Agaro Royal User manual

MANUAL
Model: Royal
Item no - 33554
Stand Mixer
W
a
r
r
a
n
t
y
2
YEARS
W
a
r
r
a
n
t
y

ABOUT THE PRODUCT
Main Components and Standard Accessories:
1
Output shaft
6
Dough hook
2
Rise button
7
Whisk
3
Speed knob
8
Beater
4
Power Cord
9
Pot cover
5
Mixing bowl

USING THE MIXING BOWL
1. In order to lift the arm, press the Rise button (2) downwards
in the direction of the arrow. The arm will now move
upwards.(FIG1)
2. Place the pot cover into its body.(FIG2)
3. Place the mixing bowl into its holding device(Step①) and
turn the bowl clockwise until it locks into place(Step ②).
FIG3)
4. Mount the required utensil（Dough hook or Beater or
Whisk）by inserting the top into the output shaft, and turn
anti-clockwise until it locks into place. (FIG4&FIG5)
5. Now fill in your ingredients.
Do not overfill the machine - the maximum quantity of
ingredients is 1.0Kg.
6. Lower the arm using the rise button (2). (FIG6)
7. Insert the mains plug into a properly installed 220-240V~
50-60Hz safety power socket.
8. Switch the machine using the speed button to a speed
between 1 and 6 (corresponding to the mixture).
9. For pulse operation (kneading at short intervals), turn the
switch to the “PULSE” position. The switch has to be held in
this position according to the desired interval length.
When the switch is released it returns automatically to the
“0” position.
10. After kneading/stirring turn the speed knob (3) back to the
“0” position as soon as the mixture has formed a ball. Then
remove the mains plug.
11. Press the rise button (2) downwards and the arm will be
raised.
12. The mixture can now be released with the help of a
spatula and removed from the mixing bowl.
13. The mixing bowl can now be removed.
14. Clean the parts as described under “Cleaning”.

Adjusting the Levels and Using the Hook for not more than
0.9kg of Mixture
Use Picture Levels Time(Min) Maximum Operation method
Doughhook
1-5 3- 5 585g flour and
315g water
1 speed run for 30s,
the 3 speed run for
30s, and then the 5
speed run for 2 min to
4 min to form a cluste
r
.
Beater 2-6 3- 10 400g flour and
500g water
2 speed run for20s,
the 6 speed run for
more than 2min40s
Whisk
6-8 3- 10
3 eggwhites
（Minimum）
Open 8 speed to run
3min above.
NOTE:
 Short operation time: With heavy mixtures, do not operate
the machine for more than six minutes, and then allow it to
cool down for a further ten minutes.

TROUBLESHOOTING
CLEANING
 Before cleaning remove the mains lead from the socket.
 Never immerse the housing with motor in water!
 Do not use any sharp or abrasive detergents.
Motor Housing
 Only a damp rinsing cloth should be used to clean the
outside of the housing.
Mixing Bowl, Mixing Equipment
CAUTION:
 The components are not suitable for cleaning in a
dishwasher. If exposed to heat or caustic cleaners they
NO. Troubles Solution
1
The machine doesn't work
•Check if the plug is in good contact with the socket
•Check if the rise button spring back in place
•Check if the machine works continuously more than 6-
10 minutes, and wait until the motor cool down
2
Noise in the mixing bowl
when working (the accessory
scraped the bowl)
•Check if the mixing bowl is properly installed
•Check if the accessory installed properly on machine
3 The pot cover doesn’t fit the
mixing bowl properly
•Check if the pot cover placed on the machine properly
•Check if the mixing bowl installed properly on machine
and locked correctly
4 The machine doesn’t work on
certain speed
•Check if the mark on speed knob correspond to the
speed silkscreen on housing
•Rotate speed knob to 0 ,and re-check if the machine
works
5 Movements when the
machine working
•Check if the anti-slip feet fall off
•Check if the machine is placed on a smooth and flat
tabletop
6
The rise button didn’t spring
back in place after installing
the mixing bowl and pot
cover
•Check if the pot cover placed on the machine properly
•Check if the mixing bowl is properly installed
might become misshapen or discolored
 Components that have come into contact with food
can be cleaned in soapy water
 Allow the parts to dry thoroughly before reassembling the
device
 Please apply a small quantity of vegetable oil likely to the
screens after they have dried

CAUTION
 Before cleaning remove the mains lead from the socket.
 Never immerse the housing with motor in water!
 Do not use any sharp or abrasive detergents.
Motor Housing
 Only a damp rinsing cloth should be used to clean the
outside of the housing.
Mixing Bowl, Mixing Equipment
CAUTION:
 The components are not suitable for cleaning in a
dishwasher. If exposed to heat or caustic cleaners they
might become misshapen or discolored
 Components that have come into contact with food
can be cleaned in soapy water
 Allow the parts to dry thoroughly before reassembling the
device
 Please apply a small quantity of vegetable oil likely to the
screens after they have dried
 The appliance is designed exclusively for home purpose
This appliance is not fit for commercial use
Do not use the appliance with wet hands. If the appliance
is humid or wet, unplug it immediately
 While cleaning, switch off the appliance and always pull
out the plug from the socket (pull on the plug, not the
cable) if the appliance is not being used and remove the
attached accessories
Children and Frail Individuals
 In order to ensure your children safety please keep all
packaging (plastic bags, boxes, polystyrene etc.) out of
their reach
Caution! Do not allow small children to play with the foil as
there is a danger of suffocation!
 Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and if they understand the hazards involved.
Special safety Instructions for this Machine
 Always disconnect the appliance from the supply if it is left
unattended and before assembling, disassembling or
cleaning
 Switch off the appliance and disconnect from supply
before changing accessories or approaching parts that
move in use

Stand Mixer
Royal (Item No - 33554)
Scan - For Warranty Registration
(Must register within 30 days
from date of purchase to avail
3 MONTHS EXTENDED WARRANTY)
or visit: www.agarolifestyle.com/product-registration or visit: www.agarolifestyle.com/service
(Fill & submit the form if you are
facing any product related issues)
Scan - To File Complaint
• Please scan the QR CODE for product registration and avail “3 MONTHS
EXTENDED WARRANTY” on product
• Please preserve the invoice for product warranty claim. Customer purchasing
from online platforms needs to produce the Online Partner's Invoice copy to
claim the warranty
For any feedback or complain, you can also connect us at:
UNIVERSAL CORPORATION LIMITED, 4/1 Middleton Street, Sikkim Commerce
House, Kolkata-700071
Email Address : [email protected]
Customer Care No: 9821-486-487
Product Name
Model
Name, Address &
Contact no of customer
Name, Address & Contact
no of dealer
Date of Purchase
Warranty Valid upto
: .................................................................................
: .................................................................................
: .................................................................................
.................................................................................
: .................................................................................
.................................................................................
: .................................................................................
: .................................................................................
LIMITED TWO YEARS WARRANTY
