Propur®HOME Whole House Water Filtration System
Now there’s a Propur® for your entire home! The most advanced 4 stage compact filtration system.
Featuring groundbreaking filtration technology - ProMaxTM FULL SPECTRUM HOME!
Proformance tested to NSF/ANSI standards 42, 53, P231 and 401 across a broad spectrum of 220+
contaminants including VOC’s, lead, fluoride, heavy metals, pesticides, SVC’s, disinfectants,
inorganic non-metallics, herbicides, pharmaceuticals, micro-organisms, taste and odor by an
independent certified water testing laboratory.
Ongoing emerging contaminants - ongoing testing including latest testing for PFOA, PFOS, Parasites
(Copepods, Blue-Green Algae), Haloacetic Acids, Microcystin and micro-plastics. See the com-
plete lab report on the Propur® HOME system at www.propurusa.com.
Propur®HOME (SYSTEM) OVERVIEW:
SYSTEM INCLUDES:
3 - stage filter tank assembly with rack
6 - ¾” push fit connectors
3 - connector tubes and tube supports
1 - ElectroCharged™ Sub-micron filter assembly with wrench and mounting bracket
5 - ¾” PEX tubing with tube supports
READ CAREFULLY AND FOLLOW ALL INFORMATION INCLUDED IN THIS INSTRUCTION MANUAL.
SOME LOCAL AND STATE CODES MAY REQUIRE THE USE OF A LICENSED QUALIFIED PLUMBING
PROFESSIONAL OR A CERTIFIED INSTALLER WHEN DISRUPTING A POTABLE WATER LINE.
INSTALLATION AND USE MUST COMPLY WITH ALL STATE AND LOCAL PLUMBING CODES.
RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Optional Pre-sediment
filter assembly
ElectroChargedTM
Sub-micron filter assembly
Pr Max
TM
What’s inside ProMaxTM set’s it apart.
FULL SPECTRUM HOME

IMPORTANT INFORMATION AND SAFETY PRECAUTIONS - PLEASE READ CAREFULLY PRIOR TO INSTALLATION
INTENDED USE FOR THE PROPUR® HOME WHOLE HOUSE WATER FILTRATION SYSTEM: This SYSTEM is designed for
point-of-entry installation for residential use in filtering either municipal or well potable water. To validate the
warranty, installation, use and maintenance of the Propur HOME system must conform to specifications,
limitations and instructions stated within this manual. For well water use, we recommend your water be
tested for pH, hardness, iron and bacteria. Iron level >.3 mg/I, may require a water softener system (Propur®
PH-2000) as this could affect the performance of the SYSTEM. The use of a Pre-sediment filter and other
equipment may be necessary to address your particular water condition(s), and if necessary, to protect the
SYSTEM. Propur® offers a City Water Test Kit and Well Water Test Kit for checking water. Visit your authorized
Propur® dealer or www.propurusa.com.
WARNING
1. Do NOT use with water that is microbiologically unsafe or of unknown quality without adequate
disinfection before the system
2. Do NOT install the system or adjacent filter housing(s) near electrical wiring or piping which may be in
the path when securing SYSTEM to a wall
3. Do NOT install SYSTEM on its side or in direct sunlight
4. SYSTEM should be installed in a dry location protected from the elements including freezing
5. Should the home electrical system require the use of the cold water system as an electrical safety
ground, a jumper MUST be used to ensure a sufficient ground connection across the filter system
installation.
6. Pressure MUST be released in the ElectroCharged™ Sub-micron filter assembly prior to removing the
filter sump
CAUTION
1. Be careful not to over-tighten any connections to avoid damage or cracks to connections which
could result in damage and or leaks
2. Use only approved thread sealant such as Teflon tape or Teflon paste when making connections.
When using paste thread sealant, label must state suitable for use with PVC and NSF approved.
Some sealant pastes may contain solvents which can soften threads resulting in damaged fittings
and leakage
3. If an irrigation/sprinkler system is present upstream of the system, a one-way check value MUST be
installed to protect your SYSTEM
4. Installation such as apartment dwelling may require a vacuum breaker valve
5. For well water installation, install SYSTEM after pressure tank
6. For city water installation, install SYSTEM after meter
7. In areas of known high sediment (such as New York), a Pre-sediment filter assembly is recommended
8. ElectroCharged™ Sub-micron filter assembly requires 3” of space below sump in order to replace
filter
9. DO NOT install where ambient temperature may go above 110°F (43.3°C)
10. DO NOT install without a pressure limiting valve should the water pressure exceed 100 psi (690kPa).
11. DO NOT install on the hot water supply line
12. Fuel or electrical power supply going to water heater may need to be shut off during installation
after water supply is shut off
13. To avoid risk of property damage due to water leakage or to replace tanks or filter cartridge, a
bypass line with ball valves MUST be installed as shown in Assembly Diagram
14. The SYSTEM MUST be flushed/purged before being connected to the main plumbing. This helps
prevent media fines from discharging into the home plumbing and water appliances. Follow
instructions (16) under GETTING STARTED
IMPORTANT NOTES
1. Before starting installation, shut off main water supply, drain pipes and release pressure as necessary
2. Check for leaks after completing installation
3. Failure to follow instruction manual will void warranty

