Agri-Fab LST 42 User manual

Model No.
LST 42
OWNERS
MANUAL
PRINTED IN U.S.A. FORM NO. 48737 (10/02)
CAUTION:
Read Rules or
Sa e Operation
and Instructions
Care ully
• Sa ety
• Assembly
• Operation
• Maintenance
• Parts
42" SNOW THROWER

2
TABLE OF CONTENTS
SAFETY RULES ...................................................................................................................................................................3
FULL SIZE HARDWARE CHART ....................................................................................................................................... 4
CARTON CONTENTS ......................................................................................................................................................... 5
ASSEMBLY INSTRUCTIONS ..............................................................................................................................................6
OPERATION ...................................................................................................................................................................... 18
MAINTENANCE ................................................................................................................................................................. 19
SERVICE AND ADJUSTMENTS ...................................................................................................................................... 20
STORAGE .......................................................................................................................................................................... 21
TROUBLESHOOTING ....................................................................................................................................................... 21
REPAIR PARTS ................................................................................................................................................................ 22
SLOPE GUIDE ................................................................................................................................................................... 27
PARTS ORDERING ............................................................................................................................................ Back Cover
IMPORTANT:
Rear wheel weights and tire chains are required to provide extra traction
and stability when using this snow thrower attachment. These items are
available where you purchased your tractor.
WHEEL WEIGHTS TIRE CHAINS

3
SAFETY
Any power equipment can cause injury i operated improperly or i the user does not understand how to operate
the equipment. Exercise caution at all times, when using power equipment.
•Read this owner's manual care ully and know how
to operate your snow thrower and how to stop the
unit and disengage the controls quickly.
•Never allow children to operate the equipment.
•Never allow adults to operate the equipment
without proper instruction.
•Keep the area o operation clear o all persons,
especially small children, and pets.
•Thoroughly inspect the area where the equipment
is to be used and remove all door mats, sleds,
boards, wires and other oreign objects.
•Disengage all clutches and shi t into neutral be ore
starting engine.
•Do not operate equipment without wearing ad-
equate winter outer garments.
•Wear substantial ootwear which will protect eet
and improve ooting on slippery sur aces.
•Check uel be ore starting the engine. Do not
remove the uel cap or ill the uel tank while the
engine is running or hot. Do not ill the uel tank
indoors. Gasoline is an extremely lammable uel.
•Make sure the snow thrower height is adjusted to
clear the type sur ace it will be used on.
•Do not use the snow thrower without the rear
weight attached to the tractor.
•Never make any adjustments while the engine is
running.
•Always wear sa ety glasses or eye shield during
operation or while per orming and adjustment or
repair.
•Do not place hand or eet near rotating parts. Keep
clear o the discharge opening at all times.
•Use extreme caution when operating on or crossing
gravel sur aces.
•Do not carry passengers.
•A ter striking a oreign object, stop the engine,
remove the wire rom the spark plug and then
thoroughly inspect the snow thrower or damage.
Repair any damage be ore restarting and operating
the snow thrower.
•I the snow thrower starts to vibrate abnormally,
stop the engine immediately and check or the
cause. Vibration is generally a warning o trouble.
•Stop the engine whenever you leave the operating
position, be ore unclogging the snow thrower or
making any adjustments or inspections.
•Take all possible precautions when leaving the unit
unattended. Disengage the attachment clutch lever
or switch, lower the snow thrower, shi t into neutral,
set the parking brake, stop the engine and remove
the key.
•When cleaning, repairing or inspecting, make
certain all moving parts have stopped. Disconnect
the spark plug wire and keep it away rom the plug
to prevent accidental starting.
•Do not run engine indoors except when transport-
ing the snow thrower in or out o the building. Open
the outside doors. Exhaust umes are dangerous.
•Do not clear snow across the ace o slopes.
Exercise extreme caution when changing direction
on slopes. Do not attempt to clear steep slopes.
Re er to the slope guide on page 27 o this manual.
•Never operate the snow thrower without guards,
plates or other sa ety protection devices in place.
•Never operate the snow thrower near glass enclo-
sures, automobiles, window wells, drop o s etc.
without proper adjustment o the snow thrower
discharge angle.
•Never direct discharge at bystanders or allow
anyone in ront o the snow thrower.
•Never run the snow thrower into material at high
speeds.
•Do not overload the machine capacity by attempt-
ing to clear snow at too ast a rate.
•Never operate the machine at high transport speed
on slippery sur aces. Look behind and use care
when backing.
•Watch or tra ic and stay alert when crossing or
operating near roadways.
•Disengage power to the snow thrower when trans-
porting or when not in use.
•Use only attachments and accessories approved by
the manu acturer o the snow thrower (such as
wheel weights, counter weights, cabs etc.)
•Never operate the snow thrower without good
visibility or light.
Look or this symbol to point out important sa ety precautions. It mean--Attention!!
Become alert!! Your safety is involved.

