AIC SB405-PV User manual

UM_SB405-PV_v1.2_021519
SB405-PV
Storage Barebone
User's Manual

Contents
Table of Contents
Preface������������������������������������������������������������������������������������������������� i
Safety Instructions ������������������������������������������������������������������������������ ii
About This Manual������������������������������������������������������������������������������ iv
Chapter 1� Product Features ��������������������������������������������������������������1
1.1 Box Contents ...........................................................................................1
1.2 Specications ..........................................................................................2
1.3 Feature .....................................................................................................3
Chapter 2� Hardware Setup ����������������������������������������������������������������7
2.1 Central Processiong Unit Setup.............................................................. 7
2.1.1 Processor Support..............................................................................................7
2.1.2 Processor Heat Sink Module and Processor Socket Assembly.......................8
2.1.3 Processor Heat Sink Module..............................................................................9
2.1.4 Heatsink Location............................................................................................ 11
2.1.5 Heatsink for Single Processor only with RAID card Function (BTO) ............ 12
2.1.6 Riser Card Installation (BTO)........................................................................... 13
2.2 System Memory ....................................................................................14
2.2.1 Dual Processor ................................................................................................ 14
2.2.2 Recommended Dimm Installation Order........................................................ 15
2.2.3 Single Processor with Raid Card Function (BTO) .......................................... 17
2.2.4 Populate DIMMs with the Single Processor .................................................. 18
2.2.5 DIMM Installation Procedure .......................................................................... 20
2.3 Removing and Installing the Top Cover ...............................................21
2.3.1 Installing/Removing the Top Cover A & B ...................................................... 22
2.3.2 Installing/Removing the Top Cover C & D ...................................................... 23
2.4 Removing and Installing the Hard Disk Drive.......................................24
2.4.1 Installing the HDD............................................................................................ 24
2.4.2 Removing the HDD from the tool tray............................................................. 25
2.4.3 Installing/Removing the HDD Tray ................................................................. 26
2.5 Removing and Installing the Fan Module.............................................29
2.5.1 Installing the Fan ............................................................................................ 29
2.5.2 Removing the Fan ........................................................................................... 29
2.6 Removing and Installing the HDD Backplane Module.........................30
2.6.1 Installing the HDD Backplane ......................................................................... 30

2.6.2 Removing the HDD Backplane ....................................................................... 30
2.7 Removing and Installing the Power Supply Unit Module ....................32
2.7.1 Installing the Power Supply Unit .................................................................... 32
2.7.2 Removing the Power Supply Unit ................................................................... 32
2.8 Removing and Installing the Motherboard...........................................33
2.8.1 Installing the Motherboard.............................................................................. 33
2.8.2 Removing the Motherboard ......................................................................... 33
2.9 Removing and Installing the Cable Cover ............................................34
2.9.1 Installing the Cable Cover ............................................................................... 34
2.9.2 Removing the Cable Cover .............................................................................. 34
2.10 Removing and Installing the Bridge....................................................35
2.10.1 Installing the Bridge ...................................................................................... 35
2.10.2 Removing the bridge ..................................................................................... 35
2.11 Removing and Installing Rear Handle ................................................36
2.11.1 Installing the Rear Handle............................................................................. 36
2.11.2 Removing the Rear Handle............................................................................ 36
2.12 Removing and Installing the Airduck..................................................37
2.12.1 Removing the Airduck ................................................................................... 37
2.12.2 Installing the Airduck..................................................................................... 37
2.13 Tool-less Blade Slide Installation ......................................................38
Chapter 3� Motherboard Settings ����������������������������������������������������� 41
3.1 Motherboard Block Diagram.................................................................41
3.2 Motherboard Content List .....................................................................42
3.3 Motherboard Layout ..............................................................................43
3.4 Internal Connectors/Jumpers..............................................................44
3.5 System LED Indicator ............................................................................49
3.5.1 Front Panel LED .............................................................................................. 49
3.5.2 Rear I350 LAN LEDs......................................................................................... 49
3.5.3 Rear PCH LAN LEDs......................................................................................... 50
3.5.4 Rear UID LED & Internal LED ........................................................................... 51
3.6 HDD Backplane: 24 Bay.........................................................................52
3.6.1 Placement: 24 Bay........................................................................................... 52
3.6.2 Connector Location: 24 Bay............................................................................ 53
3.6.3 LEDs: 24 Bay .................................................................................................... 54
Contents

3.6.4 LED Locations: 24 Bay..................................................................................... 55
3.7 HDD Backplane: 30 Bay.........................................................................57
3.7.1 Connector Location: 30 Bay............................................................................ 58
3.7.2 LEDs: 30 Bay .................................................................................................... 59
3.7.3 LED Locations: 30 Bay..................................................................................... 60
Chapter 4. BIOS Conguration Settings ������������������������������������������� 62
4.1 Navigation Keys.....................................................................................62
4.2 BIOS Setup .............................................................................................63
4.2.1 Menu................................................................................................................. 63
4.2.2 Startup.............................................................................................................. 63
4.2.3 Update.............................................................................................................. 66
4.3 Main .......................................................................................................68
4.3.1 Main.................................................................................................................. 68
4.4 Advanced................................................................................................69
4.4.1 Peripheral Conguration ................................................................................. 69
4.4.2 Video Conguration......................................................................................... 69
4.4.3 Socket Conguration....................................................................................... 69
4.4.4 PCH Conguration........................................................................................... 73
4.4.5 H2o IPMI Conguration................................................................................... 77
4.4.6 H2o Event Log Cong Manager ...................................................................... 78
4.5 Security ..................................................................................................79
4.5.1 Security ............................................................................................................ 79
4.6 Power......................................................................................................80
4.6.1 Power ............................................................................................................... 80
4.7 Boot ........................................................................................................81
4.7.1 Boot .................................................................................................................. 81
4.8 Exit..........................................................................................................82
4.8.1 Exit.................................................................................................................... 82
Chapter 5. BMC Conguration Settings�������������������������������������������� 83
5.1 Method 1 (Use the BIOS Setup) ............................................................83
5.2 Method 2 (Use a Dos Tool - Syscheck) ................................................86
5.3 Login.......................................................................................................88
5.4 Web GUI ................................................................................................89
Contents

