2agria Sweeper 7100 Cleanstar premium
Symbols, Name Plate
Please complete:
Machine Type No......................
ID/Machine No.....................
......................................................
Engine Type: ............................
Engine No.............................
Date of Purchase: ......................
For name plate,
refer to p3/fig.A/5.
For engine type and number,
refer to p42/fig. C/7.
Please state these data when order-
ing spare parts to avoid wrong deliv-
eries.
Only use original agria spare
parts!
Specifications, figures, and dimen-
sionsstatedintheseinstructionsare
notbinding.Noclaimscanbederived
from them. We reserve the right for
improvements without changing
these instructions.
Amount of delivery:
l Operating instructions
l Base machine
l Handlebars with attachment bolts
l Tool kit
Symbols
Warning – Danger
Important information
Choke
Fuel
Oil
Engine Start
Engine Stop
Brush drive
Wheel drive
Wheel drive engaged
Wheel drive disengaged
slow
fast
Open (unlocked)
Closed (locked)
Forward
Reverse
èrefer to operating instruc-
tions ...
è- Serviceç= contact
your agria-workshop

agria Sweeper 7100 Cleanstar premium 3
Fig. A
Designation of Parts
25
1 2
467 3
8
910
111213
14 15 16
17
18 19
20
21
23
24
5

4agria Sweeper 7100 Cleanstar premium
Designation of Parts
Figure A
1 Pawl for clutch lever
2Clutch lever for brush drive engagement
3Safety circuit lever
4 Twist grip for adjustment of driving speed and travelling direction
5Name plate
6Speed control lever
7Rod that pivots the implement
8Height adjustment crank
9Protective hood
10 Notched plate to lock the rod
11 Main guard
12 Coupling pin for implement attachment (optional)
13 Extension guard
14 Rotary brushes
15 Transmission (Hydrostat)
16 Wheel dog
17 Drive wheel
18 V-belt housing cover (rear)
19 V-belt housing
20 Engine base plate
21 Clamping lever for handlebars height adjustment
23 Engine
24 Handlebars
25 Dial for manual speed adjustment of rotary brushes

agria Sweeper 7100 Cleanstar premium 5
1
3
5
6
4
2
Index
Recommendations
Lubricants, Anti-Corrosive Agents .. 6
Fuel ................................................... 6
Maintenance and Repair .................. 6
Unpacking and Assembly ........... 7
Designation of Parts ................ 3, 41
1. Safety Instructions............... 8
Due Use ........................................... 8
Explanation of Warning Signs ........ 12
Explanation of Signs....................... 12
2. Specifications
Sweeper ......................................... 13
Engine............................................. 14
3. Devices and Operating
Elements
3.1 Engine.................................... 15
3.2 Speed Control Lever ............. 15
3.3 Safety Circuit Function.......... 16
3.4 Wheel Drive ........................... 17
3.5 Brush Drive ........................... 17
3.6 Handlebars ............................ 18
Handlebars Height Adjustment18
3.7 Drive Wheels ......................... 18
3.8 Snow Chains ......................... 18
3.9 Wheel dogs............................ 18
3.10 Attaching the Rotary Brushes20
3.11 Sweeping Height Adjustment 20
3.12 Side Adjustment .................... 20
3.13 Brush Speed.......................... 20
3.14 Implements ............................ 21
4. Commissioning and
Operation
4.1 Commissioning the Machine.22
4.2 Starting the Engine ................ 23
4.3 Shutting off the Engine .......... 24
4.4 Danger Zone ......................... 25
4.5 Sweeping ............................... 26
4.6 Snow Clearance.................... 26
5. Maintenance
Machine .......................................... 27
5.1 Hydrostat............................... 27
V-Belt ..................................... 27
Driving chains ....................... 27
5.2 Rotary Brushes Worm Gear 28
5.3 Brush drive ............................ 28
5.4 Drive Wheels ......................... 28
5.5 Wheel Shaft ........................... 28
5.5 Sweeper ................................ 29
5.6 Adjusting Spindle ................... 29
5,8 Safety Circuit Function.......... 16
Engine
5.9 Checking the Engine Oil Level 30
5.10 Changing the Engine Oil ....... 30
5.11 Air Filter ................................. 31
5.12 Fuel System .......................... 32
5.13 Spark Plug ............................. 33
5.14 Cooling Fan Grille .................. 33
5.15 Air Cooling System................ 33
5.16 Governor ............................... 34
5.17 Exhaust System.................... 34
5.18 Speed Control ....................... 34
5.19 Carburetor settings ............... 34
5.20 General.................................. 35
5.21 Cleaning................................. 35
5.22 Storage .................................. 36
Lubrication Chart , Electrical
Wiring ...................................... 37
6.Troubleshooting .................. 38
Inspection and
Maintenance Chart................. 40
Designation of Parts
Note fold-out pages!
Fig. A ......................................... 3
Fig. C Honda GCV160 Engine 41
Varnishes and Wear Parts ..... 41
Conformity Declaration ......... 43