4
HARDWARE PACKAGE CONTENTS
REF. QTY. DESCRIPTION REF. QTY. DESCRIPTION
Q 6 Hex Lock Nut, 1/4"
R 1 Whizlock Nut, 5/16"
S 8 Hex Nut, 5/16"
T 4 Hex Lock Nut, 5/16" (2 pcs. spare parts)
U 9 Hex Lock Nut, 3/8"
V 3 Hairpin Cotter, 1/8"
W 3 Hairpin Cotter, 5/64"
X 1 Hairpin Cotter, 3/32"
Y 2 Shear Bolt (spare parts)
Z 1 Chain, Tensioning
AA 1 Spring
BB 3 Chute Keeper
CC 1 Trunnion
DD 2 Lock Pin
EE 1 Spacer
FF 1 Plastic Cap
GG 2 Nylon Tie
A 4 Hex Bolt, 3/8" x 1"
B 2 Hex Bolt, 5/16" x 1-3/4"
C 6 Hex Bolt, 1/4" x 1"
D 4 Carriage Bolt, 3/8" x 1"
E 2 Carriage Bolt, 5/16" x 1-3/4"
F 2 Carriage Bolt , 5/16" x 1-1/4"
G 2 Carriage Bolt, 5/16" x 1"
H 2 Carriage Bolt, 5/16" x 3/4"
I 4 Shoulder Bolt, 3/8" x 5/8"
J 10 Lock Washer, 3/8"
K 10 Lock Washer, 5/16"
L 7 Washer, 1/4"
M 2 Washer, 5/16"
N 1 Washer, 3/8"
O 2 Washer, 1/2"
P 2 Bowed Washer
ABCDE FGH
Q
M
N
L
I
JK
O
T
U
S
CC
X
Y
V
Z
BB
AA
NOT SHOWN ACTUAL SIZE
SHOWN ACTUAL SIZE
W
Store these two bolts and nuts in a safe
place until needed. (See page 20.)
T
EE GG
DD FF
SPARE PARTS BAG
P
R

5
CARTON CONTENTS
1. Right Hand Side Plate (Stamped "R")
2. Le t Hand Side Plate (Stamped "L")
3. Anti-rotation Bracket
4. Engagement Rod
5. Engine Pulley Keeper
6. Le t Hand Hanger Bracket (Stamped "L")
7. Right Hand Hanger Bracket (Stamped "R")
8. Chute Crank Rod Assembly
9. Support Tube, Crank Rod
10. Li t Handle Tube and Cable
11. Clutch Idler Assembly
12. Cable Bracket
13 Housing Assembly
14. V Belt, Drive
15 V Belt, Auger (Attached to Housing Assembly)
16. Chute and Control Cable Assembly
Hardware Package (Stored inside Plastic Keg)
ASSEMBLY

6
1. Remove all parts and hardware packages rom the
carton. Lay out parts and hardware and identi y using
the illustrations on pages 4 and 5.
NOTE: Not all o the supplied parts and hardware will be
needed or your particular tractor. Unneeded items
may be discarded a ter you have completed assem-
bly.
REMOVAL OF PARTS FROM CARTON
(2) 7/16" Wrenches
(2) 1/2" Wrenches
(2) 9/16" Wrenches
(2) 3/4" Wrenches
(1) Kni e
ADDITIONAL ITEMS REQUIRED
General Purpose Grease
TOOLS REQUIRED FOR ASSEMBLY
ITEMS REMOVED FROM TRACTOR
1. Store all tractor parts that you remove and do not
need to re-use to assemble the snow thrower.
TRACTOR PREPARATION
Be ore per orming these instructions, re er to the Service
and Adjustments section o your tractor owner's manual
or speci ic sa ety instructions.
1. Allow engine, mu ler and exhaust de lector to cool
be ore beginning.
2. Remove any ront or rear attachment which is
mounted to your tractor.
3. Remove the mower deck. Re er to your tractor
owner's manual or removal instructions. Mark all
loose parts and save or re-assembly.
4. Remove the tractor hood and grill assembly. Re er to
your tractor owner's manual or removal instructions.
CAUTION:Be ore starting to assemble
the snow thrower, remove the spark plug
wire(s), set the parking brake and
remove the key rom the tractor ignition.
ASSEMBLY OF SIDE PLATES TO TRACTOR
Right hand (R.H.) and le t hand (L.H.) side o the tractor
are determined rom the operators position while seated
on the tractor.
TRACTORS WITH FRAME MOUNTED FRONT
SUSPENSION BRACKETS (See page 7 or tractors
with axle mounted ront suspension brackets.)
1. Remove two bolts rom each side o the tractor
rame as shown in igure 1.
2. I there is a third bolt on the right side, as shown in
igure 1, remove the nut and washer rom the bolt.
FIGURE 1 RIGHT SIDE VIEW
3. Assemble the R.H. Side Plate (marked "R") to the
now empty holes in the right side o the tractor rame.
Use two 3/8" x 1" hex bolts and 3/8" lock washers as
shown in igure 2. Repeat or the L.H. side.
4. Assemble the whizlock nut onto the third bolt (i
present) on the right side o the tractor.
NOTE: Be sure to reassemble all bolts and nuts
to tractor rame i you remove the side plates.
FIGURE 2 RIGHT SIDE VIEW
3/8" x 1"
HEX BOLT
3/8" LOCK
WASHER
R.H. SIDE
PLATE
5/16" WHIZLOCK NUT
(IF BOLT IS PRESENT IN TRACTOR)
REMOVE BOLTS
FROM THESE HOLES
FRONT
SUSPENSION
BRACKET
REMOVE NUT & WASHER
AND LEAVE BOLT (IF PRESENT)

7
2. Attach the R.H. Side Plate (marked "R") to the right
side o the tractor rame. For the ront hole use a 3/8"
x 1" hex bolt, a 3/8" lock washer, a 1/2" lat washer
and a 3/8" hex lock nut. Use the lat washer as a shim
between the rame and the side plate. For the rear
hole use a 3/8" x 1" hex bolt, and a 3/8" lock washer.
See igure 5. Repeat or the L.H. side.
NOTE: The bolts will cut threads into the ront holes
i that is required.
NOTE: I the side plates are removed rom the
tractor rame, bolts must be assembled back into
the empty holes in the rame.
5. Assemble a shoulder bolt, a 3/8" lock washer and a
3/8" hex lock nut to the bottom hole in each side
plate. See igure 3.
6. Proceed to page 8.
3. Assemble a shoulder bolt, a 3/8" lock washer and a
3/8" hex lock nut to the bottom hole in each side
plate. See igure 6.
FIGURE 5 RIGHT SIDE VIEW
FIGURE 6 RIGHT SIDE VIEW
FIGURE 4 RIGHT SIDE VIEW
FIGURE 3 RIGHT SIDE VIEW
TRACTORS WITH AXLE MOUNTED FRONT
SUSPENSION BRACKETS
1. Remove the bolt rom the hole on each side o the
tractor rame as shown in igure 4.
3/8" SHOULDER BOLT
3/8" HEX LOCK NUT
R. H. SIDE PLATE

