R410A 60Hz Universal Cooling Only System Technical Manual
14 SEER TOP-DISCHARGE
COOLING ONLY
TECHNICAL MANUAL
January 2021
Version A-TM-14CO-01

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
Part 1 General Information........................................................................................1
1. Model Names of Indoor/Outdoor Units .......................................................................3
2. External Appearance .....................................................................................................4
3. Features ..........................................................................................................................5
Part 2 Indoor Unit.......................................................................................................6
1. Features ..........................................................................................................................7
2. Specification....................................................................................................................8
3. Dimension .......................................................................................................................9
4. Service Space ..............................................................................................................11
5. Wiring Diagrams...........................................................................................................12
6. Electric Characteristics ...............................................................................................14
7. The Specification of Wiring ........................................................................................15
8. Field Wiring...................................................................................................................16
Part 3 Outdoor Unit..................................................................................................17
1. Specification.......................................................................................................18
2. Dimension …………………………………………………………………………….19
3. Service Space....................................................................................................20
4. Wiring Diagrams ................................................................................................22
5. Electric Characteristics ......................................................................................22
6. Operation Limits.................................................................................................23
7. Sound Levels................................................................................................................24
8. Refrigerate diagram ....................................................................................................25
Part 4 Installation.....................................................................................................26
1. Precaution on Installation...........................................................................................27
2. Vacuum Dry and Leakage Checking ........................................................................28
3. Additional Refrigerant Charge ...................................................................................30
4. Insulation Work ............................................................................................................31
5.Test Operation...............................................................................................................33
Part 5 Unit maintenance..........................................................................................34
1. Fault indicator of indoor unit.......................................................................................35
2. Fault indicator of outdoor unit ....................................................................................35
3. Flow chart of troubleshooting.....................................................................................36
4. Exploded views and part list.......................................................................................41
Content

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
1
Part 1. General Information
1. Model Names of Indoor/Outdoor Units.......................................2
2. External Appearance..................................................................3
3. Features.....................................................................................4
R410A 60Hz Universal Outdoor series

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
2
Nomenclature

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
3
1. Model Names of Indoor/Outdoor Units
1.1 Indoor Units
Model name
Dimension (H×W×D)
(inch)
Power supply
SEER 14 Cooling Only
AIDC1800NG1-D
45-3/4×19-2/3×22
208~230V-1Ph-60Hz
AIDC2400NG1-D
45-3/4×19-2/3×22
208~230V-1Ph-60Hz
AIDC3000NG1-D
45-3/4×19-2/3×22
208~230V-1Ph-60Hz
AIDC3600NG1-D
45-3/4×19-2/3×22
208~230V-1Ph-60Hz
AIDC4200NG1-D
45-3/4×19-2/3×22
208~230V-1Ph-60Hz
AIDC4800NG1-D
53-1/8×22×24-1/2
208~230V-1Ph-60Hz
AIDC6000NG1-D
53-1/8×22×24-1/2
208~230V-1Ph-60Hz
1.2 Outdoor Units
Model name
Dimension (H×W×D)
(inch)
Power supply
Cooling Only
ACTC1814NG1-D
25×21-5/6×21-5/6
208~230V-1Ph-60Hz
ACTC2414NG1-D
25×21-5/6×21-5/6
208~230V-1Ph-60Hz
ACTC3014NG1-D
25×21-5/6×21-5/6
208~230V-1Ph-60Hz
ACTC3614NG1-D
25×29-1/8×29-1/8
208~230V-1Ph-60Hz
ACTC4214NG1-D
32-5/6×29-1/8×29-1/8
208~230V-1Ph-60Hz
ACTC4814NG1-D
32-5/6×29-1/8×29-1/8
208~230V-1Ph-60Hz
ACTC6014NG1-D
32-5/6×29-1/8×29-1/8
208~230V-1Ph-60Hz

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
4
2. External Appearance
2.1 Indoor unit
Air Handler
2.2 Outdoor unit
Note: Standard outdoor unit is using plastic grill. Metal grill can be customized.

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
5
3. Features
3.1 Wide operation range, down to 19°F for heating.
3.2 Well-known brand fixed compressor, reliable quality.
3.3 Intelligent defrost programs, unit will choose different defrost program according to
real condition.
3.4 Condenser coils constructed with copper tubing and enhanced aluminum fins.
3.5 Use TXV as expansion device (14 SEER air handler).
3.6 Direct drive motors, 3-speed, provide selections of air flow to meet desired
applications.
3.7 24V control, time delay relay, fan relay and transformer included.
3.8 R410A environment friendly refrigerant.
3.9 AHRI certification, ETL certification.