6agria Sweeper 7100 Cleanstar premium
Lubricants and
Anti-Corrosive Agents:
Use the lubricants specified for engine
and gearbox (see “Specifications”).
We recommend using Bio-lubricating
oil orBio-lubricating grease for“open”
lubrication points or nipples (as speci-
fied in the operating instructions).
We recommend using Bio-slushing oil
to preserve machines and attachments
(do not apply on painted covers). You
can brush or spray the oil.
Anti-corrosive agents are environmen-
tally friendly and degrade fast.
Using ecologically safe Bio-lubricants
and Bio-anti-corrosives, you contribute
to environmental protection and to the
wellbeing of humans, animals and
plants.
Fuel
This engine runs smoothly on
commercial unleaded regular and
supergrade petrol (including E10).
Do not add oil to petrol.
If, for environmental reasons, you
use unleaded petrol, make sure the
fuelisdrainedcompletelywhenshut-
ting down the engine for more than
30 days.This is to prevent resin resi-
duefromdepositinginthe carburetor,
fuel filter, and tank. Or add a fuel
stabilizer to the fuel.
For further instructions see “Engine
Preservation”.
Maintenance and
Repair:
The trained mechanics of your agria
workshop expertly carry out any
maintenance and repair work.
Youshouldonlycarryout majormain-
tenance work and repairs on your
own, if you have the proper tools and
knowledge of machines and internal
combustion engines.
Do not hammer against the flywheel
with a hard object or metal tools as it
might crack and shatter in operation,
causing injuries and damage.Only
use suitable tools to pull off the
flywheel.
Recommendations

agria Sweeper 7100 Cleanstar premium 7
Unpacking and Assembly
Unpacking
l Open the box top.
l Cut all corners open and
fold down the sides.
1. Attaching the handlebars
Raise the handlebars
l Unscrew the clamping lever (21) until
the notches are exposed
l Pivot the handlebars (24) to the rear
up to correct working height
è page 18
l Re-tighten clamping lever (21).
Attach cables and electric lines with
the three clips (28) to the handlebars in
accordance with fig.
2. Fitting the protective hood (9)
with spacer (D), crank (8) and linch pin
(K)
3. Fitting the drive wheels
l Coat the wheel shaft on both sides
with a little grease
l fit spacer tube and drive wheels on
both sides - pay attention to direction of
arrow for cleated tyres
l Mount wheel dog with screw (2) and
securing nut - wheel dog settings
è page18.
4. Mounting extension guards
l Attach an extension guard to either
side of the main guard (11), using three
hexheadboltsandlockingnutsforeach
guard.
5. Attaching the rotary brushes
See page 19 for details
6. Starting up
See page 22 for details
1.
3.
2.
4.
5.
9
24
21
8
KD
28