3/8" LOCK
WASHER
3/8" LOCK
WASHER
R.H. SIDE
PLATE

1/2" FLAT
WASHER
3/8" x 1"
HEX BOLT
3/8" HEX
LOCK NUT
3/8" SHOULDER BOLT
3/8" HEX LOCK NUT
R. H. SIDE PLATE

3/8" LOCK
WASHER
REMOVE BOLT FROM
THIS HOLE
FRONT
SUSPENSION
BRACKET

8
FIGURE 10 RIGHT SIDE VIEW
INSTALLING HANGER BRACKETS
For better clearance, lower the tractor's suspension
arms using the attachment li t lever.
On Tractors With Foot Rest Brackets (Figure 7)
1. Remove the bolt and nut that asten the L.H. and
R.H. oot rest brackets to the rame. See igure 7.
2. Attach the L.H. Hanger Bracket (marked "L") to the
inside o the tractor rame using two 3/8" x 1"
carriage bolts, 3/8" lock washers and 3/8" hex lock
nuts. The bolt heads go on the inside o the tractor
rame. Repeat or the R.H. side. See igure 7.
FIGURE 8 LEFT SIDE VIEW
FIGURE 7 LEFT SIDE VIEW
On Tractors Without Foot Rest Brackets (Figure 8)
3. Find the empty hole beneath the oot rest. Attach
the L.H. Hanger Bracket (marked "L") to the inside
o the rame using a 3/8" x 1" carriage bolt (head to
inside), a 3/8" lock washer and a 3/8" hex lock nut.
See igure 8. Repeat or the R.H. side.
2. Assemble a shoulder bolt and 3/8" hex lock nut to
the R.H. side o the tractor rame, using the irst
empty hole to the rear o the R.H. hanger bracket.
See igure 10.
FIGURE 9 LEFT SIDE VIEW
INSTALLING SHOULDER BOLTS
All Tractors
1. Remove the bolt, washer and nut which asten the
sway bar bracket to the L.H. side o the tractor
rame. Replace with a shoulder bolt and a 3/8" hex
lock nut as shown in igure 9.
SHOULDER BOLT
3/8" HEX
LOCK NUT
R.H. HANGER BRACKET
BOLT REMOVED
FROM THIS HOLE
3/8" x 1"
CARRIAGE
BOLT
3/8" LOCK
WASHER
3/8" HEX
LOCK NUT
L.H. HANGER
BRACKET
SUSPENSION ARM
3/8" x 1"
CARRIAGE
BOLT
3/8" LOCK
WASHER 3/8" HEX
LOCK NUT
L.H. HANGER
BRACKET
SUSPENSION ARM
BOLT REMOVED
FROM THIS HOLE
SWAY BAR
BRACKET
SHOULDER BOLT
3/8" HEX
LOCK NUT

9
FIGURE 13 RIGHT SIDE VIEW
INSTALLING CLUTCH/IDLER ASSEMBLY
This section covers the installation o the Clutch/Idler
assembly to tractors with attachment clutches that are
either rod operated (p. 9), cable operated (p. 10) or
electric (p. 12). Use the appropriate instructions or
your tractor.
MANUAL (ROD OPERATED) ATTACHMENT CLUTCH
1. Move the attachment clutch lever on the dash
panel to the disengaged (down) position.
2. Screw the trunnion onto the end o the snow
thrower engagement rod as shown in igure 11.
3. Locate the clutch arm (where the mower clutch rod
was connected) underneath the right hand side the
tractor, just to the inside o the suspension arm. If
there is an extension attached to the clutch lever,
the extension, bolt and nut must be removed and
stored with the mower deck.
IMPORTANT: Re-attach the extension to the
clutch lever be ore reinstalling the mower deck.
4. Position the engagement rod to the inside o the
clutch arm and insert the drilled end o the rod
through the arm. Secure with a 5/64" hairpin cotter.
See igure 11.
5. Be sure to li t up the ront end o the engagement
rod (as shown in igure 12) when per orming the
next operation. You can temporarily support the rod
using a rubber band tied to the engine pulley
keeper.
6. Attach the snow thrower's clutch/idler assembly to
the tractor rame by sliding the assembly's notched
arms onto the two shoulder bolts assembled to the
inside o the tractor rame. Li t the ront o the
assembly and attach it to the R.H. and L.H. hanger
brackets using two pivot lock pins and 1/8" hairpin
cotters. See igure 12.
FIGURE 12 RIGHT SIDE VIEW
7. Make sure the attachment clutch lever on the dash
panel is in the disengaged (down) position.
8. Pivot the upper idler arm so that it rests against the
stop bolt and is pointing toward the ront as shown
in igure 13. Screw the trunnion along the threads
o the engagement rod until it is aligned at the ront
end o the idler arm slot. Attach the trunnion to the
slot using the 3/8" lat washer and a 5/64" hairpin
cotter. See igure 13.
9. Remove the engine pulley keeper rom the side o
the tractor rame by removing the washer and nut
that secure the keeper. Attach the new pulley
keeper supplied with the snow thrower, reusing the
original bolt, washer and nut. See igure 13.
NOTE: Some tractors may already be equipped
with an identical pulley keeper.
FIGURE 11 RIGHT SIDE VIEW
PIVOT LOCK PIN
1/8" HAIRPIN COTTER
ENGAGEMENT
ROD
IDLER ARM
5/64" HAIRPIN
COTTER
TRUNNION
STOP BOLT
3/8" FLAT
WASHER
NEW ENGINE PULLEY KEEPER WITH
ORIGINAL BOLT, NUT AND WASHER
ENGAGEMENT ROD
5/64" HAIRPIN
COTTER
TRACTOR’S CLUTCH ARM
SUSPENSION ARM
TRUNNION
REMOVE EXTENSION,
BOLT AND NUT
(IF PRESENT)

