Agrify Pure Pressure Axis Pulse User manual

Axis
Pulse
User Manual

Introduction
From all of us here at PurePressure, thank you for
purchasing the PurePressure Axis Pulse!
Sales Inquiries:
[e-mail]
General Questions:
[e-mail]
Technical Support:
[e-mail]
If these steps are followed, you can be sure to enjoy uninterrupted
operation day in and day out. The instructions in this user manual
specically focuses on the Axis Pulse, but please contact us with any
other needs and we’d be happy to help!
gopurepressure
purepressure.com

Specication Axis Pulse
Mounting & control kit included Min: 27 PSI | Max: 87 PSI
Pneumatic adjustable operation 1920 VPM @ 27 PSI | 2580 VPM @ 87 PSI
Speed VPM (Vibrations Per Minute) @ X number of PSI
Operational PSI 80 (5.5 bar)
Force 158.63 LBS
Technical Specications

01 02 03
Mount Axis Pulse adapter plate to
existing 44 gallon dolly using (4)
5/16-18 x 1 ¼” SS socket head screw
and (4) 5/16-18 SS self-locking nuts.
Use Loctite 270 to prevent loosening.
Tighten to a torque value of 11 lb-ft.
Mount Axis Pulse to Axis Pulse
adapter plate using (4) ¼-20 x 1 ½”
SS button head screw and (4) ¼-20
SS self-locking nuts. Use Loctite 270
to prevent loosening. Tighten to a
torque value of 6.4 lb-ft.
Connect ¼” NPT exhaust mufer to
Axis Pulse.
Connect 3/8” NPT push-to-connect
tting to Axis Pulse.

04 05
Connect Needle Valve and Bracket to
Hash Pump Stand using 5/16” SS self-
drilling screws provided. Approximate
mounting location to be centered on
the stand.
Insert push-to-connect tee by splicing pre-installed pneumatic tubing on pump tand.
Run ¼” pneumatic tubing off push-to-connect tee to port 1 of needle valve.
Run ¼” pneumatic tubing from port 2 of needle valve to push-to-connect tting on Axis Pulse.
Axis pulse vibrations can be controlled manually by the needle valve. Adjust accordingly
by turning the knob to the desired VPM to reduce blinding during the ltration process.
Adjustment can be locked.

Reliability, Guaranteed
gopurepressure
purepressure.com
PurePressure is committed to making operators as efcient as possible. The team is legendary for exceptional
customer service and solventless extraction trainings. The Axis Pulse includes a 1-year manufacturer warranty.
