INSTALLATION AND OPERATING INSTRUCTIONS
WALL/CEILING SECURITY HOUSINGS
HS9305 SERIES

2
IMPORTANT SAFEGUARDS
1. Read Instructions - All the safety and operating instructions should be
read before the unit is operated.
2. Retain Instructions - The safety and operating instructions should be
retained for future reference.
3. Heed Warnings - All warnings on the unit and in the operating instruc-
tions should be adhered to.
4. Follow Instructions - All operating and use instructions should be fol-
lowed.
5. Cleaning - Unplug the unit from the outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the prod-
uct manufacturer as they may cause hazards.
7. Accessories - Do not place this unit on an unstable stand, tripod, brack-
et, or mount. The unit may fall, causing serious injury to a person and
serious damage to the unit. Use only with a stand, tripod, bracket, or
mount recommended by the manufacturer or sold with the product. Any
mounting of the unit should follow the manufacturer's instructions and
should use a mounting accessory recommended by the manufacturer.
An appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
appliance and cart combination to overturn.
8. Ventilation - Openings in the enclosure, if any, are provided for ventila-
tion, to ensure reliable operation of the unit, and to protect it from
overheating. These openings must not be blocked or covered. This unit
should not be placed in a built-in installation unless proper ventilation is
provided or the manufacturer's instructions have been adhered to.
9. Power Sources - This unit should be operated only from the type of
power source indicated on the marking label. If you are not sure of the
type of power supply you plan to use, consult your dealer or local power
company. For units intended to operate from battery power or other
sources, refer to the operating instructions. This equipment is to be isolat-
ed from the mains supply by a limited power source as specified in
EN60950:1992 Clause 2.11.
10. Grounding or Polarization - This unit may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet,
try reversing the plug. If the plug should still fail to fit, contact your elec-
trician to replace your obsolete outlet. Do not defeat the safety purpose
of the polarized plug.
Alternately, this unit may be equipped with a 3-wire grounding-type plug,
a plug having a third (grounding) pin. This plug will only fit into a ground-
ing-type power outlet. This is a safety feature. If you are unable to insert
the plug into the outlet, contact your electrician to replace your obso-
lete outlet. Do not defeat the safety purpose of the grounding-type plug.
11. Power Cord Protection - Power supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
12. Power Lines - An outdoor system should not be located in the vicinity of
overhead power lines or other electric light or power circuits or where it
can fall into such power lines or circuits. When installing an outdoor sys-
tem, extreme care should be taken to keep from touching such power
lines or circuits as contact with them might be fatal. U.S.A. models only -
refer to the National Electrical Code Article 820 regarding installation of
CATV systems.
13. Overloading - Do not overload outlets and extension cords as this can
result in a risk of fire or electric shock.
14. Object and Liquid Entry - Never push objects of any kind into this unit
through openings, as they may touch dangerous voltage points or short
out parts that could result in a fire or electric shock. Never spill liquid of
any kind on the unit.
15. Servicing - Do not attempt to service this unit yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
16. Damage Requiring Service - Unplug the unit from the outlet and refer
servicing to qualified service personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled or objects have fallen into the unit.
c. If the unit has been exposed to water and/or inclement weather
(rain, snow, etc.).
d. If the unit does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions, as an improper adjustment of other controls
may result in damage and will often require extensive work by a
qualified technician to restore the unit to its normal operation.
e. If the unit has been dropped or the cabinet has been damaged.
f.When the unit exhibits a distinct change in performance--this indicates
a need for service.
17. Replacement Parts - When replacement parts are required, be sure the
service technician has used replacement parts specified by the manufac-
turer or have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
18. Safety Check - Upon completion of any service or repairs to this unit,
ask the service technician to perform safety checks to determine that
the unit is in proper operating condition.
19. Coax Grounding - If an outside cable system is connected to the unit, be
sure the cable system is grounded. U.S.A. models only--Section 810 of
the National Electrical Code, ANSI/NFPA No.70-1981, provides informa-
tion with respect to proper grounding of the mount and supporting
structure, grounding of the coax to a discharge unit, size of grounding
conductors, location of discharge unit, connection to grounding elec-
trodes, and requirements for the grounding electrode.
20. Lightning - For added protection of this unit during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the cable system. This will prevent
damage to the unit due to lightning and power line surges.