10
10. Assemble the short "V" belt onto the engine pulley
and then onto the large pulley on top o the clutch/
idler assembly. The belt must be placed to the
inside o the engine pulley keeper, the idler pulley
and the keeper bolt located beside the large pulley.
See igure 14.
IMPORTANT: Do Not assemble the "V" belt
around the outside o the engine pulley keeper or
the keeper bolt.
Hold this drawing above you while viewing the
Clutch/Idler Assembly from underneath the
tractor. Right and left in the drawing will be the
reverse of the viewer's right and left.
FIGURE 15
FIGURE 14 VIEWED FROM UNDERNEATH
FIGURE 16
CABLE OPERATED ATTACHMENT CLUTCHES
1. Assemble the cable bracket to the clutch/idler
assembly using two 5/16" x 3/4" carriage bolts,
5/16" lock washers and 5/16" hex locknuts. Use the
two ront holes in the cable bracket i your tractor
has a 42" mower deck. Use the two rear holes i
your tractor has a 46" mower deck. See igure 15.
2. Move the attachment clutch lever on the dash panel
to the disengaged (down) position.
3. Lay the clutch/idler assembly beneath the tractor.
4. Attach the tractor's clutch cable to the cable
bracket. Secure the cable housing guide (groove
down) to the cable bracket using the original collar
and retainer spring removed rom the mower deck.
See igure 16.
5. Place a spacer on the welded pin on the idler arm.
Hook the end o the clutch spring over the pin and
secure it with a 1/4" washer and a 5/64" hair cotter
pin. See igure 16.
11. Proceed to page 13.
ENGINE
PULLEY
KEEPER BOLT
IDLER
PULLEY
ENGINE
PULLEY
KEEPER
Left Side
of Tractor
CABLE
BRACKET
5/16" x 3/4"
CARRIAGE BOLT
5/16" LOCK
WASHER
5/16" HEX
LOCK NUT
42"
DECKS
46"
DECKS
5/64" HAIR
COTTER PIN
SPACER
GROOVE
1/4" WASHER
TRACTOR'S
CLUTCH CABLE

11
Hold this drawing above you while viewing the
Clutch/Idler Assembly from underneath the
tractor. Right and left in the drawing will be the
reverse of the viewer's right and left.
FIGURE 18 VIEWED FROM UNDERNEATH
FIGURE 17
6. Remove the engine pulley keeper rom the side o
the tractor rame by removing the washer and nut
that secure the keeper. Attach the new pulley
keeper supplied with the snow thrower, reusing the
original bolt, washer and nut. See igure 17.
NOTE: Some tractors may already be equipped
with an identical pulley keeper.
7. Attach the clutch/idler assembly to the tractor rame
by sliding the notched arms at the rear o the
assembly onto the two shoulder bolts assembled
to the inside o the tractor rame. Li t the ront o
the assembly, itting the sides into the R.H. and
L.H. hanger brackets. Attach the assembly to the
brackets using two pivot lock pins and 1/8" hairpin
cotters. See igure 17.
8. Assemble the short "V" belt onto the engine pulley
and then onto the large pulley on top o the clutch/
idler assembly. The belt must be placed to the
inside o the engine pulley keeper, the idler pulley
and the keeper bolt located beside the large pulley.
See igure 18.
IMPORTANT: Do Not assemble the "V" belt
around the outside o the engine pulley keeper or
the keeper bolt.
8. Proceed to page 13.
ENGINE
PULLEY
KEEPER BOLT
IDLER
PULLEY
ENGINE
PULLEY
KEEPER
Left Side
of Tractor
PIVOT LOCK PIN
1/8" HAIRPIN COTTER
NEW ENGINE PULLEY KEEPER WITH
ORIGINAL BOLT, NUT AND WASHER

12
FIGURE 20 VIEW OF BOTTOM
5. Attach the clutch/idler assembly to the tractor rame
by sliding the notched rear arms o the assembly
onto the two shoulder bolts placed on the inside o
the tractor rame. Li t the ront o the assembly so
that the sides it inside the R.H. and L.H. hanger
brackets. Attach the assembly to the brackets
using two pivot lock pins and 1/8" hairpin cotters.
See igure 21.
ELECTRIC ATTACHMENT CLUTCHES
1. Turn the clutch/idler assembly upside down and
place the extra tensioning chain through the le t
ront hole as shown in igure 19.
FIGURE 19
FIGURE 21 RIGHT SIDE VIEW
2. Hook the loose spring through the end o the
tensioning chain. See igure 20.
3. Hook the other end o the spring onto the bottom o
the bolt and nut which secure the idler pulley to the
upper idler arm. Hold the bolt head and assemble a
3/8" hex lock nut onto the bolt, leaving it loose
enough or the spring to pivot reely between the
two nuts. See igure 20.
4. Attach a 3/32" hairpin cotter to the chain, placing it
in the i th link rom the spring. See igure 20.
CHAIN
(L.H. SIDE)
3/32" HAIR
COTTER PIN
5TH LINK
LEFT
SIDE
3/8" HEX
LOCK NUT
SPRING
RIGHT
SIDE
TENSIONING CHAIN
PIVOT LOCK PIN
1/8" HAIRPIN COTTER