8agria Sweeper 7100 Cleanstar premium
Before starting the engine, read the op-
erating instructions and note:
Warning
Thissymbolmarks all paragraphs which
affectyoursafety.Passallsafetyinstruc-
tions to other users and operators.
Due Use
The sweeper, including the implements
approved by the manufacturer, is
constructed for normal use in cleaning
park and pathway areas, for gathering
and sweeping up loose dirt, and may
also be used as a snow-clearing
machine after it has been fitted with
suitable brushes and a rake blade (due
use).
Any other type of operation is consid-
ered undue.The manufacturer is not li-
able for any damages resulting from
undue use, for which the risk lies with
the user alone.
Due use includes compliance with
manufacturer’s instructions on opera-
tion, maintenance and repair.
Any unauthorized changes to the
sweeper render manufacturer liability
null and void.
General Instructions on
Safety and Accident
Prevention
Basic Rule:
The standard accident prevention regu-
lations must be adhered to, as well as
all other generally accepted rules gov-
erning operational safety, occupational
health and road traffic regulations.
For drives on public roads, the national
traffic code applies.
Accordingly, checkthesweeperforroad
and operational safety each time you
take up operation.
Only persons familiar with the sweeper
and instructed on the hazards of opera-
tion are allowed to use, maintain and
repair the sweeper.
Teenagers of 16 years or younger may
not operate the sweeper!
Only work in good light and visibility.
Operator’s clothes should fit tight.Avoid
wearing loose fitting clothes.Wear solid
shoes.
Note the warning and instruction signs
onthesweeperforsafe operation.Com-
pliance is for your own safety.
When transporting the sweeper on ve-
hicles or trailers outside the area to be
sweeped, ensure that the engine is
turned off and the wheel dogs are
engaged.
Careful with rotating tools – keep at a
safe distance!
Beware of coasting tools. Before you
start any maintenance or repair on
them, wait until tools have come to a
complete stop.
1. Safety Instructions
1

agria Sweeper 7100 Cleanstar premium 9
Riding on the machine during operation
is not permitted.
Implements and their weight affect the
driving, steering, braking, and tip-over
characteristics of the sweeper. There-
fore, ensure steering and braking func-
tions are sufficient. Match operating
speed to conditions.
Donot changesettingsofgovernor.High
engine speed increases risk of acci-
dents.
Working Area and Danger
Zone
The user is liable to third parties work-
ing within the sweeper’s working range.
Staying in the danger zone is not per-
mitted.
Check the immediate surroundings of
the sweeper before you start it. Watch
out for children and animals.
Careful! Dirt and stones may get air-
borne duringsweeping.People and ani-
mals must keep out of this area.Watch
outforvehicles,windowpanesandother
objects to avoid damage.
Before you start work, clear the area
from any foreign object. During opera-
tion,alwayswatchoutforfurtherobjects
and remove them in time.
For operationin enclosed areas,ensure
that a safety distance is kept to enclo-
sures to prevent damage to tools.
Operation and Safety
Devices
BeforeYou Start the Engine
Become familiar with the devices and
operating elements and their functions.
Above all, learn how to turn the engine
off quickly and safely in an emergency.
Ensure that all protective devices are
mounted and positioned to provide pro-
tection.
Starting the Engine
Donotstartenginein closed rooms.The
carbon monoxide contained in the ex-
haust fume is extremely toxic when in-
haled.
Before you start the engine set all oper-
ating elements to neutral or idling posi-
tion.
For starting the engine, do not step in
frontof thesweeperandthe implement.
Operation
Neverleavetheoperator’spositionat the
handlebars while sweeper is at work.
Never adjust the operating handles dur-
ing work – danger!
Duringoperationthe operatormustkeep
at a distance as defined by the handle-
bars, especially when turning the ma-
chine.
Riding on the machine during operation
or in transport is not permitted.
1. Safety Instructions
1