Debido a limitaciones de espacio, esta etiqueta puede apare-
cer en la parte inferior de la unidad.
El símbolo representado por un relámpago con
punta de flecha dentro de un triángulo equilátero,
se muestra con el objetivo de alertar al usuario
que existen "voltages peligrosos" sin aislamiento,
dentro de la cubierta de la unidad. Dichos voltages
pueden ser de tal magnitud que constituyen un
riesgo de choque eléctrico a personas.
El símbolo de exclamación dentro de un triángulo
equilátero, se muestra con el objetivo de alertar al
ususario de que instrucciones de operación y man-
tenimiento importantes acompañan al equipo.
Aus Platzgründen kann diese Warnung auf der Unterseite des
Gerätes angebracht sein.
Das Blitzsymbol im gleichseitigen Dreieck soll den
Benutzer auf nicht isolierte "Hochspannung" im
Gehäuse aufmerksam machen, die eventuell stark
genug ist, um einen elektrischen Schlag zu verur-
sachen.
Das Ausrufezeichen im gleichseitigen Dreieck soll
den Benutzer auf wichtige Bedienungs- und
Wartungsanleitungen in der dem Gerät beigefügten
Literatur aufmerksam machen.
En raison de limitation de place, cette étiquette peut être
placée sur le dessous de l'appareil.
L'éclair fléché dans un triangle équilatéral, avertit
l'utilisateur de la présence d'une "tension dan-
gereuse" non isolée à l'intérieur de l'appareil et
d'une valeur suffisante pour constituer un risque
d'électrocution.
Le point d'exclamation contenu dans un triangle
équilatéral, avertit l'utilisateur de la présence, dans
la documentation qui accompagne l'appareil, de
consignes d'utilisation et de maintenance impor-
tantes.
This label may appear on the bottom of the unit due to space
limitations.
The lightning flash with an arrowhead symbol within
an equilateral triangle is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of suffi-
cient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to presence of impor-
tant operating and maintenance (servicing) instruc-
tions in the literature accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRICAL
SHOCK, DO NOT OPEN COVERS. NO USER SERVICE-
ABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Danger: Pour éviter tout risque d'électrocution, ne pas
ouvrir le boîtier. Il n'y a pas de pièces remplaçables à l'in-
térieur. Pour toute révision, s'adresser à un technicien spé-
cialisé.
VORSICHT: UM EINEN ELEKTRISCHEN SCHLAG ZU
VERMEIDEN, ABDECKUNG NICHT ENTFERNEN.
WARTUNGEN ALLER ART QUALIFIZIERTEM PERSON-
AL ÜBERLASSEN.
Precaucion: Para Reducir El Riesgo De Choque Eléctrico,
Favor No Abrir La Cubierta. Este Equipo No Consta De
Piezas O Partes Que Requieren Servicio O Mantenimiento.
Para Reparaciones Favor Referirse A Un Técnico
Calificado.
3
SAFETY PRECAUTIONS SICHERHEITSVORKEHRUNGEN
SECURITE PRECAUCIONES DE SEGURIDAD

4
1UNPACKING
Unpack carefully. This is electromechanical equipment and
should be handled with care.
Check for the following:
•Housing (with correct model number).
•Installation Instructions (this manual).
If an item appears to have been damaged in shipment, replace
it properly in its carton and notify the shipper. If any items
are missing, notify Aigis Mechtronics.
The shipping carton is the safest container in which the unit
may be transported. Save it for possible future use.
2SERVICE
If the unit ever needs repair service, the customer should
contact Aigis Mechtronics for return authorization and ship-
ping instructions.
3CARE AND MAINTENANCE
There are no moving parts in this unit. Regularly scheduled
maintenance will help prolong the operation life of this unit.
Clean the viewing window as needed with a mild, nonabrasive
detergent in water and a soft cloth.
4DESCRIPTION/MODELS
The lightweight cast aluminum design of the HS9305 Series
housings provides the strength of 12 gage steel with the supe-
rior strength-to-weight ratio of aluminum. The removable
cover provides access to the camera and is secured using a
tamper-resistant screw. A special tool is provided for screw
removal.
These housings are designed to be mounted on the ceiling, on
the wall horizontally, or on the wall vertically.
The HS9305 Series housings accept 1⁄3-inch and 1⁄2-inch for-
mat CCD cameras with fixed format lenses and up to 6x
zoom lenses.
4.1 Models
Model No. Feature
HS9305 Clear 9.5 mm (0.37 in) viewing window
HS9305L Key lock
HS9305T Tinted 9.5 mm (0.37 in) viewing window
HS9305W Clear 12.7 mm (0.5 in) viewing window
HS9305LT Key lock and tinted 9.5 mm (0.37 in)
viewing window
HS9305LW Key lock and clear 12.7 mm (0.5 in)
viewing window
CONTENTS
1UNPACKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3CARE AND MAINTENANCE . . . . . . . . . . . . . . . .4
4DESCRIPTION/MODELS . . . . . . . . . . . . . . . . . . . .4
4.1 Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
5INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . .5
5.1 Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
5.2 Mounting the Unit . . . . . . . . . . . . . . . . . . . . . . . . . .5
5.3 Camera/Lens Installation . . . . . . . . . . . . . . . . . . . . .6
5.4 Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
6Replacement Parts/Accessories . . . . . . . . . . . . . . .7
6.1 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . .7
6.2 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
HS9305 Series
Wall/Ceiling Security Housings

