Airflow AXD610 Operation manual

Ventilation Testing
Micromanometer
Alnor®Model AXD610
AIRFLOWTM Model PVM610
Operation and Service Manual

Copyright©
TSI Incorporated / 2007-2008 / All rights reserved.
Address
TSI Incorporated / 500 Cardigan Road / Shoreview, MN 55126 / USA
Fax No.
[phone]
LIMITATION OF WARRANTY AND LIABILITY (effective July 2000)
Seller warrants the goods sold hereunder, under normal use and service as described in the
operator's manual, shall be free from defects in workmanship and material for twenty-four (24)
months, or the length of time specified in the operator's manual, from the date of shipment to the
customer. This warranty period is inclusive of any statutory warranty. This limited warranty is
subject to the following exclusions:
a. Hot-wire or hot-film sensors used with research anemometers, and certain other
components when indicated in specifications, are warranted for 90 days from the date of
shipment.
b. Parts repaired or replaced as a result of repair services are warranted to be free from
defects in workmanship and material, under normal use, for 90 days from the date of
shipment.
c. Seller does not provide any warranty on finished goods manufactured by others or on any
fuses, batteries or other consumable materials. Only the original manufacturer's warranty
applies.
d. Unless specifically authorized in a separate writing by Seller, Seller makes no warranty
with respect to, and shall have no liability in connection with, goods which are
incorporated into other products or equipment, or which are modified by any person other
than Seller.
The foregoing is IN LIEU OF all other warranties and is subject to the LIMITATIONS stated
herein. NO OTHER EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR
PARTICULAR PURPOSE OR MERCHANTABILITY IS MADE.
TO THE EXTENT PERMITTED BY LAW, THE EXCLUSIVE REMEDY OF THE USER OR
BUYER, AND THE LIMIT OF SELLER'S LIABILITY FOR ANY AND ALL LOSSES,
INJURIES, OR DAMAGES CONCERNING THE GOODS (INCLUDING CLAIMS BASED
ON CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR OTHERWISE) SHALL
BE THE RETURN OF GOODS TO SELLER AND THE REFUND OF THE PURCHASE
PRICE, OR, AT THE OPTION OF SELLER, THE REPAIR OR REPLACEMENT OF THE
GOODS. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY SPECIAL,
CONSEQUENTIAL OR INCIDENTAL DAMAGES. SELLER SHALL NOT BE
RESPONSIBLE FOR INSTALLATION, DISMANTLING OR REINSTALLATION COSTS
OR CHARGES. No Action, regardless of form, may be brought against Seller more than 12
months after a cause of action has accrued. The goods returned under warranty to Seller's
factory shall be at Buyer's risk of loss, and will be returned, if at all, at Seller's risk of loss.
Buyer and all users are deemed to have accepted this LIMITATION OF WARRANTY AND
LIABILITY, which contains the complete and exclusive limited warranty of Seller. This
LIMITATION OF WARRANTY AND LIABILITY may not be amended, modified or its terms
waived, except by writing signed by an Officer of Seller.
Service Policy
Knowing that inoperative or defective instruments are as detrimental to TSI as they are to our
customers, our service policy is designed to give prompt attention to any problems. If any
malfunction is discovered, please contact your nearest sales office or representative, or call
Customer Service department at [phone] (UK), [phone] (USA), or (1) 651-
490-2811 (International).

iii
CONTENTS
CHAPTER 1 UNPACKING AND PARTS IDENTIFICATION ............ 1
CHAPTER 2 SETTING-UP.................................................................3
Supplying Power to the Alnor AXD610/AIRFLOW PVM610 .............3
Installing the Batteries ...............................................................3
CHAPTER 3 OPERATION .................................................................5
Keypad Functions ...........................................................................5
CHAPTER 4 MAINTENANCE............................................................7
Recalibration...................................................................................7
Cases..............................................................................................7
Storage ...........................................................................................7
CHAPTER 5 TROUBLESHOOTING.................................................. 9
APPENDIX A SPECIFICATIONS.....................................................11

1
Chapter 1
Unpacking and Parts Identification
Carefully unpack the instrument and accessories from the shipping
container. Check the individual parts against the list of components below. If
anything is missing or damaged, notify TSI immediately.
1. Carrying case
2. Instrument

3
Chapter 2
Setting-up
Supplying Power to the Alnor AXD610/AIRFLOW PVM610
The Alnor AXD610/AIRFLOW PVM610 is powered with four size AA
batteries.
Installing the Batteries
Insert four AA batteries as indicated by the diagram located on the
inside of the battery compartment. The Alnor AXD610/AIRFLOW
PVM610 is designed to operate with either alkaline or NiMH
rechargeable batteries, although it will not recharge NiMH batteries.
Battery life will be shorter if NiMH batteries are used. Carbon-zinc
batteries are not recommended because of the danger of battery acid
leakage.