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
6
Part 2. Indoor Unit
1.Features ....................................................................................................................6
2.Specification .................................................................................... 7
3.Dimension ....................................................................................... 9
4.Service Space ............................................................................... 10
5.Wiring Diagrams.............................................................................11
6.Electric Characteristics .................................................................. 13
7.The Specification of Wiring............................................................ 14
8.Field Wiring ................................................................................... 15

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
7
1. Features
(1) “A” shape coils, constructed with copper tubing and enhanced aluminum fins.
(2) Direct drive motors,3 speed, provide selections of air flow to meet desired applications.
10” big fan, powerful wind. Motor is covered with thermal insulator, keep motor running in safety
status.
(3) Use TXV as expansion device (14 SEER air handler)
(4) Detachable air filter for cleaning or renewal
Versatile 4-way convertible design for vertical up airflow, horizontal right airflow.

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
8
2. Specification
Model
AIDC1800NG1-D
AIDC2400NG1-D
AIDC3000NG1-D
Power supply
V/Ph/
Hz
208~230V/1N/60Hz
208~230V/1N/60Hz
208~230V/1N/60Hz
Cooling
Capacity
Btu/h
18000
24000
30000
SEER
Btu/h.
W
14.00
14.00
14.00
Indoor external static pressure
Pa
25
25
37
Throttle type
TXV
TXV
TXV
Indoor coil
Number of row
3(row)×2(piece)
4(row)×2(piece)
4(row)×2(piece)
Tube pitch(a)xrow
pitch(b)
in
7/8 × 1/2
7/8 × 1/2
7/8 × 1/2
Fin spacing
in
1/16
1/16
1/16
Fin material
Hydrophilic
Hydrophilic
Hydrophilic
Tube outside
diameter
in
Ф ¼
Ф ¼
Ф ¼
Tube material
inner grooved
inner grooved
inner grooved
Coil height x
length x width
in
14 7/8×17 7/16×1 37/64
16 17/32×17 7/16×2 7/64
16 17/32×17 7/16×2 7/64
Number of circuit
6
8
8
Indoor fan
motor
Brand
Kangbao
Kangbao
Kangbao
Type
PSC
PSC
PSC
Input
Amp
0.82
0.94
1.31
Output
Amp
0.45
0.61
0.82
Capacitor
μF
6
6
6
Speed (Lo/Me/Hi)
rpm
340/390/440
490/530/570
530/600/670
blower
Diameter
in
12-5/16
12-5/16
12-5/16
Width
in
12-29/32
12-29/32
12-29/32
Indoor air flow
CFM
500/610/723
738/804/938
919/1060/1204
Indoor noise level
dB(A)
40
42
48
Indoor unit
Unit (HxWxD)
in
45-3/4×19-2/3×22
45-3/4×19-2/3×22
45-3/4×19-2/3×22
Packing (HxWxD)
in
47.63×22.83×25.59
47.63×22.83×25.59
47.63×22.83×25.59
Net/Gross weight
Lbs
123/134
130/141
132/143

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
9
Model
AIDC3600NG1-D
AIDC4200NG1-D
AIDC4800NG1-D
AIDC6000NG1-D
Power supply
V/Ph/
Hz
208~230V/1N/60Hz
208~230V/1N/60Hz
208~230V/1N/60Hz
208~230V/1N/60Hz
Cooling
Capacity
Btu/h
34500
42000
48000
56500
SEER
Btu/h.
W
14.00
14.00
14.00
14.00
Indoor external static
pressure
Pa
37
37
50
50
Throttle type
TXV
TXV
TXV
TXV
Indoor coil
Number of row
4(row)×2(piece)
4(row)×2(piece)
5(row)×2(piece)
5(row)×2(piece)
Tube
pitch(a)xrow
pitch(b)
in
0.83×0.53
0.83×0.53
0.83×0.53
0.83×0.53
Fin spacing
in
1/16
1/16
1/16
1/16
Fin material
Hydrophilic
Hydrophilic
Hydrophilic
Hydrophilic
Tube outside
diameter
in
Ф ¼
Ф ¼
Ф ¼
Ф ¼
Tube material
inner grooved
inner grooved
inner grooved
inner grooved
Coil length x
height x width
in
17 7/16×16
17/32×2 7/64
17 7/16×16
17/32×2 7/64
19 27/32×21 1/2×2
5/8
19 27/32×21 1/2×2
5/8
Number of
circuit
8
8
12
12
Indoor fan
motor
Brand
Kangbao
Kangbao
Kangbao
Kangbao
Type
PSC
PSC
PSC
PSC
Input
Amp
1.81
2.10
2.63
2.63
Output
Amp
1
1.23
1.36
1.36
Capacitor
μF
10
10
12
12
Speed
(Lo/Me/Hi)
rpm
690/730/805
610/723/839
820/870/920
820/870/920
blower
diameter
in
12-5/16
12-5/16
12-5/16
12-5/16
width
in
12-29/32
12-29/32
12-29/32
12-29/32
Indoor air flow
CFM
1161/1235/1376
1208/1385/1562
1434/1574/1695
1434/1574/1695
Indoor noise level
dB(A)
51
54
55
55
Indoor unit
Unit (HxWxD)
in
45-3/4×19-2/3×22
45-3/4×19-2/3×22
53-1/8×22×24-1/2
53-1/8×22×24-1/2
Packing
(HxWxD)
in
47.63×22.83×25.59
47.63×22.83×25.59
54.72×25.20×27.95
54.72×25.20×27.95
Net/Gross
weight
lbs
134/146
137/148
176/190
176/190
Notes:
1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 80°FDB, 66°FWB; Outdoor temp: 95°FDB; Equivalent ref. piping: 5m (horizontal)
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 68°FDB; Outdoor temp: 44°FDB, 43°FWB; Equivalent ref. piping: 5m (horizontal)
3. Actual noise level may differ, depending on the room structure, etc., since these noise values are from an
anechoic room.

