Aigis Mechtronics HS9383S Series User manual

Retaining ring
Retaining ring
Cradle
Terminal Lug
Threaded Hole
Rear Cap
Cradle Rail
Stainless Steel
Dust - Proof Housing
HS9383S SERIES
INSTALLATION AND OP E RATING INSTRUCTIONS
WWW.AIGISMECH.COM

2
IMPORTANT SAFEGUARDS
1. Read Instructions - All the safety and operating instructions should
beread before the unit is operated.
2. Retain Instructions - The safety and operating instructions should be
retained for future reference.
3. Heed Warnings - All warnings on the unit and in the operating
instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should be
followed.
5. Cleaning - Unplug the unit from the outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7. Accessories - Do not place this unit on an unstable stand, tripod,
bracket, or mount. The unit may fall, causing serious injury to a
person and serious damage to the unit. Use only with a stand, tripod,
bracket, or mount recommended by the manufacturer, or sold with
the product. Any mounting of the unit should follow the
manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.
An appliance and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces may
cause the appliance and cart combination to overturn.
8. Ventilation - Openings in the enclosure, if any, are provided for
ventilation and to ensure reliable operation of the unit and to protect
it from overheating. These openings must not be blocked or
covered. This unit should not be placed in a built-in installation unless
proper ventilation is provided or the manufacturer’s instructions
have been adhered to.
9. Power Sources - This unit should be operated only from the type of
power source indicated on the marking label. If you are not sure of
the type of power supply you plan to use, consult your appliance
dealer or local power company. For units intended to operate from
battery power, or other sources, refer to the operating instructions.
10. Grounding or Polarization - This unit may be equipped with a
polarized alternating-current line plug (a plug having one blade wider
than the other). This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
Alternately, this unit may be equipped with a 3-wire grounding-type
plug, a plug having a third (grounding) pin. This plug will only fit into
agrounding-type power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the
grounding-type plug.
11. Power-Cord Protection - Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords and plugs,
convenience receptacles, and the point where they exit from the
appliance.
12. Power Lines - An outdoor system should not be located in the
vicinity of overhead power lines or other electric light or power
circuits, or where it can fall into such power lines or circuits. When
installing an outdoor system, extreme care should be taken to keep
from touching such power lines or circuits as contact with them
might be fatal. U.S.A. models only - refer to the National Electrical
Code Article 820 regarding installation of CATV systems.
13. Overloading - Do not overload outlets and extension cords as this
can result in a risk of fire or electric shock.
14. Object and Liquid Entry - Never push objects of any kind into this
unit through openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. Never
spill liquid of any kind on the unit.
15. Servicing - Do not attempt to service this unit yourself as opening or
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
16. Damage Requiring Service - Unplug the unit from the outlet and refer
servicing to qualified service personnel under the following
conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions, as an improper adjustment of other
controls may result in damage and will often require extensive
work by a qualified technician to restore the unit to its normal
operation.
e. If the unit has been dropped or the cabinet has been damaged.
f. When the unit exhibits a distinct change in performance--this
indicates a need for service.
17. Replacement Parts - When replacement parts are required, be sure
the service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other
hazards.
18. Safety Check - Upon completion of any service or repairs to this unit,
ask the service technician to perform safety checks to determine that
the unit is in proper operating condition.
19. Coax Grounding - If an outside cable system is connected to the unit,
be sure the cable system is grounded. U.S.A. models only--Section
810 of the National Electrical Code, ANSI/NFPA No.70-1981,
provides information with respect to proper grounding of the mount
and supporting structure, grounding of the coax to a discharge unit,
size of grounding conductors, location of discharge unit, connection
to grounding electrodes, and requirements for the grounding
electrode.
20. Lightning - For added protection of this unit during a lightning storm,
or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the cable system. This
will prevent damage to the unit due to lightning and power-line
surges.
FCC & ICES INFORMATION
(U.S.A. and Canadian Models Only)
WARNING -This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules
and ICES-003 of Industry Canada. These limits are designed to provide
reasonable protection against harmful interference when the equipment is
operated in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Intentional or unintentional changes or modifications not expressly
approved by the party responsible for compliance shall not be made. Any
such changes or modifications could void the user’s authority to operate
the equipment.
The user may find the following booklet prepared by the Federal
Communications Commission helpful: "How to Identify and Resolve
Radio-TV Interference Problems". This booklet is available from the
U.S. Government Printing Office, Washington, DC 20402, Stock
No. 004-000-00345-4.