10 agria Sweeper 7100 Cleanstar premium
If clogging occurs in the brushes or in
the implement, turn off the engine and
cleanthebrushes or the implement with
an appropriate tool.
In case of damage to the sweeper or to
the implement, immediately turn off the
engine and have it repaired.
If steering causes problems, immedi-
atelybringthesweeperto ahaltandturn
it off.Have the malfunction removed
without delay.
To prevent the sweeper from sliding on
slopes, make sure it is secured by an-
other person using a bar or a rope.This
person must be located at a higher po-
sition than the vehicle and at a safe dis-
tance from the attachment at work.
If possible, always work horizontally on
the slope.
End of Operation
Never leave the sweeper unattended
with the engine running.
Before you leave the sweeper, turn off
the engine.
Secure sweeper against unauthorized
use - remove spark plug connector.
Implements
Only mount implements with the engine
and the implement drive switched off.
Always use appropriate tools and wear
gloves when changing implements and
parts thereof.
For mounting and dismounting imple-
ments bring stands into proper position
and ensure stability.
Secure sweeper and implements
against rolling off (wheel chocks).
Beware of injuries while coupling imple-
ments.
Mountimplementsas specified and only
couple at specified points.
Securesweeperandimplementagainst
unauthorized use and rolling off when
you leave the machine.If necessary, in-
stall transport or security devices and
secure.
Weights
Always fit weights onto appropriate
weight mounting devices.
Snow Clearing
Ensure snow dozer is mounted cor-
rectly! Wear slip-proof shoes.
Whenpivotingthesnowdozerwatchout
for crush and shear points.Adjust work-
ing speed to conditions.Operator may
be injured when the machine hits an
obstacle.
1. Safety Instructions
1

agria Sweeper 7100 Cleanstar premium 11
Maintenance and
Cleaning
Never carry out any maintenance or
cleaning with the engine running.
Before you work on the engine, always
remove spark plug connector (petrol
engine only).
Check regularly and, if necessary, re-
place all guards and tools subject to
wear and tear.
Keep sweeper and implement clean to
avoid risk of fire.
Check nuts and bolts regularly for tight
fit and re-tighten, if necessary.
Aftermaintenanceandcleaning, ensure
that you re-install all safety devices and
guards and adjust them properly.
Only use original agria spare parts.All
other commercial spare parts must cor-
respondtoqualityand technical require-
ments specified by agria.
Storage
It is not allowed to store the sweeper in
rooms with open heating.
Never park the sweeperinclosedrooms
with fuel left in tank. Fuel vapours are
hazardous.
Engine, Fuel, and Oil
Never let the engine run in closed
rooms. Extreme danger of intoxication!
For the same reason, also replace
damaged exhaust parts immediately.
Caution with hot engine parts!
The exhaust and other engine parts
become very hot, if the engine runs and
immediately after turning off. Hold for
sufficient distance from hot surfaces
and keep children away from the
running engine.
Becarefulwhendealingwithfuel.Great
danger of fire! Never refill fuel close to
open fire, inflammable sparks or hot
engine parts.Do not refill fuel in closed
rooms.Do not smoke when refilling!
Refill only with the engine switched off
and cooled down.
Do not spill any fuel, use a proper filling
device.
Incase of fuel spillage,pullthe sweeper
away from the spillage before you start
the engine.
Make sure fuel is of specified quality.
Store fuel in approved cans only.
For safety reasons the petrol tank and
fuel cap should be replaced regularly.
Store anti-corrosive agents and stabi-
lizing liquids out of reach of children. If
sickness and vomitingoccur, see a doc-
tor.If fuelhascontactedeyes,rinsethem
thoroughly, avoid inhaling of vapours.
Read and observe enclosed instruc-
tions.
1. Safety Instructions
1