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
10
3. Dimension
Dimensional Data
Model Size
Unit Height
"H" in
Unit With
"W" in
Unit Length
"D" in
Supply Duct "A"
in
Liquid Line/ Vapor
Line In
18K
45-3/4
19-2/3
22
17-7/8
3/8" / 7/8"
24K
45-3/4
19-2/3
22
17-7/8
3/8" / 7/8"
30K
45-3/4
19-2/3
22
17-7/8
3/8" / 7/8"
36K
45-3/4
19-2/3
22
17-7/8
3/8" / 7/8"
42K
45-3/4
19-2/3
22
17-7/8
3/8" / 7/8"
48K
53-1/8
22
24-1/2
19-1/2
3/8" / 7/8"
60K
53-1/8
22
24-1/2
19-1/2
3/8" / 7/8"

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
11
4. Service Space
The indoor unit should be installed in a location that meets the following requirements:
INSTALLATION NOTES:
1. When up hand discharge, how to trap or plug all drains is see the left Figure.
2. When right hand discharge, how to trap or plug all drains is see the top Figure.
3. The seal-plugs are supplied as accessories and be screwed tightly only with hand.
The thickness of the filer is 1 inch.
MODEL FILTER SIZE (inches)
18/24/30/36/42 18x20
48/60 20x22

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
12
MODEL FILTER SIZE (inches)
18/24/30/36/42 18x20
48/60 20x22
5. Wiring Diagrams
18K/24K/30K/36K/42K
48K

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
13
60K

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
14
6. Electric Characteristics
Model
Indoor Units
Indoor Fan Motor
Hz
Voltage
Min.
Max.
Amp
SEER 14 Cooling Only
AIDC1800NG1-D
60
208-230V
198V
242V
0.81
AIDC2400NG1-D
60
208-230V
198V
242V
0.95
AIDC3000NG1-D
60
208-230V
198V
242V
1.31
AIDC3600NG1-D
60
208-230V
198V
242V
1.81
AIDC4200NG1-D
60
208-230V
198V
242V
2.09
AIDC4800NG1-D
60
208-230V
198V
242V
2.63
AIDC6000NG1-D
60
208-230V
198V
242V
2.63

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
15
7. The Specification of Wiring
Note:
The cross-section areas of wires or lines should not be less than the corresponding ones listed
in the table below; Besides, if the power wires are quite long from the unit, please choose the
windings with larger cross-section area to guarantee the normal power supply.
Model
Type
Indoor power wires
Thermostat communication wires
Outdoor power
wires
Indoor
Outdoor
18 K series
（singlephase）
Cooling only
3*16Awg
3*18Awg
2*18Awg
3*16Awg
24 K series
（singlephase）
Cooling only
3*18Awg
2*18Awg
3*14Awg
30 K series
（singlephase）
Cooling only
3*18Awg
2*18Awg
36 K series
（singlephase）
Cooling only
3*18Awg
2*18Awg
42 K series
（singlephase）
Cooling only
3*18Awg
2*18Awg
3*12Awg
48 K series
（singlephase）
Cooling only
3*18Awg
2*18Awg
60 K series
（singlephase）
Cooling only
3*18Awg
2*18Awg

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
16
8. Field Wiring
1. To avoid the electrical shock, please connect the air conditioner with the ground lug.
The main power plug in the air conditioner has been joined with the ground wiring,
please do not change it freely.
2. The power socket is used as the air conditioner specially.
3. Do not pull the power wiring hard.
4. When connecting the air conditioner with the ground, observe the local codes.
5. If necessary, use the power fuse or the circuit, breaker or the corresponding scale
ampere.

