Agio 966663 User manual

E
MADE IN CHINA
IMPORTANT
PATIO FURNITURE
ASSEMBLY INSTRUCTIONS
RETAIN FOR FUTURE
REFERENCE: READ
CAREFULLY BEFORE
ASSEMBLY
Agio International
1337 Taylor Farm Road, # 100
Virginia Beach, VA 23453
WOVEN CHAISE LOUNGE WITH WHEELS
ITM./ART. 966663
BGF09638
CARE AND MAINTENANCE
FRAMES
Cleaning - Use mild soap and warm water. Do not use abrasive materials, cleansers or
bleach products. Rinse with clean water and dry thoroughly.
Maintenance - Periodically clean and dry thoroughly. Be sure to drain any water
accumulated inside the frames. To thoroughly drain frames, remove foot caps and tilt the
frames, if necessary, to remove all water. This is critical. Water allowed to accumulate
inside the frames and then exposed to sub-freezing temperatures can cause damage to
the frame tubing. Such damage is not covered under warranty. Always clean, drain and
dry thoroughly before storing for the winter. For best results, always store or cover your
furniture when not in use. We recommend commercially available outdoor furniture
covers. Any small nicks or scratches can be covered with a light application of touch-up
paint.
** When cleaning or moving large or heavy items, always have two people work
together. Never drag furniture.
FABRICS (CUSHIONS/SLINGS)
Cleaning - Wipe minor spills immediately. Clean with mild soap, warm clean water and
a soft cloth. Do not use abrasive materials and cleansers. Although fabric has been
treated to resist stains, occasional use of commercially available fabric cleaners may be
necessary. Follow manufacturer's instructions.
Maintenance - The best way to maintain the beauty of cushions and slings is to store
them in a dry area and out of the elements when not in use, or cover with commercially
available outdoor furniture covers.
MAKE SURE YOU HAVE ALL THE PARTS & HARDWARE
AS IDENTIFIED ON THE PARTS LIST
www.agio-usa.com
www.agio-usa.com
MISSING PARTS OR DAMAGED PARTS?
Please call our customer service
or visit our website at
CUSTOMER SERVICE HOURS ARE 9:00AM - 5:00PM
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS AND TO RECEIVE
UPDATED PRODUCT INFORMATION, BE SURE TO REGISTER YOUR
PURCHASE ON OUR WEBSITE AT:
FOR ADDITIONAL SUPPORT ON CARE AND MAINTENANCE OF
YOUR AGIO OUTDOOR FURNITURE PLEASE VISIT OUR WEBSITE
AT: www.agio-usa.com/support
MONDAY - FRIDAY EST.
US & Canada
United Kingdom
:1-888-383-1932 (English and French)
:0-800-092-1653 (English)
Sep-18-2013

