Agilent Technologies U2121A-101 RF User manual

Agilent Technologies
Agilent U2121A-101 RF
Switch Driver Board
Operating Guide
U2931A Operating Guide.book Page I Tuesday, June 10, 2008 10:17 AM

II U2121A-101 Operating Guide
Notices
® Agilent Technologies, Inc. , 2008
No part of this manual may be reproduced in
any form or by any means (including elec-
tronic storage and retrieval or translation
into a foreign language) without prior agree-
ment and written consent from Agilent
Technologies, Inc. as governed by United
States and international copyright laws.
Manual Part Number
U2931-90001
Edition
Second Edition, June 6, 2008
Agilent Technologies, Inc.
3501 Stevens Creek Blvd.
Santa Clara, CA 95052 USA
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connec-
tion with the furnishing, use, or per-
formance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accor-
dance with the terms of such license.
Restricted Rights Legend
U.S. Government Restricted Rights. Soft-
ware and technical data rights granted to
the federal government include only those
rights customarily provided to end user cus-
tomers. Agilent provides this customary
commercial license in Software and techni-
cal data pursuant to FAR 12.211 (Technical
Data) and 12.212 (Computer Software) and,
for the Department of Defense, DFARS
252.227-7015 (Technical Data - Commercial
Items) and DFARS 227.7202-3 (Rights in
Commercial Computer Software or Com-
puter Software Documentation).
Safety Notices
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and
met.
Trademark Acknowledgements
Pentium is a U.S. registered trademark of
Intel Corporation.
Microsoft, Visual Studio, Windows, and MS
Windows are trademarks of Microsoft Cor-
poration in the United States and/or other
countries.
U2931A Operating Guide.book Page II Tuesday, June 10, 2008 10:17 AM

U2121A-101 Operating Guide III
Safety Symbols
The following symbols on the instrument and in the documentation
indicate precautions, which must be taken to maintain safe operation of
the instrument.
Direct current (DC)
Equipment protected throughout by
double insulation or reinforced
insulation
Alternating current (AC) Off (supply)
Both direct and alternating current On (supply)
Three-phase alternating current Caution, risk of electric shock
Earth (ground) terminal
Caution, risk of danger (refer to this
manual for specific Warning or Caution
information)
Protective conductor terminal Caution, hot surface
Frame or chassis terminal Out position of a bi-stable push control
Equipotentiality In position of a bi-stable push control
U2931A Operating Guide.book Page III Tuesday, June 10, 2008 10:17 AM

IV U2121A-101 Operating Guide
General Safety Information
WARNING
• Do not load the output terminals above the specified current limits.
• Do not use the device if it appears damaged or defective.
• Observe all markings on the device before connecting any wiring to
the device.
• Do no operate the device in the presence of flammable gases or
fumes.
• Do no install substitute parts or perform any unauthorized
modification to the device.
CAUTION
•Applying excessive voltage or overloading the device will cause
irreversible damage to the circuitry.
•Use the device with the cables provided.
•Repair or service that is not covered in this manual should only be
performed by qualified personnels.
•To avoid ESD damage to the RF switch driver board, users are highly
recommended to comply with the following cautions:
•User are required to discharge themselves to any large metal object
(e.g. Shelf, desk, etc.) prior to operating the RF switch driver board.
•Operate the RF switch driver board under an ESD protected workstation,
with the minimum requirements of using wrist strap (connected to ground)
and ESD pad. The wrist strap can be grounded by connecting to the power
supply ground and/or circuit board ground.
•Avoid human body contact or a charged material to the on-board components
and circuitries. Always hold the board edges when carrying the RF switch driver
board.
U2931A Operating Guide.book Page IV Tuesday, June 10, 2008 10:17 AM

U2121A-101 Operating Guide V
Environmental Conditions
This instrument is designed for indoor use and in an area with low
condensation. The table below shows the general environmental
requirements for this instrument.
Environmental conditions Requirements
Operating temperature 0 °C to 40 °C
Storage temperature –40 °C to 70 °C
Operating humidity Up to 85% at 40 °C (non-condensing)
Storage humidity 5% to 90% RH (non-condensing)
CAUTION
The U2121A-101 RF switch driver board complies with the following safety
and EMC requirements.
•IEC 61326-2002/EN 61326:1997+A1:1998+A2:2001+A3:2003
•Canada: ICES-001:2004
•Australia/New Zealand: AS/NZS CISPR11:2004
•IEC 61010-1:2001/EN 61010-1:2001 (2nd edition)
U2931A Operating Guide.book Page V Tuesday, June 10, 2008 10:17 AM