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
17
Part 3 Outdoor Unit
1. Specification ................................................................................. 17
2. Dimensions................................................................................... 19
3. Service Space .............................................................................. 20
4. Wiring Diagrams ........................................................................... 21
5. Electric Characteristics ................................................................. 22
6. Operation Limits ........................................................................... 23
7. Sound Levels................................................................................ 24
8. Refrigerate diagram...................................................................... 25

14SEER AIR COOLING ONLY SYSTEM TECHNICAL MANUAL
18
1. Specification
Not Available
Model
ACTC1814NG1-D
ACTC2414NG1-D
ACTC3014NG1-D
ACTC3614NG1-D
Outdoor power supply
V/Ph/
Hz
230V/1N/60HZ
230V/1N/60HZ
230V/1N/60HZ
230V/1N/60HZ
Cooling
Capacity
Btu/h
18000
24000
30000
34500
Input
W
1475
1960
2460
2830
EER
Btu/h
.W
11.70
12.20
11.60
11.70
SEER (AHRI
Certified)
Btu/h
.W
14
14
14
14
Max. input consumption
W
1843.75
2450.00
3075.00
3573.50
Max. current
A
8.44
11.21
14.07
16.19
Compressor
Brand
HITACHI
HITACHI
HITACHI
HITACHI
Model
ASL145DG-C7EU
ASH201DG-C8LU1L
ASH239DG-C8DU
ASH280DG-C8DU
Type
rotary
rotary
rotary
rotary
Capacity
Amp
18.43
25.96
30.67
35.91
Input
Amp
6.04
8.48
9.96
11.74
Rated current(RLA)
A
6.10
8.7
10.2
11.9
Locked rotor
Amp(LRA)
A
33
44
56
60
Thermal protector
uf
40
40
55
70
Refrigerant oil
ml
480
570
570
570
Outdoor fan
motor
Brand
chigo
chigo
chigo
chigo
Model
S.TB-DQ-YDK-60-
6P2-AL
S.TB-DQ-YDK-85-
6P2-AL
S.TB-DQ-YDK-85-
6P2-AL
S.TB-DQ-YDK-110-
8P2-AL
Input
Amp
0.63
0.77
0.77
0.9
Output
Amp
0.26
0.37
0.37
0.48
Capacitor
μF
6.00
6.00
6.00
6.00
Speed
rpm
870
970
970
850
Outdoor coil
Number of row
1
2
2
2
Fin spacing
in
0.055
0.055
0.055
0.055
Fin material
non-Hydrophilic
Aluminum Fin
non-Hydrophilic
Aluminum Fin
non-Hydrophilic
Aluminum Fin
non-Hydrophilic
Aluminum Fin
Tube outside
diameter
in
0.276
0.276
0.276
0.276
Tube material
Inner Grooved
Inner Grooved
Inner Grooved
Inner Grooved
Coil height x length
x width
in
23.15×56.22×0.53
23.15×56.22×1.05
23.15×56.22×1.05
23.15×84.65×1.05
Number of circuit
3
4
4
6
Outdoor noise level
dB(A)
57
60
60
60
Outdoor unit
Unit (HxWxD)
in
25×21-5/6×21-5/6
25×21-5/6×21-5/6
25×21-5/6×21-5/6
25×29-1/8×29-1/8
Packing (HxWxD)
in
26×22-5/8×22-5/8
26×22-5/8×22-5/8
26×22-5/8×22-5/8
26×30×x30
Net gross weight
lbs
101/106
115/119
128/134
157/163
Refrigerant
Type
R410A
R410A
R410A
R410A
Charge
oz.
70.55
93.47
95.23
123.46
Refrigerant
pipe
Liquid side
in
3/8
3/8
3/8
3/8
Gas side
in
3/4
¾
3/4
3/4
Max. refrigerant
pipe length
ft
65 39⁄64
65 39⁄64
65 39⁄64
65 39⁄64
Max. difference in
level
ft
32 13⁄16
32 13⁄16
32 13⁄16
32 13⁄16
Design
pressure
PSI
580/174
580/174
580/174
580/174
Max pressure
PSI
609
609
609
609