Warranty limitations: This warranty is subject to the limitations set forth above. In
addition, this warranty is made to the original purchaser only, and is effective only when
item(s) is purchased from one of our authorized dealers. This warranty is not
transferable. For warranty replacements based on warranty claims submitted within the
first year of purchase, we will pay shipping and handling charges within continental
North America. After the first year, shipping and handling charges are your
responsibility. We will not be responsible for charges associated with shipments outside
continental North America at any time or for any reason.
Warranty exclusions: This warranty is subject to the exclusions as set forth above. In
addition, the following are excluded from coverage under this warranty: any item used
for commercial, contract or any other non-residential purpose; display models or items
purchased "as is"; freight damage; items subject to misuse, abuse, neglect or lack of
proper care and maintenance (including without limitation as provided in any "care and
maintenance guide"); normal wear and tear; damage caused by acts of nature, acts of
force majeure, vandalism, fire or other casualty, or improper assembly; hardware against
corrosion or rusting; purchased or replacement parts; and all plastic parts. Also excluded
are loss of use or time; inconvenience; money; travel; packaging or incidental, special or
consequential damages of any kind. Replacement of defective items as provided herein
shall constitute your sole and exclusive remedy for items which are not as warranted. In
no event shall our responsibility exceed the purchase price of the items found to be other
than as warranted. This warranty is the exclusive statement of your rights with respect
to the defects in the items you have purchased and supersedes any other express
warranty or statement, written or oral, made in connection with the purchase and sale of
such items. When used herein, the term "item" when used in the singular, refers to the
specific item found to be defective, and not to the entire set of which the item is a part.
Some states do not allow exclusion or limitation of incidental or consequential
damages, so the limitation above may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights which vary from state to
state.
*Agio will be responsible for the shipping and handling charges within the North
American continent for the first year for all valid warranty claims. After the first
year, shipping and handling charges are the responsibility of the claimant. We do
not ship outside of the North American continent.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
for compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
SPECIAL WARNINGS
THIS ITEM IS INTENDED FOR OUTDOOR DOMESTIC USE ONLY, NOT
FOR COMMERCIAL USE.
LIMITED 5 YEAR WARRANTY
·Steel Frames. Frame construction is warranted against defects in material and
workmanship for five years from purchase date. Damage to frames or welds
resulting from improper assembly or exposure to water and/or sub-freezing
temperatures is not covered.
LIMITED 1 YEAR WARRANTY
·Finishes. Paint finishes are warranted against peeling, cracking and blistering for
one year from purchase date provided the unit has not been scratched or abraded.
Chips and scratches resulting from normal wear and tear are not covered.
·Fabrics. Fabric and cushions (if applicable) are warranted against separation at
the seams for one year from purchase date. Fading and/or discoloration resulting
from exposure to the elements, oils, spills, fluids, chemicals, or any other cause is
not covered.
·Resin wicker. Resin wicker weave (if applicable) is warranted against separation
and tearing for one year from purchase date. Fading and/or discoloration resulting
from exposure to the elements, oils, spills, fluids, chemicals, or any other cause is
not covered.
Sep-18-2013

WOVEN CHAISE LOUNGE WITH WHEELS
ITM./ART. 966663
IMPORTANT!!
PLEASE READ ENTIRE
INSTRUCTION SHEET
BEFORE ASSEMBLY!!
E
1
QTYORDER PART #
DESCRIPTION
PARTS LIST
A
B
C
D
E
F
G
H
I
J
K
L
M
O
P
Q
R
S
T
Y
V
W
* NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE
SEAT FRAME
1
2
LEG-1
BOLT 12
HW0037
HW0004
WASHER 12
ALLEN WRENCH HW0252 1
ADJUSTMENT BAR
FACTORY ASSEMBLY
ADJUSTMENT BAR
COVER
FACTORY ASSEMBLY HW0509
ADJUSTMENT BAR
WASHER
FACTORY ASSEMBLY HW0510
1/4" X 47 MM BOLT
FACTORY ASSEMBLY HW0684
SLING TUBE CAP
FACTORY ASSEMBLY FC0427
FOOT CAP
FACTORY ASSEMBLY FC0611 2
1
8
2
2
2
SPRING WASHER HW0443 12
BUMPER
FACTORY ASSEMBLY 2
LEG-2
LEG-3
1
1
G0163
5/16" X 35 MM BOLT
FACTORY ASSEMBLY HW0066
1/4" X 30 MM BOLT
FACTORY ASSEMBLY HW0441
1/4" X 45 MM BOLT
FACTORY ASSEMBLY HW0721
Ø8.5 X 1.5 MM WASHER
FACTORY ASSEMBLY
Ø6.5 X 1.0 MM WASHER
FACTORY ASSEMBLY
Ø8.5 X 6.0 MM WASHER
FACTORY ASSEMBLY
Ø8.5 X 2.0 MM WASHER
FACTORY ASSEMBLY
HW0025
6
2
10
4
HW0005
HW0188
2
4
8
SL0298
SL0299
SL0300
SL0301
SL0302
HW0755
Sep-18-2013

1
2E
E
F
G
B
D
C
2X
H
A
B
2X
L
E
F
G
H
Sep-18-2013

3E
2X
O
2
IJK
M
P
Sep-18-2013
If you have any questions, please call our Customer Service Center in the US and Canada at 1-888-383-1932,
9:00am - 5:00pm Monday - Friday, EST. English and French, or you may email [email protected],
United Kingdom at 0-800-092-1653.
