique
and historic
nature of our
enamel finishes,
shades may vary
slightly.
PILLAR BOX

Premium Options
Color Matched Lids
Cast iron lids can be created for you in the
same color vitreous enamel as your Aga. If
preferred, this option must be chosen when
placing your order to ensure a perfect color
match.
Gas Burner
For those who love the look of an
Aga, but also desire a live flame
for cooking, a gas burner option to
replace the standard warming plate
on the 4 Oven Aga is available. This
option is offered in natural gas or
propane and must be specified at the
time of purchase.
The Classic Edition
The Classic Edition cooker is a
meticulous reproduction of the
original Aga design from 1932. Every
detail of the original cream colored
model from the script Aga badge
down to the flue damper control have
been painstakingly recreated. This
historically accurate design is fused
with today’s Aga function to provide
you with a timeless classic.

The very nature of molten
cast iron poured into molds
give the Aga its characteristic
finish and makes each Aga
subtly unique.
Castings undergo a three-day,
three-coat enameling process,
using Aga’s specially prepared
vitreous enamel for the highest
quality finish.
Each finished Aga is
inspected and color matched
prior to shipping

Britain’s Handcrafted Aga. Histor y In The
Making For Over 80 Years.
Since the 1920s, the Aga has been a treasured possession in kitchens across Europe and
throughout the world. Each Cooker is unique in its own fashion, cast in an historic foundry
in Coalbrookdale, Shropshire that has been smelting iron since 1709.
Today each Aga continues to be handmade by gifted craftsmen, with every step of
the building and finishing process continuously inspected for quality and excellence.
Upon completion, your Aga will be shipped from the United Kingdom to North America,
professionally delivered to your home, and carefully assembled by a skilled Aga technician
right in your own kitchen.
The deceptively simple Aga
design and graceful styling
has remained popular for
more than eight decades.
The elegant Aga styling remains
largely unchanged since the first
models were advertised in Britain in
the 1930s.
Main castings for the Aga
are made in Coalbrookdale,
Shropshire, the British foundry
where in 1709 Abraham Darby
first showed the world that iron
could be smelted using coke.
Pure Genius
Dr. Gustaf Dalen, a Nobel Prize winning Swedish physicist, lost his sight in an explosion in
1922. During his recovery at home, he became aware of how difficult it was for his wife to
prepare the daily meals. It could be simpler. He designed a stove that would be easy to use,
and consistent in its performance. Employing the tried and true concept of heat storage, he
combined a small and efficient heat source, two large hotplates and two generous ovens
into one robust and compact unit. Thus, the Aga was born.

The Aga Cook Shop Collection
offers an extensive selection
of wonderful cooking accessories
to enhance any kitchen. Our design
specialists have created everything your
kitchen needs from cast iron and stainless steel
cookware to bakeware, ceramics and cutlery.
And, Aga cookbooks are classics.
Experience The Aga Difference
To learn more about the legendary Aga, or to attend a
cooking demonstration, contact your local Aga dealer. To
locate the nearest showroom visit www.aga-ranges.com
To The Chef
With Complements
With your new Aga, you will
receive the Aga Starter Pack
to speed you on your way to
Aga cooking. This set includes
the Aga Toaster, two Roasting
Tins with Grill Racks, two Grid
Shelves, one Plain Shelf, a
Wire Brush and the popular Aga
Cookbook.