13
ASSEMBLY OF THE SNOW THROWER
1. Place the li t handle into the li t bracket on the right
side o the snow thrower. Fasten the handle to the
bracket using two 5/16" x 1-3/4" hex bolts, 5/16"
lock washers and 5/16" hex nuts. See igure 23.
FIGURE 24 RIGHT SIDE VIEW
FIGURE 23 RIGHT SIDE VIEW
6. Assemble the short "V" belt onto the engine pulley
and then onto the large pulley on top o the clutch/
idler assembly. The belt must be placed to the
inside o the engine pulley keeper, the idler pulley
and the keeper bolt located beside the large pulley.
See igure 22.
7. Place tension on the belt by pulling the le t side
tensioning chain out as ar as the 5/64" hairpin
cotter will allow. Secure the chain in this position by
inserting a 1/8" hairpin cotter through the chain.
See igure 22.
IMPORTANT: Do Not assemble the "V" belt around
the outside o the engine pulley keeper or the
keeper bolt.
Hold this drawing above you while viewing the
Clutch/Idler Assembly from underneath the
tractor. Right and left in the drawing will be the
reverse of the viewer's right and left.
FIGURE 22 VIEWED FROM UNDERNEATH
NOTE: Be sure the li t release cable's plastic covering
remains inserted into the trigger assembly while
per orming the next step.
2. Push the li t handle down into the locked position.
Insert the end o the cable wire into the hole in the
li t rod. Place the threaded itting into the slot in the
li t bracket, with one hex nut above and one hex
nut and the lock washer below the slot. Tighten the
nuts, adjusting them to eliminate slack in the cable
wire. See igure 24. Re er also to the Service and
Adjustments section on page 20 in this manual.
HINT: For easier assembly o the li t release cable,
tilt the snow thrower orward onto the spiral auger.
1/8" HAIRPIN
COTTER
ENGINE
PULLEY
ENGINE
PULLEY
Left Side
of Tractor
ENGINE
PULLEY
KEEPER
KEEPER
BOLT
IDLER
PULLEY
LIFT RELEASE
CABLE
HEX NUT
LOCK
WASHER
HEX NUT
CABLE
WIRE
LIFT
ROD
TRIGGER
ASSEMBLY

14
FIGURE 27 LEFT SIDE VIEW
FIGURE 28 RIGHT SIDE VIEW
9. Coat the top o the ring around the discharge
opening with general purpose grease. See igure 28.
10. Place the discharge chute ( acing orward) onto the
ring. Place the anti-rotation bracket on top o the
chute lange, aligning it with the holes on the right
hand side o the lange. Attach the three chute
keepers (right side up as shown) to the bottom o
the lange using six 1/4" x 1" hex bolts, 1/4" lat
washers and 1/4" hex lock nuts. Tighten carefully
so that the nuts are snug but do not dig into the
plastic chute keepers. See igure 28.
11. Place the plastic cap onto the short end o the anti-
rotation bracket. See igure 28.
12. Position the crank rod spiral so that it does not rub
against the bottoms o the notches in the chute
lange. Tighten the nuts. See igure 27.
13. Check i the crank rod rotates the chute reely. I
not, loosen by 1/4 turn each o the six hex bolts
holding the chute keepers to the chute lange.
14. Secure the control cables to the crank rod support
tube using a nylon tie.
8. Attach the chute crank rod assembly brackets to
the plastic bracket on the le t side o the thrower
housing. Align the chute crank bracket beneath the
rod support bracket and assemble both to the
plastic bracket using two 5/16" x 1" carriage bolts,
5/16" lat washers, 5/16" lock washers and 5/16"
hex nuts. Do not tighten yet. See igure 27.
FIGURE 26 LEFT SIDE VIEW
7. Attach the chute tilt control assembly to the top
side o the crank support tube using two 5/16" x
1-3/4" carriage bolts, bowed washers, 5/16" lock
washers and 5/16" hex nuts. See igure 26.
FIGURE 25 LEFT SIDE VIEW
3. Tilt the snow thrower back down to the ground.
4. Remove the nylon tie which astens the auger drive
belt to the discharge housing, leaving the belt
assembled around the pulleys.
5. Remove the nylon tie which astens the chute crank
rod to the crank rod support tube.
6. Assemble the crank rod support tube to the bracket
on the le t side o the thrower housing using two
5/16" x 1-1/4" carriage bolts, 5/16" lock washers
and 5/16" hex nuts. See igure 25.
5/16" HEX NUT
5/16" LOCK
WASHER
5/16" x 1-1/4"
CARRIAGE BOLT
CRANK ROD
SUPPORT TUBE
CHUTE CRANK ROD
CRANK SUPPORT TUBE
TILT CONTROL HANDLE
5/16" x 1-3/4"
CARRIAGE BOLT
BOWED WASHER
5/16" LOCKWASHER
5/16" HEX NUT
TILT
CONTROL
ASSEMBLY
5/16" HEX NUT
5/16" LOCK
WASHER
CHUTE CRANK
BRACKET
5/16" FLAT
WASHER
CHUTE
CRANK
ROD
ROD
SUPPORT
BRACKET
5/16" x 1"
CARRIAGE BOLT
CHUTE KEEPER
ANTI-ROTATION
BRACKET
1/4" HEX
LOCK NUT
1/4" FLAT
WASHER
1/4" x 1"
HEX BOLT
PLASTIC CAP
GREASED
SURFACE
FLANGE