VI U2121A-101 Operating Guide
Regulatory Markings
The CE mark is a registered trademark
of the European Community. This CE
mark shows that the product complies
with all the relevant European Legal
Directives.
The C-tick mark is a registered
trademark of the Spectrum
Management Agency of Australia.
This signifies compliance with
the Australia EMC Framework
regulations under the terms of the
Radio Communication Act of 1992.
ICES/NMB-001 indicates that this
ISM device complies with the
Canadian ICES-001.
Cet appareil ISM est confomre a la
norme NMB-001 du Canada.
This instrument complies with the
WEEE Directive (2002/96/EC)
marking requirement. This affixed
product label indicates that you must
not discard this electrical/electronic
product in domestic household waste.
This symbod indicates that a device,
or part of a device, may be susceptible
to electrostatic discharges (ESD),
which can result in damage to the
product. Observe ESD precautions
given on the product, or its user
documentation, when handling
equipment bearing this mark.
U2931A Operating Guide.book Page VI Tuesday, June 10, 2008 10:17 AM

U2121A-101 Operating Guide VII
Waste Electrical and Electronic Equipment (WEEE) Directive
2002/96/EC
This instrument complies with the WEEE Directive (2002/96/EC) marking
requirement. This affixed product label indicates that you must not discard
this electrical/electronic product in domestic household waste.
Product Category:
With reference to the equipment types in the WEEE directive Annex 1, this
instrument is classified as a “Monitoring and Control Instrument” product.
The affixed product label is shown as below.
Do not dispose in domestic household waste
To return this unwanted instrument, contact your nearest Agilent
Te c h no l o gi e s , o r vi si t :
www.agilent.com/environment/product
for more information.
U2931A Operating Guide.book Page VII Tuesday, June 10, 2008 10:17 AM

VIII U2121A-101 Operating Guide
DECLARATION OF CONFORMITY
According to EN ISO/IEC 17050-1:2004
Generic example
Manufacturer’s Name: Agilent Technologies Microwave Products (M) Sdn. Bhd
Manufacturer’s Address: Bayan Lepas Free Industrial Zone,
11900, Bayan Lepas, Penang, Malaysia
Declares under sole responsibility that the product as originally delivered
Product Name: Agilent RF Switch Board
Models Number: U2931A
Product Options: This declaration covers all options of the above product(s)
complies with the essential requirements of the following applicable European Directives, and
carries the CE marking accordingly:
Low Voltage Directive (2006/95/EC)
EMC Directive (2004/108/EC)
and conforms with the following product standards:
EMC Standard
StandardStandard
Standard
Limit LimitLimit
Limit
IEC 61326:2002 / EN 61326:1997+A1:1998+A2:2001+A3:2003
CISPR 11:1990 / EN55011:1990 Class A Group 1
IEC 61000-4-2:1995 / EN 61000-4-2:1995 4 kV CD, 8 kV AD
IEC 61000-4-3:1995 / EN 61000-4-3:1996 3 V/m, 80-1000 MHz
IEC 61000-4-4:1995 / EN 61000-4-4:1995 0.5 kV signal lines, 1 kV power lines
IEC 61000-4-5:1995 / EN 61000-4-5:1995 0.5 kV line-line, 1 kV line-ground
IEC 61000-4-6:1996 / EN 61000-4-6:1996 3 V, 0.15-80 MHz
IEC 61000-4-11:1994 / EN 61000-4-11:1994 1 cycle / 100%
Canada: ICES-001:2004
Australia/New Zealand: AS/NZS CISPR11:2004
The product was tested in a typical configuration with Agilent Technologies test systems.
Safety
IEC 61010-1:2001 / EN 61010-1:2001
Additional Information:
The U2931A receives power from an AC/DC power supply model DSA-60W-20 1 24060.
This DoC applies to above-listed products placed on the EU market after:
31-March-2008
Date
Tay Eng Su
Quality Manager
For further information, please contact your local Agilent Technologies sales office, agent or distributor,
or Agilent Technologies Deutschland GmbH, Herrenberger Straße 130, 71034 Böblingen, Germany.
Template: A5971-5302-2, Rev. E U2931A DoC Revision 1.0
U2931A Operating Guide.book Page VIII Tuesday, June 10, 2008 10:17 AM

