Agio ARK13600 User manual

1
Model No.
ARK13600
5 PIECE WOVEN SEATING SET WITH FIRE
ITM. / ART. 361115
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
WARNING: If the information in this
manual is not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS.
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
If you cannot reach your gas supplier,
call the fire department.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier
equipment.
Installer: Leave these instructions with
consumer.
Consumer: Keep these instructions for
future reference.
WARNING: Improper installation,
adjustment alteration, service, or
maintenance can cause injury or property
damage. Read the installation, operating,
and maintenance instructions thoroughly
before installing or servicing this
equipment.This appliance must be
installed and the gas cylinder stored in
accordance with the regulations in force.
WARNING: For Outdoor Use Only
FOR USE WITH 5KG PATIO GAS
PROPANE CYLINDER (NOT SUPPLIED)
WITH CLIP-ON CONNECTION OR USE
WITH NATURAL GAS AFTER
CONVERSION KIT (SUPPLIED) IS
INSTALLED.
WARNING: Do Not Burn Wood or any
other materials in this firepit.
WARNING:
USE FACTORY APPROVED
REPLACEMENT PARTS AND
ACCESSORIES ONLY. USE OF
UNAPPROVED PARTS OR
ACCESSORIES CAN VOID THE
WARRANTY ON THIS PRODUCT AND
RESULT IN A HAZARDOUS CONDITION.
PLEASE CONTACT US FOR
INFORMATION REGARDING
REPLACEMENT HOSES,
THERMOCOUPLES, ELECTRODES,
IGNITION MODULES, LAVA ROCKS,
LOGS, ETC.
Conditions for use of the product: This
product is for outdoor use only. Not for
co
mm
e
r
c
i
a
l
use
.
WARNING:
A
parasol shall not be placed on
or shall be used with a se
p
arate base.
Questions, Problems, Missing Parts? Before
returning to your retailer, call our customer
service department in the US and Canada at
1-888-383-1932, Monday-Friday, 9 a.m. – 5
p.m Eastern Time. English and French, or you
may Email [email protected]
International Regions: Please visit
http://www.agio-usa.com/service-center/costco
-international
WARNING: It is UNSAFE to use this product
for cookin
g
!
WARNING: Before placing the burner cover
on, make sure the firepit has been shut off
and the burner has completely cooled
down.
IMPORTANT, RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY

2
TABLE OF CONTENTS
Important Safety Information..........................................................................3
Important Information about Propane ............................................................4
Specification...................................................................................................4
Parts Identification List............................................................................... 5-6
Installation.................................................................................................. 7-9
Natural Gas Conversion......................................................................... 10-11
Batteries.......................................................................................................11
Maintenance ................................................................................................12
Lighting Instructions .....................................................................................12
Burner Cover Assembly ...............................................................................12
Troubleshooting Guide.................................................................................13

3
IMPORTANT SAFETY INFORMATION
The appliance area must be kept clear and free from combustible materials, gasoline, and other
flammable vapors and liquids.
Do not use this appliance if any part has been under water. Immediately call a qualified service
technician to inspect the appliance and to replace any part of the control system and any gas control
which has been under water.
Children and adults should be alerted to the hazards of high surface temperatures and kept
at a safe distance to avoid burns or clothing ignition.
Young children should be carefully supervised when they are anywhere near the appliance.
Clothing or other flammable material should not be hung from the appliance, or placed on or
near the appliance.
Any screen or guard removed for servicing an appliance must be replaced prior to operating
the appliance.
Installation and repair should be done by a qualified service person. The appliance should be
inspected before use and at least annually by a professional service person. More frequent
cleaning may be required as necessary. It is imperative that the control compartments,
burners and circulating air passageways of the appliance be kept clean.
Do NOT burn solid fuels in this gas fireplace.
Do NOT ignite the burner before pouring all of the burner media (fire glass) into the burner pan. The
media must be evenly distributed over the burner.
During initial firing of firepit, please stay away from the firepit for 20 minutes as fire media (fire ice)
may pop and hit someone on the face or eyes.
Do NOT ignite or use the firepit if the burner media (fire glass) are wet. Ensure the burner media are
completely dry before igniting as intense heat could cause the media to crack and pop.
It is UNSAFE to use this product for cooking!
CAUTION: The propane gas pressure regulator provided with this appliance must be used. This
regulator is set for an outlet pressure of 37 mbar.
This outdoor gas appliance is not intended to be installed in or on recreational vehicles and/or boats.
Before each use of this gas appliance, open the LP (Liquid Propane) Tank Drawer and inspect the
LP Hose. If there is evidence of excessive abrasion or wear, or the hose is cut, it must be replaced
prior to the gas appliance being put into operation. Use only the replacement hose assembly
specified in this manual. Inspect the burner before each use of the appliance. The burner must be
replaced prior to the appliance being put into operation if it is evident that the burner is damaged.
Use only the burner listed in these instructions.
Keep the fuel supply hose away from any heated surfaces. Check the tubing or the flexible hose (at
least once per month and each time the cylinder is changed). If it shows signs of cracking, splitting
or other deterioration it shall be exchanged for new hose of the same length and of the equivalent
quality; The tubing or the flexible hose must be changed within the prescribed intervals Shut off the
valve at the gas cylinder or the regulator before moving the appliance Be careful, accessible parts
may be very hot. Keep away from young children
Do Not move the appliance during use.