15
NOTE: An additional person's help may be required to
mount the snow thrower to the ront o the tractor.
1. Place the tractor and snow thrower on a lat, level
sur ace so that the tractor can be rolled orward to
attach the snow blower.
2. Remove the Attachment Pin rom the snow thrower.
3. Extend the belt out behind the snow thrower,
making sure the belt is still looped over the top o
the large drive pulley and underneath the two idler
pulleys. The "V" side o the belt must be seated in
the grooves o all three pulleys.
4. Roll the tractor up behind the snow thrower, center-
ing it between the snow thrower's mounting plates.
5. Raise the rear o the snow thrower by li ting up on
the li t handle until the notches in the mounting
plates align with the shoulder bolts in the tractor's
side plates. Guide the bolts into the notches.
6. To ease the assembly o the auger drive belt, delay
the installation o the attachment pin shown in
igure 29 until you have assembled the belt as
instructed or igures 30 and 31.
ATTACHING SNOW THROWER TO TRACTOR INSTALLING THE AUGER BELT
7. The auger belt comes preassembled to the pulleys
on the snow thrower housing. Make sure the belt
passes over the top o the auger pulley and then
twists 1/4 turn to pass underneath each side idler
pulley. The "V" side o the belt must mate with the
grooves o the pulleys. See igure 30.
FIGURE 31 VIEWED FROM UNDERNEATH
Hold this drawing above you while viewing the
Clutch/Idler Assembly from underneath the
tractor. Right and left in the drawing will be the
reverse of the viewer's right and left.
8. Push the li t handle down to increase slack in the
belt (attachment pin must irst be removed).
9. Remove the 1/8" hairpin cotter that secures the end
o the idler arm spring to the right side o the clutch
idler assembly. Swing the idler arm to the le t side.
See igure 31.
10. Place the auger belt around the rear pulley and
between the two pulleys on the idler arm. The "V"
side o the belt must be seated in the grooves o
the "V" pulleys. See igure 31.
FIGURE 30
FIGURE 29 RIGHT SIDE VIEW
IDLER
ARM
REAR
PULLEY
LEFT SIDE
OF
TRACTOR

1/8" HAIRPIN
COTTER
(Removed rom
end o spring)
ATTACHMENT PIN
1/8" HAIRPIN
COTTER
SHOULDER
BOLT
SIDE
PLATE
MOUNTING PLATE
IDLER
PULLEY
AUGER PULLEY TWIST
1/4 TURN
TWIST
1/4 TURN
IDLER
PULLEY

16
INSTALLING THE ATTACHMENT PIN
11. Li t the ront o the snow blower to align the holes
in the mounting plates and the side plates. From
the le t side o the tractor install the attachment pin
through the holes, securing it with the 1/8" hairpin
cotter. Re er back to igure 29 on page 15.
SETTING THE AUGER BELT TENSION
12. Pull the tensioning chain until the end o the spring
is pulled through the hole in the side o the Clutch/
Idler assembly. Install the 1/8" hairpin cotter
through the end o the spring, securing it on the
outside o the Clutch/Idler assembly. See igure 32.
IMPORTANT: For correct belt tension, the 1/8"
hairpin cotter must attach to the end o the spring,
not to the chain.
Hold this drawing above you while viewing the
Clutch/Idler Assembly from underneath the
tractor. Right and left in the drawing will be the
reverse of the viewer's right and left.
FIGURE 32 VIEWED FROM UNDERNEATH
CHECKLIST
Before you operate your snow thrower, please
review the following checklist to help ensure that
you will obtain the best performance from your
snow thrower.
1. All assembly instructions have been completed with
all bolts and nuts properly tightened.
2. Check the engine belt and the auger belt. Make
sure they are routed properly around pulleys and
inside all belt keepers.
3. Check discharge chute or proper rotation.
4. Check operation o tilt control or upper chute.
5. Veri y that the li t handle will lock into and release
rom the raised transport position. (Re er to the
Service and Adjustments section.)
6. Check skid shoe adjustment. (Re er to the Service
and Adjustments section.)
Operating instructions begin on page 17.
END OF
SPRING
1/8"
HAIRPIN
COTTER
LEFT SIDE
OF
TRACTOR
FLAT
PULLEY

17
OPERATION
KNOW YOUR SNOW THROWER
Read this owner's manual and safety rules before operating your snow thrower.
Compare the illustration below with your snow thrower to amiliarize yoursel with the various controls and their locations.
CHUTE TILT HANDLE Pivots the Upper Chute up or
down to control the angle and distance o discharge.
CRANK ROD Rotates the Lower and Upper Chutes to
control the direction o discharge.
LIFT HANDLE Used to li t or lower the snow thrower
to transport or operating position.
LIFT RELEASE TRIGGER Releases the lock which
holds the snow thrower in the transport position
UPPER AND LOWER DISCHARGE CHUTE Controls
direction and height o snow discharge.
SCRAPER PLATE Replaceable plate that absorbs
wear and impact rom contact with ground.
SKID SHOE Controls amount o clearance between
the scraper plate and the ground.
SPIRAL AUGER, R.H. & L.H. Feed snow to the
impeller an at the center o the housing.
BEFORE STARTING
1. Use the end o assembly checklist to veri y that all
instructions have been properly completed.
2. Make sure the skid shoes are adjusted to maintain
adequate ground clearance between the snow
thrower and the type o sur ace to be cleared.
(Re er to the Service and Adjustments section.)
3. Make sure the tractor engine has the correct oil or
winter operation (SAE 5W-30). Re er to tractor
owner's manual.
HOW TO START YOUR SNOW THROWER
1. The tractor should be sitting with the engine
running at ull throttle. Move the attachment clutch
to the engaged position, starting the snow thrower
be ore the tractor's transmission is engaged.
HOW TO STOP YOUR SNOW THROWER
1. To stop the snow thrower, disengage the tractor's
attachment clutch lever or manual clutches or the
clutch switch or electric clutches. Re er to your
tractor owner's manual.
CAUTION: Never direct discharge
towards bystanders or windows. Do not
allow anyone in ront o unit.
CONTROLLING SNOW DISCHARGE
1. To control the direction snow is thrown, the dis-
charge chute has 180 degrees o rotation. Turn the
crank rod clockwise to rotate the chute to the right.
Turn the crank rod counterclockwise to rotate the
chute to the le t.
2. To control the distance snow is thrown, the upper
section o the discharge chute pivots up and down.
Push orward on the chute tilt handle to pivot the
chute down, decreasing the distance snow is
thrown. Pull back on the handle to pivot the chute
up, increasing the distance snow is thrown.
HOW TO USE YOUR SNOW THROWER
LIFT HANDLE
LIFT RELEASE TRIGGER
CRANK ROD
CHUTE TILT HANDLE
UPPER CHUTE
LOWER CHUTE
SPIRAL AUGERS, R.H. & L.H.
SKID SHOE
SCRAPER PLATE

