Airflow AVENTA TURBO Manual

INSTALLATION & OPERATING INSTRUCTIONS
AVENTA TURBO
In-Line Centrifugal Fans
9041425
AIRFLOWTM

INTRODUCTION
Please read these instructions before commencing installation
and retain for future reference.
DESIGNATION
Aventa Turbo centrifugal in-line fans with a rotor diameter from
190 to 280mm, hereinafter referred to as the fans, are designed
to ventilate domestic and commercial premises (residential
rooms, offices, shops, garages, kitchens, lavatories and other
premises heated during winter time).
Air should not contain dust and other solid additives as well as
sticky substances and fibre materials. The temperature of
ambient air should not be higher than the values indicated.
The fans are installed in horizontal and in vertical positions in
ventilation ducts and may be used for both exhaust and input
ventilation.
The fans are designed for long-term operation without
disconnection from power supply.
According to their type electro safety, the fans fall into the
equipment of Class II.
The level of protection from access to dangerous parts and
from water penetration is IPX4.
Before commencing work ensure electrical supply is isolated
from the mains.

DIMENSIONS
Dimensions, mmFan Type Ø D Ø D C A B L E Weight
(kg)
AV100B 100 250 230 27 30 270 30 2.15
AV125B 125 250 217 27 30 270 30 2.2
AV150B 150/160 300 286 30 30 320 30 2.6
AV200B 200 340 280 30 30 354 40 4.0
AV250B 250 340 265 30 30 354 40 4.5
AV315B 315 400 280 40 40 414 40 5.1

PERFORMANCE
Fan Type Supply voltage (V)
at 50 HZ
Power
(W) Consumption current (A) Capacity (m3/h) R.P.M. Noise
level
(dBa)
Ambient
Temperature
COProtection
AV100B 230 80 0.34 250 2820 46 -25 +55 IPX4
AV125B 230 79 0.34 355 2800 46 -25 +55 IPX4
AV150B 230 80 0.35 460 2725 46 -25 +55 IPX4
AV200B 230 107 0.47 780 2660 48 -25 +55 IPX4
AV250B 230 173 0.76 1080 2090 50 -25 +50 IPX4
AV315B 230 200 0.88 1340 2655 50 -25 +50 IPX4

SAFETY REQUIREMENTS
The fan complies with the requirements according to the EU
norms and directives.
In case if a fan with the level of protection that corresponds to
the second distinctive number IPX4 is used in humid conditions,
it is necessary to provide additional protection in order to prevent
moisture access. Possible protection means:
1. If a fan is installed in a horizontal position, the duct length on
both sides should be not less than 1m.
2. In any fan position it is necessary to install a cap on the
suction branch tube.
Precautions must be taken to avoid the black-flow of gases into
the room from the open flue of fans or other open-fire
appliances.
NOTE: Installation and connection of the fan should be done by
a qualified person in accordance with the IEE wiring regulations.
Prior to connecting the fan to power supply, it is necessary to
make sure that there is no visible faults on the rotor, case, grid
and that there are no foreign items in air flow part of the case,
which may damage rotor’s blades.
CAUTION: Do not use the fan in highly explosive environment.

PREPARATION OF DEVICE OPERATION
The fan consists of: -
Case 1 with installed electric motor with impeller; capacitor 4,
installed inside of the case 1; grille 2, which is attached to the
case using screw 3 (diameter of pipes of case and grille
corresponds to diameter of installing duct); cover of terminal
block 5 for connecting of the fan to single-phase circuit;
Connecting of the fan to single-phase circuit (figure 3) is through
a switch, built-in to fixed wiring. Connection of fans to electric
power supply must be performed only through a switch with
actuation length not less than 3mm at all poles. The fan is
installed vertically or horizontally. Direction of air-charging is to
comply with direction of arrow on the fan case.
To mount the fan on the wall or ceiling, it is necessary to make
the following adjustments. Screw out from each side of the case
1 of the fan dowel 8 and install brackets, ensuring alignment of
holes in the brackets with screw heads 3.
Attach brackets to the case of the fan with dowels 8. Perforate
veiling (wall) for dowels according mounting holes of the support
and mount the fan using screws.
Connect ducts of corresponding diameter to the fan and fix them
using cable ties. For best performance smooth out flexible
ducting to reduce the effects of system resistance and do not
squash ducting at bends.

Connecting the fan having single-phase electric motor to an
alternating current power line.
It is good practise to provide a 3 amp fused spur/isolator to
isolate fan for maintenance or repair.
Figure 3
THE FAN IS COMPLETED WITH
The complete set includes:
- Fan ……………………………………….1 unit;
- Galvanised steel brackets ……………..2 units;
- User’s manual;
- Packaging

MAINTENANCE
Maintenance work may be done only after the fan has been
disconnected from the power supply.
Service includes regular cleaning of the fan surface from dust
and dirt after the fan has been disconnected from power supply.
A soft dry brush or pressed air should be used to remove dust.
The blades of rotor should be thoroughly cleaned every 6
months.
In order to do it, release the screws 3 (fig 1) and detach the grille
2 from the case 1. Use detergent dissolved in water to clean the
rotor blades. Avoid the liquid getting on the motor.
STORAGE RULES
The fan should be stored in manufacturer’s packaging in
ventilated room at air temperature room +50OC to +40OC and
relative air humidity not exceeding 80% (at T=25OC).
Presence of acid alkali and other addressive substances vapours
in the air is not permitted.

WARRANTY:
Applicable to units installed and used in the United Kingdom
Airflow guarantees the Aventa Turbo for 2 years from date of
purchase against faulty material or workmanship. The warranty
can be upgraded to 3 years upon registering on our website,
airflow.com
In the event of any defective parts being found, Airflow
Developments Ltd reserve the right to repair or at our discretion
replace without charge provided that the unit.
1. Has been installed and used in accordance with the fitting
and wiring instructions supplied with each unit
2. Has not been connected to an unsuitable electrical supply
3. Has not been subjected to misuse, neglect or damage
4. Has not been modified or repaired by any person not
authorised by Airflow Developments Ltd.
5. Has been installed in accordance with Building Regulations
and IEE wiring regulations.
Airflow Developments shall not be liable for any loss, injury or
other consequential damage, in the event of a failure of the
equipment or arising from or in connection with the equipment
excepting only that nothing in this condition shall be construed as
to exclude or restrict liability for negligence.
This warranty does not in any way affect any statutory or
other consumer rights.
Airflow Developments Ltd
Lancaster Road Cressex Business Park, High Wycombe, Bucks. HP12 3QP. U.K.
Tel: [phone]. Fax: [phone]
E-mail: [email protected]. Web: airflow.com