5.4.1 Menu Bar.......................................................................................................... 89
5.4.2 User Information and Quick Button ............................................................... 90
5.4.3 Dashboard:....................................................................................................... 91
5.4.4 Sensor ............................................................................................................. 91
5.4.5 FRU Information............................................................................................... 91
5.4.6 Logs and Report .............................................................................................. 92
5.4.7 Settings ........................................................................................................... 92
5.4.8 KVM Mouse Setting ........................................................................................ 93
Chapter 6� Technical Support����������������������������������������������������������� 95
Contents

Document Release History
Release Date Version Update Content
August
2018 1User's Manual release to public.
December
2018 1.1 1. Update cover
2. Update Motherboard Setting
Febuary
2019 1.2 1. Update Datasheet

Copyright © 2018 AIC, Inc� All Rights Reserved�
This document contains proprietary information about
AIC products and is not to be disclosed or used except in
accordance with applicable agreements.

Copyright
No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photo-static, recording
or otherwise, without the prior written consent of the manufacturer.
Trademarks
All products and trade names used in this document are trademarks or registered
trademarks of their respective holders.
Changes
The material in this document is for information purposes only and is subject to change
without notice.
Warning
1. A shielded-type power cord is required in order to meet FCC emission limits and also
to prevent interference to the nearby radio and television reception. It is essential
that only the supplied power cord be used.
2. Use only shielded cables to connect I/O devices to this equipment.
3. You are cautioned that changes or modifications not expressly approved by the
party responsible for compliance could void your authority to operate the equipment.
Disclaimer
AIC shall not be liable for technical or editorial errors or omissions contained herein.
The information provided is provided "as is" without warranty of any kind. To the
extent permitted by law, neither AIC or its afliates, subcontractors or suppliers will be
liable for incidental, special or consequential damages including downtime cost; lost
profits; damages relating to the procurement of substitute products or services; or
damages for loss of data, or software restoration. The information in this document
is subject to change without notice.
Preface
i

ii
Before getting started, please read the following important cautions:
• All cautions and warnings on the equipment or in the manuals should be noted.
• Most electronic components are sensitive to electrical static discharge. Therefore, be
sure to ground yourself at all times when installing the internal components.
• Use a grounding wrist strap and place all electronic components in static-shielded
devices. Grounding wrist straps can be purchased in any electronic supply store.
• Be sure to turn off the power and then disconnect the power cords from your system
before performing any installation or servicing. A sudden surge of power could
damage sensitive electronic components.
• Do not open the system’s top cover. If opening the cover for maintenance is a must,
only a trained technician should do so. Integrated circuits on computer boards are
sensitive to static electricity. Before handling a board or integrated circuit, touch
an unpainted portion of the system unit chassis for a few seconds. This will help to
discharge any static electricity on your body.
• Place this equipment on a stable surface when install. A drop or fall could cause injury.
• Please keep this equipment away from humidity.
• Carefully mount the equipment into the rack, in such manner, that it won’t be
hazardous due to uneven mechanical loading.
• This equipment is to be installed for operation in an environment with maximum
ambient temperature below 35°C.
• The openings on the enclosure are for air convection to protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
• Never pour any liquid into ventilation openings. This could cause fire or electrical
shock.
• Make sure the voltage of the power source is within the specication on the label when
connecting the equipment to the power outlet. The current load and output power of
loads shall be within the specication.
• This equipment must be connected to reliable grounding before using. Pay special
attention to power supplied other than direct connections, e.g. using of power strips.
• Place the power cord out of the way of foot traffic. Do not place anything over the
power cord. The power cord must be rated for the product, voltage and current marked
on the product’s electrical ratings label. The voltage and current rating of the cord
should be greater than the voltage and current rating marked on the product.
Safety Instructions

iii
• If the equipment is not used for a long time, disconnect the equipment from mains to
avoid being damaged by transient over-voltage.
• Never open the equipment. For safety reasons, only qualied service personnel should
open the equipment.
• If one of the following situations arise, the equipment should be checked by service
personnel:
1. The power cord or plug is damaged.
2. Liquid has penetrated the equipment.
3. The equipment has been exposed to moisture.
4. The equipment does not work well or will not work according to its user manual.
5. The equipment has been dropped and/or damaged.
6. The equipment has obvious signs of breakage.
7. Please disconnect this equipment from the AC outlet before cleaning. Do not
use liquid or detergent for cleaning. The use of a moisture sheet or cloth is
recommended for cleaning.
• Module and drive bays must not be empty! They must have a dummy cover.