This label may appear on the bottom of the unit due to space
limitations.
The lightning flash with an arrowhead symbol within
an equilateral triangle is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRICAL
SHOCK, DO NOT OPEN COVERS. NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
3
SAFETY PRECAUTIONS
1UNPACKING
Unpack carefully. This is electromechanical equipment and
should be handled with care.
Verify the unit model number.
Verify that parts listed as follows have been included.
2 SERVICE
If the unit ever needs repair service, the customer should
contact Aigis Mechtronics for return authorization and
shipping instructions.
3 CARE AND MAINTENANCE
There are no moving parts in this unit. Regularly scheduled
maintenance will help prolong the operation life of this unit.
Clean the viewing window as needed with a mild,
nonabrasive detergent in water and a soft cloth.
4 DESCRIPTION
The HS9383S Series of environmental housings are attractive
stainless steel enclosures designed for CCD camera
installations.
Hardware Kit
Quantity Part Description
2 1/4-20 x 1/4-inch BHCS (Button Head Cap Screw)
2 1/4-20 x 3/8-inch BHCS (Button Head Cap Screw)
2 1/4-20 x 1/2-inch BHCS (Button Head Cap Screw)
11/4-20 x 5/8-inch BHCS (Button Head Cap Screw)
1 1/4-20 x 3/4-inch BHCS (Button Head Cap Screw)
1 0.4 mm (0.016 in) Plastic Spacer
11.65mm (0.292 in) Plastic Spacer
1 3.9 mm (0.154 in) Plastic Spacer
1 7.4 mm (0.292 in) Plastic Spacer
19.8 mm (0.385 in) Plastic Spacer
2 5/16 Flat Washers
2 1/4 Lock Washer
1Cable Ties
1 Bit Driver 5/32
If an item appears to have been damaged in shipment, replace
it properly in its carton and notify the shipper. If any items are
missing, notify an Aigis Mechtronics Sales Representative or
Customer Service. The shipping carton is the safest container
in which the unit may be transported. Save it for possible future
use.
5 INSTALLATION
This installation should be made by a qualified
service person and conform to all local codes.
5.1 Model Designation
Model Voltage
No. Rated Input Range Output
HS9383S --- --- ---
HS9383S-2H 24 VAC, 21.6 to 26.6 24 VAC,
50/60 Hz 50/60 Hz
HS9383S-5H 230VAC 207-253 24VAC
50Hz 50/60Hz
HS9383S-6H 120VAC 108 to 132 24VAC,
50/60 Hz 50/60 Hz
Power Requirements:
Heater requires 10 watts.
Do Not Exceed 30 VAC Input on 24 VAC models.
Operation above 30 VAC violates low voltage operation
(Class 2 Specifications). Normal operation is 24 VAC.
Maximum Camera/Lens Size:
Model Numbers HS9383S, HS9383S02H and HS98383S-5H accept
cameras up to 2.5 x 2.3 in (64 W x 58 H mm), lenses up to 2.6 x 2.9 in (67
Wx75 H mm), and camera/lens combinations up to 7.0 in (178mm).
Model Numbers HS9383S-5H and HS9383S-6H accept cameras up to
2.5 x 2.3 in (64 W x 58 H mm), lenses up to 2.6 x 2.9 in (67 W x 75 H
mm), and camera/lens combinations up to 9.0 in (228.6 mm).
5.2 Tools Required
Min. 3/16 x 4-inch Flat blade screwdriver
Phillips head screwdriver
5/32-inch (or 4 mm) hex wrench
5/16-inch (or 8 mm) hex wrench
1-3/4-inch open end wrench Or 10-inch Channel lock pliers
10-inch adjustable wrench
Wire cutter/stripper/crimper tool