AGA COOKER PRODUCT SPECIFICATIONS
2 OVEN AGA SPECIFICATIONS
Product Type Heat storage cooker
Overall Dimensions 33 1/2”h x 38 7/8”w x 26 3/4”d
Oven Dimensions Roasting - 10”h x 13.75”w x 19.5”d
Simmering - 10”h x 13.75”w x 20.75”d
Oven Capacity Roasting - 1.5 cu ft
Baking - 1.5 cu ft
Total Capacity 3.0 cu ft
Weight 900 lbs. The Aga is a flat load which spreads the weight over 7 sq. feet
MODELGAS MODELS ELECTRIC MODELS
Fuel/Power Natural or Liquid Propane Gas 240 volt, 15 amp circuit
Vent Options
The most effective of the three available venting system options for your
home - standard, direct or power - will be determined by a pre-installation
site survey performed by a certified Aga fitter. Contact your local
authorized Aga dealer to arrange a survey.
No venting required
Servicing Annual maintenance is recommended, as well as a
10-year service.
Annual servicing is not required.
Routine service is recommended
at 5-year intervals.
Warranty 5 year limited parts and labor. 1 year on gas power vent, gas train - including
thermocouple, gas valve, pilot assembly and controls thermostat.
3 OVEN AGA SPECIFICATIONS
Product Type Heat Storage Cooker
Overall Dimensions 33 1/2”h x 38 7/8”w x 26 3/4”d
Oven Dimensions
Roasting - 10”h x 13.75”w x 19.5”d
Simmering - 10”h x 13.75”w x 20.75”d
Baking - 10”h x 13.75”w x 20.5”d
Oven Capacity Roasting - 1.5 cu ft
Baking - 1.5 cu ft
Total Capacity 4.5 cu ft
Weight 1052 lbs. The Aga is a flat load which spreads the wieght over 7 sq. feet
Fuel TypesNatural or Liquid Propane
Vent Options Standard Vent only
Sevrvicing Annual maintenance is recommended, as well as a 10-year service plan
Warrranty 5 year limited parts and labor.
4OVEN AGA SPECIFICATIONS
Product Type Heat Storage Cooker
Overall Dimensions 33 1/2”h x 38 7/8”w x 26 3/4”d
Oven Dimensions Roasting - 10”h x 13.75”w x 19.5”d Simmering - 10”h x 13.75”w x 20.75”d
Baking - 10”h x 13.75”w x 19.5”d Warming - 10”h x 13.75”w x 20.75”d
Oven Capacity
Roasting - 1.5 cu ft
Baking - 1.5 cu ft
Warming - 1.5 cu ft
Total Capacity 6.0 cu ft
Weight 1290 lbs. The Aga is a flat load which spreads the weight over 10 sq ft.
MODEL Gas Models ELECTRIC MODELS
Fuel/Power Natural or Liquid Propane Gas 240 volt, 15 amp circuit
Vent Options
The most effective of the three available venting system options for
your home - standard, direct or power - will be determined by a
pre-installation site survey performed by a certified Aga fitter. Contact
your local authorized Aga dealer to arrange a survey.
No venting required
Servicing Annual maintenance is recommended, as well as a
10-year service.
Annaul servicing is not required.
Routine service is recommended
at 5-year intervals.
Warranty 5 year limited parts and labor. 1 year on gas power vent, gas train - including thermocouple,
gas valve, pilot assembly and controls thermostat.
Dimensions are for reference only. Consult your Aga fitter and our installation and operating manual for installation specifications.

AGA COMPANION PRODUCT SPECIFICATIONS
COMPANION ONLY
Product Type Dual Fuel
Overall Dimensions 33 1/2”h x 23 1/2”w x 23 3/4”d
Oven Dimensions Top - 8 1/2”h x 13 3/4”w x 19”d
Bottom - 10”h x 13 3/4”w x 17”d
Oven Capacity Top - 1.5 cu ft
Bottom - 1.5 cu ft
Total Capacity 3.0 cu ft
Weight 310 lbs.
Fuel Types Natural or LPG (burners)/Electric Ovens
Burner Ratings Right Front - 12,000 BTU Right Rear - 6,150 BTU
Left Front - 6,150 BTU Left Rear - 10,600 BTU
Oven Rating Top - Heat with 7 pass, 2100 watt broiler
Bottom - Convection
Vent Hood 300 CFM hood recommended
Warranty 1-year limited warranty
MODULE ATTACHED TO A 2,3 OR 4 OVEN AGA
Product Type Dual Fuel
Overall Dimensions 33 1/2”h x 23 1/2”w x 26 3/4”d
Oven Dimensions Top - 8 1/2”h x 13 3/4”w x 19”d
Bottom - 10”h x 13 3/4”w x 17”d
Oven Capacity Top - 1.5 cu ft
Bottom - 1.5 cu ft
Total Capacity 3.0 cu ft
Weight 310 lbs.
Fuel Types Natural or LPG (burners)/Electric Ovens
Burner Ratings Right Front - 12,000 BTU Right Rear - 6,150 BTU
Left Front - 6,150 BTU Left Rear - 10,600 BTU
Oven Rating Top - Heat with 7 pass, 2100 watt broiler
Bottom - Convection
Vent Hood 300 CFM hood recommended
Warranty 1-year limited warranty
Dimensions Including Cooker
2 Oven 33 1/2”h x 62 3/8”w x 27 1/2”d
3 Oven 33 1/2”h x 62 3/8”w x 27 1/2”d
4 Oven 33 1/2”h x 82”w x 27 1/2”d
Dimensions are for reference only. Consult your Aga fitter and our installation and operating manual for installation
specifications.
When attaching your Module to your Aga Cooker, both units must be ordered simultaneously to ensure a perfect color
match. The Cooker and Module will join together.
Please note the Companion can not be fitted to a Cooker.
Installation
Each Aga is hand built, piece-by-piece. So, your 2, 3 or 4 Oven
Aga will arrive from the United Kingdom knocked down and be
professionally assembled by a certified Aga installer. Depending on
whether your kitchen is in pre-construction stage or is an existing
space, the installer will develop an installation plan for you.
For Pre-Construction Kitchens
The installer will coordinate with your architect or builder to
determine which venting options are suitable for your home and
communicate the necessary specifications to the builders plan.
For Existing Kitchens
An Aga installer will first visit your kitchen for a site survey to
determine which venting options are suitable for your home. The
installer will then work with you and your retailer to ensure the
proper style is ordered.
DIRECT VENT STANDARD VENT
POWER VENT ELECTRIC