U2121A-101 Operating Guide IX
Product Regulations
Performance Criteria
IEC 61326-1:2002 / EN 61326-1:1997+A1:1998+A2:2001+A3:2003
CISPR 11:1990 / EN 55011:1990
– Group 1 Class A
IEC 61000-4-2:1995 / EN 61000-4-2:1995 (ESD 4kV CD, 8kV AD) A
IEC 61000-4-3:1995 / EN 61000-4-3:1996 (3V/m, 80% AM) A
IEC 61000-4-4:1995 / EN 61000-4-4:1995 (EFT 0.5kV line-line, 1kV line-earth) A
IEC 61000-4-5:1995 / EN 61000-4-5:1995 (Surge 0.5kV line-line, 1kV line-earth) A
IEC 61000-4-6:1996 / EN 61000-4-6:1996 (3V, 0.15~80 MHz, 80% AM, power line) A
IEC 61000-4-11:1994 / EN 61000-4-11:1994 (Dips 1 cycle, 100%) A
Canada: ICES-001:2004
Australia/New Zealand: AS/NZS CISPR11:2004
EMC
IEC 61010-1:2001 / EN 61010-1:2001
Safety
Additional Information:
The product herewith complies with the essential requirements of the Low Voltage Directive 2006/95/EC and the
EMC Directive 2004/108/EC and carries the CE Marking accordingly (European Union).
1
Performance Criteria:
A Pass - Normal operation, no effect.
B Pass - Temporary degradation, self recoverable.
C Pass - Temporary degradation, operator intervention required.
D Fail - Not recoverable, component damage.
N/A – Not applicable
Notes:
Regulatory Information for Canada
ICES/NMB-001:2004
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est confomre à la norme NMB-001 du Canada.
Regulatory Information for Australia/New Zealand
This ISM device complies with Australian/New Zealand AS/NZS CISPR11:2004
U2931A Operating Guide.book Page IX Tuesday, June 10, 2008 10:17 AM

XU2121A-101 Operating Guide
U2931A Operating Guide.book Page X Tuesday, June 10, 2008 10:17 AM

U2121A-101 Operating Guide 1
Contents
Introduction 2
Standard Purchase Items Checklist 4
Product at a Glance 5
Product outlook 5
Product dimensions 6
Connector Pins Configuration 7
Installation Guide 10
A. Check your system 11
B. Install prerequisites and software 12
C. Connect the hardware solution to your PC 14
D. Launch the Agilent U2121A-Based RF Switch Driver Software 15
Supported Switches 19
Product Characteristics and Specifications 21
Maintenance 23
Disassemble Procedure 24
Ordering Info 26
Optional accessory 26
Appendix A: Control Instructions 29
Appendix B: Y1157A Cable Assembly Instructions 31
U2931A Operating Guide.book Page 1 Tuesday, June 10, 2008 10:17 AM

2U2121A-101 Operating Guide
Introduction
The Agilent U2121A- 101 (also known as U2931A) RF switch driver
with cable is an adapter board designed for use with the Agilent
U2121A digital IO device. It enables you to control various types of
RF switches easily and has enhanced driving capability and consists
of different types of connectors to suit different switches.
The U2121A- 101 purchase consists of a driver interface module, an
interface cable (equipped with a 37- pin D- sub connector on one end
and four 10- way terminal block connectors on the other end), a
10- pin to D- sub adapter, and a 24 VDC, 2.5 A power adapter. This
module is connected to the U2121A using the provided interface
cable. You can also use the Y1157A[1] cable, which is a 10- pin ribbon
connector to 9- pin D- Sub cable kit for the Agilent N1810/11/12
coaxial switches.
This module is consists of five RF switch driver channels and one
general IO terminal. Each channel is pre- programmed to drive three
different types of Agilent RF switches. Only one type of RF switch
can be connected to a single channel during operation.
The U2121A-101 module is designed to handle 24 VDC switches.
[1] Refer to Appendix B for Y1157A cable kit assembly.
CAUTION
DO NOT connect different types of RF switches to the same channel during
operating time.
U2931A Operating Guide.book Page 2 Tuesday, June 10, 2008 10:17 AM

U2121A-101 Operating Guide 3
Power supply
The switches on this module are powered by the provided power
adapter. There is only one power supply voltage available for this
module, which is 24 VDC, 2.5 A.
Power consumption
The U2121A- 101 can drive up to 1500 mA continuously using the
provided power supply. For each channel, it is able to drive up to 300
mA load per switch. Precaution must be taken to ensure that the
total current consumption on all channels is not more than 1500 mA,
which is the maximum driving capability of the module.
U2931A Operating Guide.book Page 3 Tuesday, June 10, 2008 10:17 AM