OPERATING SPECIFICATIONS
Maximum temperature: 49°C, 120°F
Minimum temperature: 1°C, 34°F
Maximum line pressure: up to 125 psi (8.61 Bar)
Maximum vacuum: 140mmHg, 5.5” Hg
Maximum recommended service flow rate: 7gpm
SYSTEM SPECIFICATIONS
Overall size: 3 stage tank assembly w/rack size: 25” X 10” X 28”
Tank size: 7” x 17” each
Overall size: stage 4 ElectroCharged™ Sub-micron filter assembly: 7” x 15”
Complete system weight: 65 lbs
Port size: ¾” INLET and OUTLET
Push fit connectors: ¾” for PEX (with tube supports), CPVC or Copper
Expected capacity: 50,000 gallons or up to 1 year (dependent on specific water source and usage)
For well water application check iron level. Above .3 mg/I, call for information as this may require a
water softener.
Pre-sediment filter (optional): When sediment may be of concern, we recommend the installation of a
Pre-sediment filter assembly. Item # PH-PRE filter assembly. Recommended filter cartridge replacement up
to 6 months or as needed.
Depending on your specific water condition, Propur® offers additional “Pre” or “Post” add-on optional filters.
Please contact Propur® Technical Support should you have questions about your specific needs.
Replacement Filters:
3 stage filter tank assembly – item# PH-1000RTA
ElectroCharged™ Sub-micron filter cartridge – item# PH-EC-RF
Pre-sediment 5 micron filter cartridge – item# PH-PRE-RF

GETTING STARTED
1. SHUTOFF MAIN AND INLET WATER SUPPLY AND DEPRESSURIZE BEFORE STARTING INSTALLATION
2. Basic tools and materials required (not included). Plumbing may vary. Other materials may be
required.
a. Pipe cutter
b. Compression fittings for INLET and outlet/To household plumbing – ¾” NPT fittings x size
of piping
c. 3 ball valves and piping for bypass line set up
d. PTFE Tape or paste (NSF approved for PVC)
e. Adjustable wrench
f. Ground kit if required
3. See Assembly Diagram below
4. For City Water installation, install SYSTEM after the meter
5. For Well Water installation, install SYSTEM after the pressure tank
6. Remove components from carton and inspect
7. 3 stage filter tanks MUST be installed in sequence 1-2-3 with ElectroCharged™ Sub-micron following
tank 3
8. Tanks are pre-filled at the factory. ElectroCharged™ Sub-micron filter assembly comes with
replaceable filter cartridge
9. DO NOT use pipe solvent (dope) as some types may cause damage to plastic fittings
10. DO NOT overtighten as it may cause damage to components and or property
11. Determine location for SYSTEM and make sure SYSTEM is connected with the correct flow direction
12. Install Bypass set up as shown in Assembly Diagram above
13. BEFORE FINAL CONNECTION/INSTALLATION to household plumbing, follow surge flushing (16) on next
page
14. Check to see if jumper ground kit is required before using
15. Remove ElectroCharged™ Sub-micron filter cartridge from housing before Surge flushing process in
step (16)
USE TUBE SUPPORTS
WITH PEX TUBING
INCLUDED
Optional Pre-sediment
filter assembly
ElectroChargedTM
Sub-micron filter assembly
INSTALLS LIKE
ElectroChargedTM
Sub-micron filter
assembly