12 agria Sweeper 7100 Cleanstar premium
Before you dispose of opened and
seemingly empty pressurised tins (e.g.
ofassist-startingliquids)makesurethey
are completely empty.Empty them in
ventilated places safefrom spark forma-
tion or flames.If necessary, dispose of
tins in hazardous waste deposits.
Be careful when draining hot oil, dan-
ger of burns.
Makesure oilisofspecifiedquality.Stor-
age is in approved cans only.
Disposeofoil,greases,andfilterssepa-
rately and properly.
Tyres and
Tyre Air Pressure
When working on tyres, make sure
sweeperisparkedproperlyandsecured
against rolling off.
Any repairs are to be carried out by
trained mechanics only and with the
appropriate tools.
Regularly check tyre air pressure.
Excessive pressure may cause bursts.
Use appropriate tyre air pressure when
mounting weights or implements.
Electrical System and
Battery
Persons having a pacemaker must not
touch live parts of ignition system when
the engine is running.
1. Safety Instructions
Explanation of
Warning Signs
Before any cleaning, maintenance, and
repairwork switchofftheengine andpull
spark plug connector.
With engine running, keep at a safe dis-
tance.Dirt and stones may get airborne
during sweeping. People and animals
must keep out of this area.
Signs
When working with the ma-
chine, wear individual pro-
tective ear plugs.
Wear protective gloves.
Wear solid shoes.
1

agria Sweeper 7100 Cleanstar premium 13
2. Specifications
Transmission:
Wheel drive..........................Hydrostat
Drive on driving wheels with chain drive
Ground speeds:
Forward travel, steplessly .. 0 - 5 km/h
Reverse travel , steplessly.. 0 - 3 km/h
Brush drive......................... worm gear
...............V-belt clutch with idler pulley
Brush speed is adjusted steplessly via
a variator from 100 rpm to 200 rpm
Always use original agriaV-belts (see
wear parts list on page 41)
Handlebars:
height-adjustable without tools
Noise level:
Noise level: .......................... LpA 75 dB
in accordance with EN 11201 (at
operator’s ear)
sound power level in accordance with
EN ISO 3744:1995 :...............................
measured............................. LWA 95dB
guaranteed........................... LWA 96 dB
Vibration acceleration value:
on handlebar grip........ ahw = 3,02 m/s2
in accordance with 2002/44/EC
Sweeper
agria-Cleanstar premium
7100 221 .......... 100 cm brushes fine
7100 321 ..... 100 cm brushes coarse
Weights:
Cleanstar premium...approx.102.5kg
Collector 100 cm.........approx. 13,0 kg
Snow dozer blade100 cm approx.13,5 kg
Spray apron ..................approx. 2,5 kg
Sprinkling assy .............approx. 4,0 kg
Tyres:..................... 3.50 - 6 field tyres
Optional:........... 13x5.00-6 Lawn tyres
Tyre pressure: ........................ 0,8 bar
2
Dimensions:
a...................................... 890 mm
b...................................... 630 mm
e....................................1335 mm
h.............................960-1060 mm
l......................................1650 mm
L Collector .................... 1930 mm
L Snow dozer ...............1890 mm
A....................................1000 mm
S...................................... 480 mm

14 agria Sweeper 7100 Cleanstar premium
Engine
Manufacturer: ........................ Honda
Type: ...........................GCV 160 N2E
Version: ....................... Fan-air-cooled
1 cylinder-4-stroke
OHC engine (petrol)
Bore: ........................................ 64 mm
Stroke: ..................................... 50 mm
Piston displacement:.......... 160 ccm
Output: ............... 4.1 kW at 3600 rpm
Torque:max. 11.4 Nm at 2500 rpm
Spark plug: ...... NGK BPR6ES Bosch
Spark plug gap: ............... 0.7–0.8 mm
Ignition:
Transistor trip coil, contactless;
ignition point: 20° bef ore dead centre,
radio remote screened according to
VDE 0879
Valve lash (engine cold)
Intake: ........................ 0.15 ± 0.04 mm
Outlet: ........................0.20 ± 0.04 mm
Starter:..........................Recoil starter
Fuel tank capacity: ................... 1.1 l
Fuel:............................ unleaded petrol,
octane number at least 91 RON
(also E10)
refer to fuel recommendations
Air filter:................. Dry element filter
Carburetor:.............. Float carburetor
Throttle valve type
Mixture control screw: ... opened by
approx. 1 turn in base setting
Top no-load speed: ..........3250 rpm
Idling speed: ........... 1550–1850 rpm
Engine oil:
Filling quantity ............... approx. 0.55 l
Multi-grade oil SAE 10 W-40
SG, SF or higher quality grade
Operability on Slopes:
Engine is suited for use on slopes
(with oil level at “max” = upper level
mark)
Continuous operation possible up to
20° inclination (37 %)
2. Specifications
2

