AINA AVC1 User manual

AINA Vehicle Cradle
QUICK GUIDE
AINA Wireless
DOC ID : IU0007 ver. 2.0.
D Charging
contacts
C Standard
1/4"-20 female
thread
B AMPs hole
paern
A Lanyard
hole
INCLUDED IN THE PACKAGE
DESIGN
E USB-A male charging
cable (936mm long)
X 1 X 4
X 1

COMPATIBLE MOUNTS AND PLATES
• Any camera mount with standard 1/4"-20 UNC male with screw 6mm
threads
• Any mount or plate with standard AMPs hole paern: 30x38mm with
four M4 screws
• Compable with all major mount manufacturers, such as Arkon
Mounts (www.arkon.com), RAM Mount (www.rammount.com) and
GPS lockbox (www.gpslockbox.com)
CHARGING INSTRUCTIONS
1. Slide the PTT Voice Responder clip into the Vehicle Cradle
2. Connect the charging cable’s USB-A male end into: a vehicle power
adapter, a car charger or a USB-A female socket
NOTE use only USB cered power supply, rated current 700mA - 2.8A
and voltage 4.75—5.25V. Charging temperature range 10°- 40°C
NOTE 2 do NOT cut the cable, always connect to USB power supply

LANYARD (OPTIONAL)
• Oponal where driving regulaons require a tethered communicaon
device
• Guide the key-chain ring on the lanyard through the lanyard hole on
the back of the cradle
• Use the carabiner to hook into the Voice
Responder's top loophole
CUSTOMER CARE
If any part of the equipment is damaged on arrival, contact the shipper
to conduct an inspecon and prepare a damage report. Save the
shipping container and all packing materials unl the inspecon and the
damage report are completed.
In addion, contact the Customer Care to make arrangements for
replacement equipment. Do not return any part of the shipment unl
you receive detailed instrucons from an AINA Wireless representave.
Contact Customer Care at:
E-mail: [e-mail]

Image in 1:1 size. Can be used as an drilling template.
