Airflow Aria 100B Installation guide

Aria 100B - 90000687
Aria 100T - 90000688
Aria 100H - 90000689
Aria 100MST - 90000690
Fan overview
Page 3 of 16
123
4
5
Range overview
Aria fans are designed for ventilation of domestic
premises i.e. bathrooms, toilets and shower rooms.
They are recommended for 'through the wall'
instilation.
The Aria 100B model may be used as a simple
extract fan operated by a remote switch.
The Aria 100T model includes an adjustable timer
function 2 to 30 minutes.
The Aria 100HT model includes an adjustable timer
function 2 to 30 minutes and an adjustable humidity
function 60 to 90% RH.
The Aria 100MST models includes adjustable timer
function 2 to 30 minutes and motion sensing.
1-cover, 2-casing, 3-motor
4-impeller, 5-control.
Aria 100T, 100HT, 100MST
Wiring for fans with external switching
Electrical installation
Aria 100B, 100HT, 100MST
Wiring for fans with no external switching
Fan dimensions Electrical installation
The Aria fan range is IPX4 rated and is suitable for
mounting in Zone 2 in bathrooms, toilets, kitchens,
utility rooms and inside shower cubicles when installed
with a 30mA RCD. In addition AFDD protection is also
required.
The fan requires a 220 - 240V 50Hz single phase
supply. Class II equipment. BS EN 60417. An external
3A fuse is required for each fan unit. Cable sizes
(max): Fixed flat wiring 2 core 1mm2, 3 core 1/1.5mm2
All electrical installation work to be carried out by a
competent person in compliance with the relevant
Building Regulations/Standards as well as the current
edition of BS7671 (IET Wiring Regulations).
Important notes
The Aria range also complies with the requirements of
the EU norms and directives. Do not place the
ventilator near direct heat sources, e.g. radiant
heaters, or where temperatures can exceed 40°C
(104°F). Precautions must be taken to avoid back flow
of gases in rooms with open flue fuel burning
appliances.
Page 4 of 16
Fan adjustment - Timer
The fan with timer function switches on when the
voltage is supplied to the Ls terminal via an external
switch.
After the voltage to the Ls terminal is disconnected the
fan continues to run for the set overrun period between
2 and 30 minutes. The overrun period is adjusted by
turning the potentiometer (T) clockwise to increase and
anti-clockwise to decrease.
T
Fan assembly - Timer and Humidity /Timer
Fan Size Max flow,
m3/h
Max
pres-
sure, Pa
Nominal
power, W
Noise
level
dB(A)
100mm 66.5 31.8 626
Fan Range
Installation and Operating Guide
Page 2 of 16
Mechanical installation
Aria fans can be wall mounted.
For mounting the fan, a ø100mm is required for the
spigot, as well as at least two holes for the mounting
screws. When mounting the fan, remove the front
cover and place the fan into the pre drilled hole. Make
sure that the spigot fits into any pre-installed ducting.
Wire the fan appropriately according to page 5,
ensuring that the cables from the fan are routed
through the provided cable hole.
Use at least two mounting screws to secure the fan to
the ceiling or wall ensuring not to over tighten and
replace the front cover with the retention screw.
Ensure free running of the fan impeller and that
flexible duct connections are not over tightened to the
fan outlet spigot.
Airflow recommends that rigid ducting is used instead
of flexible ducting, this will ensure maximum
performance
Aria 100
Front cover
Fan body
assembly
Electronic
Control
T & HT
80000510 Issue 2 09/18
Page 5 of 16 Page 6 of 16 Page 7 of 16 Page 8 of 16

Fan adjustment - Humidity / Timer
Humidity and timer functions are activated when the
voltage is supplied to the Ls terminal via an external
switch or when the humidity level rises above the set %
RH level (adjustable between 60 and 90% RH).
After the voltage to the Ls terminal is disconnected or
the humidity level falls below the set %RH level, the fan
continues to run for the set overrun period between 2
and 30 minutes.
The humidity level is adjusted
by turning the potentiometer
(H) clockwise to increase and
anti-clockwise to decrease. To
set the maximum humidity
level the potentiometer (H)
has to set at the max position
(90%).
See page 8 “Fan adjustment -
Timer” for timer adjustment
instructions.
T
H
Page 9 of 16
T
Through the wall installation with flexible
ducting
To maximise airflow rigid ducting should be used.
Where flexible ducting is used the diameter must be
maintained and it is good ventilation practice that the
ducting is extended to 90% of its possible length in
order to maintain the best possible airflow. Ensure
that flexible duct connections are not over tightened to
the fan outlet spigot. The fan and ducting should be
installed in accordance with the requirements of the
Domestic Ventilation Compliance Guide, part of the
Building Regulations.
1. Has been installed and used in accordance with the
fitting and wiring instructions supplied with each unit.
2. Has not been connected to an unsuitable electrical
supply.
3. Has not been subjected to misuse, neglect or
damage.
4. Has not been modified or repaired by any person not
authorised by Airflow Developments Ltd
5. Has been installed in accordance with latest Building
Regulations and BS7671 wiring regulations by a
recognised competent installer.
Airflow Developments Ltd shall not be liable for any
loss, injury or other consequential damage, in the event
of a failure of the equipment or arising from, or in
connection with, the equipment excepting only that
nothing in this condition shall be construed as to
exclude or restrict liability for negligence.
This warranty does not in any way affect any statutory or
other consumer rights.
Recommended Best Practice
The Building Regulations 2010, Statutory Instrument
Part 9, paragraph 42, imposes a requirement that
testing and reporting of mechanical ventilation
performance is conducted in accordance with an
approved procedure.
Compliance with this requirement by an assessed and
registered ‘Competent Person’ should follow a ‘Best
Practice’ process and adopt air flow measurement,
Method A – The Unconditional Method – using a
suitable UKAS certified measuring instrument.
Generically referred to as a ‘Zero Pressure Air Flow
Meter’ or ‘Powered Flow Meter’.
Further information on this method is detailed in NHBC
Building Regulations Guidance Note G272a 10/13 and
BSRIA ‘A Guide to Measuring air flow rates’ document
BG46/2015
Maintenance
SAFETY FIRST: ALWAYS ISOLATE THE FAN UNIT
FROM THE POWER SUPPLY BEFORE REMOVING
THE COVER.
When installed according to these instructions the Aria
range is completely safe. The materials used do not
constitute a hazard.
Cleaning
The external housing of the fan can be wiped with a
damp cloth. Do not use household cleaners containing
abrasives.
Note: Always isolate the fan when cleaning. Never
clean any parts of the fan assembly by immersing in
water or using a dishwasher.
Warning
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision
Fan adjustment - Motion sensor / Timer
The fan with motion sensor and timer function switches
on when movement is detected between a distance of
1 and 4 metres from the fan. The sensor has a
detection angle of 100° horizontally.
Once movement ceases, the fan continues to run for
the set overrun period which is adjustable between 2
and 30 minute.