agria Sweeper 7100 Cleanstar premium 15
3. Devices and Operating Elements
The agria Cleanstar sweeper is suited
forapplicationinamenity areas andwin-
ter road clearance. The following com-
ponents are available for sweepers:
l Rotary brushes 100 cm
coarse ........... agria item no.6194 151
fine ................ agria item no.6194 161
l Collector
100 cm agriaitemno.6194221
l Sprinkling assy
agriaitemno.6194481
l Spray apron agria item no.6194921
The following implement is available for
winter road clearance:
l Snow dozer
100 cm agriaitemno.6196021
3.1 Engine
The four-stroke petrol engine runs on
commercial petrol (refer to fuel recom-
mendations p6).
During the first 20 operating hours
(break-in period) do not operate the
engine at maximum speed.
Even after the break-in period never
operate the engine at higher speedthan
is necessary for the work in hand.
IHigh engine speed is harm-
ful to any engine and consid-
erably affects its longevity. This ap-
plies especially for no load operation.
Any overspeed (have the engine roar)
can result in immediate damage.
Cooling System
The engine is fan-cooled. Therefore
keep the grille on the recoil starter and
thecoolingfins onthecylinderclean and
free from sucked-in plant trash.
Idling Speed
Always ensure that idling-speed is ad-
justed correctly.At low speeds and with
the speed control lever set to idle, the
engineissupposedtorun smoothly and
without run-out.
Air Filter
The air filter cleans the air as it is in-
ducted. A clogged filter reduces engine
output.
Ignition System
The engine is equipped with a mainte-
nance-free, contactless electronic igni-
tion system. We recommend to have
necessarycheck-ups done byanexpert
only.
3.2 Speed Control Lever
(Engine-shut-off switch)
The speed control lever (A/6) on the
handlebar sets the engine speed
steplesslyandactuates theCHOKEand
the engine-shut-off switch. For the ap-
propriate positions see the illustration.
IThe speed control lever also
serves as engine safety circuit.
In an emergency move the lever to po-
sition "STOP" to shut off the engine in-
stantly.
3
A/6

16 agria Sweeper 7100 Cleanstar premium
3.3 Safety Circuit Lever
The Cleanstar premium sweeper has
a safety circuit mechanism for wheel/
brush drives integrated in the clutch
lever.
Stop position: Upon release of the
lever (A/3) – with wheel drive or brush
drive engaged – the ignition system is
switched off (engine is shut off).
Caution – engine keeps running due to
centrifugal mass.
Start position: When starting and
during work breaks set the clutch lever
(A/2) and the driving twist grip (A/4) to
"0"
Operating position: Press the
safety circuit lever (A/3) down to start
operation.
WDo not tie down the safety
circuit lever.
IThesafety circuit leveralsoserves
as engine safety circuit in an
emergency.Upon release, the lever will
automatically go to STOP position.


2
3. Devices and Operating Elements

3
0
3

agria Sweeper 7100 Cleanstar premium 17
3.4 Wheel Drive
l When the twist grip (A/4) is turned in a
clockwise direction themachinetravelsforwards
at an increasing speed of max. 5 km/h
l When the twist grip (A/4) in an anti-clockwise
direction the machine travels backwards at an
increasing speed of max. 3 km/h
l Marking on the top of the twist grip:
= middle setting = "0" setting
3.5 Brush drive
The brushes are driven by a V-belt clutch and a
worm gear.
Operate clutch lever (A/2) to turn the brushes
on/off:
When the clutch lever is released and the
ratchet is not locked into place the brush drive
is switched off ("0").
When the clutch lever is engaged the brush
drive is switched on ("I").
By use of the pawl (A/1) the clutch lever can be
locked in a switched-on position.
After the first hour of use the clutch setting must
bechecked and adjusted where necessary (see
Maintenance).
INote: Park the sweeper only
when all drives are disengaged
(see Chapter “Storage”) to avoid clutch
problems.
3. Devices and Operating Elements
3
0
A/4
A/2
A/1
0
I