4
2. Place the blade of the screwdriver under the lip of the
raised section in the rear cap, gently push the
screwdriver against the housing. Pull the cradle from the
housing. See Figure 2.
5.5 Camera/Lens Installation
With the cradle removed from the housing, follow all of the
steps below.
1. Place the camera/lens combination into the cradle
assembly.
FFiixxeeddLLeennssCCaammeerraass::
Position the camera/lens 1 mm (0.04 in) away from the
faceplate. The camera/lens are secured to the cradle
with a 1/4-20 button head cap screw (BHCS) and a
combination of nylon spacers and washers. See Figure 3.
Figure 1: Removing Rear Retaining Ring
Figure 2: Removing Cradle Assembly
Input Power Cord - North American
Cable Type: SJTOW-A rated.
Cable Size: Outside diameter between 4.3 mm
(0.170 in) & 11.9 mm (0.470 in).
Cable Shape: Round.
Conductors: 3 conductor version and
2 conductor version.
Agency Rating: UL/C.S.A., UL VW-1.
Environmental: Outdoor rated.
Temperature Rating: 105 ¡ C.
Voltage Rating: 300 V.
Sources: Belden 19506
Belden 19509
Northwire 573939
Input Power Cord - European
Cable Type: H05RN-F3G0.75 and
H05RN-F3G1.00.
Cable Size: Outside diameter between 4.3 mm
(0.170 in) & 11.9 mm (0.470 in).
Cable Shape: Round.
Conductors: 3 conductor version and
2 conductor version.
Agency Rating: VDE.
Environmental: Outdoor rated.
Sources: Olflex 1600252
Olflex 1600253.
Retaining ring
5.4 Cradle Removal
1. Remove the cradle from the housing by first removing
the rear retaining ring from the rear cap. Place a flat
blade screwdriver underneath the relieved portion of the
retaining ring and gently pry it outward. See Figure 1.
Lens Control Cable
Cable Type: Jacketed multiconductor cable.
Cable Size: Outside diameter between 4.3 mm
(0.170 in) & 11.9 mm (0.470 in).
Cable Shape: Round.
Shield: Overall shielding.
Conductors: Stranded 20 to 16 AWG wire.
No. of Conductors: 4 and 8.
Conductor Insulation: Color coded.
Sources: Belden 9552
Belden 9554.
5.3 Cable Requirements Video Transmission
(Coaxial)
Cable Type: RG-59/U (Runs < 1000 ft)
RG-11/U (Runs < 2000 ft).
Cable Size: Outside diameter between 4.6mm
(0.181 in) & 7.9 mm (0.312 in).
Cable Shape: Round.
Shield: > 93% Braided Copper Shield.
Center Conductor: Stranded Copper Center.
DC Resistance: >15 Ohms/1000 ft (RG-59/U)
> 6 Ohms/1000 ft (RG-11/U).
Cable Impedence: 75 Ohm.
Agency Rating: UL
Environmental: Outdoor rated.
Temperature Rating: 80 ¡ C.
Sources: Belden 9259
Belden 9238.

5.8 Power Connection
5.8.1 Power Connection HS9383S
1. Pull the wires through the conduit fitting and make sure
that the threaded section of the fitting mates up with the
threads in the rear cap.
2. Pull the wires through the threaded hole in the rear cap
of the cradle.
3. A screw, nut and terminal lug are provided for the safety
ground.
4. Unscrew the terminal lug and attach the ground wire.
Attach the lug back to the rail of the cradle.
5. Connect the power wires to the camera per instructions
provided with the camera.
5
Spacer
Washer
1/4 - 20 Screw
Spacer
Washer
1/4 - 20 Screw
Figure 3: Mounting a Fixed Lens Camera
Figure 4: Mounting a Zoom Lens Camera
WARNING: Only use the cables specified under
INSTALLATION, Cable Requirements for wiring of
all cameras and lenses.
Cradle
Terminal Lug
Threaded Hole
Rear Cap
Cradle Rail
Figure 5: Power Connection
ZZoooommLLeennssCCaammeerraass::Allow 3/16-inch (5 mm) clearance
from the front face of the lens to the front faceplate of the
cradle during the camera/lens assembly. This clearance
provides the necessary space for the lens to extend
outward when zooming. Secure both the camera and the
lens to the cradle with the 14 -20 BHCS and appropriate
plastic spacer. See Figure 4.
5.8.2 Power Connection HS9383-2H
1. Pull the wires through the conduit fitting and make sure
that the threaded section of the fitting mates up with the
threads in the rear cap.
2. Pull the power wires through the threaded hole in the
rear cap of the cradle.
3. A screw, nut and terminal lug are provided for the safety
ground. See Figure 5.
5.7 Video Cable Connection
1. Pull the video cable through the conduit fitting and make
sure that the threaded section of the fitting mates up
with the threads on the rear cap.
2. Pull the video cable through the threaded hole in the rear
cap of the cradle.
3. Connect the video cable to the camera.
4. If using a zoom lens, pull the lens cable through the
conduit fitting and attach to the zoom lens pursuant to
the manual supplied with that product.
4. Unscrew the terminal lug and attach it to the ground
wire. Attach the lug back to the rail of the cradle.
5. Install the power wires by using the gray connectors
provided. Push and hold the side of the connector that
does not have wires in it. Slide the tip of the wire into
the opening of the connector until it stops then release.
Repeat this same operation for the other connector. See
Figure 5.
6. Connect the camera to the black and white wires per the
instructions provided with your camera.
Gray
Connectors
Insert wire
Insert wire
Figure 6: Wire Connectors