4
IMPORTANT SAFETY INFORMATION ABOUT
PROPANE (LP) GAS
The cylinder supply system must be arranged for vapor withdrawal.
This appliance shall be used only outdoors in a well-ventilated space and shall not be
used in a building, garage, or any other enclosed space.
When this appliance is not in use, the gas must be turned off at the supply cylinder.
Storage of this appliance indoors is permissible only if the cylinder is disconnected and
removed from the appliance.
Cylinders must be stored outdoors in a well-ventilated area out of the reach of
children .Disconnected cylinders must have protective caps installed and must not be
stored in a building, garage, or any other enclosed areas.
Change the gas cylinder in an amply ventilated area, away from any ignition source
(candle, cigarettes, other flame producing appliances).
Check that the regulator seal is correctly fitted and able to fulfill its function.
Do not obstruct the ventilation holes of the cylinder housing.
Use only the type of gas and the type of cylinder specified by the manufacturer.
In case of violent wind particular attention must be taken against tilting of the appliance.
This appliance is for use only with a 5KG Patio Gas Cylinder unless converted for use with
Natural Gas with the provided gas conversion kit. The cylinder must be equipped for a clip-on
regulator. See Figure 1.
Figure1
SPECIFICATIONS
Appliance Category II2H3P Appliance Type A Country GB
INPUT High Fire Low Fire
Propane(G31) 9.0 kW 643 gr per hr. 6.0 kW 429 gr per hr.
Natural Gas (G20) 9.0 kW 3.5 kW
Propane Regulator Pressure 37 mbar 1.50 mm Injector, Marking: 1.50
Natural Gas Inlet Pressure 20 mbar 2.15 mm Injector, Marking: 2.15
Clearances to combustible
surfaces
Sides 24 in / 60.96 cm Top: 72 in / 182.88 cm

5
PART DESCRIPTION PART# QTY
A CONTROL KNOB FP2329 1
B GAS VALVE FP3703 1
C THERMOCOUPLE FP2331 1
D FLEX CONNECTOR FP2332 1
E ELECTRODE FP2333 1
F IGNITION MODULE FP2334 1
G CHAIN FP1736 1
H PROPANE ORIFICE FP2510 1
I LP REGULATOR HOSE FP2025 1
J FOOT CAPS FC0759 4
K “AA” BATTERY HW0905 1
L AIR SHUTTER FP1922 1
M FIRE ICE (TOTAL:7KG) FP1644 1
N NATURAL GAS ORIFICE FP2512 1
O M4 SCREW HW0898 2
P 1/4" X 20 MM SCREW HW0036 12
Q 1/4" X 50 MM SCREW HW0090 4
R 1/4" NUT HW0014 8
S Ø6.5 X 1.0 MM WASHER HW0004 16
T
Ø20 X Ø6.5 X 2.0 MM
WASHER HW0594 8
U HEX BOLT DRIVER HW0252 1
V HEX WRENCH HW0009 1
PARTS IDENTIFICATION LIST