18 agria Sweeper 7100 Cleanstar premium
1Wheel dog
2Screw with nut
3Drive wheel
4Spacer tube
1Grip end
2Dog pin
3Hole on drive wheel
3
3. Devices and Operating Elements
3.6 Handlebars
Handlebars Height Adjustment
l Unscrew the clamping lever (21) until the
notches are exposed
l Adjustthehandlebars(24)to thedesiredheight
and notch them into the proper position.
l Re-tighten clamping lever (21).
3.7 Drive Wheels
The drive wheels (3) are attached with dogs (1)
and screws (2) to the shaft. This allows
attachment and removal.
Spacer tubes (4) are fitted between the gearbox
and drive wheels.
3.8 Snow Chains
Themountingofsnowchainsistobeundertaken
when the driving wheels have been removed.
The lock and the tightening chains must be on
theinnersideofthewheels, otherwise there may
be possible damage to the wheel dog (1).
3.9 Wheel Dogs
Wheel dogs are fitted to engage/disengage the
wheels independently of the gearbox.
Pushing the Machine
Disengage the dogs to push the machine when
the engine is shut off.
Turning Aid
Engangethedog on onewheelforeasierturning.
Engaging the Wheel Dogs
l Align thedogpins (2)withthe appropriateholes
(3) on the drive wheels.
l Turn the pins on their ends (1) by 90 degrees
until the ends mesh into the slot.Turn each dog
to either side until the pin locks completely into
the hole.
Disengaging the Wheel Dogs
l Grab the end (1) of each dog pin to pull it out
and rotate it by 90 degrees.
1
32



agria Sweeper 7100 Cleanstar premium 19
3. Devices and Operating Elements
3.10 Attaching the
Rotary Brushes
Wear safety gloves to
attach/remove the brus-
hes. Danger of crushing.
Mount the discs onto both
sides of the rotary brushes.
Pushthetensioninganchorage
through the left rotary brush.
Pushthe tensioninganchorage
with the rotary brush through the
drive shaft from the left - insert
grooveon rotary brushes into cam
of the drive plate.
slide right rotary brush onto
tensioning anchorage
- insert groove on rotary brushes
into cam of the drive plate.
Screw on and tighten hexago-
nal nut.
To remove the brushes, reverse
the above order.
3
3
1Rightrotary brush
2Leftrotary brush
3Nut cap
4Tensioning anchorage
5Disc
6Nut
3





3

20 agria Sweeper 7100 Cleanstar premium
25
3
3. Devices and Operating Elements
3.11 Sweeping Height
Adjustment
The sweeping height is altered by adjusting
the castor wheel.
l Turn the crank (8) to adjust the wheelheight.
l Reduce the sweeping height only if absolu-
tely necessary (to the height of X) to ensure
clean sweeping and long service life of the
brushes.
Dirt, powder snow............. x = 2–3mm
Wet snow..................... x = max 8 mm
3.12 Side Adjustment
The brush can be angled to the right or left to
sweep the rubbish or snow to one side.
l Fold the rod (7) forward until the notches
are exposed.
l Pivot the rod to turn the brushes to the left
or right.
l Fold the rod to the rear and down again and
mesh it into the proper notch.
3.13 Sweeping Speed
The speed of the rotary brushes is steplessly
adjusted via a variator.
Always engage the brush drive before you
adjust sweeping speed.
Adjustment
Select a slow speed for dust sweeping:
Turn the dial (25) in counter-clockwise
direction.
Select a fast speed for snow sweeping:
Turn the dial (25) in clockwise direction.
ITo adjust the speed from slow
to fast, give the dial a maximum
turn of 6 full turns.