18
RAISING AND LOWERING
3. To raise, push down on the li t handle until the
snow thrower locks in the raised transport position.
4. To lower, push down slightly on the li t handle and
pull the trigger. With the trigger pulled, slowly lower
the snow thrower until it reaches the ground.
CAUTION: Do not operate the snow
thrower without rear wheel weights and
tire chains attached to the tractor to
provide extra traction and stability.
DANGER: Shut o engine and
disengage snow thrower be ore
unclogging discharge chute. Unclog
using a wooden stick, not your hands.
REMOVING SNOW
Snow removal conditions vary greatly rom light lu y
snow all to wet heavy snow. Operating instructions
must be lexible to it the conditions encountered. The
operator must adapt the lawn tractor and snow thrower
to depth o snow, wind direction, temperature and
sur ace conditions.
5. Be ore beginning operation, thoroughly inspect the
area o operation and remove all door mats, sleds,
boards, wires and other oreign objects.
6. The spiral auger speed is directly related to engine
speed. For maximum snow removal and discharge,
maintain high engine r.p.m. ( ull throttle). It is
advisable to operate the lawn tractor at a slow
ground speed (1st gear) or sa e and e icient snow
removal.
7. In deep, dri ted or banked snow it will be necessary
to use ull throttle and a slow ground speed (1st
gear). Drive orward into the snow, depress the
tractor's clutch-brake pedal and allow the spiral
auger to clear the snow. Repeat this method until a
path is cleared. On the second pass, overlap the
irst enough to allow the snow thrower to handle
the snow without repeated stopping and starting o
orward motion.
8. In extremely deep snow, raise the snow thrower
rom the ground to remove the top layer and drive
orward only until the tractors ront tires reach the
uncleared bottom layer o snow. Depress the
tractor's clutch-brake pedal and allow the spiral
auger to clear the snow. Reverse the tractor and
lower the snow thrower to the ground. Drive the
tractor orward until the snow again becomes too
deep. Repeating this process into and out o dri ts
will eventually clear even the deepest o snow
piles.
9. I the snow thrower becomes clogged with snow or
jammed with a oreign object, disengage the snow
thrower immediately and shut o the tractor engine.
Unclog the snow thrower be ore resuming opera-
tion.
OPERATING TIPS
1. Discharge snow down wind whenever possible.
2. To help prevent snow rom sticking to the snow
thrower, allow the snow thrower to reach outdoor
temperature be ore using it. A light coat o wax may
also be applied to the inside sur ace o the snow
thrower housing and discharge chute.
3. Use tire chains to improve traction.
4. Use rear wheel weights to improve traction.
5. Be ore the irst snow all, remove all stones, sticks
and other objects which could become hidden by
the snow. Permanent obstacles should be marked
or visibility.
6. Overlap each pass slightly to assure complete
snow removal.
LUBRICATION
1. Oil all pivot points on the snow thrower.
2. Oil the pivot points o the two idler arms on the
clutch/idler assembly.
3. Apply penetrating oil to the control cables o the
discharge chute.
4. Apply a good grade o spray lubricant to the trigger
assembly and the chute tilt control assembly.
CHECK SCRAPER AND SHOES FOR WEAR
(Refer to figures 33 and 34 on page 19.)
5. The scraper plate and skid shoes on the bottom o
the snow thrower are subject to wear. To prevent
damage to the spiral auger housing, replace plate
and shoes be ore wear is excessive.
Service Dates
Check or loose asteners X
Check scraper and shoes or wear X X
Cleaning X
Lubrication Section X
MAINTENANCE SCHEDULE
Fill in dates as you
complete regular service.
Be ore each use
A ter each use
Every season
Be ore storage
MAINTENANCE
CUSTOMER RESPONSIBILITIES
Read and ollow the maintenance schedule and the maintenance procedures listed in this section.