5
Chapter 3
Operation
Keypad Functions
ON/OFF Key Press to turn the Alnor AXD610/AIRFLOW
PVM610 on and off. During the power up
sequence the display will show the following:
Model Number, Serial Number, Software Revision
and Last Date Calibrated.
ft/min / m/s Key Pressing this key changes the display to read air
velocity, converted from.
in H2O / Pa / hPa /
kPa / mm HG Key
Pressing this key changes the display to read
differential pressure.
0 Key Pressing the 0 key zeroes the pressure
measurement.
Changing Units To change units, first put the desired measurement
(air velocity or temperature) on the display. Then
press and hold the left, unlabelled key for five
seconds. Finally, use the ST and ENTER key to
select the units.

7
Chapter 4
Maintenance
The Alnor AXD610/AIRFLOW PVM610 requires very little maintenance to
keep it performing well.
Recalibration
To maintain a high degree of accuracy in your measurements, we
recommend that you return your Alnor AXD610/AIRFLOW PVM610 to TSI
for annual recalibration. Please contact one of TSI’s offices or your local
distributor to make service arrangements and to receive a Return Material
Authorization (RMA) number. To fill out an online RMA form, visit TSI’s
website at http://service.tsi.com.
U.S. & International UK
TSI Incorporated TSI Instruments Ltd.
Alnor Products Stirling Road
500 Cardigan Road Cressex Business Park
Shoreview MN 55126-3996 High Wycombe
Tel: [phone] Bucks
[phone] HP12 3RT United Kingdom
Fax: [phone] Tel: [phone]
Fax: [phone]
Cases
If the instrument case or storage case needs cleaning, wipe it off with a soft
cloth and isopropyl alcohol or a mild detergent. Never immerse the Alnor
AXD610/AIRFLOW PVM610. If the enclosure of the Alnor
AXD610/AIRFLOW PVM610 becomes broken, it must be replaced
immediately to prevent access to hazardous voltage.
Storage
Remove the batteries when storing the unit for more than one month to
prevent damage due to battery leakage.

9
Chapter 5
Troubleshooting
Table 5-1 lists the symptoms, possible causes, and recommended solutions
for common problems encountered with the Alnor AXD610/AIRFLOW
PVM610. If your symptom is not listed, or if none of the solutions solves
your problem, please contact TSI.
Table 5-1: Troubleshooting the Alnor AXD610/AIRFLOW PVM610
Symptom Possible Causes Corrective Action
No Display Unit not turned on Switch unit on.
Low or dead batteries Replace batteries.
Dirty battery contacts Clean the battery
contacts.
Velocity reading
fluctuates unstable
Fluctuating flow Reposition probe in
less-turbulent flow.
Instrument Error
message appears
Fault in instrument Factory service required
on instrument.
WARNING!
The pressure sensor is protected from damage up to 7 psi (48 kPa or
360 mmHg). At higher pressure it can burst!

11
Appendix A
Specifications
Specifications are subject to change without notice.
Static/Differential Pressure:
Range1: -15 to +15 in. H2O (-28.0 to +28.0 mm Hg, -3735 to
+3735 Pa)
Accuracy: ±1% of reading ±0.005 in. H2O (±0.01 mm Hg, ±1 Pa)
Resolution: 0.001 in. H2O (0.1 Pa, 0.01 mm Hg)
Velocity From a Pitot Tube:
Range2: 250 to 15500 ft/min (1.27 to 78.7 m/s)
Accuracy3: ±1.5% at 2000 ft/min (10.16 m/s)
Resolution: 1 ft/min (0.1 m/s)
Instrument Temperature Range:
Operating (Electronics): 40 to 113°F (5 to 45°C)
Storage: -4 to 140°F (-20 to 60°C)
Instrument Operating Conditions:
Altitude up to 4000 meters
Relative humidity up to 80% RH, non-condensing
Pollution degree 1 in accordance with IEC 664
Transient over voltage category II
External Meter Dimensions:
3.3 in. ×7.0 in. ×1.8 in. (8.4 cm ×17.8 cm ×4.4 cm)
Meter Weight:
Weight with batteries: 0.6 lbs (0.27 kg)
Power Requirements:
Four AA-size batteries (included)
1Overpressure range = 7 psi (190 in. H2O, 360 mmHg, 48 kPa).
2Pressure velocity measurements are not recommended below 1,000 ft/min (5 m/s) and are
best suited to velocities over 2000 ft/min. Range can vary depending on barometric
pressure.
3Accuracy is a function of converting pressure to velocity. Conversion accuracy improves
when actual pressure values increase.
