AIC SB202-LE User manual

UM_SB202-LE_v1.1_042919
SB202-LE
Storage Sever Barebone
User's Manual

Contents
Table of Contents
Preface������������������������������������������������������������������������������������������������� i
Safety Instructions ������������������������������������������������������������������������������ ii
About This Manual������������������������������������������������������������������������������ iv
Chapter 1� Product Features ��������������������������������������������������������������1
1.1 Box Contents ...........................................................................................1
1.2 Specications ..........................................................................................2
1.3 Feature .....................................................................................................3
Chapter 2� Hardware Setup ����������������������������������������������������������������5
2.1 Central Processing Unit (CPU)................................................................ 5
2.1.1 Processor Support..............................................................................................5
2.1.2 Installing the CPU ...............................................................................................5
2.1.3 CPU Heatsink Installation ..................................................................................8
2.2 System Memory Setup ............................................................................ 9
2.2.1 DIMM Installation ...............................................................................................9
2.2.2 DIMM Location ................................................................................................ 10
2.2.3 Dimm Slot Installation Order........................................................................... 10
2.3 Top Cover ...............................................................................................11
2.3.1 Removing the Top Cover ................................................................................. 11
2.4 Power Supply Unit Module....................................................................12
2.4.1 Replacing the Power Supply Unit ................................................................... 12
2.5 Fan Module ............................................................................................13
2.5.1 Replacing the Fan ........................................................................................... 13
2.6 Hard Disk Drive ......................................................................................14
2.6.1 Replacing the Hard Disk Drive ....................................................................... 14
2.7 HDD Backplane......................................................................................15
2.7.1 Replacing the HDD Backplane ........................................................................ 15
2.8 Slide Blade Installation..........................................................................16
Chapter 3�Hardware Settings ����������������������������������������������������������� 20
3.1 Block Diagram........................................................................................20
3.2 Content List............................................................................................21
3.3 Layout.....................................................................................................23
3.4 Connector and Jumper..........................................................................24

3.5 System LED Indicator ............................................................................26
3.5.1 Internal LED...................................................................................................... 26
3.5.2 Front Panel LED ............................................................................................... 28
3.5.3 Rear Panel LED ................................................................................................ 29
3.6 HDD Backplane: 2 Bay...........................................................................30
3.6.1 Placement ........................................................................................................ 30
3.6.2 Connector ........................................................................................................ 30
3.6.3 LED Indicator.................................................................................................... 31
3.7 HDD Backplane: 12 Bay.........................................................................32
3.7.1 Placement ........................................................................................................ 32
3.7.2 Connector......................................................................................................... 33
3.7.3 LED Indicator.................................................................................................... 35
3.7.4 Jumper ............................................................................................................. 37
3.7.5 Drive Slot Map.................................................................................................. 38
Chapter 4. BIOS Conguration Settings ������������������������������������������� 39
4.1 Navigation Keys.....................................................................................39
4.2 BIOS Menu .............................................................................................40
4.3 Main........................................................................................................41
4.3.1 Main.................................................................................................................. 41
4.4 Advanced................................................................................................42
4.4.1 Trusted Computing.......................................................................................... 42
4.4.2 ACPI Settings ................................................................................................... 42
4.4.3 Onboard Device Conguration........................................................................ 43
4.4.4 Hardware Health Conguration ...................................................................... 43
4.4.5 Super IO Conguration .................................................................................... 43
4.4.6 S5 RTC Wake Settings ..................................................................................... 44
4.4.7 Serial Port Console Redirection ...................................................................... 44
4.5 Chipset ...................................................................................................45
4.5.1 Intel Server Platform Services Conguration................................................. 45
4.5.2 North Bridge Conguration ............................................................................. 45
4.5.3 South Bridge Conguration............................................................................. 46
4.6 Security ..................................................................................................47
4.6.1 Security ............................................................................................................ 47
4.7 Server Management ..............................................................................48
Contents

4.7.1 FRB-2 Timer..................................................................................................... 48
4.7.2 OS Watchdog Timer......................................................................................... 48
4.7.3 System Event Log............................................................................................ 49
4.7.4 BMC Network Conguration ........................................................................... 49
4.8 Boot ........................................................................................................50
4.8.1 Boot .................................................................................................................. 50
4.9 Save and Exit..........................................................................................51
4.9.1 Save and Exit.................................................................................................... 51
Chapter 5. BMC Conguration Settings�������������������������������������������� 52
5.1 Login.......................................................................................................52
5.2 Web GUI ................................................................................................53
5.2.1 Menu Bar.......................................................................................................... 53
5.2.2 User Information and Quick Button ............................................................... 54
5.2.3 Dashboard........................................................................................................ 55
5.2.4 Sensor .............................................................................................................. 55
5.2.5 System Inventory............................................................................................. 56
5.2.6 FRU Information............................................................................................... 56
5.2.7 Logs and Reports ............................................................................................ 57
5.2.8 Settings ............................................................................................................ 58
5.2.9 Remote Control................................................................................................ 60
5.2.10 Power Control ................................................................................................ 65
5.2.11 Chassis Identify Control................................................................................ 66
5.2.12 Set Front Panel Enables ................................................................................ 66
5.2.13 Maintenance .................................................................................................. 67
5.2.14 Sign out .......................................................................................................... 69
Chapter 6� Technical Support����������������������������������������������������������� 70
Contents

Document Release History
Release Date Version Update Content
April
2019 1User's Manual release to public.
Contents

Copyright © 2019 AIC, Inc� All Rights Reserved�
This document contains proprietary information about
AIC products and is not to be disclosed or used except in
accordance with applicable agreements.