16. Surge flushing: It is important to surge flush the SYSTEM prior to final connection/installation to
household plumbing and use to prevent carbon media fines or carbon dust from discharging into
the household plumbing and water appliances.
a. Install temporary line at OUTLET of Sub-micron filter assembly to allow water to drain out
b. BYPASS LINE valve should be turned off
c. Slowly turn on the water supply line. You may notice discolored and or cloudy water due to carbon
fines flowing into the drain. This is normal as the SYSTEM is being flushed out. Continue to slowly turn
on and flush until clear water free from discoloration and cloudiness is flowing
d. Once completed, disconnect the temporary line at OUTLET and finish connection/installation to the
household plumbing line
17. Make sure SYSTEM is firmly attached and supported
18. Once installation is complete, reinstall ElectroCharged™ Sub-micron filter cartridge into housing.
Slowly turn on water supply line and press red button on filter head to release air pressure
19. Run system and inspect for any leaks
20. Should water appear cloudy in a glass, this is normal as there maybe air bubbles still in the system
and will dissipate with use
MAINTENANCE
1. USE OF BYPASS LINE: BYPASS LINE is intended to be used when circumventing the system for
maintenance or repair of SYSTEM. To use,
a. Shut off the main supply line and open faucet to release pressure
b. Close the INLET and OUTLET valve and open the BYPASS line valve
2. ElectroCharged™Sub-micron filter cartridge replacement – recommend every 6 months or;
a. Should there be a noticeable reduction in water flow, change in taste or if the filter
cartridge becomes heavily discolored, indication the Sub-micron filter cartridge
should be replaced.
b. Replacement instructions
i. TURN OFF MAIN WATER SUPPLY, INLET and OUTLET WATER VALVES
ii. Place a bucket under the filter housing assembly to catch excess water
iii. Relieve water pressure by pressing red button on Sub- micron filter assembly
head
iv. Unscrew clear housing sump using supplied wrench and slowly turn to the left
until sump is detached from assembly head. Discard old filter cartridge. Wash
sump thoroughly with mild soap and water. Rinse well. DO NOT place in
dishwasher.
v. Remove and lubricate O-ring with food grade oil
vi. Insert new cartridge and re-install sump housing. Be sure O-ring is positioned
correctly in the proper groove before tightening onto the head. Tighten using
supplied wrench only. Caution not to overtighten as damage and or leakage
could occur.
vii. Slowly turn on main water supply and open INLET and OUTLET valves
viii. Press red button on head to release air pressure and check for leaks
ix. Flush system for several minutes.
x. You are now ready to use.
3. Manufacturer recommends ElectroCharged™ Sub-micron filter housing assembly be replaced every
4 years to maintain warranty
4. Use only warm, soapy water to clean the outside of the 3 stage filter tank housings. Rinse well with
fresh, clean water. Never use chemical cleaning products on the filter’s housing exterior surface as
this may cause damage to the housings.
5. 3 stage tank assembly replacement
a. Shut off the main water supply line, INLET and OUTLET valves
b. Disconnect the INLET and OUTLET side of the 3 stage tank assembly
c. Disconnect the ElectroCharged™Sub-micron filter assembly from 3 stage tank
assembly
d. Depending on the installation, the rack may need to be detached from the wall in
order pull out (slide) the 3 stage tank assembly from the rack
e. Continue replacement installation with step 16 through step 20

LIMITED PROPUR® HOME WARRANTY
PROPUR®LIMITED WARRANTY
Lincoln-Remi Group, LLC d/b/a Propur® (“PP”) sells its products with the intent that they are free from defects.
PP warrants to the original retail purchaser/consumer when purchased from an authorized Propur® dealer, that its
products will be free of defects in material and workmanship under normal use for the following periods beginning on
the date of purchase: 5 year limited warranty on Propur®HOME components only excluding the filter element or media,
one (1) year for ElectroCharged™ Sub-micron filter element. PP will replace or repair any component in the Propur®
HOME system, at its sole discretion, during the Warranty Period. Any damage caused by misuse or abuse; accident;
improper installation; dropped product; failure to follow recommended installation or provide recommended mainte-
nance; transportation damage; neglect; environmental conditions; or any other conditions whatsoever that are beyond
the control of PP are excluded from this warranty. This express limited warranty shall be the sole and exclusive warranty.
No warranty is given as to the service life of the filter media or any filter element as it will vary with water conditions and
water consumption. ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS OR FITNESS FOR ANY PARTICULAR PURPOSE OR ANY OTHER POTENTIAL OBLI-
GATION ON THE PART OF PP WITH RESPECT TO PRODUCTS SOLD BY PP ARE DISCLAIMED. EXCEPT FOR ANY EXPRESS WAR-
RANTIES, ALL PROPUR® PRODUCTS ARE SOLD “AS-IS”. PP shall not be held liable for any incidental, consequential or
special damages of any sort whatsoever. The liability of PP is limited to the original retail purchaser and to the repair or
replacement of defective components during the Warranty Period. No refunds will be given at any time. The liability of
PP terminates upon the expiration of the Warranty Period or transfer of product ownership. To obtain warranty service on
your Propur® product, mail the product with your dated sales receipt as proof of purchase, postpaid, to the following
address: Propur, 1200 Benstein Rd, Commerce Twp, MI 48390. NO C.O.D’s This warranty provides you with specific legal
rights. You may have additional rights which may vary from country to country. Because of individual country laws and
regulations, some of the above limitations and exclusions may not apply to you.
For any warranty questions, please call 1-800-544-3533 or email to [email protected].
Attention CA, IA and WI Consumers In compliance with state law for CA, IA and WI, Propur® water filtration
products are sold and shipped to residents of these states without any health related performance claims
except for aesthetics including chlorine reduction, and improvement with taste, odor and sediment.
2017 Propur®Water Filters. ALL RIGHTS RESERVED V12142017
PURCHASE DATE: ___________________________
For questions or concerns, please contact our customer service representatives at 1(800)544-3533
or email at [email protected]