4U2121A-101 Operating Guide
Standard Purchase Items Checklist
Verify that you have received the following items with your purchase.
U2121A- 101 RF switch driver board with cable purchase. If anything is
missing or damaged, please contact the nearest Agilent Sales Office.
✔RF switch driver board
✔RF switch driver board interface
✔U2931- 60013 10 ways IDC to 9- pins D- Sub adapter
✔U2931- 60012 power adapter
✔Agilent U2121A- 101 RF Switch Driver Board Operating Guide
✔Agilent U2931A RF Switch Driver Product Reference CD- ROM
U2931A Operating Guide.book Page 4 Tuesday, June 10, 2008 10:17 AM

U2121A-101 Operating Guide 5
Product at a Glance
Product outlook
Top view (without casing)
Connector for
general I/O
Connector for
general output
Connector for
general input
DC power jack Power Digital IO Connector for
rating terminal N181x RF switches
Connector for Connector for 8762/3/4
8765x-024 RF switches 8765x/324 RF switches
U2931A Operating Guide.book Page 5 Tuesday, June 10, 2008 10:17 AM

6U2121A-101 Operating Guide
Product dimensions
Top view (without casing)
Top view (with casing)
Front view (with casing) Side view (with casing)
72.00 mm
150.00 mm
85.00 mm
153.00 mm
38.00 mm 85.00 mm
U2931A Operating Guide.book Page 6 Tuesday, June 10, 2008 10:17 AM

U2121A-101 Operating Guide 7
Connector Pins Configuration
Pin out configuration for all terminals
Ta b le 1 8762/2/3 and 8765x-324 Series switches (X1 to X5)
Pin Function
1Position#1
2Position#2
3N.C.
4+24V
Ta b le 2 8765x-024 Series switches (SL1 to SL5)
Pin Function
1Position#2
2N.C.
3+24V
4+24V
5Position#1
Ta b le 3 N181X Series switches (SV1 to SV5)
Pin Function Pin Function
1GND2 +5V
3N.C.4IndicatorB
5PositionB6 +5V
7PositionA8 IndicatorA
9+24V10 N.C.
U2931A Operating Guide.book Page 7 Tuesday, June 10, 2008 10:17 AM

8U2121A-101 Operating Guide
IO mapping
There are three main control bits used in the U2121A- 101 as shown
in tables below. These control bits also refers to the U2121A control
bit status.
Ta b le 4 Output enable/disable control
Control Stage Control Bit, DO14 Description
Output disabled OFF (0) To disable all outputs in U2121A-101
Output enabled ON (0) To enable all outputs in U2121A-101
Ta b le 5 Position information read back control
RF Switches Control Bit Description
D16 D15
8765x and 8762/3/4 OFF (0) ON (1) Read position information from 8765x and
8762/3/4 series switches
N181x ON (1) OFF (0) Read position information from N181x
series switches
WARNING
DO NOT set both D15 and D16 control bits to ON stage!
U2931A Operating Guide.book Page 8 Tuesday, June 10, 2008 10:17 AM

U2121A-101 Operating Guide 9
Each of the five RF switch channels uses two digital output pins and
two digital input pins during the operation.
Ta b le 6a IO mapping for 8762/3/4, 8765x-324 and N181x Series RF switches
Channel Control Bit Position Bit
State A State B State A State B
1O1O2I1I2
2O3O4I3I4
3O5O6I5I6
4O7O8I7I8
5 O9 O10 I9 I10
General IO O11, O12 & O13 I11, I12 & I13
Ta b le 6b IO mapping for 8765x-024 Series RF switches
Channel Control Bit Position Bit
State A State B State A State B
1O2O1I2I1
2O4O3I4I3
3O6O5I6I5
4O8O7I8I7
5O10O9I10I9
General IO O11, O12 & O13 I11, I12 & I13
Ta b le 7 Position indicator stage definition
RF Switches Model Activated Deactivated
8732/3/4 Series and 875x Series OFF (0) ON (1)
N181x Series ON (1) OFF (0)
U2931A Operating Guide.book Page 9 Tuesday, June 10, 2008 10:17 AM

10 U2121A-101 Operating Guide
Installation Guide
Follow the step- by- step instructions shown in the following flowchart
to get started with the preparations and installations of your Agilent
U2121A- Based RF Switch Driver Software.
NOTE
You need to install the IVI-COM driver if you are going to use the U2121A-101
with Agilent VEE Pro, LabVIEW, or Microsoft®Visual Studio®.
A. Check your system
B. Install prerequisites and software
C. Connect the hardware solution to your PC
D. Launch the Agilent U2121A-Based RF
Switch Driver Software
U2931A Operating Guide.book Page 10 Tuesday, June 10, 2008 10:17 AM