Copyright
No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photo-static, recording
or otherwise, without the prior written consent of the manufacturer.
Trademarks
All products and trade names used in this document are trademarks or registered
trademarks of their respective holders.
Changes
The material in this document is for information purposes only and is subject to change
without notice.
Warning
1. A shielded-type power cord is required in order to meet FCC emission limits and also
to prevent interference to the nearby radio and television reception. It is essential
that only the supplied power cord be used.
2. Use only shielded cables to connect I/O devices to this equipment.
3. You are cautioned that changes or modifications not expressly approved by the
party responsible for compliance could void your authority to operate the equipment.
Disclaimer
AIC shall not be liable for technical or editorial errors or omissions contained herein.
The information provided is provided "as is" without warranty of any kind. To the
extent permitted by law, neither AIC or its afliates, subcontractors or suppliers will be
liable for incidental, special or consequential damages including downtime cost; lost
profits; damages relating to the procurement of substitute products or services; or
damages for loss of data, or software restoration. The information in this document
is subject to change without notice.
Instruction Symbols
Special attention should be given to the instruction symbols below.
NOTE This symbol indicates that there is an explanatory or
supplementary instruction.
CAUTION
This symbol denotes possible hardware impairment. Upmost
precaution must be taken to prevent serious harware damage.
WARNING
This symbol serves as a warning alert for potential body
injury. The user may suffer possible injury from disregard or
lack of attention.
Preface
i

Before getting started, please read the following important cautions:
• All cautions and warnings on the equipment or in the manuals should be noted.
• Most electronic components are sensitive to electrical static discharge. Therefore, be
sure to ground yourself at all times when installing the internal components.
• Use a grounding wrist strap and place all electronic components in static-shielded
devices. Grounding wrist straps can be purchased in any electronic supply store.
• Be sure to turn off the power and then disconnect the power cords from your system
before performing any installation or servicing. A sudden surge of power could
damage sensitive electronic components.
• Do not open the system’s top cover. If opening the cover for maintenance is a must,
only a trained technician should do so. Integrated circuits on computer boards are
sensitive to static electricity. Before handling a board or integrated circuit, touch
an unpainted portion of the system unit chassis for a few seconds. This will help to
discharge any static electricity on your body.
• Place this equipment on a stable surface when install. A drop or fall could cause injury.
• Please keep this equipment away from humidity.
• Carefully mount the equipment into the rack, in such manner, that it won’t be
hazardous due to uneven mechanical loading.
• This equipment is to be installed for operation in an environment with maximum
ambient temperature below 35°C.
• The openings on the enclosure are for air convection to protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
• Never pour any liquid into ventilation openings. This could cause fire or electrical
shock.
• Make sure the voltage of the power source is within the specication on the label when
connecting the equipment to the power outlet. The current load and output power of
loads shall be within the specication.
• This equipment must be connected to reliable grounding before using. Pay special
attention to power supplied other than direct connections, e.g. using of power strips.
• Place the power cord out of the way of foot traffic. Do not place anything over the
power cord. The power cord must be rated for the product, voltage and current marked
on the product’s electrical ratings label. The voltage and current rating of the cord
should be greater than the voltage and current rating marked on the product.
• If the equipment is not used for a long time, disconnect the equipment from mains to
avoid being damaged by transient over-voltage.
• Never open the equipment. For safety reasons, only qualied service personnel should
open the equipment.
Safety Instructions
ii

• If one of the following situations arise, the equipment should be checked by service
personnel:
1. The power cord or plug is damaged.
2. Liquid has penetrated the equipment.
3. The equipment has been exposed to moisture.
4. The equipment does not work well or will not work according to its user manual.
5. The equipment has been dropped and/or damaged.
6. The equipment has obvious signs of breakage.
7. Please disconnect this equipment from the AC outlet before cleaning. Do not
use liquid or detergent for cleaning. The use of a moisture sheet or cloth is
recommended for cleaning.
• Module and drive bays must not be empty! They must have a dummy cover.
iii

Thank you for selecting and purchasing the SB202-LE.
This user's manual is provided for professional technicians to perform easy hardware
setup, basic system congurations, and quick software startup. This document pellucidly
presents a brief overview of the product design, device installation, and rmware settings
for SB202-LE. For the latest version of this user's manual, please refer to the AIC website:
http://www.aicipc.com/en/productdetail/50969.
Chapter 1 Product Features
SB202-LE is a flexible storage server barebone that is specifically designed to
accommodate diverse corporations and enterprises for managing heavy workloads and
multiple applications.
Chapter 2 Hardware Setup
This chapter displays an easy installation guide for assembling the hardware in this
product. Utmost caution for proceeding to set up the hardware is highly advised. Most of
the components are highly fragile and vulnerable to exterior influence. Do not endanger
the device by placing the device in an unstable environment.
Chapter 3 Hardware Settings
This chapter elaborates the overall layout of the system barebone, including multifarious
connectors, jumpers, and LED descriptions. These descriptions assist users to congure
different settings and functions of the motherboard, as well as to conrm the location of
each connector and jumper.
Chapter 4 BIOS Conguration Settings
This chapter introduces the key features of BIOS, including the descriptions and option
keys for diverse functions. These details provide users to effortlessly navigate and
congure the input/output devices.
Chapter 5 BMC Conguration Settings
This chapter illustrates the diverse functions of IPMI BMC, including the details on logging
into the web page and assorted denitions. These descriptions are helpful in conguring
various functions through Web GUI without entering the BIOS setup. For more information
of BMC congurations, please refer to IPMI BMC (Aspeed2400) User's Manual for a more
detailed description.
Chapter 6 Technical Support
For more information or suggestion, please contact the nearest AIC corporation
representative in your district or visit the AIC website: http://www.aicipc.com/tw/en. It is
our greatest honor to provide the best service for our customers.
iv
About This Manual