6
3. Replace the rear retaining ring by inserting it into the
housing groove. This secures the cradle assembly in the
housing. If the housing needs to be tamper-resistant, the
HS9380TK (purchased separately) should be installed at
this time.
4. Attach the housing to the appropriate mount using
instructions provided with the mount. According to the
orientation of the housing, the cradle assembly may need
rotating to align the camera image. To rotate the cradle
assembly (while mounted), use 1-3/4 wrench or channel
lock pliers to grasp the flats on the raised section of the
rear cap to rotate to the desired position. This is best
accomplished while viewing the image on the monitor.
See Figure 8.
5.11 Installing Conduit
1. Apply pipe sealant or teflon tape to the threaded section
of the conduit fitting.
2. Install fitting in the rear cap and tighten with an adjustable
wrench.
Figure 9: Rotate Cradle Assembly
5.9 Desiccant Bag
There is one desiccant bag provided with this housing to
absorb moisture. Remove the adhesive strip on the back
of the desiccant bag and adhere the bag to the cradle in a
location that will not interfere with the camera or sliding
the cradle back into the housing.
5.10 Re-installing the Cradle Assembly
1. Place the cradle in the housing, push the front cap of the
cradle past the rubber o-ring in the rear of the housing,
stop pushing when the rear cap of the cradle is touching
the o-ring in the rear of the housing.
2. Insert the tip of a flat head screwdriver in the slot of the
housing, lay the screwdriver across the raised section of
the rear cap, and push in towards the housing to close
the cradle. See Figure 8.
Figure 8: Inserting Cradle Assembly
Black
115 VAC
Input
White
Red
24 VAC
White/
Black
Striped
To Heater/Defogger
Red
White/
Black
Striped
6
5
2
1
12
11
8
7
To Camera
Figure 7: HS9383S-6H Transformer
Wired for 24 Volt Camera
5.8.3 Power Connection HS9383S-6H
1. Installing a 24-volt camera into the HS9383S-6H housing
utilizes the internal transformer for the camera.
2. Pull the wires through the conduit fitting and make sure
that the threaded section of the fitting mates up with the
threads in the rear cap.
3. Pull the wires through the threaded hole in the rear cap of
the cradle.
4. A screw, nut and terminal lug are provided for the safely
ground.
5. Unscrew the terminal lug and attach the ground wire.
Attach the lug back to the rail of the cradle.
6. Connect the supply (115Vac ) to the primary flying leads
of the transformer (white wire on pin1, black wire on pin
6 ). Gray connectors have been pre wired with these
connections. See Figure 6. Push and hold the side of the
connector that does not have wires in it. Slide the tip of
the wires into the opening of the connector until it stops
then release. Repeat theses operations for th other side.
7. Connect the secondary flying leads to the cameras 24-volt
input. See Figure 7.

7
6. MOUNTING
1. Determine a secure mounting location.
2. Cautions:
a. For a secure installation, use four 8-mm (5/16-in)
diameter fasteners (not included). Use stainless steel
or zinc plated fasteners.
b. If bolts are used, they should extend through the
mounting surface and be secured with flat washers,
lock washers, and nuts on the opposite side. Each
bolt must have a minimum pull-out strength of 200 kg
(450 lb).
c. If studs are used, they should be anchored in
concrete or welded to a steel backer plate. Each
stud must have a minimum pull out strength of 200 kg
(450 lb).
c. If studs are used, they should be anchored in
concrete or welded to a steel backer plate. Each
stud must have a minimum pull out strength of 200 kg
(450 lb).
d. If the wall mount is attached to wood or to a blind
structure (with no access to the rear), each fastener
must have a minimum pull-out strength of at least 200
kg (450 lb).
3. Locate the four holes or stud locations using the flange as
a template (four holes equally spaced on a 69.9-mm (2-3/4-
in bolt circle).
4. Install the mount using bolts or studs at least 8-mm (5/16-
in) in diameter.
5. Turn the housing into position and lock the mounting head
in by using the supplied 1/8 long-arm hex wrench to
tighten screws.
For more information see the MT9208SS & MT9212SS
Stainless Steel Mount Instruction Booklet.
7. DIMENSIONAL OUTLINES
mm
in
95,3
3.75
3/4-14 NPT
PIPE THREADS
ø
HS9383S-6H
17.72
450.1
HS9383S 300.2
11.82
HS9383S-2H
HS9383S-5H

'2005 Aigis Mechtronics
1124 Louise Road Winston-Salem, NC 27107-5450
Tel: [phone] Fax: [phone]
Data subject to change without notice.
100 0132 003 AIG 01/07
Printed in U.S.A.