5
To p Panel
Spacer
Mounting System
Flange Nut,
Bushing &
Washer
Top Panel
Top Panel
Key
or Tool
Lock or
Tamper-resistant
Screw
Cover
Top Panel
Cove
r
5INSTALLATION
This installation should be made by qualified service personnel
and conform to the National Electrical Code and applicable
local codes.
5.1 Disassembly
1. Remove the hardware kit from the outside of the hous-
ing. The hardware kit should contain the following items:
(1) 1⁄4-20 Button-head Flange Screw
(1) Tamper-resistant Tool (basic models only)
(1) Alternate Camera Bracket
(1) Key (locking models only)
2. All Models: Use the special tool provided to unscrew the
front two tamper-resistant screws, or use the key pro-
vided to unscrew the lock. See Figure 1.
Figure 1 Unscrewing the Cover
3. Remove the cover by grasping it and pulling forward and
down. See Figure 2.
Figure 2 Removing the Cover
4. Unscrew the flange nut and remove the camera mounting
system from the top panel. See Figure 3.
Figure 3 Removing the Mount System
NOTE: Do not lose these parts. They will be needed in
reassembly.
5.2 Mounting the Unit
1. Position the top panel on the ceiling or the wall horizon-
tally or vertically, depending on installation requirements.
See Figures 4 and 5.
NOTE: A smooth, square surface is ideal for proper installa-
tion.
Figure 4 Positioning Top Panel on Ceiling
Figure 5 Positioning Top Panel on Wall

6
Studs
Spacer
Washer
Bushing
Flange Nut
Spacer
Washer
Bushing
Flange Nut
Studs
Button Head
Flange Screw Camera
Camera
Alternate
Camera Bracket
Camera
Bracket
Button Head
Flange Screw
2. Reattach the camera mounting system to the top panel
using the 6-mm flange nut, nylon bushing, 5⁄16-in washer, and
nylon spacer. Use either stud provided, depending on the
camera size and mounting configuration. See Figures 9 and
10.
Figure 9 Securing the Mount System
Figure 10 Securing the Mount System
3. Secure the camera to the camera mount using one 1⁄4-20 x
1⁄2-inch button-head flange screw. See Figures 11, 12, and
13.
Figure 11 Camera Mounts
Knockouts
Knockout
Anchor Bolts
Top Panel
Mounting Bracket
Screw Screw
Camera Bracket
Alternate
Camera Bracket
2. Mark the wall for bolt anchor holes. At least six (6) 8-
mm (5⁄16-in) bolts will be needed.
3. Drill the holes.
4. Decide how wiring will be routed into the housing. If
needed, remove the appropriate knockout. Two PG 13.5
(1⁄2-inch) and one PG 21 (3⁄4-inch) are provided.
See Figure 6.
Figure 6 Knockouts
5. Mount the top panel by installing the anchor bolts. See
Figure 7.
5.3 Camera/Lens Installation
1. If the installation requires the unit to mounted horizon-
tally on a wall, remove the camera bracket from the
mounting system and attach the alternate camera bracket
provided in the hardware kit. See Figure 8.
Figure 8 Alternate Camera Mount
Figure 7 Mounting Top Panel

7
Mounting System
Camera
Camera
Mounting System
To p Panel
Cover
Figure 12 Camera and Mount System
Figure 13 Camera and Mount System
5.4 Final Assembly
1. Mount the cover by aligning the studs with the slots on
the top panel and pushing up and back. See Figure 14.
Figure 14: Replacing the Cover
2. If necessary, remove cover to make any final adjustments
to the camera and camera mounting system. Replace
cover. Camera/lens should be positioned as close to the
viewing window as possible.
3. All Models: Secure the cover by screwing the tamper-
resistant screw or the lock down tight to the cover. See
Figure 15.
NOTE: Retain the special tool or key for future use.
6REPLACEMENT PARTS
& ACCESSORIES
6.1 Replacement Parts
Part No. Description
315 2250 004 Key Hardware Kit (locking models only)
315 2250 005 Tamper-resistant Tool (basic models only)
Hardware Kit
6.2 Accessories
Defogger kits are recommended for use in areas where con-
densation could cause fogging of the viewing window.
Model Description
HS9315-6 115 VAC, 50/60 Hz, 50 W thermostatically
controlled defogger kit
HS9315-2 24 VAC, 50/60 Hz, 50 W thermostatically
controlled defogger kit
HS9315-5 230 VAC, 50/60 Hz, 50 W thermostatically
controlled defogger kit
Do Not Exceed 30 VAC Input on 24 VAC models.
Operation above 30 VAC violates low voltage operation
(Class 2 Specifications). Normal operation is 24 VAC.
Maximum Camera/Lens Size: Housing accepts
camera/lens combinations up to 300 L x 64 W x 54 H mm
(11.8 x 2.5 x 2.1 in).
Tool
or Key Lock or Screw
Cover
Figure 15: Securing the Cover

100 0019 001 AIG 10/02
Printed in U.S.A.
©2002 Aigis Mechtronics
1124 Louise Road, Winston-Salem, NC 27107-5450
Tel: [phone] Fax: [phone]
Data subject to change without notice