19
SERVICE AND ADJUSTMENTS
CAUTION:Be ore servicing or adjusting
the snow thrower, shut o the engine,
remove the spark plug wire(s), set the
parking brake and remove the key rom
the tractor ignition.
FIGURE 34FIGURE 33
REPLACING AUGER BELT
1. Disengage the tractor's attachment clutch.
2. Lower the snow thrower to the ground.
3. Remove the attachment pin.
4. Lock the snow thrower's li t handle in the down
position to decrease belt tension.
5. Release the spring tension rom the auger belt idler
arm on the bottom o the clutch/idler assembly.
6. Remove the auger drive belt rom the clutch/idler
assembly and rom the spiral auger housing.
7. Install new belt over top o large auger drive pulley
and under the two side idler pulleys. Twist the belt
1/4 turn to seat the "V" o the belt in the groove o
each idler pulley. Re er to igure 30 on page 15.
8. Assemble the belt onto the clutch/idler assembly.
Re er to igures 31 and 32 on pages 15 and 16.
SKID SHOE ADJUSTMENT
1. The skid shoes are mounted on each side o the
spiral auger housing. They regulate the distance
the scraper plate is raised above the plowing
sur ace. When removing snow rom a gravel
driveway or and uneven sur ace, it is advisable to
keep the scraper plate as high above the sur ace
as possible to prevent possible damage to the
spiral auger. On blacktop or concrete sur ace, keep
the scraper plate as close to the sur ace as pos-
sible.
2. Raise the snow thrower o the ground and place a
block under each end o the scraper plate. Loosen
the six hex nuts securing the skid shoes to the
housing. Adjust the skid shoes up or down and
retighten the nuts securely. Adjust both skid shoes
to the same height to keep the housing and the
scraper plate level. See igure 33.
LIFT RELEASE CABLE ADJUSTMENT
1. I the li t rod does not lock the snow thrower
securely in the transport position, loosen the upper
hex nut on the li t bracket a ew turns and tighten
the lower hex nut. Re er to igure 24 on page 13.
2. I the li t rod ails to unlock completely to lower the
snow thrower, loosen the lower hex nut on the li t
bracket a ew turns and tighten the upper hex nut.
Re er to igure 24 on page 13.
CLUTCH DISENGAGEMENT ADJUSTMENT
(Only tractors with clutch engagement rods.)
I the spiral auger on the snow thrower does not stop
when the attachment clutch lever on the tractor is
disengaged, then adjustment is necessary. Proceed as
ollows. Re er back to igure 13 on page 9.
1. Place the attachment clutch lever in the disen-
gaged position.
2. Remove the hairpin cotter rom the engagement
rod trunnion and li t the trunnion out o the hole in
the idler arm.
3. Screw the trunnion a ew turns towards the ront
end o the rod.
4. Replace the trunnion into the hole in the idler arm
and secure it with the hairpin cotter.
Check the operation o the snow thrower. I the
spiral augers still do not stop, repeat the above
steps until the augers stop when the attachment
clutch lever is placed in the disengaged position.
SPIRAL AUGERS
1. The spiral augers are secured to the auger sha t
with two shear bolts and hex lock nuts. I you hit a
oreign object or i ice jams the augers, the snow
thrower is designed so that the bolts will shear.
2. I the augers will not turn, check to see i the shear
bolts have sheared. See igure 34. Two replace-
ment shear bolts and hex lock nuts have been
provided with the snow thrower. For uture use
order part number 710-0890A shear bolt and
number 43064 hex lock nut.

20
PARTS TO REMOVE AT END OF SEASON
1. Remove the drive belt rom the engine pulley.
2. Remove the clutch/idler assembly. (The two hanger
brackets and the two shoulder bolts may be le t
attached to the tractor rame.)
3. Remove the engine pulley keeper and replace it
with the tractor's original engine pulley keeper (rod
or cable operated attachment clutches only).
4. Remove the engagement rod rom the tractor's
clutch arm (rod operated attachment clutches only).
See igure 11 on page 9.
5. I a ront mounted attachment is to be used,
remove the side plates rom the tractor. Be sure to
assemble bolts back into the empty holes in the
tractor rame. See igures 1 and 2 on page 6.
STORAGE RECOMMENDATIONS
1. Lower the snow thrower to the ground.
2. Remove the snow thrower rom the tractor.
3. Clean the snow thrower thoroughly. Wash o any
salt deposit which may have dried on the thrower
and housing.
4. Any bare metal that has become exposed should
be painted or coated with a light oil to prevent rust.
5. Store in a dry place.
REMOVING THE SPIRAL AUGER HOUSING
1. Lower the snow thrower to the ground.
2. Remove the attachment pin. See igure 29 on page
15.
3. Lock the snow thrower's li t handle in the down
position to decrease belt tension.
4. Release the spring tension rom the auger belt idler
arm on the bottom o the clutch/idler assembly.
5. Remove the auger drive belt rom the clutch/idler
assembly. See igure 31 on page 15.
6. Pull the spiral auger housing assembly o o the
tractor.
CAUSEPROBLEM CORRECTION
Clogged discharge chute
Spiral augers don't turn
Snow thrower stalls tractor engine
TROUBLESHOOTING
STORAGE
1. Upper or lower V belt too loose 1. Increase tension on V belt
2. Upper or lower V belt broken 2. Replace V belt
3. Shear bolts are sheared. 3. Replace shear bolts
1. Tractor ground speed too ast 1. Use lower tractor gear
2. Tractor throttle set too low 2. Increase to ull throttle
3. Snow too deep 3. Raise the snow thrower
4. Snow melts during contact with 4. Allow snow thrower to cool to
the snow thrower outdoor temperature be ore using
Front wheels slide instead o steering
Snow thrower rides up over snow
1. Object jammed in spiral auger 1. Stop engine, disengage the snow
thrower clutch and clear the auger
2. Hard or heavy snow 2. Increase to ull throttle and
decrease ground speed
Not enough traction at ront wheels 1. Increase scraper plate clearance
by lowering skid shoes
2. Pull down on li t handle to
increase weight on ront wheels
1. Tractor ground speed too ast 1. Reduce ground speed
2. Bottom snow is icy or hard packed 2. Lower the skid shoes so that ront
o skid shoe is lower than the rear
